DREAMS Windsor User manual

Windsor Bedstead
Two person
assembly
1 hour approx
assembly time
MK1 220324

Thank you
Hello, thanks for choosing to purchase your bed from Dreams - you're now on your way to
creating a functional and fabulous room. Before you begin building your furniture, please take a
moment to read through the instructions and make sure that you've got all the relevant parts
listed on the following pages.
Assembly tips
Before you begin, it’s best to identify all parts and fittings to build your furniture.
We advise laying these out on the floor to check you have everything, and
familiarising yourself before building.
We recommend that you build your new furniture in the room you’d like it
to be located - this will help prevent any risk of damage to your newly
built furniture whilst moving it.
Top tip
Safety and care
It’s really important to ensure children and animals are kept away from the
assembly area, as there are small components used in this bed which could
present a choking hazard. All plastic and wrapping materials should also be
To keep your little ones busy, there is a colouring page inside the back cover.
Help and support
At Dreams, it’s our mission to give the whole nation a great night’s sleep - this
means that the quality of our products is of utmost importance to us. If there
are any issues with your product or any missing parts, please visit our website
at www.dreams.co.uk/help
Recycling
Please ensure that packaging is disposed of in a safe and environmentally
friendly way, and recycle where possible. Our assembly instructions are
printed on recycled paper. Please keep your assembly instructions safe
to refer back to in the future.
Windsor bedstead - Assembly Guide - Page 2

Windsor bedstead - Assembly Guide - Page 3
A
1
1
A. Headboard
B. Footboard
C. Side rail - Left 1
D Side rail - Right 1
1
1
E. Wooden Slat Set
F. Wooden Slat Set Support Leg
1
2
2
H. *Sprung Slat Frame Centre Support Leg*
I. *Sprung Slat Frame Outer Support legs*
J. Angle Brackets
K. Legs 4
B
K
K
K
K
J
J
C
D
G
H I
Parts list
* These items are supplied separately but only when the
upgraded slat-frame system is selected at time of purchase*.
The legs (H&I) are supplied packed inside the slat-frame
carton itself.
Note:
Standard wooden slat set (part E)
Upgraded sprung slat frame (part G)
EF
817161514131211101019876543210cm
Parts
Important information
The bed you have purchased comes with 2 different base options; solid slats or sprung slats.
Please identify which base you have purchased as the assembly method may change.
If you have purchased solid or sprung slats please follow the instructions below in the current order.
G. *Upgraded Sprung Slat Frame* 1

Windsor bedstead - Assembly Guide - Page 4
Spring washer for M8 bolts
Spring Washer
for M6 bolts
Bolts (M8x30mm)for fitting
side rails (C&D) to headboard
& footboard (A&B)
Hardware included for fitting wood slats or upgraded sprung slat frame (pack B)
Hardware included for bed assembly (pack A)
a x16 b x18
Flat Washer for M8 bolts
c x18
Allen key for M8 bolt
d x1
Nuts for M8 bolt for
fitting legs (K) to angle
brackets (J)
j x2
Screw (5x40mm) for
fitting slat support leg (F)
Spanner for M8 nut
k x1
f x6 g x7
Allen Key
for M6 bolts
h x1 u x1
v x6
e x6
Bolts (M6x40mm)
for fitting wooden slat set
(E) or the sprung slat frame
(F) to side rail slat supports
Sleeve nut
for M6 bolts
Flat washer for M6 bolts &
for support leg screw (U)
Fittings
Please check you have all the parts listed below with your product:
Tools required
Please check you have all these below
Cross head screwdriverTape measure
Sprung slat frame
outer support legs
Sprung slat frame
centre support leg
Bolts (M6x15mm) for
fitting support legs (H&I)
to the sprung frame (G).
p x8 h x1 I x2
Extra hardware included when fitting upgraded sprung slat frame
Note:
the following fittings will be found in the carton which contains the upgraded metal slat frame itself.

Windsor bedstead - Assembly Guide - Page 5
1Bed assembly - use pack 'A'
a x8 bx8 cx8
d
x1
10mm
a
bc
&
A
A
B
&
CD
B
C
D
d
2
a x8 b x8 c x8
d
x1
J
J
&
C
D
a
b
c
d
J
B
100%
Make certain the bed is squared up
as shown in the diagram then tighten
all bed assembly bolts 100%.

