EasyStand Bantam PT50001-1 User manual

Please ensure the Assembly Manual stays with the unit at all times.
Assembly Manual
PT50001-1 Extra Small and PT50002-1 Small

Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Mobile Assembly ................................10
Note: The serial number is located on the leg bracket.
Table of Contents
Date Purchased:
Serial #:
Contact Altimate Medical for any information required prior to purchase. This owner’s manual along
with other information is freely available by request or by downloading from easystand.com.
IMPORTANT
EasyStand Warranty Registration
FREE GIFT Upon Completion
(warranty & oer valid in the United States only)
To register online go to easystand.com/warranty
or Scan the
QR Code
IMPORTANT! Please complete and return within 30 days. To receive the free gift,
please ll out all information. Thank You.

SYMBOL/LABEL LEGEND
CAUTION/WARNING/ATTENTION
PINCHPOINT
SERIAL NUMBER
SN
TEMPERATURE
DATE OF MANUFACTURE
SEE INSTRUCTIONS FOR USE
TYPE BF APPLIED PART
MANUFACTURER
HUMIDITY ATMOSPHERIC PRESSURE
MEDICAL DEVICE
CONFORMITÈ EUROPËENNE PRESCRIPTION ONLY
POTENTIALLY HOT SURFACE
Accessible surfaces which may
exceed 105˚F/41˚C and could be a
hazard to persons with skin damage
or not having sensation.
CERTIFICATION LABEL/UNIQUE DEVICE IDENTIFICATION LABEL
Serial Number
Item Number
Item Description
Unique Identier
Waste of electrical and electronic equipment must not be disposed as unsorted municipal waste. It must be
collected separately, and must be disposed as per local regulations. Contact your authorized representative
for information concerning the decommissioning of your equipment.

Assembly
1. Remove all parts from the box. Remove the two bolts
and two coved nuts from front frame.
2. Flip up the rear frame to allow easier access to the post.
Attach the front and rear frames to one another.
3. Place the two coved nuts into the bottom of the frame
and ush with the tube. You may have to tap them in with
a rubber hammer to make them ush.
Page 1

4. Place the two bolts into the top of the frame and screw
into the coved nut, making sure they are ush. Tighten
securely.
5A. Place the unit back in the normal position. If you
ordered the optional Manual Hydraulic Actuator with
Removable Handle, remove knob, bolt and spacer from
center of handle. Insert spacer as shown.
5B. Place bolt into the spacer as shown.
6. Place knob onto bolt and tighten securely.
Page 2
5A 5B

7. Remove pin from the pump, place pump handle onto
pump shaft as shown and place pin through holes.
8. Place top of handle on to the handle, insert 2 bolts and
tighten securely.
9A. If the Gas Spring Lockout was ordered, unlock the gas
spring by pulling the plunger.
9B. If the Gas Spring Lockout was not ordered, remove
the bolt from the lower part of the cylinder on the mast as
shown, discard bolt.
Page 3
9A 9B

9. Use the optional pump handle or step on the gas spring
assist pedal to raise the seat about 3/4 the way up as
shown. Line up the following arm with the back angle
tube.
10. Depress the spring button to allow the following arm
to slide into place. Match the following arm position color
with the corresponding seat depth color. Tighten the knob
securely (for information on seat adjustments
see the Instructions for Use Manual).
11. Loosen the ratchet handles on the foot plates and
swivel into place (for information on foot plate
adjustments see the Instructions for Use Manual).
Page 4

12A. Insert each knee bracket into the tubes onto the
unit, with the clamp down.
12B. Depress the spring button to allow the bracket to
slide into place, advance until the spring button locks into
place.
For the Swing-Away Knee Pads, insert bracket into place
and tighten knobs securely.
13. Insert each knee pad bracket into the slots on the knee
bracket. Tighten knobs securely.
14. Remove knob from the knee pad, leaving the plastic
and rubber washer in place on the knee pad, place the
knee pad and washers onto the knee pad bracket. Place
knob onto bolt as shown. Repeat steps for the opposite
side (for information on knee pad adjustments see the In-
structions for Use Manual).
Page 5
12A 12B

15. If you ordered the Supine option, remove the
controller from the packaging. Remove the two bolts on
the bottom of the controller, leaving nuts in place.
16. Place controller onto the bracket on the side of the
unit. The bracket will slide into the slot on the bottom of
the controller.
17. Making sure the nuts are in the back on the
controller, line up holes and insert both bolts. Tighten
securely.
Page 6
bracket

