EGO CH3200 User manual

WARNING: To reduce the risk of injury, the user must read and understand the
Operator’s Manual before using this product. Save these instructions for future reference.
OPERATOR’S MANUAL
56-VOLT
CHARGER
MODEL NUMBER CH3200/CH3200-FC
Español p. 41
Français p. 21

56V CHARGER — CH3200/CH3200-FC2
TABLE OF CONTENTS
FCC Statement.......................................... 3
Safety Symbols ......................................... 4
Safety Instructions......................................5-9
Introduction ........................................... 10
Specications ......................................... 10
Description .........................................11-12
Operation...........................................13-16
Maintenance .......................................... 17
Troubleshooting ........................................ 18
Warranty ...........................................19-20

56V CHARGER — CH3200/CH3200-FC 3
READ ALL INSTRUCTIONS!
READ & UNDERSTAND
OPERATOR’S MANUAL
This battery charger has many features for making its use more pleasant and
enjoyable. Safety, performance, and dependability have been given top priority in the
design of this product making it easy to maintain and operate.
FCC STATEMENT
1. This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
1) This device may not cause harmful interference.
2) This device must accept any interference received, including interference that
may cause undesired operation.
2. Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
NOTICE: This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one
or more of the following measures: Reorient or relocate the receiving antenna. Increase
the separation between the equipment and receiver. Connect the equipment into an
outlet on a circuit different from that to which the receiver is connected. Consult the
dealer or an experienced radio/TV technician for help.

56V CHARGER — CH3200/CH3200-FC4
SAFETY SYMBOLS
The purpose of safety symbols is to attract your attention to possible dangers. The
safety symbols and the explanations with them deserve your careful attention and
understanding. The symbol warnings do not, by themselves, eliminate any danger. The
instructions and warnings they give are no substitutes for proper accident prevention
measures.
WARNING: Be sure to read and understand all safety instructions in this
Operator’s Manual, including all safety alert symbols such as “DANGER,” “WARNING,”
and “CAUTION” before using this tool. Failure to following all instructions listed below
may result in electric shock, fire, and/or serious personal injury.
WARNING: The operation of any power tools can result in
foreign objects being thrown into your eyes, which can result in
severe eye damage. Before beginning power tool operation, always
wear safety goggles or safety glasses with side shields and a full
face shield when needed. We recommend a Wide Vision Safety Mask
for use over eyeglasses or standard safety glasses with side shields. Always use eye
protection which is marked to comply with ANSI Z87.1.

56V CHARGER — CH3200/CH3200-FC 5
SAFETY INSTRUCTIONS
This page depicts and describes safety symbols that may appear on this product. Read,
understand, and follow all instructions on the machine before attempting to assemble
and operate.
Safety Alert Indicates a potential personal injury
hazard.
Read &
Understand
Operator’s
Manual
To reduce the risk of injury, user must read
and understand the operator’s manual
before using this product. Failure to do so
can result in serious injury to the operator
and/or bystander.
Eye Protection
Always wear safety goggles or safety
glasses with side shields when operating
this product that comply with ANSI Z87.1
Wet Conditions
Alert
Do not expose to rain or use in damp
locations.
Class II
Construction Double-insulated construction
V Volt Voltage
A Amperes Current
min Minutes Time

56V CHARGER — CH3200/CH3200-FC6
Alternating
Current (AC) Type of current
Direct Current
(DC) Type or a characteristic of current
n0No-Load Speed Rotational speed, at no load
Hz Hertz Frequency (cycles per second)
WWatt Power
lb Pound Weight
kg Kilogram Weight
°F Degrees
Fahrenheit Temperature
°C Degrees Celsius Temperature

