EasyStand Evolv Adjustable Shadow Tray User manual

Evolv Adjustable Shadow Tray
Assembly
Customer Service
800.342.8968 507.697.6393
Required Tools:
-13mm open end wrench
-Hex Wrench
1. To install the support arm, rst remove the nut and the washer from
the pre-assembled bolt on the arm, leaving the bolt and the two halves
of the tting (one plastic and one metal) in place on the tube. Thread
the bolt into the hip plate. Once the bolt has been secured and the
support arm has the desired level of tension, install the nut and lock
washer on the bolt protruding through the opposite side of the hip
plate, closest to the user. Use either the small end of the wrench from
the supplied tool kit, or a 17mm socket wrench (preferred) to securely
tighten the nut.
A setscrew in the metal half of the support arm fitting may be used
to adjust the level of the tray once the installation is complete.
2. Place the tray bracket on the unit
as shown. Insert one bolt and hand
tighten.
3. Insert second bolt and tighten both
bolts securely.
4. Place the cloth protection sleeve on
the tray bracket as shown.
Set
Screw
5. Insert tray tube into the tray bracket. 6. Insert bolt into desired hole.
Note: You may need assistance lining
up the hole from a partner.
7. Place washer onto bolt.

8. Place nut onto bolt. 9. Using hex wrench and 13mm
wrench tighten securely.
10. Place black protective cap onto
nut.
9. Pull the cloth protection sleeve on
the tray tube as shown.
Tray top assembly instructions are
located in the owners manual.