18. If you ordered the 11”x19” Black molded tray, place
tray on the oor upside down as shown. The longer tray
arm will go on the right side, the short arm on the left side.
19A. Remove the four nuts from the mounting bolts on the
arms and discard, do not remove the acorn nut and bolt.
19B. With the acorn nut facing up, place the longer arm on
the right side of the tray, line up the two mounting holes.
Insert bolt, and tighten snug.
Page 7
20A. Place the second bolt into the hole.
20B. Using an allen wrench tighten both bolts securely.
With the acorn nut facing up, place the shorter arm on the
left side of the tray and repeat steps 18-19.
20A 20B
19A 19B
Acorn Nut
Short Tray Arm
Long Tray Arm
Mounting
Holes

Page 8
21A. For the tray, remove the nut from the bolt on the tray
arm and discard the nut. Make sure all other
hardware stays on the bolt.
21B. Place the ratchet handle onto the bolt and tighten se-
curely. Repeat steps for the other side.
22. If you ordered the optional Shadow Tray, loosen the
ratchet handles on the side of the tray, ip the arms up
so they are lined up with the tray as shown and tighten
the ratchet handles. Insert the two tray arms into the tray
bracket on the bottom of the tray. One of the arms is lon-
ger than the other for easier installation (for information
on Shadow Tray adjustments see the Instructions for Use
Manual). The bolts on the arms are used as a stop for fu-
ture reference. Place the quick release pins into the holes
of the tray to secure into place.
23. For the Swing-Away Shadow Tray, the knobs are lo-
cated in the bag your manual came in, Place knobs onto
unit as shown, insert tray bracket and tighten securely.
Caution: After placing the tray into position, ensure the
ratchet handles on the side of the tray are tightened
securely.
24A
21A 21B

Page 9
24A. If not already on the unit, remove the knob from the
center post and place the back onto the unit as shown.
24B. Place the back in the desired position. Insert knob
and tighten securely.
25A. If the optional dual lift control was ordered, insert bolt
into push handle as shown and line up dual
controller. Screw the bolt into the dual controller,
tighten securely.
25B. If you ordered the optional headrest, insert the head
support onto the unit and tighten securely.
25A
25B
26A. If you ordered the optional Elbow Pad Cutout,
remove Chest Pad from tray. Disregard bolts, replace bolts
with bolts in the bag with the Elbow Pad Cutout.
Place Elbow Pad Cutout onto the tray. Line up Chest Pad
bracket with holes, insert bolts into Tray and Elbow Pad
Cutout. Tighten securely.
24A 24B

Assembly
Page 10
Mobile Option Assembly
Note: If this is an option added after the initial purchase,
you must remove the existing front assembly before
proceeding.
27. The Mobile option consists of two drive wheel
assemblies, a “T” style front weldment, barrel nuts and
bolts. You will need a 5mm allen wrench and a rubber
hammer for assembly.
28. Set the Bantam on its back and attach the “T”
weldment to the frame. Note that the front curves upward.
29. Line up holes and place the coved nuts on the
bottom of the frame. You may have to tap them with a
rubber hammer to make them ush. Tighten bolts securely.
Weldment
Curves
Upward

Page 11
30. Attach the interchangeable right and left drive wheel
assemblies to the front frame.
31. Line up the holes and tap in the coved nuts and
tighten bolts securely. Making sure the coved nuts are
ush with the base. Position the Bantam upright and
re-tighten the frame bolts.
Mobile Adjustment & Usage
32. To lock or unlock the drive wheels, turn the drive wheel
lock one quarter turn.
Use the push rim adjustment to position the push rims
forward or aft, for transferring or self-propulsion. Tighten to
lock in position.
Independent
Drive Wheel
Locks
Independent
Push Rim
Angle
Adjustments

SEE INSTRUCTIONS FOR USE
MANUFACTURER
PRESCRIPTION ONLY
Options & Parts Detail
Page 12

262 West 1st St.
Morton, MN 56270 USA
Toll Free: 800.342.8968 or 507.697.6393
Fax Free: 877.342.8968 or 507.697.6900
email: [email protected]
easystand.com
Standing technology should only be used under the guidance of a physician with recommendations for standing program protocol and any
medical precautions. Standing programs should be monitored by the attending therapist. AMI maintains a policy of continual product
improvement and reserves the right to change features, specications, and prices without prior notication. Check with AMI for latest info.
FORM MBANEX-SMALL 120723 REV A Copyright © 2023 Altimate Medical, Inc. All rights reserved. Printed in the U.S.A.