56V CHARGER — CH3200/CH3200-FC 7
WARNING: Read and understand all instructions. Failure to follow all
instructions listed below may result in electric shock, re and/or serious
personal injury.
The term “power tool” in all of warnings listed below refers to corded power tools or
battery operated (cordless) power tools.
WARNING: To ensure safety and reliability, all repairs should be performed by a
qualified service technician.
WORK AREA SAFETY
◾Keep the work area clean and well lit. Cluttered or dark areas invite accidents.
◾Do not operate power tools in explosive environments, such as in the
presence of ammable liquids, gases, or dust. Power tools create sparks,
which may ignite the dust or fumes.
ELECTRICAL SAFETY
◾Avoid body contact with grounded surfaces, such as pipes, radiators, ranges,
and refrigerators. There is an increased risk of electric shock if your body is
grounded.
◾Power tool plugs must match the outlet. Never modify the plug in any way.
Do not use any adapter plugs with grounded power tools. Unmodified plugs and
matching outlets will reduce the risk of electric shock.
◾Do not expose power tools to rain or wet conditions. Water entering a power
tool will increase the risk of electric shock.
◾Do not abuse the cord. Never use the cord for carrying, pulling, or unplugging
the power tool. Keep the cord away from heat, oil, sharp edges, or moving parts.
Damaged or entangled cords increase the risk of electric shock.
◾When operating a power tool outdoors, use an extension cord suitable for
outdoor use. Use of a cord suitable for outdoor use reduces the risk of electric
shock.

56V CHARGER — CH3200/CH3200-FC8
◾Use charge the EGO lithium-ion battery packs list below:
CHARGER BATTERY PACKS
CH3200/CH3200-FC BA1400/BA1400-FC: 56V 2.5Ah Lithium-ion
BA2800/BA2800-FC: 56V 5.0Ah Lithium-ion
BA4200/BA4200-FC: 56V 7.5Ah Lithium-ion
BA1400T/BA1400T-FC: 56V 2.5Ah Lithium-ion
BA2240T/BA2240T-FC: 56V 4Ah Lithium-ion
BA2242T/BA2242T-FC: 56V 4Ah Lithium-ion
BA2800T/BA2800T-FC: 56V 5Ah Lithium-ion
BA4200T/BA4200T-FC: 56V 7.5Ah Lithium-ion
BA5600T/BA5600T-FC: 56V 10Ah Lithium-ion
BA6720T/BA6720T-FC: 56V 12Ah Lithium-ion
SERVICE
◾Have your charger serviced by a qualied repair person using only identical
replacement parts. This will ensure that the safety of the charger is maintained.
◾When servicing a charger, use only identical replacement parts. Follow
instructions in the Maintenance section of this manual. Use of unauthorized
parts or failure to follow Maintenance instructions may create a risk of shock or
injury.
SAFETY RULES FOR CHARGER
CAUTION:To reduce risk of injury, charge only Li-Ion type rechargeable
batteries. Other types of batteries may burst, causing personal injury or damage.
◾This manual contains important safety and operating instructions for 56V
Charger CH3200/CH3200-FC.
◾Before using the battery charger, read all instructions and cautionary markings
on (1) battery charger, (2) battery pack, and (3) product using battery.
◾Do not use the charger outdoors or expose it to wet or damp conditions.
Water entering the charger will increase the risk of electric shock.
◾Do not handle charger, including the charger plug and charger terminals
with wet hands.
◾Use of an attachment not recommended or sold by the battery-charger
manufacturer may result in a risk of re, electric shock, or injury to persons.

56V CHARGER — CH3200/CH3200-FC 9
◾Recharge only with the charger specied by the manufacturer. A charger that
is suitable for one type of battery pack may create a risk of fire when used with
another battery pack.
◾Do not abuse the cord or charger. Never use the cord to carry the charger. Do
not pull the charger cord to disconnect the plug from a receptacle. Damage to
the cord or charger could occur and create an electric shock hazard. Replace
damaged cords immediately.
◾Make sure that the cord is located so that it will not be stepped on, tripped
over, come in contact with sharp edges or moving parts, or otherwise be
subjected to damage or stress. This will reduce the risk of accidental falls,
which could cause injury and damage to the cord, which could then result in
electric shock.
◾Keep the cord and charger from heat to prevent damage to housing or
internal parts.
◾Do not allow gasoline, oils, petroleum-based products, etc. to come in
contact with plastic parts. These materials contain chemicals that can damage,
weaken, or destroy plastic.
◾Do not operate the charger with a damaged cord or plug, which could cause
shorting and electric shock. If damaged, have the charger repaired or replaced
by an authorized service technician at an EGO Service Center.
◾Do not operate the charger if it has received a sharp blow, been dropped,
or has otherwise been damaged in any way. Take it to an authorized service
technician for an electrical check to determine if the charger is in good working
order.
◾Do not disassemble the charger. Take it to an authorized service technician
when service or repair is required. Incorrect reassembly may result in a risk of
electric shock or fire.
◾Unplug the charger from the electrical outlet before attempting any
maintenance or cleaning to reduce the risk of electric shock.
◾Disconnect charger from the power supply when not in use. This will reduce
the risk of electric shock or damage to the charger if metal items should fall into
the opening. It will also help prevent damage to the charger during a power surge.
◾Risk of electric shock. Do not touch the uninsulated portion of output connector
or uninsulated battery terminal.
◾To reduce the risk of injury, close supervision is necessary when an
appliance is used near children.

