Eaton Bussmann Series User manual

Installation manual PUB10706
3A3771 Rev B Effective January 2019
Contents
Description Page
Kit contents ..............................1
Instructions for assembly ...................2
Kit contents
(3) 6-port lugs, (3) anti-rotation plates, (6) #6 plate screws,
(3) mounting screws, (1) terminal shroud, (2) #4 x 1/2” hi-lo
screws, (1) Warning / Torque Label, and (1) cover plate
Wire range 1/0-14 AWG (maximum 6) copper or aluminum
wires.
This kit is UL Listed (File E64983) for eld installation on the
loadside of the 400 A Frame Compact Circuit Protector (CCP)
or 400 A CUBEFuse holder.
Note:The purpose of these lugs is to distribute power to more
than one load and are to be installed only on the loadside.
6-port multi-wire lug kit for use on 400 A
Compact Circuit Protector and 400 A CUBEFuse
holders Catalog no. CCP2-MW6-6
Terminal
shroud
Hi-lo
screws
Cover plate
Lug
Mounting screw
Plate
screw
Anti-rotation plate
Figure 1
HAZARD OF ELECTRIC SHOCK, EXPLOSION OR
ARC FLASH
MAY RESULT IN DEATH OR SERIOUS INJURY
Working on or near energized circuits poses a
serious risk of electric shock. De-energize all
circuits before installing or servicing this equipment
and follow all prescribed safety procedures.
RIESGO DE DESCARGA ELÉCTRICA,
EXPLOSIÓN O ARCO ELÉCTRICO
PUEDE CAUSAR LESIONES GRAVES O
INCLUSO LA MUERTE
Trabajar en o cerca de circuitos energizados
representa un grave riesgo de descarga eléctrica.
Desconecte todos los circuitos antes de realizar
alguna instalación o de dar servicio a este equipo
y siga todos los procedimientos de seguridad
indicados.
RISQUE D’ÉLECTROCUTION, D’EXPLOSION OU
D’ARC ÉLECTRIQUE
RISQUE DE MORT OU DE BLESSURES GRAVES
Travailler sur des circuits sous tension ou `a
proximité pose un risque grave de choc électrique.
Mettez tous les circuits hors tension avant d’installer
ou d’effectuer l’entretien de cet équipement et
suivre toutes les procédures de sécurité prescrites.

CCP2-MW6-6
Installation manual PUB10706
3A3771 Rev B
Effective January 2019
Eaton and Bussmann are valuable trademarks
of Eaton in the U.S. and other countries. You
are not permitted to use the Eaton trademarks
without prior written consent of Eaton.
Eaton
1000 Eaton Boulevard
Cleveland, OH 44122
Eaton.com
Bussmann Division
114 Old State Road
Ellisville, MO 63021
United States
Eaton.com/bussmannseries
© 2019 Eaton
All Rights Reserved
Printed in USA
Publication No. PUB10706
3A3771
January 2019
Instructions for assembly
If CCP or CUBEFuse holder is already installed in equipment,
it must be removed from equipment for installing this kit.
This kit is intended for use only on the loadside. See Figure 1.
1. Remove and discard existing loadside wire lugs from
CCP or CUBEFuse holder, if applicable.
2. Assemble anti-rotation plate to lug and secure with
#6 plate screws. Torque to 0.6 N•m (5 lb-in).
NOTE: Use only mounting screws provided with kit. Do not
substitute, or electrical spacings may not be met.
3. Assemble lug on top of the terminal as shown and
tighten securely with mounting screw.Torque to 22.0
N•m (200 lb-in).
4. Use the cover plate (with wire seal use only).
The CCP or CUBEFuse holder may be installed into
equipment at this time. After installation, mount terminal
shroud with hi-lo screws (see Figure 1).
FIELD WIRINGS:
Note: It may not be possible to install the largest conductors
in adjacent lug ports due to the wire insulation thickness.
Use only connections that allow inserting wires without
undue insulation interference between wires at the lug.
When fully inserted into the lug, the insulation should be
within 1/8 inch of the lug. Strip wires to lengths shown
below.
Wire size range — AWG (mm2)Torque — N•m (lb-in)
10-14 (6-2.5) 3.9 (35)
8 (10) 4.5 (40)
4-6 (25-16) 5.0 (45)
1/0-2 (50-35) 5.6 (50)
Lug port Wire strip length — in
Upper 3/4 to 7/8
Middle 1-3/8 to 1-1/2
Lower 2 to 2-1/8
These instructions are published solely for information
purposes and should not be considered all-inclusive.
If further information is required, consult Application
Engineering at 855-287-7626 Monday-Friday from 7:00 a.m.
— 5:00 p.m. Central time or email FuseTec[email protected].
Sale of the product shown in this document is subject to
terms and conditions outlined in appropriate Bussmann
Division selling policies or other contractual agreements
between the parties.This document is not intended to and
does not enlarge or add to any such contract.The sole source
governing the rights and remedies of any purchaser of this
equipment is the contract between the purchaser and the
Bussmann Division.
NO WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING
WARRANTIES OF FITNESS FOR A PARTICULAR PURPOSE
OR MERCHANTABILITY, OR WARRANTIES ARISING FROM
COURSE OF DEALING OR USAGE OF TRADE, ARE MADE
REGARDING THE INFORMATION, RECOMMENDATIONS AND
DESCRIPTIONS CONTAINED HEREIN.
In no event will the Bussmann Division be responsible to the
purchaser or user in contract, in tort (including negligence),
strict liability or otherwise for any special, indirect, incidental
or consequential damage or loss whatsoever, including
but not limited to damage or loss of equipment use, plant
or power system, cost of capital, loss of power, additional
expenses in the use of existing power facilities or claims
against the purchaser or user by its customers resulting
from the use of the information, recommendations and
description contained herein.
WARNING:
CONDUCTORS SIZED FOR LOAD CURRENTS LOWER
THANTHE FUSE RATING WILL NOT BE PROTECTED BY
THE FUSE.
EACH LOAD CONDUCTOR MUST BE PROTECTED BY
AN INDIVIDUAL OVERCURRENT PROTECTIVE DEVICE
AND MEET ANY ADDITIONAL REQUIREMENTS OFTHE
NATIONAL ELECTRICAL CODE.
Quantity
BUSSMANN SERIES CCP
051712705097
CCP2-MW6-6 400 A Frame and 400 A CUBEFuse holder
MULTI WIRE LUGS
FOR BUSSMANN SERIES 400 A CCP AND
400 A CUBEFUSE HOLDER
Made in
USA
