ELCOM Euro-500 Handy Series User manual

Euro-500 Handy
Euro-500TX Handy
Service manual
version 1.1
© Elcom, s. r. o.

This manual, so as any of its parts, must not be copied,
reproduced, or otherwise forwarded without the editor‘s
consent.
Elcom, s. r. o., all rights reserved

Euro-500TX Handy © Elcom, s. r. o.
Service manual
Contents
1 Introduction..................................................................................................................9
1.1 Euro-500TX Handy technical parameters ............................................................9
1.2 System conguration ............................................................................................9
1.3 Block chart of ECR Euro-500TX...........................................................................9
2 Circuit schemes and functions ................................................................................10
2.1 Power supply circuits..........................................................................................10
2.1.1 External power supply.........................................................................................................10
2.1.2 Primary power supply..........................................................................................................10
2.1.3 The +5 V power source (VCC) and the NMI signal generator.............................................10
2.1.4 The +5 V power source (VCC1).......................................................................................... 11
2.1.5 Power supply for the printer performance circuits (VH) ...................................................... 11
2.1.6 Accumulator voltage to the VH voltage converter ............................................................... 11
2.1.7 NiMH accumulator charging circuit .....................................................................................12
2.1.8 Fiscal memory power supply circuits ..................................................................................12
2.1.9 Power supply voltages characteristics ................................................................................12
2.2 The microcontroller and its support circuits ........................................................13
2.2.1 The E-500TXN microcontroller............................................................................................13
2.2.2 Memory circuits ...................................................................................................................15
2.2.3 Start-up and turning off of the system .................................................................................16
2.2.4 Real-time circuit ..................................................................................................................16
2.3 I/O circuits...........................................................................................................17
2.3.1 Printing control circuits ........................................................................................................17
2.3.2 Keyboard.............................................................................................................................18
2.3.3 Displays...............................................................................................................................20
2.3.4 Communication circuits .......................................................................................................21
2.3.5 Connexion of scal memory circuits ...................................................................................24
2.3.6 Other circuits .......................................................................................................................25
3 Thermal printer LT1320 .............................................................................................27
3.1 Basic specication ..............................................................................................27
3.2 Thermal head .....................................................................................................27
3.2.1 Thermal head composition..................................................................................................27
3.2.2 Data processing in the printing head...................................................................................28
3.2.3 Printing data and their position............................................................................................28
3.2.4 Thermistor specication ......................................................................................................28
3.2.5 Time diagram ......................................................................................................................28
3.3 Paper feeding .....................................................................................................29
3.3.1 Step-motor specication......................................................................................................29
3.3.2 Excitation sequence ............................................................................................................29
3.3.3 Control circuit ......................................................................................................................29
3.4 Printing head position sensor .............................................................................30
3.5 Paper tape presence detectors ..........................................................................30
3.6 Overall time diagram ..........................................................................................30
3.7 Printer connectors ..............................................................................................31
3.7.1 Printing head connectors ....................................................................................................31
3.7.2 Terminal for the sensors......................................................................................................32
3.8 Cleaning of the printing head..............................................................................32
4 Reinstallation of individual modules.......................................................................33
4.1 ECR disassembly ...............................................................................................33
4.2 Reinstallation of accumulator .............................................................................35
4.3 Printer reinstallation............................................................................................35
4.4 Motor reinstallation .............................................................................................38

