Installation/Operating Instructions
Premier/Series C Crank-Operated Projection Screen by Draper
Copyright © 2004 Draper Inc. Form PremierC_Inst04 Printed in U.S.A.
Operation
To lower screen surface, attach the crank handle to the “U” joint stud located
on the left-hand side of the screen. With the crank handle in its operating posi-
tion, rotate counterclockwise. An internal pin within the gear box will stop the
screen when fully extended. The crank handle can be removed if desired. The
shipping support brackets must be removed from each end of dowel
during initial operation: see below.
To raise screen surface, attach the crank to the “U” joint stud located on the
left hand side of the screen. With the crank handle in its operating position,
rotate clockwise. An internal pin within the roller will stop the screen when fully
retracted. The crank handle can be removed if desired.
Note: The shipping support brackets must be removed from each end of
dowel during initial operation before screen is operated in UP direction. After
screen is installed, run viewing surface DOWN to access screws that hold
brackets to dowel. Loosen hex head screw, remove bracket and retighten
screw at each end of dowel. Raise and lower viewing surface several times to
confirm satisfactory operation.
Caution
➀Read instructions through completely before proceeding; keep them
for future reference. Follow instructions carefully. Installation contrary
to instructions invalidates warranty. Care in both mounting and
correct operation will mean long and satisfactory service from your
Draper screen.
➁Screen should be accessible for complete removal should fabric
become damaged or should other service be required.
➂Screen should be installed level (using a carpenter’s level).
➃Nothing should be fastened to screen dowel or viewing surface.
➄Operating crank is packed separately in screen carton. Do not
discard with packing material.
NOTE: Screen has been thoroughly inspected and tested at factory
and found to be operating properly prior to shipment.
If you encounter any difficulties installing or servicing your Premier/
Series C screen, call your dealer or Draper, Inc., Spiceland, Indiana,
U.S.A., (765) 987-7999; fax (765) 987-7142; or e-mail
[email protected].
Hanging Screen
Your Draper screen can be mounted on a wall or suspended from the ceiling.
With either method of installation, the case must be mounted level and with
the flat back parallel to the wall.
To reduce the risk of personal injury, use only the hardware which comes with
the screen or is specified in these instructions.
The screen should be mounted into studs or blocking in the wall/ceiling, or in
drywall (minimum thickness ½" [13 mm]) with specified anchors. For any other
type of installation, follow all local building and safety codes.
Steel studs, concrete or cinder block walls and all other types of non-wood
frame construction require the use of special screws or anchors. The selection
of appropriate mounting hardware should be made by a qualified professional
installer.
When locating viewing surface and checking clearance for screen’s opera-
tion, remember surface is centered in case. Handle case carefully to avoid
scratching.
Regardless of mounting method, screen should be positively and securely
supported so that vibration or even abusive pulling on the viewing surface will
not cause case to work loose or fall. Installer must insure that fasteners used
are of adequate strength and suitable for the mounting surface chosen.
Suspended Installation
Suspend screen from holes in endcaps. “S” hooks are included with screen.
Chains (or cable) and turn-buckles should be provided by installer. Chains
should be attached to beams or other structural members. Turnbuckles should
be adjusted so screen hangs level.
Wall Installation
Mount screen through holes in back of endcaps as shown. No. 12 screws
for wood or aluminum are provided. However, if screen attaches to plaster,
gypsum board or masonry, installer should furnish toggle bolts, molly bolts,
nylon or lead anchors as required.
Recessed Installation
Recess should permit access for removal of screen if necessary. Screen may
be mounted as in suspended or wall installation.
Please Note: Instructions for adjusting Draper’s Tab-Tension
System are on page 2.
Dowel Shipping
Bracket
Minimum 2" (5 cm)
wide slot for passage
of viewing surface
Optional ceil-
ing slot kit
also avail-
able; see
page 2 for
diagram
Premier/Series C by Draper Page 2 of 4
www.draperinc.com (765) 987-7999
Tab-Tension Adjustment Procedure for Premier/Series C
➀Determine which side requires adjustment.
➁Secure dowel with one hand.
Caution: Do not touch or bend surface.
➂Using Philips-head screwdriver, depress spring-loaded adjustment
screw (see drawing) and slowly turn clockwise to tighten tension, or
counterclockwise to loosen tension. The screw adjusts in ¼ turn
increments. Adjust only one increment (¼ turn).
➃If problem is not corrected, leave screen in position for 24 hours to allow
surface material to stretch into position.
➄If problem still is not corrected, repeat steps 2 and 3.
Dowel Adjustment
Screw
Tensioning
Cable
Other Types of Installation
Appropriate hardware
provided by installer.
Suspended Wall
Appropriate hardware
provided by installer.
51/4"
(133 mm)
113/16"
(46 mm)
57/8"
(15 cm)
Mounting
hole
13/8"
(35 mm)
1"
(25 mm) 15/16"
(24 mm)
21/8"
(54 mm)
Targa or
Premier Case
Back
Ceiling Tile
Ceiling Trim Kit
21/8"
21/16"
4" 63/8"
1/16"
Dimensions—Ceiling Trim KitDimensions—Premier/C
