D-306048 WP8033 Installer's Guide 1
WP8033
Version 18
Installer’s Guide
Table of Contents
1. INTRODUCTION ................................................. 2
1.1 System Features .......................................... 2
2. CHOOSING THE INSTALLATION LOCATION .. 6
3. WP8033 INSTALLATION.................................... 7
3.1 WP8033 Wiring Diagram .............................. 7
3.2 Opening the WP8033 Control Panel and
Bracket Mounting............................................... 8
3.3 Connecting to the Telephone Line (detail
"K" in Figure 3.1)................................................ 8
3.4 Connecting Wired Zone and Siren (detail
"B" in Figure 3.1)................................................ 9
3.5 GSM Module and SIM Installation (detail
"L" in Figure 3.1) .............................................. 10
3.6 Output Interface Module Installation
(located in place of detail "E" in Figure 3.1)... 11
3.7 Installing the PLINK3 DSC......................... 12
3.8 Optional Expander Module (detail "I" in
Figure 3.1)......................................................... 13
3.9 Connecting Power to the Control Panel ... 15
3.9.1 Battery Insertion................................. 16
3.9.2 Connect AC Power to the Unit ........... 16
3.10 Closing the WP8033 Control Panel......... 17
4. VISUAL INDICATIONS, FIRST KEYPAD
ENROLLMENT AND USING PROX TAG..............18
4.1 WP8033 LED Indications ............................18
4.2 Enrollment of the First Keypad..................18
4.3 Using the Prox Tag .....................................19
5. MAINTENANCE.................................................19
5.1 Dismounting the Control Panel .................19
5.2 Replacing the Backup Battery ...................19
5.3 Fuse Replacement ......................................19
5.4 Replacing/Relocating Detectors ................19
5.5 Annual System Check ................................19
APPENDIX A. Specifications ...............................20
A1. Functional...................................................20
A2. Wireless ......................................................20
A3. Electrical .....................................................20
A4. Communication ..........................................21
A5. Physical Properties....................................21
A6. Peripherals and Accessory Devices .........21
APPENDIX B. Compliance with Standards ..........22
Quick User Guide to Main Alarm Control
Operations by the keypad ...................................23

2 D-306048 WP8033 Installer's Guide
1. INTRODUCTION
WP8033 is a PowerG-enabled professional all-in-one wireless security, fire and safety system supporting advanced
applications and DSC's PowerG™ Two-Way, Time Division Multiple Access (TDMA) and Frequency Hopping Spread
Spectrum (FHSS) wireless technology. This offers unmatched wireless robustness, superior range and long battery life; a
perfect and user friendly solution for both monitoring service providers and professional installers.
The system consists of the WP8033 control panel that does not include a built-in keypad and that operates in
conjunction with a wireless keypad display device. The control panel accommodates all control circuitry and operation
software for a programmable 64-zone alarm system, while the keypad display unit enables the installer and the user to
enter their commands and provides visual and audible feedback.
The system is supplied with 3 instruction manuals:
WP8033 Installer's Guide (this manual) –for use of system installer during system installation.
The Keypad Installer’s Guide -–for use of system installer during keypad installation and WP8033 configuration.
The Keypad User’s Guide -–also for use of system installer during system installation and configuration, but also for
the master user of the system, once installation is completed. Hand over this manual to the master user of the system.
1.1 System Features
The following table lists the WP8033 features with a description of each feature and how to use it.
Feature
Description
How to configure and use
Visual Alarm
Verification
The WP8033 when used with PGx9934 PIR-
camera detector and GPRS communication
is able to provide the Monitoring Station with
clips captured in alarm situations. The
system sends the clips to the Monitoring
Station automatically for burglary alarms and,
depending on setup, also for fire and
personal emergency alarms.
1. Setup GPRS communication: see GSM
Module Installation section 3.5)
2. Configure camera settings:refer to the
PGx9934 Installation Instructions
3. Enable fire and personal alarm
verification:see Keypad Installer’s Guide.
On demand clips from
cameras
The WP8033 can provide images from the
PGx9934 by demand from a remote
PowerManage server. Pictures are taken
based on a command from the monitoring
station. To protect customers' privacy, the
system can be customized to enable the "On
Demand View" only during specific system
modes (i.e. Disarm, Home & Away) and also
to a specific time window following an alarm
event.
1. Setup the On demand feature:see
Keypad Installer’s Guide
2. To request and view images:refer to the
PowerManage User's Guide
Easy Enrollment
PowerG devices are enrolled from the control
panel. "Pre-enrollment" can also be
performed by entering the PowerG device ID
number and then activating the device in the
vicinity of the panel.
To enroll or pre-enroll devices: see
Keypad Installer’s Guide
Device Configuration
Device parameters and related system
behavior can be configured from the keypad
or from a remote location.
Each PowerG device has its own settings
which can be configured through the keypad
by entering the "DEVICE SETTINGS" menu.
To configure devices from the keypad:
see Keypad Installer’s Guide and also the
individual device's Installation Instructions.
To configure devices from a remote
location: refer to the PowerManage User's
Guide and to the Remote Programmer PC
software User's Guide.

