dynarex 10215 User manual

Reorder Nos. 10215
10216
Steerable Knee Walkers
with Basket
Steel
Your Dynarex product is warrantied to be free of defects
in materials and workmanship for the lifetime of the
product for the original consumer purchaser. This item
was built to exacting standards and carefully inspected
prior to shipment. This Limited Lifetime Warranty is
an expression of our confidence in the materials and
workmanship of our products and our assurance to
the consumer of years of dependable service.
The Warranty shall not apply under the following
conditions:
problems arising from normal wear; problems arising
from failure to adhere to the product instructions;
problems arising from misuse, negligence, accident or
improper operation, maintenance or storage; problems
arising from modifications or unauthorized repairs, parts
or attachments; products where the serial number has
been removed or defaced; problems with non-durable
components, such as rubber accessories, casters, and
grips, which are subject to normal wear and need
periodic replacement. Dynarex shall not be liable for
any consequential or incidental damages whatsoever.
Dynarex shall repair or replace defective products at its
option. The foregoing warranty is exclusive and in lieu
of other express warranties, if any, including the implied
warranties of merchantability and fitness of a particular
purpose. The remedy for any violation of the implied
warranty shall be limited to repair or replacement of the
defective product pursuant to the terms contained herein.
If you have a question about your Dynarex device or this
warranty, please contact an authorized Dynarex dealer.
LIMITED LIFETIME WARRANTY
11
Manufactured for: Dynarex Corporation
10 Glenshaw Street • Orangeburg, NY 10962
USA • www.dynarex.com
Made in China
R180115
SYMBOL GLOSSARY
For an explanation of symbols
used in Dynarex packaging, visit
dynarex.com/symbols.php

Parking Brake Lock
Handlebars
Steering Tiller
Knee Platform
SecureLock
Mechanism
Star Screw
Star Screw
Basket
Hand Brake Lever
Hand Brake Lever
10215
STEP 1:
To Assemble the Knee Walker Frame
• Unpack contents from carton.
• Raise the handlebar and lock in place
using the SecureLock Mechanism.
(See page 6 for instructions on using
the SecureLock Mechanism.)
• For item # 10216 open the split frame so
the wheels are flat to the floor. Lock in
place using the SecureLock Mechanism.
STEP 2:
To Raise and Adjust the Handlebar
Height
• Turn the star screw counterclockwise
and remove from the handlebar post.
(Figure A on page 4.)
• Extend handlebars up to desired height,
align holes on handlebar post. While in
the standing position, the handlebars
should be set at wrist height when
standing straight.
• Insert star screw and turn the star screw
clockwise to tighten the handlebar post
into position.
• Tighten star screw securely.
1 2
ASSEMBLY INSTRUCTIONS
10216
Handlebars
Star Screw
Basket
Basket
Receptacles
Pad Lock
Knob
SecureLock
Mechanism
Parking Brake Lock
Steering Tiller
Knee
Platform

3 4
(Figure B)
(Figure C)
(Figure D)
(Figure A)
STEP 3:
To Adjust the Height of the Knee
Platform Cushion
For 10215
• Insert the knee platform post into
receptacle on frame. (Figure B)
• Lift the knee platform to desired height.
• Align the holes and insert the push pin
into the hole, sliding the retainer tab
onto the pin. (Figure C)
• Push lever closed for a secure lock.
(Figure D)
For 10216
• Insert the knee platform post into
receptacle on frame. (Figure B)
• Lift the knee platform to desired height.
• Then, insert star screw and turn the star
screw clockwise to tighten the knee
platform post into position.

USING THE SECURELOCK
5 6
• To lock the mechanism extend the two
parts of the walker so that the mecha-
nism closes.
Locking Lever
Groove
Locking
Lever
STEP 4:
To Attach Basket
• Line up the back of the basket and slide it
down over the hooks of the post.
• Push it down until it is securely in place.
• To remove the basket, lift the basket up.
STEP 5:
To Use and Adjust the Brakes
• The Knee Walker’s brake is similar to a
bicycle and also has a locking feature.
• Do not use the Knee Walker if the brake
system is not working properly.
• Use an Allen Wrench to loosen the hand
lever to reposition locking mechanism
and re-tighten to a comfortable position.
• The brake tightness can be adjusted with
the nuts at either end of the brake cable.
Turning the screw counterclockwise will
loosen the brake and turning the screw
clockwise will tighten it.
• To use the brake, squeeze the hand
brake lever.
• To lock the brake, squeeze the hand
brake lever and push down on the brake
locking button to secure a full lock. When
done correctly, brake locking button will
stay locked in the downward position.
• To release brake, squeeze the hand
brake lever again and the brake locking
button will pop up automatically.
Release
Pin
Release Pin Hole
• When mechanism is properly closed the
release pin will be fully engaged in the
release pin hole.

OPERATING THE KNEE WALKER
The Dynarex Knee Walker is a mobility
device that provides strength and comfort
to anyone who may have an injury below
the knee. It allows an even distribution of
body weight by supporting half of the
weight on the device and the other half on
the non-injured leg. The device has a
cushioned platform to support both the
injured leg and ankle to make certain that
no weight will be placed on the lower leg.
The device is designed for easy steering
and stopping. Brakes are also featured
on this device for controlled movement
and safety.
• Placement of injured leg on pad should
be centered side to side and positioned
forward to cover the full length of pad.
• With injured leg on pad, stand as
straight as possible (adjust the height of
the Knee Walker as necessary).
• With injured foot pointing down, the
propulsion leg should be maintained as
close as possible to the pad.
• While on your toes, start out with small
steps with propulsion leg. Concentrate
on keeping that leg next to the pad. With
practice, you should be able to move
forward without deviating to the
opposite side.
7 8
• Lift the locking lever so that it is inside
the locking lever groove. If the locking
lever is too short and can not enter
the groove, rotate the locking lever
to elongate.
• Once the locking lever is in an upright
position, turn it 90 degrees so it locks into
place.

• Engage the lock and practice bending,
reaching and transfers on and off the
Knee Walker. DO NOT use the Knee
Walker by yourself until you have been
properly trained, you have practiced with
someone and you feel confident you can
maneuver by yourself.
• The use of the Knee Walker is individual
to the person. You should develop your
own methods for use based on your
personal level of function and ability.
• NEVER attempt a maneuver that has not
been practiced.
• Be aware of your surroundings when
operating the Knee Walker. Look for
hazards and avoid them.
• Contact your provider if any parts are
loose or show excessive wear.
• Do not operate on loose gravel or uneven
surfaces.
• Do not travel over large cracks or
fissures.
910
• Stop and move forward slowly when
encountering cracks or separations in
walkway surfaces.
• Do not operate in excess of 3 miles per
hour (slow-to-moderate walking speed).
• Do not turn unless one foot is on the
ground.
• Never make a sharp turn at high speed.
• Do not turn at speeds over 1 mph
(very slow walking speed).
• Do not operate on inclines above
15 degrees (slight incline).
• Do not travel over drops or barriers
such as curbs or parking stops.
• This is a medical device, not a toy. Do
not allow children or adults to use this
as a toy or for entertainment.
• Always check the fasteners on the
handlebar post, wheels, brakes, and
pad for tightness before use.
CAUTION CAUTION
