Eco-Systems RIO 10X10 User manual

SETUPS
RIO 10X10

GENERAL

STEP 01
PART: QTY: DESCRIPTION:
POST 1 1 RR125_8 Post Drilled for Internal Connector and Pre-Installed Door Hardware
POST 2 1 RR125_8 Post Drilled for Internal Connector and Pre-Installed Door Hardware
BEAM 2 3 Z45 Beam Formed w/ Locks
BEAM 3 2 Z45 Beam Formed w/ Locks
BEAM 4 1 Z45 w/ Door Stops
INFILL 1 1 56.5625” x 45” Laminated Reco
INFILL 3 1 Reco Inll
STEPS:
1- Attach BEAM 2 to Both POST 1 and POST 2
2- Attach BEAM 3
3- Insert INFILL 3 and Attached BEAM 2
NOTE: Door Hinge Channel Should be Above BEAM 3
STEPS:
1- Slide INFILL 1 in place and Secure BEAM 2
2- Place and Secure BEAM4 and BEAM 3
POST 1
POST 2
BEAM 2
BEAM 2
BEAM 2
INFILL 3
BEAM 3
BEAM 3
BEAM 4
INFILL 1
PART 1 PART 2

STEP 02
PART: QTY: DESCRIPTION:
COUNTER 1 Custom Bamboo Top
DOOR 2 Pre Assembled Doors w/ White Inll
STEPS:
1- Attach BEAM 2 to Both POST 1 and POST 2
2- Attach BEAM 3
3- Insert INFILL 3 and Attached BEAM 2
NOTE: Door Hinge Channel Should be Above BEAM 3
COUNTER
DOOR

STEP 03
PART: QTY: DESCRIPTION:
POST 6 1 RR91 @ 88” w. Base Plate
BEAM 7 2 Z45 FORMED BEAM w/ LOCKS
STEPS:
1- Attach BEAM 7 and POST 6
BEAM 7
BEAM 7
POST 6

PHOTOS