Euro-500TX Handy © Elcom, s. r. o.
Service manual
Euro-500TX Handy © Elcom, s. r. o.
Service manual
4.5 Reinstallation of the main PCB...........................................................................39
4.6 EPROM reinstallation .........................................................................................39
4.7 Defective SRAM replacement or replacing the SRAM to higher capacity ..........40
4.8 NiCd accumulator reinstallation..........................................................................41
4.9 Reinstallation of the keyboard or individual keys................................................41
4.10 Reinstallation of displays ..................................................................................43
4.10.1 Reinstallation of displays for the ECR Euro-500TX Handy ...............................................43
4.10.2 Reinstallation of displays for the Greek version of Euro-500TX Handy ............................44
4.11 ECR connectors................................................................................................45
4.11.1 Connectors placed on the main PCB ................................................................................45
4.11.2 Connector for external devices..........................................................................................45
4.12 Segment LCD backlight installation..................................................................46
4.13 Connection of the external ECR drawer ...........................................................46
4.14 Connection of the external keyboard................................................................48
4.15 Connection of Euro-500TX Handy to the PC using the RS-232 interface........48
4.16 Scanner and scales connection to the Euro-500TX Handy via the RS-232 inter-
face......................................................................................................................49
5 ECR tests ...................................................................................................................50
5.1 Display tests .......................................................................................................50
5.2 Printer tests ........................................................................................................51
5.2.1 Printing test .........................................................................................................................51
5.2.2 Thermal head position test..................................................................................................51
5.2.3 Paper presence sensor test ................................................................................................51
5.3 Keyboard tests....................................................................................................52
5.3.1 Keyboard test 1 ...................................................................................................................52
5.3.2 Keyboard test 2 ...................................................................................................................52
5.4 Communication interfaces tests .........................................................................53
5.4.1 RS-232 serial interface test for PC......................................................................................53
5.4.2 RS-232 serial interface test for scanner and scales............................................................54
5.4.3 External PC keyboard interface test....................................................................................54
5.5 ECR drawer test.....................................................................................................................55
5.6 Fiscal memory tests............................................................................................55
5.6.1 FM data reading tests .........................................................................................................55
5.6.2 FM data writing tests .......................................................................................56
5.6.3 FM working voltages test ....................................................................................................56
5.6.4 FM control signals test 1 .....................................................................................................56
5.6.5 FM control signals test 2 .....................................................................................................57
5.7 EPROM checksum test ......................................................................................57
5.8 Accumulator tests ...............................................................................................57
5.8.1 Accumulator status test .......................................................................................................57
5.8.2 VCC1 power supply test......................................................................................................58
6 Troubleshooting ........................................................................................................59
6.1 Power supply troubleshooting ............................................................................59
6.2 Microprocessor troubleshooting .........................................................................60
6.3 Printing troubleshooting......................................................................................61
6.4 Display troubleshooting ......................................................................................63
6.5 Keyboard troubleshooting...................................................................................63
6.6 Communication troubleshooting .........................................................................64
6.7 Real-time and date troubleshooting....................................................................64
6.8 Miscellaneous troubleshooting ...........................................................................64
7 Ordering and listing of spare parts..........................................................................66
7.1 ECR parts classication......................................................................................66

Euro-500TX Handy © Elcom, s. r. o.
Service manual
Euro-500TX Handy © Elcom, s. r. o.
Service manual
7.2 Arrangement and listing of main PCB parts........................................................66
7.3 Arrangement and listing of keyboard parts .........................................................75
7.4 Arrangement and listing of segment LCD module ..............................................76
7.5 Arrangement and listing of connectors PCB.......................................................77
7.6 Arrangement and listing of interconnecting PCB ................................................77