56V CHARGER — CH3200/CH3200-FC10
◾Only use attachments recommended or sold by manufacturer.
◾To reduce the risk of electrical shock, do not put charger in water or other
liquid. Do not place or store appliance where it can fall or be pulled into a
tub or sink.
◾Save these instructions. Refer to them frequently and use them to instruct
others who may use this tool. If you lend this tool to someone else, also lend
these instructions to them to prevent misuse of the product and possible injury.
SAVE THESE INSTRUCTIONS!

56V CHARGER — CH3200/CH3200-FC 11
INTRODUCTION
Congratulations on your selection of the 56V charger. It has been designed, engineered
and manufactured to give you the best possible dependability and performance.
Should you experience any problem you cannot easily remedy, please contact EGO
customer service center 1-855-EGO-5656.
This manual contains important information on to the safe assembly, operation and
maintainance of your 56V charger. Read it carefully before using the charger. Keep this
manual handy so you can refer to it at any time.
SERIAL NUMBER _____________________ DATE OF PURCHASE _________________
YOU SHOULD RECORD BOTH SERIAL NUMBER AND DATE OF PURCHASE AND KEEP IN A SAFE
PLACE FOR FUTURE REFERENCE.
SPECIFICATIONS
Charger Input 120V~60Hz, 320W
Charger Output 56V
Charger Weight 2.47 lb. (1.12 kg)
PACKING LIST
PART NAME QUANTITY
Charger 1
Operator’s Manual 1

56V CHARGER — CH3200/CH3200-FC12
DESCRIPTION
KNOW YOUR CHARGER (Fig. 1)
The safe use of this product requires an understanding of the information on the
product and in this operator’s manual, as well as knowledge of the project you are
attempting. Before use of this product, familiarize yourself with all its operating features
and safety rules.
1
Electrical Contacts
Mounting Slot
Wall Mounting Holes
Power Cord
Ventilation
LED Indicators 1
LED Indicators 2

56V CHARGER — CH3200/CH3200-FC 13
LED INDICATOR 1/2: Indicates the charging status.
MOUNTING SLOT: Guides the battery pack when it is installed on the charger.
WALL MOUNTING HOLE: For convenient storage on the wall.

56V CHARGER — CH3200/CH3200-FC14
OPERATION
HOW TO CHARGE THE BATTERY PACK
WARNING:
Do not use the charger outdoors or expose it to wet or damp
conditions. Water entering the charger will increase the risk of electric shock.
NOTICE: Lithium-Ion battery packs are shipped partially charged. Before using it the
first time, fully charge the battery pack.
1. Connect the charger to the power supply
(120V~, 60Hz). The LED Indicator 1 will
briefly shine green and the LED Indicator
2 will briefly shine red at the same time,
indicating that the charger is working
correctly.
2. Align the raised ribs of the battery pack
with the mounting slots in the charger
and slide the battery pack down onto the
charger (Fig. 2).
3. The charger will communicate with the battery pack to evaluate the condition of
the battery pack.
4. When the battery pack is charging, the LED Indicator 1 on the charger will flash
green. For BA1400, BA1400-FC, BA2800, BA2800-FC, BA4200 and BA4200-FC
battery packs: the power indicator on the battery will flash in sequence: red,
orange and green. For BA1400T, BA1400T-FC, BA2240T, BA2240T-FC, BA2242T,
BA2242T-FC, BA2800T, BA2800T-FC, BA4200T, BA4200T-FC, BA5600T, BA5600T-
FC, BA6720T and BA6720T-FC battery packs, the last LED indicator on the battery
will keep flashing green while the former LEDs shine solid green.
5. When the battery pack is 80% charged, the LED Indicator 1 will stop flashing and
will shine green continuously. The LED Indicator 2 start flashing green.
2
LED Indicator 1
LED Indicator 1

