Dyson Pure Cool User manual

Operating manual
TP04
06.07.201811:40 - C93644_TP04_OPMAN_ANZ_X438-OPMAN-93644.indd_15_4c0s

2
Maintenance
Changing the glass HEPA filters
Changing the carbon filters
Cleaning
Important information
Troubleshooting
Additional information
Getting started
Registration
Important safety instructions
Assembly
Controls
Additional functions
Connecting to the Dyson Link app
Information menu
Auto mode
Airflow
Oscillation
Night mode
4
6
9
10
11
12
14
16
17
18
19
20
22
24
25
26
Contents
06.07.201811:40 - C93644_TP04_OPMAN_ANZ_X438-OPMAN-93644.indd_15_4c0s

3
We're here to help
Support centre
AU: 1800 239 766
NZ: 0800 397 667
AU: [e-mail]
NZ: [email protected]
Online
AU: www.dyson.com.au/support
NZ: www.dyson.co.nz/support
Download the
Dyson Link app
The Dyson Link app allows you to
control, monitor, customise and get
automatic setting upgrades for your
appliance on your mobile device.
Search for the Dyson Link app on
the App Store or Google Play.
Thank you for choosing to
buy a Dyson purifying fan
06.07.201811:40 - C93644_TP04_OPMAN_ANZ_X438-OPMAN-93644.indd_15_4c0s

4
Registration
After registering your 2 year guarantee, your Dyson
appliance will be covered for parts and labour
(excluding filters) for 2 years from the date of purchase,
subject to the terms of the Dyson guarantee.
Your serial number can be found on your rating plate
which is on the base of the appliance.
Note your serial number for future reference.
This illustration is for example purposes only.
Small details may vary slightly from those shown.
06.07.201811:40 - C93644_TP04_OPMAN_ANZ_X438-OPMAN-93644.indd_15_4c0s

5
Register by mail
Complete and return the form to
Dyson in the envelope supplied.
Register by phone
Call our dedicated Helpline.
AU: 1800 239 766
NZ: 0800 397 667
Register online
Visit our website to register your
Dyson full parts and labour
guarantee online.
AU: www.dyson.com.au/register
NZ: www.dyson.co.nz/register
Register with your smartphone
Download the Dyson Link app
and you will be taken through
registration as part of the set up.
4 easy ways to register
your 2 year guarantee
06.07.201811:40 - C93644_TP04_OPMAN_ANZ_X438-OPMAN-93644.indd_15_4c0s

6
IMPORTANT SAFETY
INSTRUCTIONS
BEFORE USING THIS APPLIANCE READ
ALL INSTRUCTIONS AND CAUTIONARY
MARKINGS IN THIS MANUAL AND ON THE
APPLIANCE
When using an electrical appliance, basic
precautions should always be followed, including
the following:
WARNING
THE FAN AND THE REMOTE CONTROL BOTH
CONTAIN MAGNETS.
1. Pacemakers and defibrillators may be affected
by strong magnetic fields. If you or someone in
your household has a pacemaker or defibrillator,
avoid placing the remote control in a pocket or
near to the device.
2. Credit cards and electronic storage media may
also be affected by magnets and should be kept
away from the remote control and the top of
the appliance.
WARNING
These warnings apply to the appliance, and
also where applicable, to all tools, accessories,
chargers or mains adaptors.
TO REDUCE THE RISK OF FIRE, ELECTRIC
SHOCK, OR INJURY:
3. This Dyson appliance is not intended for
use by children, or persons with reduced
physical, sensory or mental capabilities, or
lack of experience and knowledge, unless
they are supervised and/or given instruction
by a responsible person concerning use of the
appliance to ensure that they can use it safely.
Cleaning and user maintenance should not be
performed by children without supervision.
4. Ensure that the appliance is fully assembled in
line with the instructions before use.
5. Do not allow to be used as a toy. Close attention
is necessary when used by or near children.
Children should be supervised to ensure that
they do not play with the appliance.
6. Use only as described in this Dyson Operating
Manual. Do not carry out any maintenance other
than that shown in this manual, or advised by the
Dyson Customer Care Helpline.
06.07.201811:40 - C93644_TP04_OPMAN_ANZ_X438-OPMAN-93644.indd_15_4c0s

