DRAGONFIRE RacePace Smash User manual

DragonFire
DragonFire Racing
3191 N. Washington St. Suite 2
Chandler, AZ 85225
1 [phone]
WWW.DRAGONFIRERACING.COM
RacePace “Smash” Rear Bumper for RZR 900
Part # 01-1910 2015 RZR 900 Black
Part # 01-1911 2015 RZR 900 Red
Congratulations on the purchase of the RacePace Smash Rear Bumper for RZR 900 models. Designed to give your RZR
personalized style while still keeping the back end protected. Be sure to check out the full line of DragonFire Accessories for
your RZR 900 at your local authorized dealer or online at http://www.DragonFireRacing.com
Disclaimer
Off road activities can be hazardous and could lead to injury, dismemberment, paralysis and death. No warranty
of representation is made as to the products ability to protect the user from any injury or death. The user assumes
that risk. The acceptance and /or use of this merchandise purchased from DragonFire by the customer hereby
shall release DragonFire from any and all liability pertaining to the use of such merchandise.
Step 1: Place vehicle on a at and level surface. Place gear selector in “Park” and remove keys
from the ignition.
Step 2: Remove cosmetic plugs from rear plastics on both passenger and driver side. (Figure A)
Step 3: Inside the driver side fender, locate the 2 holes on the top frame rail near the mufer.
Thread the holes using the supplied 5/16” self threading bolts. (Figure B) After holes
have been threaded remove the bolts and retain for later use.
Step 4: Repeat Step 3 on passenger side.
Step 5: Locate supplied Upper mounting bracket. (Figure C) Install bracket with weld nut toward
the inside of the vehicle, using hardware from Step 3. Leave loose for adjustment later.
(Figure D)
• Read and understand these instructions before installing product
• This product does not provide roll over protection
• Do not use product if there are any signs of damage
Tools Required
Ratchet with 6” Extension
1/2” Socket
9/16” Socket
17mm Socket

DragonFire
Step 6: Repeat Step 5 for Passenger side.
Step 7: With both upper brackets installed, place the bumper on the vehicle with the upper struts aligned with the holes. (Figure E)
Note: This step may require assistance from an additional person.
Step 8: Install supplied 10mm bolts and washers onto lower bumper mount, leaving loose for adjustment later. (Figure F)
Step 9: Align the upper mount brackets with the upper struts and install supplied 3/8” hardware. (Figure G) Leave loose for adjustment later.
Step 10: Align bumper with vehicle tail lights and tighten all hardware to the specications in the table below.
Step 11: This completes installation. Time to ride and enjoy!
ProTip: Periodically check all hardware and re-tighten if needed.
For further assistance, please contact your authorized DragonFire dealer.
SIZE Torque
5/16" 12 ft-lbs. (144 in-lbs.)
3/8” 30 ft-lbs.
10mm 30 ft-lbs.
