EasyThreed X7 Configuration guide

Please watch operation video in Website or YouTube Channel:Easythreed 3D
This manual is written in accordance
with EasyThreed X7 3D printer。
Printer upgrades and equipment models
are slightly different, is a normal phenomenon,
based on the actual products received.
User manual inside TF card.
EasyThreed X7 3D Printer Install instruction

List of install parts: All parts listed as shown in the figure
1, Assemble the X&Z set and the printer base as shown in the following figure. Note that
the print head is facing the front of the printer
2,Then fix the printer base and the X&Z set with M5 * 40 screw, and use M5 wrench.
3，Install filament holder , With M3 Screw 。

4，Printer Wire Connection, connect X.Z,E motor cable. There are signs on the
motor lines.Corresponding connection。
Connect Z Axis limit switch
Connect the Power Cable. And Power On.
Connect Z Axis
limit switch
X motor
E motor
Z motor
Cable
connector