Euro-500TX Handy © Elcom, s. r. o.
Service manual
Euro-500TX Handy © Elcom, s. r. o.
Service manual
Table of gures
Fig. 1.1: Block chart of ECR Euro-500TX.........................................................................9
Fig. 2.1 Primary power supply........................................................................................10
Fig. 2.2 +5 V power supply and the NMI signal generator .............................................10
Fig. 2.3 VCC1 power supply........................................................................................... 11
Fig. 2.4 VH power supply ............................................................................................... 11
Fig. 2.5 Accumulator voltage converter circuit................................................................ 11
Fig. 2.6 NiMH accumulator charging circuit....................................................................12
Fig. 2.7 FM power supply circuits...................................................................................12
Fig. 2.8 The E-500TXN microcontroller..........................................................................13
Fig. 2.9 Memory connexion ............................................................................................15
Fig. 2.10 Reset controller ...............................................................................................16
Fig. 2.11 Standby controller............................................................................................16
Fig. 2.12 Real-time circuit...............................................................................................16
Fig. 2.13 Printer control signals......................................................................................17
Fig. 2.14 Printer motor control and control of the journal winding motor........................17
Fig. 2.15 Journal winding motor connexion....................................................................18
Fig. 2.16 Receipt paper tape detection in the printer .....................................................18
Fig. 2.17 Journal paper tape detection in the printer......................................................18
Fig. 2.18 Measuring the printer head temperature .........................................................18
Fig. 2.19 Detecting the printer head position..................................................................18
Fig. 2.20 Connectors for tting the interconnect PCB ....................................................18
Fig. 2.21 Keyboard connexion scheme ..........................................................................19
Fig. 2.22 Signal chart on the 7442 decoder (outlets A – C)............................................19
Fig. 2.23 Signal chart on the 7442 decoder (outlets 0 – 7) ............................................19
Fig. 2.24 The display control in the Euro-500TX Handy.................................................20
Fig. 2.25 Segment LCD and the NJU6432B display controller connexion .....................21
Fig. 2.26 NJU6432B display controller connexion..........................................................21
Fig. 2.27 View on the display placement in Euro-500TX Handy ....................................22
Fig. 2.28 View on the display placement in Greek version of Euro-500TX Handy.........22
Fig. 2.29 Communication circuits and the external PC keyboard interface....................23
Fig. 2.30 Connectors for tting the connectors PCB ......................................................24
Fig. 2.31 FM connexion..................................................................................................24
Fig. 2.32 Power supply voltage checking circuits...........................................................25
Fig. 2.33 Buzzer circuit...................................................................................................25
Fig. 2.34 Drawer opening circuit and the opening signal chart ......................................25
Fig. 2.35 The circuit reading the keyboard and jumpers’ status .....................................25
Fig. 2.36 Individual ECR connectors pin connexion.......................................................26
Fig. 2.37 Connector PCB connexion ..............................................................................26
Fig. 3.1 Thermal head connexion...................................................................................27
Fig. 3.2 Printing data placement.....................................................................................28
Fig. 3.3 Time diagram ....................................................................................................28
Fig. 3.4 Performance signals of the step-motor .............................................................29
Fig. 3.5 Control circuit ....................................................................................................29

Euro-500TX Handy © Elcom, s. r. o.
Service manual
Euro-500TX Handy © Elcom, s. r. o.
Service manual
Fig. 3.6 Outer part of the head position sensor ..............................................................30
Fig. 3.7 Sensor circuit on the main PCB ........................................................................30
Fig. 3.8 External sensor circuit on the Interconnect PCB...............................................30
Fig. 3.9 Overall time diagram ........................................................................................30
Fig. 3.10 Placement of thermal head connector.............................................................31
Fig. 3.11 Sensor connexion to the connector .................................................................32
Fig. 4.1 Rough ECR cover disassembly chart................................................................33
Fig. 4.2 Releasing of the keyboard.................................................................................34
Fig. 4.3 Pulling out the middle cover ..............................................................................34
Fig. 4.4 Fixation and localisation of the accumulators....................................................35
Fig. 4.5 Printer reinstallation at segment LCD................................................................36
Fig. 4.6 Printer reinstallation at alphanumerical LCD .....................................................37
Fig. 4.7 Motor reinstallation ............................................................................................38
Fig. 4.8 Bottom view of motor cover...............................................................................38
Fig. 4.9 Fitting of the main PCB .....................................................................................39
Fig. 4.10 EPROM chip on the main PCB .......................................................................40
Fig. 4.11 NiCd accumulator on the main PCB ................................................................41
Fig. 4.12 Keyboard disassembly ....................................................................................42
Fig. 4.13 Individual keyboard keys .................................................................................42
Fig. 4.14 Display reinstallation .......................................................................................43
Fig. 4.15 Display reinstallation in the Greek version of Euro-500TX Handy .................44
Fig. 4.16 ECR connectors ..............................................................................................45
Fig. 4.17 Connectors PCB placement ............................................................................45
Fig. 4.18 Segment LCD backlight installation.................................................................46
Fig. 4.19 Overlay for PCB for the LCD with backlight ....................................................46
Fig. 4.20 Connection of the external ECR drawer..........................................................47
Fig. 4.21 Modular jack 4×4 connexion............................................................................47
Fig. 4.22 Connection of the external keyboard...............................................................48
Fig. 4.23 Mini DIN PS/2 connector .................................................................................48
Fig. 4.24 PC communication cable connexion ...............................................................48
Fig. 4.25 Scanner/scales communication cable connexion............................................49
Fig. 5.1 The segment LCD area division ........................................................................50
Fig. 5.2 The keyboard keys arrangement.......................................................................52
Fig. 5.3 The correct sequence for pressing the keys at keyboard test 2........................53
Fig. 5.4 Modular jack 6×6 terminal connector ................................................................53
Fig. 5.5 Mini DIN PS/2 terminal connector .....................................................................54
Fig. 7.1 Main PCB top overlay........................................................................................66
Fig. 7.2 Main PCB bottom overlay..................................................................................67
Fig. 7.3 Keyboard PCB top overlay ................................................................................75
Fig. 7.4 Segment LCD module top and bottom overlay .................................................76
Fig. 7.5 Connectors PCB overlay ...................................................................................77
Fig. 7.6 Intercon PCB top and bottom overlay ...............................................................77