D-306048 WP8033 Installer's Guide 3
Diagnostics of the
control panel and
peripherals
You can test the function of all wireless
sensors deployed throughout the protected
area, to collect information about the
received signal strength from each
transmitter and to review accumulated data
after the test.
To perform diagnostics and to obtain
signal strength indication: see the keypad
Installer’s Guide
Conducting periodic
tests
The system should be tested at least once a
week and after an alarm. The periodic test
can be conducted locally or from a remote
location (with the assistance from a non-
technical person in the house).
To conduct a walk test locally: see the
keypad Installer’s Guide or the keypad
User’s Guide
To conduct a walk test from remote
location: refer to the Remote Programmer
PC software User's Guide.
Partitions
The partitioning feature, when enabled,
divides your alarm system into distinct areas
each of which operates as an individual
alarm system. Partitioning can be used in
installations where shared security systems
are more practical, such as a home office or
warehouse building.
1. Enable partitioning:see the keypad
Installer’s Guide
2. Setup partition association for each
device: see the keypad Installer’s Guide
To understand more about partitioning:
see the keypad Installer’s Guide.
Device configuration
templates
The default parameters with which a new
device is enrolled into the system can be set
before you enroll devices. This default
template saves time on device configuration.
1. Define enrollment defaults for devices:
see the keypad Installer’s Guide
2. Enroll or pre-enroll devices: see the
keypad Installer’s Guide
SirenNet - distributed
siren using Smoke
detectors
All PowerG smoke detectors are able to
function as sirens, alerting on any of 4 types of
alarm in the system: burglary, gas, fire or
flood.
Enable and configure SirenNet for each
smoke detector:refer to the PGx9926 /
PGx9916 Installation Instructions
Wired Siren outputs
The control panel can operate a wired siren
and strobe devices
Install and connect wired siren: see
section 3.8 Optional Expander Module
Wired zones and
programmable
outputs (PGM)
The control panel can support wired detectors
and control automation devices with
programmable wired outputs.
1. Connect a wired zone or PGM device: see
section 3.4 Adding a Wired Zone and Siren.
2. Program the wired zone: see the keypad
Installer’s Guide
3. Program PGM outputs behavior: see the
keypad Installer’s Guide.
Reporting to Private
Users and/or
Monitoring Station by
telephone, SMS and
IP communication
The WP8033 system can be programmed to
send notifications of alarm and other events
to 4 private telephone subscribers by voice*
and also to 4 SMS cellular phone numbers
and to report these events to the Monitoring
Station by SMS, PSTN or IP communication.
To configure notifications to Private
phones:see the keypad User’s Guide
To configure reporting to the Montioring
Station:see the keypad Installer’s Guide
Quick installation with
link quality indication
With PowerG devices, there is no need to
consult the keypad when mounting a
wireless device, because PowerG devices
include a built-in link quality indicator.
Choosing the mounting location is a quick
and easy process.
To choose the ideal location to mount a
wireless device, see Chapter 2 Choosing the
Installation Location.
*
Supported in specific WP8033 variants (for further details, please contact your DSC representative).