7
7. Suitable for dry location ONLY. Do not use
outdoors or on wet surfaces and do not expose
to water or rain.
8. Do not handle any part of the plug or appliance
with wet hands.
9. Do not operate any appliance with a damaged
cable or plug. Discard the appliance or return
to an authorised service facility for examination
and/or repair. If the supply cable is damaged
it must be replaced by Dyson, its service agent
or similarly qualified person in order to avoid
a hazard.
10. If the appliance is not working as it should,
has received a sharp blow, has been dropped,
damaged, left outdoors, or dropped into water,
do not use and contact the Dyson Customer
Care Helpline.
11. Do not stretch the cable or place the cable under
strain. Keep cable away from heated surfaces.
12. Do not run cable under carpeting. Do not
cover cable with throw rugs, runners or similar
coverings. Arrange cable away from traffic area
and where it will not be tripped over.
13. Do not unplug by pulling on the cable.
To unplug, grasp the plug, not the cable. The use
of an extension cable is not recommended.
14. Do not put any object into openings or the inlet
grille. Do not use with any opening blocked;
keep free of dust, lint, hair, and anything that
may reduce airflow.
15. Do not use any cleaning agents or lubricants
on this appliance. Unplug before cleaning or
carrying out any maintenance.
16. Always carry the appliance by the base, do not
carry it by the loop amplifier.
17. Turn off all controls before unplugging. Unplug
from socket when not in use for extended
periods. To avoid a tripping hazard, safely coil
the cable.
18. Do not use near furnaces, fireplaces, stoves or
other high temperature heat sources.
19. Do not use in conjunction with or directly next
to an air freshener or similar products. Do not
spray or apply perfumes directly on or near the
filter. Keep essential oils and chemicals away
from the appliance.
20. WARNING: Chemical Burn and Choking
Hazard. Keep batteries away from children.
This product contains a lithium button/coin cell
battery. If a new or used lithium button/coin cell
battery is swallowed or enters the body, it can
cause severe internal burns and can lead to
death in as little as 2 hours. Always completely
06.07.201811:40 - C93644_TP04_OPMAN_ANZ_X438-OPMAN-93644.indd_15_4c0s

8
secure the battery compartment. If the battery
compartment does not close securely, stop using
the product, remove the batteries, and keep it
away from children. If you think batteries might
have been swallowed or placed inside any part
of the body, seek immediate medical attention.
21. This appliance is only to be used with the power
supply unit provided with it.
READ AND SAVE THESE
INSTRUCTIONS
THIS DYSON APPLIANCE IS INTENDED FOR
HOUSEHOLD USE ONLY
Do not pull on the cable. Do not store near
heat sources.
Do not use near
naked flames.
Do not carry by the air
loop amplifier. The air
loop amplifier is not
a handle.
Do not spray scented
products such as air
freshener or perfume
near the filter or
the appliance.
06.07.201811:40 - C93644_TP04_OPMAN_ANZ_X438-OPMAN-93644.indd_15_4c0s

9
Remove the glass HEPA
filters from their protective
packaging and push into the
shrouds until secure.
Use both hands to lift the
appliance out of the box, taking
care to hold by the base of the
appliance only.
Do not lift out by the
amplifier loop.
Take the carbon filters out
of the box and remove the
protective packaging.
Attach both carbon filters to
the appliance.
Position the shrouds onto the base
and push gently until they click
securely into place.
Place the remote control on the top
of the appliance with the buttons
facing down.
Plug in and switch on.
Assembly
x2
x2
x2
x2
clik
clik
x2
x2
x2
x2
clik
clik
x2
x2
x2
x2
click
click
06.07.201811:40 - C93644_TP04_OPMAN_ANZ_X438-OPMAN-93644.indd_15_4c0s

10
Controls
x2
x2
x2
x2
clik
clik
Airflow
direction
Auto
mode
Night
mode
Information
menu
Airflow
speed
Oscillation
ON/OFF
Standby
ON/OFF
Standby
ON/OFF
06.07.201811:40 - C93644_TP04_OPMAN_ANZ_X438-OPMAN-93644.indd_15_4c0s

11
Additional functions
Standby ON/OFF
Press the Standby ON/OFF button on the appliance or
remote control to stop the purifying fan. The appliance
will continue to monitor the air quality if the continuous
monitoring function has been enabled, otherwise it will
go in to standby.
To reactivate the appliance press the Standby ON/OFF
button on the appliance or remote control.
Continuous monitoring
The continuous monitoring function will:
• Collect extensive environmental information (see the
"Information menu" section).
• Allow historical air quality information to be displayed
on the screen and in the Dyson Link app.
To enable/disable continuous monitoring, press and
hold the Auto mode button for 5 secs.
06.07.201811:40 - C93644_TP04_OPMAN_ANZ_X438-OPMAN-93644.indd_15_4c0s

12
Connecting to the Dyson Link app
The Dyson Link app allows you to
control, schedule, monitor, and
customise your settings for your
appliance from your mobile device.
Wi-Fi is enabled by default. To
disable or enable the Wi-Fi press
and hold the ON/OFF button on the
appliance for 5 Seconds.
Plug in your appliance to the mains
electricity supply and turn on
the power.
Check your mobile device
is compatible with the app,
switched on, connected to a Wi-Fi
network and Bluetooth®wireless
technology enabled.
If you do not already have the
Dyson Link app you will need to
download it from the App Store or
Google Play.
Open the Dyson Link app and
follow the instructions to create a
new account if you do not already
have one.
Follow the on-screen instructions
to pair your appliance to the Dyson
Link app.
You will now be able to use the
Dyson Link app to create custom
settings, monitor information
from the appliance, control
your appliance, schedule use
and also keep up to date with
system upgrades.
If you experience problems
downloading the Dyson Link app
or pairing your device; first check
that you are connected to a Wi-Fi
network and Bluetooth®wireless
technology is enabled on your
mobile device and try again.
If you continue to experience
problems downloading the app or
pairing your device, please contact
the Dyson Helpline.
Google Play and the Google Play logo are
trademarks of Google Inc.
Apple and the Apple logo are trademarks of
Apple Inc., registered in the U.S. and other
countries. App Store is a service mark of Apple
Inc., registered in the U.S. and other countries.
App functionality may vary by location.
Requires WiFi and a smart phone. Standard
data and messaging rates may apply.
The Bluetooth®word mark and logos are
registered trade marks owned by the Bluetooth
SIG, Inc. and any use of such marks by Dyson is
under license.
06.07.201811:40 - C93644_TP04_OPMAN_ANZ_X438-OPMAN-93644.indd_15_4c0s

