EasyStand Bantam Y5500 Medium User manual

262 West 1st St.
Morton, MN 56270 USA
Toll Free: 800.342.8968 or 507.697.6393
Fax Free: 877.342.8968 or 507.697.6900
email: [email protected]
easystand.com
Please ensure the Assembly Manual stays with the unit at all times.
Standing technology should only be used under the guidance of a physician with recommendations for standing program protocol and any
medical precautions. Standing programs should be monitored by the attending therapist. AMI maintains a policy of continual product
improvement and reserves the right to change features, specifications, and prices without prior notification. Check with AMI for latest info.
FORM NEWMBANMAN 060421 REV A Copyright © 2021 Altimate Medical, Inc. All rights reserved. Printed in the U.S.A.
Assembly Manual
Assembly Manual

SYMBOL/LABEL LEGEND
!
!
CAUTION/WARNING/ATTENTION
PINCHPOINT
SERIAL NUMBER
SN
TEMPERATURE
DATE OF MANUFACTURE
Waste of electrical and electronic equipment must not be disposed as unsorted municipal waste. It must be
collected separately, and must be disposed as per local regulations. Contact your authorized representative
for information concerning the decommissioning of your equipment.
SEE INSTRUCTIONS FOR USE
TYPE BF APPLIED PART
MANUFACTURER
HUMIDITY ATMOSPHERIC PRESSURE
MEDICAL DEVICE
CONFORMITÈ EUROPËENNE PRESCRIPTION ONLY
POTENTIALLY HOT SURFACE
Accessible surfaces which may
exceed 105˚F/41˚C and could be a
hazard to persons with skin damage
or not having sensation.
CERTIFICATION LABEL/UNIQUE DEVICE IDENTIFICATION LABEL
Serial Number
Item Number
Item Description
Unique Identifier
Options & Parts Detail-Y5500 Medium Bantam
Page 16

Table of Contents
Assembly ................................... 1
Options & Parts Detail.........................15
Date Purchased Serial #
Contact Altimate Medical for any information required prior to purchase. This owner’s manual along with
other information is freely available by request or by downloading from easystand.com.
Options & Parts Detail-Y5500 Medium Bantam
Page 15

1. Remove all parts from each box and remove
all packaging.
Position the base of the unit as shown to install
the casters on to the caster brackets.
2. Remove the hardware on both casters and set
out as shown. This is how the hardware will be
assembled. The casters are supplied with a
locking compound pre-applied to the threaded
stem. Do not remove this material, it is important
to prevent the casters from loosening over time.
Make sure the caster is in the lock position as
shown.
3. Place metal washer onto the stud of the
caster.
Assembly
Page 1 Page 14
Caster Brackets
40A. For the Standard Actuator Handle, remove
bolts and nuts from the pump handle socket.
Place pump handle socket onto pump and align
holes. Place bolts through top of the pump
handle socket and place nuts on bottom. Tighten
securely.
40B. For the Adjustable/Removable Actuator
Handle, remove pull pin from the pump socket
41. Insert pump handle and secure pull pin into
place.
42. Remove bolts from pump handle top. Place
pump handle top on pump handle and align
holes. Tighten securely.
43. If the optional Elbow Pad Cutout was
ordered, remove the Chest Pad from tray.
Disregard bolts, replace bolts with bolts in the
bag with the Elbow Pad Cutout.
Place Elbow Pad Cutout onto the tray. Line up
Chest Pad bracket with holes, insert bolts into
Tray and Elbow Pad Cutout. Tighten securely.
40A 40B