4 D-306048 WP8033 Installer's Guide
Device Locator
Helps you to easily identify the actual device
displayed on the keypad LCD display.
To read more on the Device Locator: see
the keypad User’s Guide
To use the device locator when bypassing
a zone or when clearing a bypassed zone:
see the keypad User’s Guide
To use the device locator when conducting
the periodic test: see the keypad Installer’s
Guide or the keypad User’s Guide
Guard key-safe
WP8033 is able to control a safe that holds
site keys that are accessible only to the site's
guard or Monitoring Station's guard in the
event of an alarm.
1. Connect the safe to the panel: see
section 3.8 Optional Expander Module
Mounting, Figure 3.8b
2. Configure the safe's zone type to
"Guard Zone": see the keypad Installer’s
Guide
3. Setup guard code: see the keypad
Installer’s Guide
Arming key
External system may control arming and
disarming of the WP8033 system
Connect the external system output to the
panel: see section 3.8 Optional Expander
Module Mounting, Figure 3.8b

D-306048 WP8033 Installer's Guide 5
System Architecture:
Security Detectors and Transmitters
Control Panel and Display
Keypad
Keyfobs, Keypad and
Keyprox
PGx9934
Motion Detector
with Camera
PGx9904
Motion Detector
PGx9974
Mirror Detector
WP8033
PGx9939
PGx9929
Two-way
Keyfobs
WK141
Two-way
Keypad
Safety Detectors
WK160 Keyprox
PGx9926 Smoke
Detector
PGx9916
Smoke & Heat
Detector
PGx9905
Temperature
Detector
PGx9913
Carbon Monoxide (CO) Detector
Sirens
PGx9911
Outdoor
Siren
PGx9901
Indoor Siren

6 D-306048 WP8033 Installer's Guide
2. CHOOSING THE INSTALLATION LOCATION
To ensure the best possible mounting location of the WP8033 control panel, the following points should be observed:
The selected location should be approximately in the center of the installation site between all the transmitters,
preferably in a hidden location.
In close proximity to an AC source
In close proximity to a telephone line connection (if PSTN is used)
Where there is good cellular coverage, if GSM-350 is used
Far from sources of wireless interference, such as:
oComputers or other electronic devices, power conductors, cordless phones, light dimmers, etc.
oLarge metal objects (such as metal doors or refrigerators)
Note: A distance of at least 1 meter (3 ft) is recommended.
When mounting wireless devices:
Make sure that the signal reception level for each device is either "Strong" or "Good", but not "Poor".
Wireless magnetic contacts should be installed in a vertical position and as high up the door or window as possible.
Wireless PIR detectors should be installed upright at the height specified in their Installation Instructions
Repeaters should be located high on the wall in mid-distance between the transmitters and the control panel.
WARNING! To comply with FCC and IC RF exposure compliance requirements, the control panel should be located at
a distance of at least 20 cm from all persons during normal operation. The antennas used for this product must not be
co-located or operated in conjunction with any other antenna or transmitter.
Customer Premises Equipment and Wiring
A. Network Service Provider's Facilities
F. Alarm Dialing Equipment
B. Telephone Line
G. Answering System
C. Network Demarcation Point
H. Unused RJ-11 Jack
D. RJ-31X Jack
I. Fax Machine
E. Telephone
J. Computer
Note: The REN is used to determine the number of devices that may be connected to a telephone line. Excessive RENs on a telephone line
may result in the devices not ringing in response to an incoming call. In most but not all areas, the sum of RENs should not exceed five (5.0).
To be certain of the number of devices that may be connected to a line, as determined by the total RENs, contact the local telephone
company.
Connection to telephone company provided coin service is prohibited. Connection to party lines service is subject to state tariffs.
The installer should verify line seizure. Be aware of other phone line services such as DSL. If DSL service is present on the
phone line, you must install a filter. It is suggested to use the DSL alarm filter model Z-A431PJ31X manufactured by
Excelsus Technologies, or equivalent. This filter simply plugs into the RJ-31X jack and allows alarm reporting without
breaking the internet connection.
A
B
C
D
E
F
G
H
I
E
E
H
J

