Dynojet WIDEBAND CX User manual

WIDEBAND CX
INSTALLATION GUIDE
1WIDEBAND CX
1DIAGNOSTIC TO CAN TO POWER
VISION CABLE
1O2 SENSOR
1VELCRO
3ZIP TIE
For Use With Honda Power Vision
PARTS LIST
PLEASE READ ALL DIRECTIONS BEFORE STARTING INSTALLATION
2191 MENDENHALL DRIVE, NORTH LAS VEGAS, NV 89081
800-992-4993 IWB-PV16-1WWW.DYNOJET.COM

IWB-PV16-1 HONDA
INTRODUCTION
INSTALLING THE WELD BOSS AND SENSOR
WIDEBAND CX OVERVIEW
Thank you for purchasing the Wideband CX (WBCX) from
Dynojet Research. The WBCX module is the tuning tool
for gathering Wideband Air Fuel Ratio data for monitoring
engine performance.
Use your Power Vision module to view and log WBCX
data; combine your Wideband data with Dynojet’s Power
Core software to create your perfect tune and achieve
optimal performance from your vehicle.
Note: This WBCX device only pairs with the Power Vision
module for this vehicle.
1 Mock up the O2 sensor installation location on the
exhaust system in a manner that reduces the risk of
moisture contamination on the sensor. Condensation can
build up in the exhaust pipes and potentially damage the
sensor.
2 Ideally, you should orient the weld boss so the sensor
is between the 9 o’clock and 3 o’clock position. A 10°
inclination off the horizontal plane should be considered
a minimum.
Note: Verify you have adequate clearance for the sensor
and wiring harness. Make sure the O2 sensor harness is
as straight as possible. If you must secure the harness
to keep away from danger make sure you do not squeeze
the sheathing of the harness.
3 Mark the sensor installation location and install the weld
boss.
4 Thread the O2 sensor into the weld boss.
5 Connect the O2 sensor cable to the O2 sensor and route
the cable to the WBCX location.
Note: If you must secure the harness to keep away from
danger, make sure you do not squeeze the sheathing of
the harness.
6 Attach the six wires from the O2 Sensor cable to the
screw terminal on the WBCX module.
Note: Piercing the holes with a paperclip will make
inserting the wires easier.
7 Install the terminal strip plug.
WBCX CAN PORT
CONNECT TO
POWER VISION
WBCX TERMINAL STRIP
CONNECT TO O2 SENSOR
WIDEBAND CX OVERVIEW
LOCATIONORIENTATION
WBCX CAN PORT
CONNECT TO
VEHICLE
ATTACH O2 WIRES TO WIDEBAND CX

INSTALLATION GUIDE
INSTALLING THE WBCX
1 Secure the WBCX under the seat near the diagnostic port
using the supplied Velcro. Be sure to clean the mounting
surfaces thoroughly with the supplied alcohol swab.
2 Remove the cable that was included with the Power
Vision from the Diagnostic port of the vehicle
3 Using the supplied cable with the WBCX, connect
one end to the Power Vision and the other end to the
diagnostic port of the vehicle.
4 Connect the flat, 4 pin plug of the cable into the port of
the WBCX module. You can use either port.
Grom Models: the diagnostic port is located under the
seat.
CONNECTING TO THE POWER VISION
1 Following the instructions included with your Power
Vision, secure the Power Vision to the vehicle using the
supplied Velcro. Make sure the Power Vision will not
interfere with the operation of the vehicle.
2 Attach the large connector from the Wideband harness to
the port on the Power Vision. POWER VISION PORT
CONNECT TO WBCX
CONNECT THE WIDEBAND HARNESS
DIAGNOSTIC PORT

PUSH THE LIMIT.
WWW.DYNOJET.COM
© 2019 DYNOJET RESEARCH ALL RIGHTS RESERVED