Euro-500TX Handy © Elcom, s. r. o.
Service manual
Table of tables
Tab. 2.1 Description of the E-500TXN microcontroller signals .......................................13
Tab. 2.2 Winding motor connexion .................................................................................18
Tab. 3.1 Gates (strobes) placement ...............................................................................28
Tab. 3.2 Step-motor specication ...................................................................................29
Tab. 3.3 Excitation sequence signals .............................................................................29
Tab. 3.4 Connector types placed on the printer..............................................................31
Tab. 3.5 Thermal head connector pin description...........................................................31
Tab. 3.6 Sensor terminal pin description ........................................................................32
Tab. 4.1 Table of shown parts.........................................................................................33
Tab. 4.2 Table of shown parts.........................................................................................35
Tab. 4.3 Table of shown parts.........................................................................................36
Tab. 4.4 Table of shown parts.........................................................................................37
Tab. 4.5 Table of shown parts ........................................................................................38
Tab. 4.6 Table of shown parts.........................................................................................39
Tab. 4.7 Table of shown parts.........................................................................................40
Tab. 4.8 Table of shown parts.........................................................................................41
Tab. 4.9 Table of shown parts.........................................................................................42
Tab. 4.10 Table of shown parts.......................................................................................43
Tab. 4.11 Table of shown parts .......................................................................................44
Tab. 4.12 Table of shown parts.......................................................................................46
Tab. 4.13 Pin connexion for the scanner ........................................................................49
Tab. 4.14 Pin connexion for the scales...........................................................................49
Tab. 5.1 The ECR Euro-500TX Handy tests...................................................................50
Tab. 5.2 FM partitioning for individual tests ....................................................................55
Tab. 7.1 Bill of material for the main PCB.......................................................................67
Tab. 7.2 Bill of material for the keyboard PCB................................................................76
Tab. 7.3 Bill of material for the segment LCD module ....................................................76
Tab. 7.4 Bill of material for the connectors PCB .............................................................77
Tab. 7.5 Bill of material for the Intercon PCB .................................................................78

Euro-500TX Handy © Elcom, s. r. o.
Service manual
9
1 Introduction
1.1 Euro-500TX Handy technical parameters
Euro-500TX Handy is a portable ECR with following parameters:
• primary power supply external adapter 230 V, 50-60 Hz/24 V,2.08 A
• internal power supply 2× NiMH accumulator 7.2 V, 1,500 mAh
or lead accumulator 6 V, 1,200 mAh
• maximal power input 10 W
• microprocessor system 16-bit microcontroller, 256 kB EPROM, 128 or 512 kB RAM
• memory power backup NiCd accumulator 3.6 V, 60 mAh
• printer thermal, CITIZEN 1320
• cashier and customer displays 1: alphanumerical cashier LCD 2×20 characters and seg-
mented customer LCD
2: 2× alphanumerical LCD 2×20 characters
• keyboard 30 single keys and one double key
1.2 System conguration
The Euro-500TX handy has been designed as a portable ECR. Its most important parameters are low
weight, small size and possibility to operate for a longer period of time without external power supply.
At the heart of the ECR lies the 16-bit microcontroller E-500TXN that features 11 I/O ports and two serial
transfer channels. The ECR programme is stored in 256 kB of EPROM memory. Following the EPROM
programme version, the ECR operates on 128 or 512 kB of RAM.
The system contains:
• power supply circuits
• microprocessor system
• real-time circuit
• reset controller
• power supply checking circuit
• keyboard interface
• display interface
• serial interfaces RS-232 for PC, scanner and electronic scales
• interface for external PC keyboard
• power input reduction circuits
• drawer opening circuit
• paper tape detection circuits
• cashier LCD backlight
• customer LCD backlight (optional for ECRs with segment customer LCD)
• scal memory with its support circuits (optional)
1.3 Block chart of ECR Euro-500TX
MICROCONTROLLER
E-500TXN
Real-time
circuit
RS-232 PC
interface
RS-232 scales
and scanner
interfaces
Power supply
checking
Paper tape
sensor
External PC
keyboard
EPROM�
256 kB
SRAM�
128 (512) kB
Power input
control
circuit
Display
Keyboard
Printer
Fiscal
memory
D0 – D7
A0 – A18
8-bit data bus
19-bit address bus
Fig. 1.1: Block chart of ECR Euro-500TX