56V CHARGER — CH3200/CH3200-FC 15
6. When the battery pack is fully charged. Two LED Indicators will shine green
continuously. The power indicator on the battery pack will go out. Wait until the
cooling fan stops, remove the battery pack from the charger and disconnect the
charger from the power supply.
NOTICE:
◾A significantly reduced run time after fully charging the battery pack indicates
that the batteries are near the end of their usable life and must be replaced.
◾The charger may become warm during charging. This is part of the normal
operation of the charger. Charge in a well-ventilated area.
LED FUNCTIONS OF CHARGER
STATUS
LEDs ON THE CHARGER POWER INDICA-
TOR ON THE
BATTERY PACK
BATTERY
PACK
POWER
DESCRIPTION
LED 1 LED 2
Defective OFF Flashing
Red or OFF OFF - Battery pack or charger is defective.
Cold/Hot
Battery OFF Solid Red OFF - Battery pack is too hot or too cold.
Charging Flashing
Green OFF Flashing RED,
ORANGE and
GREEN alternately/
Last LED flashing
GREEN, the former
LEDs shining solid
GREEN.
<80%
Charging
80%
Charged Solid Green Flashing
Green
80% to
100%
Full
Charged Solid Green Solid Green OFF 100% Charging is complete. Maintenance
charging.

56V CHARGER — CH3200/CH3200-FC16
CHARGING A HOT OR COLD BATTERY PACK
If the battery pack is outside the normal temperature range, the LED Indicator 2 will
shine red continuously. Allow the battery pack to cool down or warm up. If charging
does not restart when the battery pack returns to the normal temperature, reinsert the
battery pack.
DEFECTIVE BATTERY PACK OR CHARGER
If the charger detects a problem, the LED Indicator 2 will flash red.
1. Try to remove and reinsert the battery pack in the charger. If the LED Indicator 2
still flashes red the second time, try charging a different battery pack.
2. If a different battery pack charges normally, dispose of the faulty battery pack
(refer to the instructions in the battery pack manual).
3. If a different battery pack also indicates an error, unplug the charger and wait
until the LED Indicator 2 goes out. Then reconnect the plug to the power supply.
4. If none of the above solves the problem, call EGO Customer Service.
WALL-MOUNT HOLES
The charger has hanging holes for convenient storage (Fig.1). Install screws in the wall
4 inches (101.6 mm) apart. Use screws sufficiently strong to support the combined
weight of the charger and battery pack.
To prevent the battery pack from falling out, hang the charger only in the vertical
orientation.

56V CHARGER — CH3200/CH3200-FC 17
MAINTENANCE
WARNING: To avoid serious personal injury, always remove the battery pack
from the tool when cleaning or performing any maintenance.
WARNING: When servicing, use only identical EGO replacement parts. Use of
any other parts may create a hazard or cause product damage. To ensure safety and
reliability, all repairs should be performed by a qualified service technician at an EGO
Service Center.
WARNING: It is not recommended to use compressed dry air as cleaning
method of the charger. If cleaning with compressed air is the only method to apply,
always wear safety goggles or safety glasses with side shields. If the operation is dusty,
also wear a dust mask.
GENERAL MAINTENANCE
Avoid using solvents when cleaning plastic parts. Most plastics are susceptible to
damage from various types of commercial solvents and may be damaged by their use.
Use a clean piece of cloth to remove dirt, dust, oil, grease, etc.
WARNING: Do not at any time let brake fluids, gasoline, petroleum-based
products, penetrating oils, etc. to come in contact with plastic parts. Chemicals can
damage, weaken or destroy plastic which may result in serious personal injury.