D-306048 WP8033 Installer's Guide 7
3. WP8033 INSTALLATION
Required tool: Philips screwdriver #2.
WP8033 mounting process is shown in Figures 3.1 - 3.10.
3.1 WP8033 Wiring Diagram
A. Expander Module Flat
Cable
B. Wired Zone / Special
Siren Terminal Block
C. Battery Connector
D. ENROLL button
E. Front Unit
F. Output Interface Module
G. Expander Module Wiring
Terminal Blocks
H. Back Unit
I. Power Supply
J. Expander Module
K. Power Connector
L. Phone Wiring Connectors
M.GSM-350
* or External Power Supply Unit
** or External Power Connector
*** or Terminal Block in North American Panels
Figure 3.1 –WP8033 Wiring Diagram

8 D-306048 WP8033 Installer's Guide
3.2 Opening the WP8033 Control Panel and Bracket Mounting
To Mount the Unit:
1. Release the screws
2. Remove the front cover
3. Mark 5 drilling points on the mounting surface, then
drill 5 holes and insert wall anchors and then fasten
the back unit with 4 screws
A. Mounting surface
B. Back unit
C. 5 screws
* For back tamper
Figure 3.2 –Back Unit Mounting
3.3 Connecting to the Telephone Line (detail "K" in Figure 3.1)
PHONE WIRING
Connect the telephone cable to the SET connector and connect the telephone line cable to the LINE connector
(through the desired wiring cable entry).
Note: The telephone cable should be no longer than 3 meters.
A. LINE B. SET C. Tel line wall jack
Figure 3.3 –Phone Wiring
If DSL service is present on the phone line, you must route the phone line through a DSL filter (refer to MESSAGE TO
THE INSTALLER on page 2 for further details).

D-306048 WP8033 Installer's Guide 9
3.4 Connecting Wired Zone and Siren (detail "B" in Figure 3.1)
If an expander module is not used, one wired zone and one low voltage siren can be connected directly to the front
panel PCB.
WIRED ZONE
*
&SIREN WIRING
A. GND
B. Wired Zone
C. Siren
D. For future use
E. Site external siren MG electronics
MG441PDS or equivalent 6-12VDC,
150 mA Max
F. Magnetic contact or any other contact
(not a detector)
G. Alarm N.C.
Figure 3.4 –Wired Zone and Siren Wiring
*
Wired zones can be enrolled in any zone in the WP8033- G2 control panel from 01 to 64

10 D-306048 WP8033 Installer's Guide
3.5 GSM Module and SIM Installation (detail "L" in Figure 3.1)
Plug in the GSM module and fasten it as shown in the above
drawing making sure that the two leading slots on both sides of
the GSM module slide along the two leading ribs on the front
unit.
A. GSM module
B. Leading ribs
C. Leading slot (1 of 2)
D. Front unit
Caution! Do not install or remove the GSM module when the
system is powered by AC power or backup battery.
Insert the SIM card into the GSM module as shown in
the above drawing.
1. Slide top cover.
2. Open cover
3. Align SIM card in cover (note cover orientation)
4. Slide SIM card into cover
5. Rotate cover to close
6. Lock cover to close
IMPORTANT! Do not insert or remove SIM card when
the control panel is powered by AC power or battery.
Figure 3.5 –Optional GSM Module Mounting and SIM Card Insertion

