E-Pill 960622 User manual

e-pill®4 Alarm Vibrating Pill Box (960622)
This e-pill Medication Reminder can remind you to take your medications up to four (4) times per
day by a vibrating / beeping / vibrating + beeping alarm. Alarms repeat automatically every day,
no reset required. The four (4) alarms can be set independently of each other. The pill box has four
4) compartments (four doses per day). The easy to read display features a backlight.(
Never Forget to take your Medications Again!
SETTING your new e-pill 4 Alarm Vibrating Pill Box:
CLOCK – Set the Current Time
If the display is NOT on, please remove TWO (both)
insulator strips located under the pill tray. One insulator is
for the clock and the other insulator for the alarm.
• Slide the left side switch to T-SET.
• Press or hold the HOUR button to set the correct
HOUR. Please observe the PM indicator.
• Press or hold the MINUTE button to set the correct
MINUTES.
• If necessary press the 12H/24H button after setting
the time to switch between 12 hour (AM/PM)
format and 24 hour (military time) format.
• Slide the switch back to TIME.
ALARMS - Set Alarms (up to 4 daily alarms)
For each alarm slide the left switch to 1, 2, 3 or 4 (Alarm #).
• Slide the left switch to the alarm you want to set.
• Press or hold the HOUR button to set the correct HOUR. Please
observe the PM indicator.
• Press or hold the MINUTE button to set the correct MINUTES.
• Press ALARM ON/OFF button to turn alarm ON. A “pill” symbol
must appear with the alarm # (Note. You MUST turn on each
individual alarm by PRESSING the ALARM ON/OFF button).
• Slide the switch back to TIME. Repeat for each alarm you want to set.
MODE - Set type of Alarm (VIB / BEEP / VIB + BEEP)
Select how you want to be notified when the alarm goes off. The setting applies to all alarms.
• Slide the right switch and leave it in postition. Select VIB (Vibrating Alarm), BEEP
(Beeping Alarm) or VIB+BEEP (both).
MEDICATION TIME. How to use your new e-pill Medication Reminder:
ALARM - What to do when the ALARM goes OFF
Alarm will vibrate/sound (or both) for 30 seconds. The alarm will repeat twice - in four (4)
minutes and after 8 minutes. While the alarm is vibrating/beeping you will see a flashing “Pill
Symbol” and the (1, 2, 3 or 4) and the Scheduled Alarm Time will be shown on the display,
directing you to the pill box with the same # on the back of your e-pill device.
• TAKE your MEDICATIONS.
• Press ROUND BUTTON (ALARM ON/OFF) after you have taken your medications.
The alarm will go off again tomorrow at the same time (no reset required).
Please turn

If medication times are missed, you should follow the directions from your physcian or
pharmacist before taking any medication out of sequence.
PILLBOX – Daily Medication Tray
Your e-pill comes complete with a Medication Tray (“Pill Box”) containing four compartments.
Pill compartments are labeled 1thru 4on the back. The medication compartment snaps open and
will store your pills when locked.
BATTERY – How to Replace the Batteries
Your e-pill 4 Alarm Vibrating Pill uses four replaceable
batteries. One (1) AAA battery is used for the alarm
(sound and vibration). Three (3) Button Cell batteries are
used for the clock. Replace batteries when the display
fades (clock batteries) or when the alarm is getting weak
(alarm battery). Normal battery life is 12 months.
To open the battery compartment, slide the switch
labeled OPEN in the direction of the arrow, and
SLIGHTLY OPEN the top casing. Be careful, if you use
too much force to open you may risk breaking the hinges
on the back of the top casing. Then lift the back of the casing to separate it from the lower casing.
The batteries are now visible.
Remove the old batteries: Place a new fresh AAA (1) battery in the compartment as indicated by
the polarity symbols. Place three (3) fresh Button Cell with the positive side up in the battery
compartment. Compatible Button Cell batteries:
AG13 280-08 (Citizen)
GPA76 SR44SW (Maxell, SONY, Toshiba, Seiko, )
LR44 9 (Renata)
SR44 S200, A
303 (Duracell, Varta, Ray-O-Vac,
Panasonic)
GS14
S06 707
RESET – How to reset the “computer”
Take a paper clip (not a sharp instrument) and insert it in the small hole above the word RESET
(located on back of the e-pill 4 alarm vibrating pill box, above the word “Medication” between pill
box 2 and pill box 4 - NOT the hole for the sound maker on the right side).
• Press down until 12:00 is displayed. Set the Time and Alarm(s) again.
BACKLIGHT – Turning on the backlight
To turn on the backlight, simply press any button.
Disclaimer: This e-pill Medication Reminder is only a supplement to any memory system that you
currently use to remind yourself to take medications. The user maintains full responsibility
to administer medication at the appropriate times. e-pill, LLC assumes no responsibility for
any incidental or consequential damages, including but without limitation, damages or injuries
resulting from malfunction of the product. e-pill,LLC’s liability shall in no circumstances
exceed the amounts paid by the user for the timer.
e-pill®Medication Reminders
e-pill, LLC, 49 Walnut Street Bldg. 4, Wellesley, MA 02481, USA
Phone: 1-800-549-0095 (+1-781-239-2941 U.S & International)
www.epill.com
110126