4. Place the caster onto the caster bracket hole
as shown.
5A. Place the black cupped washer onto the
caster stud with the flat part on the caster
bracket.
5B. Place the second metal washer into the black
washer on the caster stud.
6. Making sure the caster is in the locked
position, place the lock nut onto the caster stud
and tighten securely using provided wrench.
5A 5B
Page 2
37. Remove knobs (bolts on standard knees)
from the knee pads, place the knee pads on the
bracket with the larger end of the pad to the
outside and the seamside down. Place into
desired position and tighten securely.
38A. If the Lateral Supports were ordered, loosen
knob on lateral bracket and place lateral pad
bracket onto bracket as shown. Tighten knob
securely.
38B. Loosen knob on the back and Insert lateral
assembly. Tighten knob securely.
Repeat steps for other side.
39. If the Hip Supports were ordered, loosen
knob on tube on the back rear of the seat. Insert
bracket into the tube and tighten securely.
Repeat steps for other side.
Page 13
38A 38B

7. Place black cap onto the unit to cover
hardware.
Repeat these steps for installation of the second
rear caster.
8. With assistance, place the base unit as shown,
if the back option was NOT ordered, skip to step
#21. Place the back as shown and place the
following arm as shown.
Place the controller and hand pendent on the
right hand side of the unit keeping the cables
clear of the following arm as shown below.
9A. Remove the screw from the following arm
and set the screw aside. You will need this later.
9B. On the following arm, turn the knob all the
way loose, flip the gray tab of the knob fully open
until it clicks open.
Following Arm
9A 9B
Page 3
34. There are 2 knobs in the parts bag.
Screw each knob slightly into the tray bracket on
the unit. Place tray onto unit. Tighten securely.
Caution: After placing the tray into position,
ensure the ratchet handles on the side of the
tray are tightened securely.
35A. If the High Mount Chest Vest Bracket was
ordered, loosen knob on the bracket and insert
head support.
35B. If the Head Support was ordered, loosen the
knob on the back and insert the Head Support,
tighten knob securely.
36A. Insert each knee bracket assembly into
the tube along the seat post. Depress the spring
button to allow the bracket to slide into place,
advance until the spring button locks into place.
Tighten knob securely. For Swing-Away knees,
place into the tube, and tighten knob securely.
36B. Insert knee pad bracket into knee assembly,
Depress the spring button to allow the bracket to
slide into place, advance until the spring button
locks into place. Tighten knob securely.
Repeat steps for the other knee pad assembly.
Page 12
35A 35B
36A 36B

10. With assistance, insert the following arm
onto the tube with the color strips on the unit
until the red color setting is reached on the
following arm indicator area knotch.
11. Install the screw that was removed onto the
following arm and tighten securely. Flip the gray
tab closed and tighten knob securely.
12. Remove a bolt, wagon wheel plastic washer,
metal washer and nut from the parts bag. These
will be used on the hip pivot.
Page 4
31. Lock the casters, loosen the knobs on the
tray receiver all the way, then flip open gray tabs
until it clicks. Insert the two tray arms into the
tray bracket on the bottom of the tray as shown.
32. If the swing away shadow tray was ordered,
using a wrench, remove the nut from the bolt on
the tray arm and discard the nut. Make sure all
other hardware stays on the bolt.
33A. Flip the tray arm as shown.
33B. Place the ratchet handle onto the bolt and
tighten securely.
Repeat steps for the other side.
Page 11
Following Arm Notch
Hip Pivot Bracket
33A 33B
Knobs

29A 29B
13. With assistance, position the back in the slot
on the seat as shown.
14. Line up the holes and place the wagon wheel
plastic washer between the hip pivot bracket and
the slot on the seat, insert bolt from the inside of
the unit.
Repeat these steps for the other side of the unit.
15. Place the metal washer and lock nut onto the
bolt.
Page 5
28. Place nuts onto bolts, remove nut caps.
Tighten nuts securely and replace caps.
29A. Run the cables inside the adjustment
wheel. Insert tie strap into hole
Note: Tie Strap will be in a bag on the controller.
29B. Do the same for the other side. Line cable
clip up with hole on unit. Insert tie strap and
tighten. Trim excessive strap and turn cut end
inward.
Do not twist cables when installing
controller.
For controller usage see pg. 23 in the
Instructions For Use manual.
30. If the optional Shadow Tray was ordered,
place the tray upside down as shown. Flip the
chrome arms as shown, remove 4 bolts from bot-
tom of the tray. Place arm brackets onto tray and
line up holes in arm bracket with holes on the
tray. Insert 4 bolts and tighten securely.
If the optional Swing-Away Tray was ordered skip
to step 32.
Page 10
Adjustment Wheel