Euro-500TX Handy © Elcom, s. r. o.
Service manual
10
Euro-500TX Handy © Elcom, s. r. o.
Service manual
11
2 Circuit schemes and functions
2.1 Power supply circuits
2.1.1 External power supply
The switched pulse power supply circuit ONTOP 100-240 V, 50-60 Hz, 24 V/1.5 A, 36 W serves as the
external power supply for the ECR. Its primary function is to produce unidirectional voltage needed for the
proper ECR functionality from the mains voltage.
2.1.2 Primary power supply
The primary power supply serves as the supply of voltage for the +5 V voltage source in the case that the
external power supply is connected. This circuit is built around the MC34063 universal unidirectional vol-
tage changer that guarantees high resistance to the mains interference. Its high efciency (80 %) secures
effective voltage conversion and low heat emissions (low cooling demands). The output voltage is approx.
8.25 V and is marked as VSS in the scheme.
2.1.3 The +5 V power source (VCC) and the NMI signal generator
This power source manufactures the VRAM and VCC voltages. VCC voltage is needed for the circuits that
are at all times powered as the ECR is on. The KA278R05 linear voltage stabiliser is at the heart of this
circuit that xedly supplies +5 V voltage. Figure 2.2 shows the NMI signal generator as well and this circuit
features NCP301 comparator with threshold level 4.5 V. The main use for the NMI signal is that informs
the microprocessor of the voltage drop and is also used to shut down all the power sources. The D4 diode
produces the VRAM voltage, the R9 resistor ensures the constant charging of the BT1 NiCd accumulator
while the ECR is on, and the JP1 jumper is used for ECR clearing. The gure also shows the PWRSW that
is used to connect the main ECR power switch.
C1
1u/35V
C2
1u/35V
3
4
2
1
EMI
FILTER
.
.
EF1
2x3,3mH/1,5A
VINADP+
ADP-
D1
MBRS340T3
8
7
6
5
1
2
3
4
U13
MC34063
R20
0R22
R21
1k
R22
5k6
C4
470p
L1
120uH
D3
FMKA140
C5
330u/25V
VSS
C3
330u/25V
F2
1.85A
VINf
Fig. 2.1 Primary power supply
R5
150k
R9
1k0/F
C9
2200u/25V
BT1
3V6, 60mAh
VCC VRAM
D4
FMKA140
21
4
3
U14
KA278R05
JP1
Batt 3p
NMI
1
2
PWRSW
AVA 5400-2P-S
C13
100n
C70
100n
R30
0R
NMI
VBAT1
R6
22k
RST 1
IN 2
GND 34 N.C.
N.C.
5
U12
NCP301LSN45T1
D15
FMKA1 40
VS S
Fig. 2.2 +5 V power supply and the NMI signal generator

