EasyStand Evolv Youth User manual

Owner’s Manual
™
™
Youth

800-342-8968 www.easystand.com
!!
-40º C
50º C
Store in less than 70% humidity
and temerapture - 40º C to 50º C
SYMBOL LEGEND
ATTENTION, consult
accompanying documents.
TYPE B APPLIED PART
PINCHPOINT FOOT TRAP
Serial Number
SN
ENVIRONMENTAL
CONDITIONS
DATE OF MANUFACTURE
Please be environmentally responsible and recycle this product through your
recycling facility at its end of life.
Afin de préserver l’environnement, veuillez confier ce produit à votre centre de recyclage à la fin de sa
durée de vie.
Nachdem dieses Produkt ausgedient hat, entsorgen Sie es bitte auf umweltfreundliche Weise, indem Sie
es zu der entsprechenden Recyclingstelle bringen.
Wees a.u.b. milieubewust en recycleer dit product via uw recycleerder na het verstrijken van de levensduur.
Sea responsable con respecto al medio ambiente y recicle este producto al finalizar su vida útil en el lugar de reciclaje
correspondiente.
Siate responsabili verso l’ambiente e riciclate questo prodotto, al termine della sua vita d’uso, presso la vostra sede di
riciclaggio.
Kierrätä tämä tuote sen käyttöiän lopussa ympäristövastuullisella tavalla paikallisella kierrätyslaitoksella.
Var miljömedveten och återvinn denna produkt efter dess användning.
Vi ber deg ta hensyn til miljøet og resyklere dette produktet ved hjelp av de rette resykleringsfasilitetene når produktet
ikke lenger kan brukes.
Vis venligst hensyn til miljøet ved at levere produktet til det nærmeste genbrugsanlæg, når det ikke længere fungerer.
Por favor, assuma responsabilidade ambiental, reciclando este produto em suas instalações de reciclagem no final de
sua vida útil.

Table of Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . 2
Basic Unit Assembly-Evolv Youth . . . . . . . . . . . . 3
Configuration Assembly
Glider . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Shadow Tray . . . . . . . . . . . . . . . . . . . . . . . . 9
Pow’r Up Lift Option . . . . . . . . . . . . . . . . . . . . . 11
Option Assembly . . . . . . . . . . . . . . . . . . . . . . . 15
Basic Unit Reference Drawing-Evolv . . . . . . . . . 24
Evolv Youth Options & Parts Detail . . . . . . . . . 25
Adjusting Your Evolv . . . . . . . . . . . . . . . . . . . . . 27
Perfect Fit Guide. . . . . . . . . . . . . . . . . . . . . 29
Glider Adjustments . . . . . . . . . . . . . . . . . . 30
Shadow Tray Adjustments . . . . . . . . . . . . . 31
Transferring & Standing ..................32
Maintenance ...........................33
Specifications ..........................34
Standing Log . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . 36
Videos on EasyStand Evolv assembly & fitting can be viewed at www.easystand.com/video

Congratulations on your purchase of the Easystand Evolv standing frame! We at Altimate
Medical have designed the EasyStand Evolv with your comfort and happiness in mind.
This manual is an integral part of your standing system and should be read completely
and thoroughly by anyone that will be operating the unit.
This will ensure that the EasyStand Evolv is assembled properly and used in the most
beneficial manner.
AMI recommends that an attendant be present when the EasyStand Evolv is being used.
Should any problem arise that you cannot solve by reading this manual, please contact your
local supplier or call Altimate Medical Inc. at 1-800-342-8968 or 507-697-6393.
It is important and necessary that you inspect your EasyStand Evolv periodically to assure
that it is in safe operating condition. Minor adjustments can be made by the operator.
However, replacement of worn parts, major adjustments, or any other important corrections
should be handled by an authorized supplier or service center. Only Altimate Medical, Inc.
approved replacement parts should be used to ensure safety and performance.
Do not use the EasyStand Evolv without consulting your physician.
Failure to consult a qualified physician prior to using the EasyStand Evolv could lead
to severe medical problems. We recommend that a good standing program be
established and supervised by a qualified physician or physical therapist.
Date Purchased Serial #
Introduction
page 1 p
Introduction