27A 27B
16. Using an allen wrench and the wrench from
the toolkit, tighten the bolt and lock nut snug.
Do not overtighten.
Repeat steps for the other side of the unit.
17. If the Pow’r Up Lift option was ordered,
remove the protective packaging from the hand
pendent.
18. Remove the 2 nuts and 2 bolts from the hip
pivot bracket.
Page 6
25. While supporting the front wheel assembly,
using the 4 bolts and lock washers that were
removed from the front wheel assembly, insert
and start the 2 top bolts into the base and wheel
assembly, than insert and start the 2 lower bolts,
making sure to start all 4 bolts before tightening
securely.
26. Loosen ratchet handle and place both foot
plates on the unit, with the ratchet handle to the
outside of the unit.
27A. If the Supine option was ordered, place the
unit back onto its wheels. Locate the bolts with
the coved washers and nuts on the back left
handed side of the unit.
27B. Support the coved washer and remove only
the nuts. Place the controller bracket onto the
bolts.
If the Supine option was not ordered skip to step
#30.
Page 9

19. Place controler bracket onto the inside of the
hip pivot bracket as shown
20. Insert 2 bolts and 2 nuts and tighten
securely.
21A. Remove one of the covers for the hip pivot
from the parts bag. Remove the 3 flat head
scews from the inside of the cover. Place cover
on the hip pivot. Make sure the EasyStand label
is not upside down.
21B. Replace the 3 flat head scews tighten
securely.
Repeat steps for the other cover.
Page 7
22. Making sure casters are locked, with
assistance, position unit as shown. Remove
styrofoam from inside of the unit.
23. Remove all 4 bolts and lock washers from the
front wheel assembly.
24. With the openings on the bottom of the
frame facing down, place the wheel
assembly into the seat assembly.
Page 8
21A 21B

19. Place controler bracket onto the inside of the
hip pivot bracket as shown
20. Insert 2 bolts and 2 nuts and tighten
securely.
21A. Remove one of the covers for the hip pivot
from the parts bag. Remove the 3 flat head
scews from the inside of the cover. Place cover
on the hip pivot. Make sure the EasyStand label
is not upside down.
21B. Replace the 3 flat head scews tighten
securely.
Repeat steps for the other cover.
Page 7
22. Making sure casters are locked, with
assistance, position unit as shown. Remove
styrofoam from inside of the unit.
23. Remove all 4 bolts and lock washers from the
front wheel assembly.
24. With the openings on the bottom of the
frame facing down, place the wheel
assembly into the seat assembly.
Page 8
21A 21B

27A 27B
16. Using an allen wrench and the wrench from
the toolkit, tighten the bolt and lock nut snug.
Do not overtighten.
Repeat steps for the other side of the unit.
17. If the Pow’r Up Lift option was ordered,
remove the protective packaging from the hand
pendent.
18. Remove the 2 nuts and 2 bolts from the hip
pivot bracket.
Page 6
25. While supporting the front wheel assembly,
using the 4 bolts and lock washers that were
removed from the front wheel assembly, insert
and start the 2 top bolts into the base and wheel
assembly, than insert and start the 2 lower bolts,
making sure to start all 4 bolts before tightening
securely.
26. Loosen ratchet handle and place both foot
plates on the unit, with the ratchet handle to the
outside of the unit.
27A. If the Supine option was ordered, place the
unit back onto its wheels. Locate the bolts with
the coved washers and nuts on the back left
handed side of the unit.
27B. Support the coved washer and remove only
the nuts. Place the controller bracket onto the
bolts.
If the Supine option was not ordered skip to step
#30.
Page 9