D-306048 WP8033 Installer's Guide 11
3.6 Output Interface Module Installation (located in place of detail "E" in Figure 3.1)
The output interface module is designed to provide alarm, trouble events and status signals to external devices such as
long range wireless monitoring transmitters, CCTV systems, home-automation systems and LED annunciation panels
(for further details see the output interface module Installation Instructions).
The output interface module provides 5 solid state relay contact outputs and is designed to be used as a plug-in
internal add-on module with the WP8033 control panel.
Mount the output interface module as shown in Figure 3.6.
1. Press downward on the output interface module (C), located in the back panel, between its 2 clips.
2. Connect the output interface module flat cable (F) to the front panel receptacle (marked “IP”) and to the flat cable
receptacle of the output interface module (G).
Caution! The connector with strain relief clip (F1) is for the front unit –do not connect it to the back unit!
Notes:
The output interface module will be active only if the output interface module option was enabled in the control panel
(see section 4.7.6, “PGM Output Configuration”.
For wiring instructions, refer to the output interface module Installation Instructions included in the module's package.
Caution! When mounting the output interface module it is strongly recommended to route the wiring cable (E) as
shown in Figure 3.6) to prevent interference which may occur if routed too close to the control panel antennas.
A. Front panel receptacle
(marked “IP”)
B. Front unit
C. Output Interface Module
D. Back unit
E. Wiring Cable
F. Flat cable
F1. This side for front unit
F2. This side for back unit
G. output interface module flat
cable receptacle
Figure 3.6 –Output Interface Module Mounting

12 D-306048 WP8033 Installer's Guide
3.7 Installing the PLINK3 DSC
The PLINK3 DSC is used to view and control the WP8033 system over the Internet.
Perform the following instructions for the PLINK3 DSC installation.
Note: PLINK3 DSC operation is not backed up
by the control panel’s battery and it is shut down
during AC failure.
1. Mount the internal PLINK3 DSC into the back
unit and fasten it with 2 screws.
2. Connect the flat cable (B) from the front panel
to the PLINK3 DSC, as follows: Connector B1
to the front panel; connector B2 to the
PLINK3 DSC.
3. Connect the Cat-5 cable from the PLINK3
DSC to the home router.
Note: In order to prevent interference to the
antenna, do not route the Cat-5 cable through
the cable entry knockout on the right side of
the panel.
A. Cat-5 cable to home router
B. Flat cable
B1. This side for front unit
B2. This side for PLINK3 DSC
Figure 3.7 –PLINK3 DSC Mounting

D-306048 WP8033 Installer's Guide 13
3.8 Optional Expander Module (detail "I" in Figure 3.1)
The Expander module is an optional module. If this optional module is used, the wired zone or special siren on the front
panel should not be used.
Mount the Expander module as shown in Figure 3.8a.
1. Press downward on the Expander module (located in the back panel) between its 2 clips.
2. Connect the Expander module flat cable to the front panel Expander receptacle.
Caution! The receptacle with strain relief clip is for the front unit –do not connect it to the back unit!
A. 2 clips
B. Flat cable with one strain relief clip
B1. This side for front unit
B2. This side for back unit
Figure 3.8a –Expander Module

14 D-306048 WP8033 Installer's Guide
OPTIONAL EXPANDER MODULE, ZONES, SIRENS, AUDIO BOX AND WIRED DETECTORS WIRING
A. Back Unit
B. Expander
C. Internal siren or strobe 6-12 VDC,
150 mA Max.
D. External siren MG441PDS or similar siren 12 VDC
(nominal) 350 mA Max.
E. Connect wired detectors as illustrated.
Note:
The wired detector should be installed at least 2
meters away from the control panel.
Regarding the two wired zones, the control panel
classifies the events according to the resistance it
measures as shown in the table below.
E.O.L or Arming Key Resistance
Range
Zone
Arming Key
0 kΩ 1.76 kΩ
Tamper
Tamper
1.76 kΩ 2.64 kΩ
Normal
Arm
2.64 kΩ 3.52 kΩ
Tamper
Tamper
3.52 kΩ 5.26 kΩ
Alarm
Disarm
5.26 kΩ ∞
Tamper
Tamper
F. Detector without tamper switch or arming key
G. Detector with tamper switch or arming key's tamper
H. PGM device
I. Wired zone A or B
J. Ground (GND)
Figure 3.8b –Zone
and Siren Wiring
Notes for EXPANDER module wiring:
* Wired zone