page 2
Safety Precautions
•The EasyStand Evolv (Youth) is designed to accommodate most individuals from 4’- 5'6" (122cm-168cm) and up
to 200 lbs (90kg). If you do not meet these specifications and have not been properly fit by a qualified therapist or
physician, Altimate Medical Inc. does not recommend that you use the EasyStand Evolv Youth.
•Altimate Medical Inc. recommends that you consult with your therapist or physician prior to starting a standing
program.
•Check your EasyStand periodically to make sure that all nuts, bolts and adjustable parts are tightened securely.
•Never reposition the foot holders while you are in the standing position. Consult with your therapist or physician
for proper foot placement and angle.
•If the unit was exposed to temperatures of less than 50˚F (23.5˚C), you must allow the unit to warm up to room
temperature before use.
•Use body weight to lower the seat. Do not use excessive force.
•The EasyStand is for indoor use only.
•Always use your EasyStand on a level surface.
•Violently thrusting in the EasyStand may cause it to tip.
•You should always put the rear casters and/or wheels in the locked position before transferring into the
EasyStand. Use these locks whenever you want to keep the EasyStand stationary.
• The EasyStand Evolv (Youth) meets EN12182:1999 (test standard) for strength, durability and tipping stability.
• Please contact Altimate Medical Inc. for relevant clinical data and literature, strength, durability and test results
as applicable.
•The EasyStand Evolv Electric Lift meets the requirements of IEC 60601-1 and 60601-2.*
•Electronic equipment can be affected by Radio Frequency Interference (RFI). CAUTION should be exercised
when using portable communication equipment around such equipment. If RFI causes erratic behavior, use the
mechanical release to lower the unit to the seated position immediately. *
•*Altimate Medical products are specifically designed to be used with Altimate Medical accessories and options.
Unless otherwise noted, accessories and options from other manufacturers have not been tested by Altimate
Medical and are not recommended for use with Altimate Medical products.
•* It is recommended that you remove the batteries if the equipment is not likely to be used for quite some time.
• It is recommended that the equipment be stored in air less than 70% humidity and temperatures -22 to 122 F
(-30 to +50 C).
*Evolv Pow’r Up Option Only
Safety Precautions

FIG.1
FIG. 3
FIG. 2
FIG.5
FIG. 3
Basic Unit Assembly-EasyStand®Evolv™
page 3 p
Basic Unit Assembly-Evolv
Videos on EasyStand Evolv
assembly & fitting can be viewed
at www.easystand.com/videos

page 4
Basic Unit Assembly-Evolv
FIG. 1
FIG. 2
FIG. 2
FIG. 3
Front Column
Main Frame
Note: Bolts are currently in proper location.
FIG. 1- Attach the axle weldment to the front column with bolts and
tighten securely.
FIG. 2- Attach the casters to the rear of the base, lock the casters
and hand tighten, do not overtighten.
Slide the front column into the opening of the main frame as shown.
Install the four bolts into the holes. Do not tighten securely until all
bolts are started.
Lift seat up and flip down footplates. Then insert quick adjust
handles into footplates. Tighten securely.
FIG. 3- Attach the pump handle to the pump on the main frame with
bolts and tighten securely. Insert top of handle into pump
handle and tighten securely. (If your unit has the Pow’r Up option
refer to page 11.)
FIG. 3

FIG. 5
FIG. 4
FIG. 6
page 5 p
Basic Unit Assembly-Evolv

page 6
Basic Unit Assembly-Evolv
FIG. 4
FIG. 6
FIG. 5
FIG. 4- Place kneepad onto knee bracket. Insert
bolts and tighten securely.
FIG. 5- Insert the tray post into the front column.
Holes in the post must face upward. Place tray
onto the tray post, insert nut into slot and tighten
securely.
FIG. 6- Install the seat onto the main frame. For
easier installation, pump the seat halfway up.
Tighten the bolts securely.
For Evolv adjustments,see page 27.

page 7 p
Configuration Assembly-Glider
Configuration Assembly-Evolv™Glider™
FIG. 8
FIG. 7

page 8
Configuration Assembly-Glider
FIG. 8
FIG. 7
FIG. 7- Slide the front Glider column into the opening of the main
frame as shown. Install the four bolts into the holes. Do not
tighten securely until all bolts are started.
FIG. 8- Slide the handles into the slots. Tighten securely.
For Glider adjustments, see page 30.

FIG. 9
FIG. 9
FIG. 10
FIG. 10
FIG. 11 FIG. 11
FIG. 12
FIG. 13
FIG. 15
FIG. 14
Configuration Assembly-
Evolv™Shadow Tray
page 9 p
Configuration Assembly-Shadow Support Tray

page 10
Configuration Assembly-Shadow Tray
FIG. 12
FIG. 13
FIG. 14
FIG. 9- Attach the axle weldment to the front column with bolts and tighten securely.
FIG. 10- Lock the casters and hand tighten to the rear base. Do not overtighten.
Slide the front column into the opening of the main frame as shown. Install the four bolts into the holes.
Do not tighten securely until all bolts are started.
Flip down footplates and insert quick adjust handles. Tighten securely.
FIG. 11- Install the left table arm rest. Tighten bolts securely.
FIG. 12- Install the right table arm rest. Tighten bolts securely
FIG. 13- Install the table top onto the right table arm rest. Tighten bolts securely.
FIG. 14- Place kneepad onto knee bracket. Insert screws and tighten securely.
FIG. 15- Remove the bolts from the pump handle and install it onto the pump on the main frame and tight-
en securely. Insert top of handle into pump handle and tighten securely.
For Shadow Tray adjustments, see page 31.
FIG. 15