29A 29B
13. With assistance, position the back in the slot
on the seat as shown.
14. Line up the holes and place the wagon wheel
plastic washer between the hip pivot bracket and
the slot on the seat, insert bolt from the inside of
the unit.
Repeat these steps for the other side of the unit.
15. Place the metal washer and lock nut onto the
bolt.
Page 5
28. Place nuts onto bolts, remove nut caps.
Tighten nuts securely and replace caps.
29A. Run the cables inside the adjustment
wheel. Insert tie strap into hole
Note: Tie Strap will be in a bag on the controller.
29B. Do the same for the other side. Line cable
clip up with hole on unit. Insert tie strap and
tighten. Trim excessive strap and turn cut end
inward.
Do not twist cables when installing
controller.
For controller usage see pg. 23 in the
Instructions For Use manual.
30. If the optional Shadow Tray was ordered,
place the tray upside down as shown. Flip the
chrome arms as shown, remove 4 bolts from bot-
tom of the tray. Place arm brackets onto tray and
line up holes in arm bracket with holes on the
tray. Insert 4 bolts and tighten securely.
If the optional Swing-Away Tray was ordered skip
to step 32.
Page 10
Adjustment Wheel

10. With assistance, insert the following arm
onto the tube with the color strips on the unit
until the red color setting is reached on the
following arm indicator area knotch.
11. Install the screw that was removed onto the
following arm and tighten securely. Flip the gray
tab closed and tighten knob securely.
12. Remove a bolt, wagon wheel plastic washer,
metal washer and nut from the parts bag. These
will be used on the hip pivot.
Page 4
31. Lock the casters, loosen the knobs on the
tray receiver all the way, then flip open gray tabs
until it clicks. Insert the two tray arms into the
tray bracket on the bottom of the tray as shown.
32. If the swing away shadow tray was ordered,
using a wrench, remove the nut from the bolt on
the tray arm and discard the nut. Make sure all
other hardware stays on the bolt.
33A. Flip the tray arm as shown.
33B. Place the ratchet handle onto the bolt and
tighten securely.
Repeat steps for the other side.
Page 11
Following Arm Notch
Hip Pivot Bracket
33A 33B
Knobs

7. Place black cap onto the unit to cover
hardware.
Repeat these steps for installation of the second
rear caster.
8. With assistance, place the base unit as shown,
if the back option was NOT ordered, skip to step
#21. Place the back as shown and place the
following arm as shown.
Place the controller and hand pendent on the
right hand side of the unit keeping the cables
clear of the following arm as shown below.
9A. Remove the screw from the following arm
and set the screw aside. You will need this later.
9B. On the following arm, turn the knob all the
way loose, flip the gray tab of the knob fully open
until it clicks open.
Following Arm
9A 9B
Page 3
34. There are 2 knobs in the parts bag.
Screw each knob slightly into the tray bracket on
the unit. Place tray onto unit. Tighten securely.
Caution: After placing the tray into position,
ensure the ratchet handles on the side of the
tray are tightened securely.
35A. If the High Mount Chest Vest Bracket was
ordered, loosen knob on the bracket and insert
head support.
35B. If the Head Support was ordered, loosen the
knob on the back and insert the Head Support,
tighten knob securely.
36A. Insert each knee bracket assembly into
the tube along the seat post. Depress the spring
button to allow the bracket to slide into place,
advance until the spring button locks into place.
Tighten knob securely. For Swing-Away knees,
place into the tube, and tighten knob securely.
36B. Insert knee pad bracket into knee assembly,
Depress the spring button to allow the bracket to
slide into place, advance until the spring button
locks into place. Tighten knob securely.
Repeat steps for the other knee pad assembly.
Page 12
35A 35B
36A 36B