13
06.07.201811:40 - C93644_TP04_OPMAN_ANZ_X438-OPMAN-93644.indd_15_4c0s

14
Information menu
Scroll through the options to monitor
the performance of your appliance.
The menu will also allow you
to access information about
the pollutants in the air and the
temperature and humidity levels.
When a particular type of pollutant
causes air quality to decrease, the
symbol for that pollutant will show in
the display.
Small details may vary slightly from
those shown.
06.07.201811:40 - C93644_TP04_OPMAN_ANZ_X438-OPMAN-93644.indd_15_4c0s

15
Indoor air quality - 12 seconds
Monitor the current air quality with a
graph showing the last 12 seconds
of data.
Particulate matter (PM2.5)
Microscopic particles up to 2.5
microns in size, suspended in the air
we breathe. These include smoke,
bacteria and allergens.
Particulate matter (PM10)
Larger microscopic particles up to
10 microns in size, suspended in the
air we breathe. These include dust,
mould and pollen.
Nitrogen dioxide and other
oxidising gases
These potentially harmful gases are
released into the air by combustion,
for example the burning gas
when cooking and in vehicle
exhaust emissions.
Volatile organic compounds
VOC’s are typically odours that may
be potentially harmful. These can be
found in cleaning products, paints
and new furnishings.
Indoor temperature
Monitor the ambient
temperature to help maintain a
comfortable environment.
Indoor humidity
The amount of water vapour in the
air, shown as a percentage of the
maximum possible humidity at the
current temperature.
Filters
The remaining filter life is shown in
the display and will indicate when
either filter needs replacing.
Wi-Fi
The current status of connection
to the Wi-Fi network.
06.07.201811:40 - C93644_TP04_OPMAN_ANZ_X438-OPMAN-93644.indd_15_4c0s

16
Auto mode
When Auto mode is selected the
on-board sensors will intelligently
adjust the settings of the appliance
according to the quality of air.
The appliance will pause once the
sensors detect that the target air
quality level has been reached.
The sensors will continue to monitor
the air quality, switching the
appliance back on when air quality
levels have dropped.
06.07.201811:40 - C93644_TP04_OPMAN_ANZ_X438-OPMAN-93644.indd_15_4c0s

17
Airflow
Air will be purified continuously,
whether the air is set to flow from the
front or the back.
For purification and cool airflow,
select the airflow direction to
the front.
For purification without cool airflow
from the front, select the airflow
direction to the back.
Press the Airflow speed button
to increase and decrease the
airflow speed.
1-10
1-10
06.07.201811:40 - C93644_TP04_OPMAN_ANZ_X438-OPMAN-93644.indd_15_4c0s

18
Night mode
Night mode will dim the display
and the appliance will run more
quietly, making it ideal for use
while sleeping.
If Auto mode has been set,
Night mode will reduce airflow
speeds to range from 1 to 4.
You can manually change the
airflow from 1-10.
Press the Night mode button
multiple times to scroll through the
timer options.
1-4
1-10
Manual
AUTO mode
06.07.201811:40 - C93644_TP04_OPMAN_ANZ_X438-OPMAN-93644.indd_15_4c0s

19
Oscillation
Press the Oscillation button to scroll
through the options from 0° to 350°.
Customise your oscillation settings
in the Dyson Link app.
Small details may vary slightly from
those shown.
06.07.201811:40 - C93644_TP04_OPMAN_ANZ_X438-OPMAN-93644.indd_15_4c0s

20
Changing the glass HEPA filters
The shrouds will release
with the glass HEPA
filters attached.
Unplug the appliance from
the mains electricity supply.
Slide the buttons down on
both sides of the shrouds.
Important: Always unplug the
appliance before changing filters.
The remaining filter life is shown in
the display and will indicate when
the non-washable glass HEPA filter
needs replacing.
Dispose of used filter units in
accordance with local regulations.
Empty the glass HEPA filters
directly into the bin by pushing
in both the purple tabs on
the shrouds.
clik
x2
clik
x2
x2
x2
clik
x2
clik
x2
x2
x2
clik
x2
clik
x2
x2
x2
x2
x2
x2
x2
clik
clik
x2
x2
x2
x2
clik
clik
1 2 3
06.07.201811:40 - C93644_TP04_OPMAN_ANZ_X438-OPMAN-93644.indd_15_4c0s