4a
Fit wooden slats - use pack 'B'
i.
g x7
f x6
ex6
h x1
e
v
f
g
Lift the bed and turn
back onto it's legs -
don't put all the weight
of the bed onto the legs
and pivot it, or the legs
may be damaged,
please lift it then put it
into it's final location.
Using two bolt sets
(e, v, & g) and sleeve
nuts (f) loosely fix one
slat in the two holes
next to the headboard.
Carefully roll out the
slats to halfway down
the bed aligning with
the holes in the centre
of metal support rails.
E
E
v x6u x1
Windsor bedstead - Assembly Guide - Page 6
3
b
x2
c
x2
x2
j
k
x1
j
bc
k
With help, turn bed on it's side, do not allow it to twist.
Screw in each leg, please do not over-tighten.
Fit the legs

Windsor bedstead - Assembly Guide - Page 7
ii.
e
v
f
g
Using two more bolt
sets, loosely bolt the
central slat into
position - arrange the
slats then tighten all
four bolt sets 100%
using Allen key (h).
E
iv)
iii.
g
u
Adjustable
Foot
Roll out the rest of the
wooden slats and fix
with the last two bolt
sets, arrange all the
slats then fully tighten
using Allen key (h) .
F
E
e
v
f
g
Fit the support leg (F)
to the centre slat using
screw (u) and flat
washer (g). Fully
tighten using a cross-
head screwdriver.
Carefully turn the
adjustable foot
clockwise until it just
touches the floor and
slat is horizontal.

Windsor bedstead - Assembly Guide - Page 8
4a
i.
20mm 60mm 100mm
The support legs each have four adjustable parts that need to be set to suit the height of the bed slat frame.
Please adjust the height of each leg by selecting the correct hole and inserting the bolts and nuts as shown.
You can fine-tune the height of each leg by screwing the adjustable foot in or out so it just touches the floor.
Fitting upgraded sprung slat frame use pack 'B'
v x4p x8h x1
p
p
p
pp
p
Open the sprung slat frame and
lay the frame face down on the
working surface. Fit the support
legs (I & H) to the positions
shown, securing with the bolts (p).
Fully tighten using Allen key (h). H
ii.
I
G
I

Windsor bedstead - Assembly Guide - Page 9
g x4
fx4
ex4 hx1
e
f
g
v
Finally, please check carefully
that all bolts are fully tightened
before the bed is used.
Carefully turn the slat frame over
and position onto the metal slat
supports on each side panel.
Align the frame with the fixing holes
at each end and secure using four
sets of bolts (e, v & g) and sleeve-
nuts (f).
When all in place tighten using Allen
key (h).
G
iii)
Fitupgraded sprung slat frame use pack 'B'
4b
iv)

Windsor bedstead - Care and maintenance - Page 10
Care and maintenance
Here are some tips to keep your new bed in tip-top condition
Cleaning
To clean your new bed, we'd advise using a warm damp cloth or if fabric, remove
dust using a low suction vacuum cleaner. Please dry-clean the pillows if it is
necessary to clean them.
Please do not use abrasive chemicals or bleach as this may damage the product.
Checking and moving
Periodically we recommend you check that the screws or fixtures haven't become
loose over time. To move your new bed, we recommend lifting it where possible, as
dragging or pushing it could cause damage to the legs or flooring.
Wood
Please note each of our wooden pieces are unique, meaning that markings and
shade can vary slightly between beds. Over a period of time, the wood might
lighten or fade slightly due to light exposure.
Fabric
Please note depending on the lighting, positioning and surroundings of your
period of time, the colour might lighten or fade slightly due to light exposure.
Metal
Metal tends to be more resilient to everyday wear and tear. We recommend to
gently dust your metal furniture and keep it dry to maintain its look.
Thank you for shopping with us - we hope you have a
great night's sleep.
12.5
W
H
Overall Dimensions (LWH cm)
Double: 206 x 151.5 x 117
King: 216 x 166.5 x 117
Internal Dimensions (LWH cm)
Double: 192 x 137
251 x 102 :gniK
Distance between slats (cm)
Double: 9
King: 8.7
L
4
4
37.5
17
670 x 53 x 9
745 x 53 x 9
) mm HWL( snoisnemiD talS
Double:
King:
31.5
Floor to top
of slat
6
Top of side rail
to top of slat