4. Place the caster onto the caster bracket hole
as shown.
5A. Place the black cupped washer onto the
caster stud with the flat part on the caster
bracket.
5B. Place the second metal washer into the black
washer on the caster stud.
6. Making sure the caster is in the locked
position, place the lock nut onto the caster stud
and tighten securely using provided wrench.
5A 5B
Page 2
37. Remove knobs (bolts on standard knees)
from the knee pads, place the knee pads on the
bracket with the larger end of the pad to the
outside and the seamside down. Place into
desired position and tighten securely.
38A. If the Lateral Supports were ordered, loosen
knob on lateral bracket and place lateral pad
bracket onto bracket as shown. Tighten knob
securely.
38B. Loosen knob on the back and Insert lateral
assembly. Tighten knob securely.
Repeat steps for other side.
39. If the Hip Supports were ordered, loosen
knob on tube on the back rear of the seat. Insert
bracket into the tube and tighten securely.
Repeat steps for other side.
Page 13
38A 38B

1. Remove all parts from each box and remove
all packaging.
Position the base of the unit as shown to install
the casters on to the caster brackets.
2. Remove the hardware on both casters and set
out as shown. This is how the hardware will be
assembled. The casters are supplied with a
locking compound pre-applied to the threaded
stem. Do not remove this material, it is important
to prevent the casters from loosening over time.
Make sure the caster is in the lock position as
shown.
3. Place metal washer onto the stud of the
caster.
Assembly
Page 1 Page 14
Caster Brackets
40A. For the Standard Actuator Handle, remove
bolts and nuts from the pump handle socket.
Place pump handle socket onto pump and align
holes. Place bolts through top of the pump
handle socket and place nuts on bottom. Tighten
securely.
40B. For the Adjustable/Removable Actuator
Handle, remove pull pin from the pump socket
41. Insert pump handle and secure pull pin into
place.
42. Remove bolts from pump handle top. Place
pump handle top on pump handle and align
holes. Tighten securely.
43. If the optional Elbow Pad Cutout was
ordered, remove the Chest Pad from tray.
Disregard bolts, replace bolts with bolts in the
bag with the Elbow Pad Cutout.
Place Elbow Pad Cutout onto the tray. Line up
Chest Pad bracket with holes, insert bolts into
Tray and Elbow Pad Cutout. Tighten securely.
40A 40B

Table of Contents
Assembly ................................... 1
Options & Parts Detail.........................15
Date Purchased Serial #
Contact Altimate Medical for any information required prior to purchase. This owner’s manual along with
other information is freely available by request or by downloading from easystand.com.
Options & Parts Detail-Y5500 Medium Bantam
Page 15

SYMBOL/LABEL LEGEND
!
!
CAUTION/WARNING/ATTENTION
PINCHPOINT
SERIAL NUMBER
SN
TEMPERATURE
DATE OF MANUFACTURE
Waste of electrical and electronic equipment must not be disposed as unsorted municipal waste. It must be
collected separately, and must be disposed as per local regulations. Contact your authorized representative
for information concerning the decommissioning of your equipment.
SEE INSTRUCTIONS FOR USE
TYPE BF APPLIED PART
MANUFACTURER
HUMIDITY ATMOSPHERIC PRESSURE
MEDICAL DEVICE
CONFORMITÈ EUROPËENNE PRESCRIPTION ONLY
POTENTIALLY HOT SURFACE
Accessible surfaces which may
exceed 105˚F/41˚C and could be a
hazard to persons with skin damage
or not having sensation.
CERTIFICATION LABEL/UNIQUE DEVICE IDENTIFICATION LABEL
Serial Number
Item Number
Item Description
Unique Identifier
Options & Parts Detail-Y5500 Medium Bantam
Page 16

262 West 1st St.
Morton, MN 56270 USA
Toll Free: 800.342.8968 or 507.697.6393
Fax Free: 877.342.8968 or 507.697.6900
email: [email protected]
easystand.com
Please ensure the Assembly Manual stays with the unit at all times.
Standing technology should only be used under the guidance of a physician with recommendations for standing program protocol and any
medical precautions. Standing programs should be monitored by the attending therapist. AMI maintains a policy of continual product
improvement and reserves the right to change features, specifications, and prices without prior notification. Check with AMI for latest info.
FORM NEWMBANMAN 060421 REV A Copyright © 2021 Altimate Medical, Inc. All rights reserved. Printed in the U.S.A.
Assembly Manual
Assembly Manual