terminals can be connected to a normally closed contact of a detector, switch (for example a Tamper
switch of any device), or a pushbutton, via a 2.2 K  resistor. The 12V terminal can be used to supply 12V (up to
36mA) to a detector (if necessary).
** The EXT terminal can be used to trigger an external siren.
The INT terminal can be programmed for an "internal siren" or "strobe" (see par. 4.7).
The 12V and "GND" terminals can be connected to a siren (for constant DC power supply).
*** The.12V supply to the PGM device is fused. Current is limited to 100 mA.
WARNING! When plugging terminals back into place, be sure to align them carefully with the pins on the PCB.
Misaligned or reverse insertion of terminals may damage internal WP8033 circuits!
IMPORTANT! The terminals for internal and external sirens are DC outputs intended for 12V sirens. Connecting a
loudspeaker to any of these outputs will cause a short circuit and will damage the unit.

D-306048 WP8033 Installer's Guide 15
3.9 Connecting Power to the Control Panel
Note: This equipment should be installed in accordance with Chapter 2 of the National Fire Alarm Code, ANSI/NFPA
72.
Connect the power cable and close the control panel as shown in Figures 3.9a –3.10.
POWER CABLE CLAMP EXTRACTION AND POWER CONNECTION FOR INTERNAL POWER SUPPLY
Perform steps 1 & 2 on a workbench before mounting.
1. Thick cable entry: Pull out a desired wiring plastic
cap (1 of 4).
2. Extract cable clamp (I) for use in the next step.
3. Insert the power cable through the desired wiring
channel (A). Route it to the power supply unit (E) and
remove the safety cover (D). Connect the 2 wires of
the power cable to the power supply terminal block
(F) with a screwdriver. Fasten the screws tightly.
Fasten the power cable by its clamp (B or C) and
close the safety cover (D).
4. Connect the power supply output cable (G) to the
power connector (H) in the front panel.
A. Optional wiring channels
B. For thin cable
C. For thick cable (reversed clamp)
D. Safety cover
E. Power supply unit
F. Power supply terminal block
G. Power supply output cable
H. Power connector
(*) Do not route wiring in this area, to enable proper
closure of the control panel.
I. Cable clamp.
Figure 3.9a –Power Cable Clamp Extraction and Power Connection for Internal Power Supply

16 D-306048 WP8033 Installer's Guide
EXTERNAL POWER CONNECTION
Connect the power adaptor to the front panel power connector.
Figure 3.9b –External Power Connection
3.9.1 Battery Insertion
Open battery compartment cover.
Insert one 6-battery pack or 8-battery
pack and connect its connector as
shown in Figure 3.8c.
A. Front unit
B. Battery cable
C. Battery cable connector
D. Slot for battery cable
Figure 3.9c –Battery Insertion
3.9.2 Connect AC Power to the Unit
Connect power to the WP8033 to mains power outlet (see Figures 3.8a and 3.8b).
Disregard any “trouble” indications pertaining to lack of battery or lack of telephone line connection.

D-306048 WP8033 Installer's Guide 17
3.10 Closing the WP8033 Control Panel
Control panel final closure is shown below.
To close the Control Panel:
1. Connect the flat cables, between front and back units, in their
respective connectors (up to 3, according to options).
2. Make sure that the "Power" indicator on the control panel lights
green.
3. Close the panel and fasten the 2 screws.
Figure 3. 10 - Final Closure