Euro-500TX Handy © Elcom, s. r. o.
Service manual
10
Euro-500TX Handy © Elcom, s. r. o.
Service manual
11
2.1.4 The +5 V power source (VCC1)
This power source supplies a group of logical circuits with power. Those circuits are not powered all the
time (printing, serial port transmission, etc… in normal mode) and function from time to time as needed. In
the economy and standby mode this power supply is ineffectual.
2.1.5 Power supply for the printer performance circuits (VH)
This power source is used for the supplying of the printer’s thermal head performance circuits, the step-
-motor circuit, and the produces programming voltages for the scal memory.
2.1.6 Accumulator voltage to the VH voltage converter
The voltage converter is used to produce the VH voltage for the printer’s thermal head performance circuits.
The core element here is the LM2588-ADJ that converts the accumulator voltage to the xed voltage of
23 V. The converter is switched off automatically when the EECR gets connected to the external power
source.
C7
330u/25V
VCC1VCC
SAVEPWR
T5
RFP15P05(SFP9Z34)
R29
100k
T6
BC817
R35
100k
T7
BC817
R113
100k
NMI
Fig. 2.3 VCC1 power supply
C16
2200u/25V
VHVIN
D2
MBRS340T3
T1
RFP15P05(SFP9Z34)
R1
100k
R2
100k
T2
BC817
T3
BC817
R3
100k
R4
100k
SAVEPWR
NMI
Fig. 2.4 VH power supply
BAT+
Ls1
47uH Ds1
MBRS340T3
Rs1
2k7/F
Rs2
47k
Rs3
2k7/F
Cs3
1u
Cs1
330u/25V
VHSU
Rs5
10k
Rs4
1M
VIN
NMI
Cs4
100n
PD
1
Comp
2FB 3
GND
4
SW 5
Sync
6
Vin
7
Us1
LM2588-ADJ
Cs2
100n
Ds2
LL4148
Rs6
2k2
Ds3
LL4148
Ts1
2N7002
Rs7
22k
Rs8
47k
Fig. 2.5 Accumulator voltage converter circuit

Euro-500TX Handy © Elcom, s. r. o.
Service manual
12
Euro-500TX Handy © Elcom, s. r. o.
Service manual
13
2.1.7 NiMH accumulator charging circuit
The accumulator charging is controlled by the BQ2000 integrated circuit that contains the complete service
and checking of the rapid charging process of the NiMH accumulator. All accumulators are charged using
the constant current of approx. 400 mA and the charging process is nished when the slight drop in accumu-
lator voltage has been detected (a property of the NiMH accumulators when they are fully charged to more
than 0.2 C). The BQ2000 contains also the accumulator temperature protection for safety reasons and the
timer that terminates the charging process if the previous measures should fail.
The connexion with the T4 transistor ensures the total disconnection of accumulators from the other power
source circuits during the charging process so the voltage drop of the fully charged accumulator could be
reliably detected.
2.1.8 Fiscal memory power supply circuits
Special voltages are needed to program and verify data in the scal memory. The circuits shown in the
gure 2.7 produce these voltages.
2.1.9 Power supply voltages characteristics
VSS primary power supply for the VCC manufacture
values: 8.2 V ± 10 % while mains powered
0 V while accumulator powered
VCC power supply for the logical circuits (logical circuits that are powered all the time)
values: 5 V ± 5 %
SNS
1
VSS
2
LED
3
BAT
4TS 5
RC 6
VCC 7
MOD 8
Uc1
BQ2000
Tc
2
RFP15P05(SFP9Z34) + Cooler
Tc1
BC817
Rc7
220
Rc12
2k2
Rc13
2k2
Dc2
FMKA140
Lc1
120uH
BAT+
Cc7
10u/10V
Rc11
270k (100k)
Rc9
47k (22k)
Rc10
100k
Cc6
100n
BAT
BAT
Rc8
4k7
VIN
Dc3
5V1
Cc3
100u/10V
BAT-
Cc2
100n
VCC2
Rc4
270k
Cc1
33n
VCC2
RC
RC
Rc1
10k
Rc2
22k
VCC2
TSENS
TSENS
VIN VIN
Dc1
FMKA140
Cc5
4p7Cc4
1n
Rc6
1k
Rc3
100k
TEMP
Cc8
1n
Cc9
47u/25V Rc5
1k
Rc14
0.068
Rc15
22k
Rc16
6k8
VCC2
Rc17
10k
Tc3
MMB3904LT1
Tc4
BC857
Tc5
BC857
Fig. 2.6 NiMH accumulator charging circuit
VH VFP
R15
100k R17
100k
R16
100k
RST
VPP-GEN
13,2V
D6
SMKA140
VCC
T10
BC817
T9
BC817
T8
BSS84
C49
1u/35V
PV
Vout
2Vout 7
NC 5
Vout 6 Vout
3
Vin
1
Adj
4
NC 8
U15
LM317L
R11
2k/F
R10
220R/F
C10
100n
C11
100n
D18
FMKA140
R13
100R
R18
220R/F
VFD
Vout
2Vout 7
NC 5
Vout 6 Vout
3
Vin
1
Adj
4
NC 8
U16
LM317L
R19
1k0/F
D8
FMKA140
VCC
C14
100n
C15
1u/35V
PV
R14
22R
D7
FMKA140
6,5V
Fig. 2.7 FM power supply circuits

