DREAMS PAXTON User manual

PAXTON DOUBLE AND KING BED
Assembly Instructions

Thank you
Hello, th ase your be om Dranks for choosing to purch d fr eams - you're now on your way to your best
ever night's sleep. Before you begin building your bed, please take a moment to read through the
ins s lis .tructions and make sure that you've got all the relevant part ted on the following pages
Assembly tips
Before you begin, it’s best to identify all parts and fittings to build your bed.
W lo o che vere advise laying these out on the f or t ck you have e ything, and
f f beamiliarising yoursel fore building.
At Dreams, it’s our mission to give the whole nation a great night’s sleep - this
Help and support
means that the quality of our products is of utmost importance to us. If there
ar t or an sing pare any issues with your produc y mis ts, please visit our website
at www.dreams.co.uk/help
It’s really important to ensure children and animals are kept away from the
Safety and care
a sembl ea, as y ar s there are small components used in this bed which could
pr sent a choking ha are z d. All plastic and wrapping materials should also be
kept away from children and animals to prevent any risk of suffocation.
T eep yo k our little ones busy, there is a colouring page inside the back cover.
Please ensure that packaging is disposed of in a safe and environmentally
Recycling
fr y w eciendl ay, and r ycle where possible. Our assembly instructions are
pr se k ep your as r tions safe inted on recycled paper. Plea e sembly inst uc
t fer back t to re o in the fu ure.
We recommend that you build your new bed in the room you’d like it to be
lo ted - tca his will help prevent any risk of damage to your newly built bed
w thilst moving i .
Top tip
Pa ton Double Bed andx King Bed 2 - Assembly Guide - Page

Paxton Double Bed and King Bed - Assembly - Page 3
Parts
Important infomation
Please identify which base you have purchased with your bed frame as the assembly method
may change. Once you have identified you have all of the relevant parts fittings, please
follow the instruction for your chosen base below;
Solid Slats Page (7)
Sprung Slats Page (8,9,10)
A. Headboard 1
Parts List
B. Footboard 1
C. Side Rails 2
D. Support Rail 1
E. Middle Legs Support 2
A
B
c
c
D
E

Pa ton Double Bed andx King Bed 4 - Assembly Guide - Page
0 1 2 3 4 5
cm
Fittings
Please check you have all the parts listed below with your product:
Tools required
Please check you have all these below:
Note: The following fitting will be found in the box which contains the Sprung Frame, NOT with the bed
frames Assembly Kit
6 7 8 9 10 11 12 13 14 15 16 17 18
J
Flat Washer pcs8
Sleeve Nut 20 6M6x mmx pcs
Bolt M6x45mmx pcs8 Allen Key x pc 4mm 2

ASSEMBLY
A
c
c
B
I
Paxton Double Bed and King Bed - Assembly - Page 5
- Use Bolt (mounted on the Headboard
and Footboard) to fix the Side Rail (C)
onto Headboard (1) and Footboard (2) by
using Allen Key (I).

Once the feet have been assembled and attached,
They should be adjusted to ensure they do not touch the
floor, (10mm above the floor) to allow for movement
once the mattress is placed on the bed frame.
It is important to note that when moving the bed that it is
not dragged into its new position to prevent the
possibility of these feet being twisted or angle to one
side, which could lead to the collapse of the centre of the
legs.
To move the bed, remove the mattress and lift the bed
into its new position to avoid damage.
Ensure the feet are at degree to the floor before repacing
the mattress.
Attach central support "D" to support feet "E".
Use bolts "F" and flat washers "H", tighten using
allen key "I".
Place the fixed central support "D"
onto the support block on
Headboard "A" and footboard "B".
IMPORTANT
E
10mm
A
B
c
c
D
E
D
E
I
F
H
Paxton Double Bed and King Bed - Assembly - Page 6

Solid slat assembly
Identify the slat system you have purchased...
Standard wooden slat system.
Place the fixed wood slats onto the slat holders
on side rails "C".
Fix the slats at both ends and the middle using
bolts "F" , sleeve nuts "G", tighten with key "I".
I
F
H
G
I
Paxton Double Bed and King Bed - Assembly - Page 7
1

Sprung slat assembly
Sprung slat system
Lx8
Jx2
Kx1
1
Pa ton Double Bed and 8x King Bed - Assembly Guide - Page

Sprung slat assembly
2
I
K
J
J
L
Lx8 Ix1
Adjust leg height to suit bed frame
10mm
Fix the center legs to the frame.
Used bolts " ",tighten using allen key " ”L I
A1
Pa ton Double Bed andx King Bed 9 - Assembly Guide - Page

Sprung slat assembly
Turn the metal slat frame falling upward and
carefully lower the slat frame into the bed.
Ensure that the frame sits on the guides located
on the side rails "C".
Position the slat frame so that the holes in the
side rail "C".
Position the slat frame to the side rails "C" by
threading bolt "F" through the holes in the frame
and the side rails "C".
Finally, tighten bolt "F" into the sleeve nut "G"
from the top of slats frame with allen key "I".
I
F
H
G
I
Paxton Double Bed and King Bed - Assembly - Page 10
3