18 D-306048 WP8033 Installer's Guide
4. VISUAL INDICATIONS, FIRST KEYPAD
ENROLLMENT AND USING PROX TAG
4.1 WP8033 LED Indications
The following table provides a detailed description of the LED indications on the WP8033 panel.
Color
Definition
LED Operation
Green
Local Power indication
STEADY: Indicates that system has mains power
BLINKING: Low battery state
NO LIGHT: AC failure
Green
Ready / Not Ready
Indication
STEADY: All partitions are ready
NO LIGHT: Not Ready / at least one partition is Not Ready
Red
System Arming State
Indication
STEADY: AWAY / At least one partition is AWAY
BLINKING: HOME / At least one partition is HOME and no
partitions are in AWAY
NO LIGHT: The system is presently in the disarmed state
Orange
System Not Online
Indication
STEADY: System is unavailable (Sync/Updating/In-menu)
NO LIGHT: System is available
Orange
System Trouble indication
STEADY: System has trouble
NO LIGHT: No trouble –all is well
4.2 Enrollment of the First Keypad
The WP8033 is designed to operate wirelessly with the keypad installed anywhere within the protected premises.
The first keypad is always enrolled as Keypad no. 1.
Note: The enrolment procedure described here is for the first keypad only. The enrolment of additional keypads is
performed via the first enrolled keypad (for instructions, refer to the keypad Installer’s Guide, section 3.4.2).
Step
Action
1
Press the "ENROLL" button (physically located inside the front unit of the WP8033 control panel –see
Figure 3.1) for 2 seconds. If no keypad exists in the first location, the "ENROLL" LED on the WP8033 blinks
slowly for 1 minute (go to step 3).
If a keypad already exists in the first location, the "ENROLL" LED on the WP8033 control panel lights
steady for 10 seconds (go to step 2).
Note: Pressing the "ENROLL" button takes the system out of any menu mode (Installer Mode, User
Settings and Periodic Test).
2
Press the "ENROLL" button again within the timeout period (10 seconds). Any keypad that was enrolled in
keypad no. 01 is deleted from the system.
The "ENROLL" LED on the WP8033 blinks slowly for 1 minute.
3
During this 1 minute period, hold the button for 5-7 seconds, until the LED on the keypad lights
red, and release*. The "ENROLL" LED on the WP8033 will indicate the result of the enrollment procedure.
WP8033 "ENROLL" LED indication Result
Blinks fast for 5 sec. Successful enrollment of keypad
Lights steadily for 5 sec. Wrong device type
4
Upon completion of the enrolling procedure, the keypad is ready for immediate use even if the system is
currently in the Armed state.
Note: If the keypad was previously enrolled, it will be relocated automatically to Keypad no. 1. However, all
of the configured parameters will be lost and the keypad will revert to the default parameters.
*
If the keypad is battery-powered: first press any button on the keypad momentarily to take the keypad out of sleep mode and then
hold the button for 5-7 seconds, until the LED on the keypad lights red, and release.

D-306048 WP8033 Installer's Guide 19
4.3 Using the Prox Tag
Proximity tags enable authorized people to enter
restricted areas. Presenting a valid proximity tag to the
tag reader (as shown in the drawing) while the system is
armed causes the system to disarm. Presenting a valid
proximity tag to the tag reader while the system is
disarmed causes the system to be armed in AWAY
(optional HOME) mode. To enroll / delete proximity tags,
refer to the keypad User’s Guide.
Notes:
1. Use of the Proximity tags is optional.
2. Proximity tags are not compatible for use when partition
is enabled.
5. MAINTENANCE
5.1 Dismounting the Control Panel
A. Remove the screw that fastens the front unit to the back unit, see Figure 3.2.
B. Remove the 4 screws that fasten the back unit to the mounting surface - Figure 3.2 - and remove the control panel.
5.2 Replacing the Backup Battery
Replacement and first-time insertion of battery pack is similar, see Figure 3.9c.
With a fresh battery pack, correct insertion and tightened battery compartment lid, the TROUBLE indicator on the
keypad should extinguish. However, the “MEMORY” message will now blink in the display (caused by the “tamper”
alarm you triggered when opening the battery compartment lid). Clear it by arming the system and immediately
disarming.
5.3 Fuse Replacement
The WP8033 has two internal fuses that has automatic reset. Therefore, there is no need to replace the fuses.
When over current condition occurs, the fuse cuts off the circuit current. Upon fault current being removed for several
seconds, the fuse is automatically reset and allows current flow through the circuit again.
5.4 Replacing/Relocating Detectors
Whenever maintenance work involves replacement or re-location of detectors, always perform a full diagnostic test
according to the keypad User’s Guide, section 12.9.
Remember! A "poor" signal is not acceptable.
5.5 Annual System Check
Note: The WP8033 system must be checked by a qualified technician at least once every three (3) years (preferably
every year).
The annual system check is designed to ensure proper operation of the alarm system by performing the following checks:
Periodic test
Arm/disarm function
No trouble messages are displayed on control panel
The clock displays the correct time
Reporting: generating an event to be transmitted to the Monitoring Station and to the user.

