INTRODUCTION
Thank you for acquiring the DT370CR/ DT370Q, part of DT Research’s line of tablets.
Featuring a slim yet robust enclosure, the DT370CR/ DT370Q with 7” TFT display is
powered by the Intel® Atom™ quad-core or Qualcomm octa-core processor, oering
opmal combinaons of performance and power savings. The DT370CR/ DT370Q
is available with Microso® Windows® or Android operang system. The soware
operang system features web browser, client/ server compung soware, media
player, accessories, and applicaons support.
PACKAGE CONTENTS
• One DT370CR/ DT370Q with Baery Pack and Handstrap
• AC-DC Power Adapter with Power Cord
• Basic Operaon Guide
* If your DT370CR/ DT370Q contains camera or barcode scanner, please refer to the
Tablet Modules Basic Operaon Guide for detailed operaon.
DT370CR/ DT370Q

Button Functions
BUTTON ACTION
Power Buon
Programmable buon without
the scanner module
As scanner trigger when
equipped with the scanner
module
4-way tacle buon
Enter buon and
Programmable buons
Baery Latch
Input/ Output Ports
Headphone Jack
USB Port
DC Power Input
Back Camera
(oponal on DT370CR)
Barcode Scanner (oponal)
A
B
C
23
PRECAUTIONS
• Always exercise care when operang and handling the DT370CR/ DT370Q.
• Do NOT apply excessive pressure to the display screen.
• Avoid prolonged exposure of the display panel to any strong heat source.
Wherever possible, the DT370CR/ DT370Q should face away from direct light to
reduce glare.
• If the AC-DC power adapter is used to recharge or power the tablet, do NOT use
any AC-DC adapter other than the one provided or acquired from the manufac-
turer or its partners.
• In the unlikely event that smoke, abnormal noise, or strange odor is present,
immediately power o the DT370CR/ DT370Q and disconnect all power sources.
Report the problem to your device provider immediately.
• Never aempt to disassemble the DT370CR/ DT370Q, as this will void the
warranty.
BASIC FEATURES
The DT370CR/ DT370Q wireless tablet integrates a bright and mul-touch display,
one USB port, and embedded networking elements such as wireless LAN and
Bluetooth. The DT370CR/ DT370Q is complemented by a suite of accessories,
including baery expansion, and charging cradles, for a comprehensive user
experience.
A DT370CR/ DT370Q typically integrates an 802.11ac wireless LAN (WLAN) adapter
that may connect to other wireless devices or access points. If your DT370CR/
DT370Q does not come with such a network adapter, please consult your device
provider to establish the desired network connecvity.
1
2
3
4
5
D
E
Power/Battery LED Status:
• Blue indicates the baery is 25% to 100% charged
• Blinking blue indicates the baery is charging
• Orange indicates that the baery is between 11% to 25%
• Blinking Orange indicates that the baery is below 10%
5
2
1
4
3
A
D
E
B
C

Start Up
If the power up (from Standby mode or otherwise) is successful, the appropriate
interface will be displayed aer a launch sequence of several seconds. The wireless
LAN connecon may take 10-15 seconds to be established.
Configuring the Mobile Tablet
The DT370CR/ DT370Q may be congured using the ulies and methods dictated
by the soware operang system. The DT370CR/ DT370Q should be congurable
for various properes such as user proles, network features, and several system
elements.
Wireless Networking
Wireless LAN
The DT370CR/ DT370Q is oen delivered with an embedded (user-inaccessible)
802.11ac WLAN adapter equipped with a hidden custom antenna.
• Through the support of typical WLAN adapters, the DT370CR/ DT370Q should be
able to detect all 802.11 access points in the vicinity for you to select the access
point of your choice for connecon.
• The SSID and WEP/WPA/WPA2 (if enabled) parameters on the DT370CR/ DT370Q
and the access points have to match. The SSID is case-sensive and it is recom-
mended that you enable WEP/WPA/WPA2 encrypon (or advanced alternaves)
for secure access.
• When WEP/WPA/WPA2 is enabled, you may need to consult your network
administrator or your networking equipment literature to properly congure
associated sengs such as Authencaon mode, etc.
• Refer to the access point operang manuals for seng up the 802.11 access
points.
Bluetooth
The Bluetooth conguraon applicaon is enabled from the Windows System Tray or
from the Android Sengs APP. Follow the instrucons and opons provided within
the applicaon to congure and invoke Bluetooth connecvity with the correspond-
ing peripherals.
OPERATION
Powering ON and OFF
To acvate the DT370CR/ DT370Q, push and quickly release the Power Buon. The
display will come on in a few seconds. To put the DT370CR/ DT370Q in Standby mode,
push and quickly release the Power Buon. To turn the DT370CR/ DT370Q o for
extended storage, power o safely using any soware funcon that “shuts down
computer” provided in the soware operang system.
NOTE:
The baery pack shipped with your tablet may be low in power—please use the
AC-DC adapter with the DT370CR/ DT370Q when seng up for the rst me to
fully charge the baery pack, or use the oponal baery charger kit.
NOTE:
When the baery pack is charging, the blue-colored Baery LED should blink
slowly. If plugging in the AC-DC adapter does not trigger this blinking acvity
and the LED stays dark, the baery pack(s) may have been drained substanally.
Try unplugging/ replugging the AC-DC adapter to the DT370CR/ DT370Q a few
mes to acvate the charging process.
NOTE:
To conserve power, use (push and quick release) the Power Buon to put the
tablet in “Standby” mode while not in use. Pushing briey on the same buon
will wake up the system within seconds.
NOTE:
For DT370CR, avoid using the Power Buon (“hold 4+ seconds” feature) to turn
o the tablet—this form of hardware shutdown is intended to be a means of
recovery from lockups, and not as normal operaon.
45

USING THE MOBILE TABLET
Peripherals Support
Through its USB port, the DT370CR/ DT370Q supports a wide range of USB-based
peripherals. These peripherals are applicable for soware installaon, applicaons
storage, data storage, and system soware recovery and updates.
For More Support
Users can download the Tablet Modules Basic Operaon Guides from the DT
Research website.
67
To Hold the Tablet
Le hand: grip the le back side of the tablet
with your le hand four index ngers, with
thumb resng on the top of the back side of the
tablet and palm securely against the back.
Right hand: grip the right back side of the tablet
with your right hand four index ngers, with
thumb resng on the top of the back side of the
tablet and palm securely against the back.
Federal Communication Commission Interference
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protecon against harmful interference in
a residenal installaon. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with
the instrucons, may cause harmful interference to radio communicaons.
However, there is no guarantee that interference will not occur in a parcular
installaon. If this equipment does cause harmful interference to radio or
television recepon, which can be determined by turning the equipment o
and on, the user is encouraged to try to correct the interference by one of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separaon between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
FCC Cauon: Any changes or modicaons not expressly approved by the
party responsible for compliance could void the user’s authority to operate
this equipment.
This device complies with Part 15 of the FCC Rules.
Operaon is subject to the following two condions: (1) This device may not
cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operaon.
This device and its antenna(s) must not be co-located or operang in
conjuncon with any other antenna or transmier.
This Class [B] digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du
Canada.