56V CHARGER — CH3200/CH3200-FC18
TROUBLESHOOTING
PROBLEM CAUSE SOLUTION
Charger doesn’t work. The
LED Indicator 2 flashes
red.
Battery pack or charger
fault or bad connection
between the battery pack
and charger.
1. Try to remove and
reinsert the battery pack
in the charger.
2. Try charging a different
battery pack.
3. Unplug the charger and
wait until LED Indicator
2 goes out, then
reconnect the plug to
the power supply.
4. If none of the above
solves the problem, call
EGO Customer Service.
Charger does not work
and the LED Indicator 2
shines solid red.
Battery pack is too hot or
too cold.
Allow the battery pack to
cool down or warm up. If
charging does not restart
when the battery pack
returns to the normal
temperature, reinsert the
battery pack.

56V CHARGER — CH3200/CH3200-FC 19
WARRANTY
EGO WARRANTY POLICY
5-year limited warranty on EGO POWER+ outdoor power equipment and portable power
for personal, household use.
3-year limited warranty on EGO POWER+ System battery packs and chargers for
personal, household use. An additional 2-year extended warranty applies for the
10.0Ah/12.0Ah battery whether sold separately (Model# BA5600T/BA6720T) or
included with any tool, if it is registered within 90 days of purchase. 5-year limited
warranty on CHV1600 charger, designed for use with Zero Turn Riding Mower for
personal, household use.
2 year/1year limited warranty on EGO outdoor power equipment, portable power,
battery packs, and chargers for professional and commercial use.
The detailed warranty periods by products can be found online at
http://egopowerplus.com/pages/warranty-policy.
Please contact EGO Customer Service Toll-Free at 1-855-EGO-5656 any time you
have questions or warranty claims.
LIMITED SERVICE WARRANTY
EGO products are warranted against defects in material or workmanship from the date
of original retail purchase for the applicable warranty period. Defective product will
receive free repair.
a) This warranty applies only to the original purchaser from an authorized EGO
retailer and may not be transferred. Authorized EGO retailers are identified online
at http://egopowerplus.com/pages/warranty-policy.
b) The warranty period for reconditioned or factory certified products used for
residential purpose is 1 year, for industrial, professional or commercial purpose is
90 days.
c) The warranty period for routine maintenance parts, such as, but not limited
to, blades, trimmer heads, chain bars, saw chains, belts, scraper bars, blower
nozzles, and all other EGO accessories is 90 days for residential purpose, 30 days
for industrial, professional or commercial purpose. These parts are covered for
90/30 days from manufacture defects in normal working conditions.

56V CHARGER — CH3200/CH3200-FC20
d) This warranty is void if the product has been used for rental purpose.
e) This warranty does not cover the damage resulting from modification, alteration
or unauthorized repair.
f) This warranty only covers defects arising under normal usage and does not cover
any malfunction, failure or defect resulting from misuse, abuse (including overloading
of the product beyond capacity and immersion in water or other liquid), accidents,
neglect or lack of proper installation, and improper maintenance or storage.
g) This warranty does not cover normal deterioration of the exterior finish, including
but not limited to scratches, dents, paint chips, or to any corrosion or discoloring
by heat, abrasive and chemical cleaners.
HOW TO OBTAIN SERVICE
For warranty service, please contact EGO customer service toll-free at
1-855-EGO-5656. When requesting warranty service, you must present the original dated
sales receipt. An authorized service center will be selected to repair the product according
to the stated warranty terms. When bringing your product to the authorized service center,
there may be a small deposit that will be required when dropping off your tool. This
deposit is refundable when the repair service is deemed to be covered under warranty.
ADDITIONAL LIMITATIONS
To the extent permitted by applicable law, all implied warranties, including warranties
of MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE, are disclaimed. Any
implied warranties, including warranties of merchantability or fitness for a particular
purpose, that cannot be disclaimed under state law are limited to the applicable
warranty period defined at the beginning of this article.
Chervon North America is not responsible for direct, indirect, incidental or consequential
damages.
Some states do not allow limitations on how long an implied warranty lasts and/or do
not allow the exclusion or limitation of incidental or consequential damages, so the
above limitations may not apply to you.
This warranty gives you specific legal rights, and you may also have other rights which
vary from state to state.
For customer service contact us toll-free at: 1-855-EGO-5656 or EGOPOWERPLUS.COM.
EGO Customer Service, 769 SEWARD AVE NW / Suite 102 Grand Rapids, MI 49504