page 11 p
Pow’r Up Lift Option
EasyStand®Evolv™Pow’r Up Lift Option
Raising/Lowering the Pow’r Up Lift Option
WARNING! THE EVOLVPOW’R UP OPTION IS NOTDESIGNED FOR CONTINUOUS USE.
Duty Cycle 10% Max, 1 min. / 19 min.
FIG. A Assemble the handle control onto the unit in reference to the drawing.
FIG. B Raising the Lift
Press the UP (arrow up) button on the hand control to lift the seat.
Lowering the Lift
Press the DOWN (arrow down) button on the hand control to lower the seat.
FIG. B
FIG. A
!!
Getting Started
The unit will arrive to you unplugged from the battery, you need to plug in the white cord that
supplies power to the pump and the black cord that supplies power to the remote. The black
cord has a notch on it to make it clip into place. Fully charge battery before use.

page 12
Pow’r Up Lift Option
Activating the Mechanical Emergency Release
CAUTION: USING THE EMERGENCY MECHANICAL RELEASE AS THE PRIMARY MEANS
TO RETURN TO THE SEATED POSITION CAN CAUSE DAMAGE TO YOUR UNIT. ONLY USE THE
MECHANICAL RELEASE IN EMERGENCY SITUATIONS.
All Altimate Medical electric lift products are equipped with a mechanical release to be used in
emergency situations.
FIG. C-The release allows the user to be lowered to a seated position in the unlikely occurance of
the battery losing charge while the user is in a standing position. The actuator only retracts if the
release is pulled and there is weight on the seat. The release is located on the left side of the seat
and is signified by a red tag with the word “EMERGENCY”.
1. To activate the emergency mechanical release pull out the quick release pin located on the left side
of the seat.
2. Squeeze the handle and if necessary, push down on the seat.
FIG. C
!!

Charging the Battery
FIG. D- The Easystand Evolv Pow'r up Lift uses two 12 volt sealed lead batteries rated at 2.9
amps each. An EasyStand Evolv Youth can be lifted approximately 100 times on one full
battery charge. An audible alarm will sound when the battery is low. A battery needing to be
fully recharged will take approximately 8 hours. The EasyStand Evolv Youth can be raised to
the standing position while being charged. The function of the charger is to detect a full
battery and then provide a constant potential power supply to hold the battery at a full
condition without overcharging it. When the battery EMF rises to a factory-preset point, the
charger circuit will not allow the peak output voltage to exceed that value. This factory setting
protects a battery from excessive depletion of electrolyte, which can occur from overcharging.
WARNING: USE ONLY CELL-CON MODEL # 452240-SC FOR CHARGING THE
EASYSTAND EVOLV POW’R UP OPTION.
1. Plug the receptacle into a wall outlet. The light on the charger will be green indicating an
open circuit.
2. Plug the charger cord into the side of the hand control. The light on the charger will turn
red indicating the batteries are being charged.
3. When the batteries are charged, the light on the charger will turn green.
page 13 p
Pow’r Up Lift Option
FIG. D
!!

page 14
Pow’r Up Lift Option
Battery Replacement
FIG. E-Once the batteries have reached the end of their useful life they are considered hazardous
waste. Please contact your local recycling authority for information on disposing of your batteries.
WARNING: ALTIMATE MEDICAL STRONGLY RECOMMENDS THAT BATTERY
REPLACEMENT BE PERFORMED BY A QUALIFIED TECHNICIAN. WARRANTY WILL BE
VOIDED IF IDENTICAL BATTERY IS NOT REPLACED.
1. If necessary, remove the charger from the hand pendant.
2. Take the cover off the control box to access the batteries and wiring.
3. Remove the plug connecting the batteries to the control box.
4. Remove the batteries.
5. Replace the batteries with the identical type.
6. Remount the wires to the batteries and insert the plug into the control box.
FIG. E
!!

page 15 p
Option Assembly
Option Assembly-Back Option Assembly
Back Option
Assembly

19” Contoured Back
PNG50068
Removable 19”
Contoured Back
PNG50174
19” Flat Back
PNG50067
Removable 19” Flat
Back
PNG50173
13” Contoured Back
PNG50062
Removable 13”
Contoured Back
PNG50172
page 16
Option Assembly
Back Options

Back Options
A
Removable
Actuator
Left Handle
PNG50127
A
B
C
D
E
F
B
Standard
Actuator
Left Handle
PNG50126
C
Standard
Actuator
Right Handle
PNG50059
page 17 p
Option Assembly
13” Flat Back
PNG50066
Removable 13”
Flat Back
PNG50171
Pump Handles
D
Removable
Actuator
Right Handle
PNG50035
E
T-Style
Handle
Extension
PNG50070
F
Quad Grip
Handle
Extension
PNG50044