20 D-306048 WP8033 Installer's Guide
APPENDIX A. Specifications
A1. Functional
Zones Number
Up to 64 wireless zones, (including 2 hard-wired inputs).
Hard-wired Zone Requirements
2.2 kE.O.L. resistance (max. resistance of wires 220 
Maximum Loop Current
1.5 mA
Maximum Loop Voltage
3.3 V
Loop Shorted
0 –1.47 V (0 –1.770 Ω)
Loop Normal
1.47 –1.8 V and 2.02 –2.3 V
Loop Open
2.3 –3.3 V (5.06 - ∞ Ω)
Installer and User Codes
1 master installer (9999 by default)*
1 installer (8888 by default)*
1 master user, no. 1 (1111 by default)
Users nos. 2 - 48
* Codes must not be identical
Control Facilities
- Integral keypad, wireless keyfobs and keypads
- SMS commands via optional GSM/GPRS module.
- Remote control by telephone.
Arming Modes
AWAY, HOME, AWAY-INSTANT, HOME-INSTANT, LATCHKEY, FORCED, BYPASS.
Alarm Types
Silent, personal panic/emergency, burglary, gas, fire and flood.
Siren Signals
Continuous (intrusion / 24 hours / panic); triple pulse –short pause - triple pulse... (fire);
four pulses –long pause –four pulses... (gas);
long pulse –long pause –long pulse... (flood).
Siren (bell) Timeout
Programmable (4 min. by default)
Internal Sounder Output
At least 85 dBA at 3 m (10 ft)
Supervision
Programmable time frame for inactivity alert
Special Functions
- Chime zones
- Diagnostic test and event log.
- Local and Remote Programming over Telephone, GSM /GPRS connections.
- Calling for help by using an emergency transmitter.
- Tracking inactivity of elderly, physically handicapped and infirm people.
- Message center (recording and playback)
Data Retrieval
Alarm memory, trouble, event log
Real Time Clock (RTC)
The control panel keeps and displays time and date. This feature is also used for the log
file by providing the date and time of each event
Battery Test
Once every 10 seconds
A2. Wireless
RF Network
PowerG –2-way synchronized Frequency Hopping (TDMA / FHSS)
Frequency bands (MHz)
433 –434
868 - 869
912 - 919
Hopping frequencies
8
4
50
Region
Worldwide
Europe and South Africa
North America and
selected countries
Encryption
AES-128
A3. Electrical
External AC/AC adaptor
NA
External AC/DC adaptor
External (wall-mounted) switching power supply 100VAC to 240VAC, 50/60 Hz, 0.5A
/ 12.5 VDC, 1.2A
Internal AC/DC
Internal switching power supply:
Input: 100-240VAC, 0.75A
Output: 12.5 VDC, 1.6A.
Current Drain
Approx. 260 mA standby at the beginning (power ON) and then goes down to 60 mA,
1400 mA max. current drain during alarm.
Low Battery Threshold
7.2 V (6-cell battery pack)
9.6 V (8-cell battery pack)
Backup Battery Pack
Backup Battery Options:
Backup period
Maximum external devices current (1)
1300 mAh
6 Battery Pack (2)
1800 mAh
8-BatteryPack (3)
2200 mAh 8-Battery
Pack (4)
4h
180 mA
300 mA
380 mA
8h
70 mA
125 mA
160 mA
12h
35 mA
70 mA
95 mA
24h
max backup w/o
load 22 hours
12 mA
25 mA
32h
no backup
0 mA
10 mA
39h
no backup
no backup
0 mA