Euro-500TX Handy © Elcom, s. r. o.
Service manual
12
Euro-500TX Handy © Elcom, s. r. o.
Service manual
13
VRAM power supply for the microprocessor, RAM memory, and the real-time circuit
values: 4.75 V ± 5 %
VCC1 power supply for the logical circuits (the group of logical circuits powered only in normal
mode)
values: 4.9 ± 5 %
VH power supply for the printer performance circuits, the step-motor, the circuit producing the
FM programming voltage, and the drawer opening circuit
values: 24 V ± 0.2 V while mains powered
23 V ± 0.3 V while accumulator powered
VFP the scal memory programming voltage
values: from 12.5 V to 13 V
VFD the scal memory programming voltage
values: from 6 V to 6.5 V
VBAT1 accumulator voltage
values: from 5.5 V (accumulator empty) to 9.25 V (accumulator full), standard operating
voltage from 7.2 V to 8.2 V
2.2 The microcontroller and its support circuits
2.2.1 The E-500TXN microcontroller
The ECR Euro-500TX Handy employs the 16-bit microcontroller E-500TXN. This microcontroller fully con-
trols the ECR. Its properties are:
• 2 kB RAM on chip
• 11 I/O ports
• maximum 16 MB of ad-
dressing for the programme
memory
• maximum 16 MB of ad-
dressing for the data memo-
ry
• ve 16-bit timer/readers
• seven external interrupts
• two full duplex serial chan-
nels (USART)
• 10-bit A/D converter, eight
channels
• 8-bit D/A converter, two
channels
• watchdog timer
• clock frequency up to
18 MHz
• on-chip oscillator and timer
circuits
• QFP 100 case
The gure 2.8 shows the pin place-
ment and the table 2.1 lists the pin
descriptions for the E-500TXN.
VRAMx
FM-AL/CN0
FM-AH/CN1
A16 /CN2
FM-DIR/SCL
SDA
FM-SEL
FM-PGM
VPP -GE N
NC
GND
TX D0
TX D1
RXD0
RXD1
EKB-DAT
EKB-CLK
FD0
FD1
FD2 /RW2
FD3 /RW3
FD4 /RW4
FD5 /JP4
FD6 /JP5
GND
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
23
24
25
22
FD7/
D1 D2 D3 D 4 D5 D6 D7
VRAMx
A0 A1 A2 A3 A 4 A5 A6 A7
G ND
A8 A9 A10 A11 A1 2 A13
26 27 28 29
30 31 32 33 34 35 36 37 38 39
40 41 42 43 44 45 46 47 48 49
50
A14
A15
A16
A17
A18
NC
GND
LCD-SEL
SYSCLK
STB Y
RS T
GND
EXTA L
XTA L
VRAMx
NC
RD
NC
MD0
MD1
MD2
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76 77 78 79
80 81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99
100
E-500TXN
NC
CS4
EN
SAVEPWR
B
A
PR-SET
PR-SEL
GND
CS0x
CS1
CS2
NC
RDKEYB
GND
BUZZER
DRAWER
HS
PS2
PS1
P-LOW
TS
VRAMx
POWER
JP6
D0
LCD-CLK
LCD-DATA
NMI
HWR
VRAMx
Fig. 2.8 The E-500TXN microcontroller
Pin #. Signature Type Signal description
1 VRAMx I +5V power supply
2 FM-AL/CN0 O validity of lower address byte for FM / keyboard control
3 FM-AH/CN1 O validity of higher address byte for FM / keyboard control
4 A16/CN2 O highest address bit for FM / keyboard control
5 FM-DIR/SCL O permission to read data from FM / clock signal for serial EPROM
6 SDA I/O data conductor for communication with serial EPROM
Tab. 2.1 Description of the E-500TXN microcontroller signals

Euro-500TX Handy © Elcom, s. r. o.
Service manual
14
Euro-500TX Handy © Elcom, s. r. o.
Service manual
15
Pin #. Signature Type Signal description
7 FM-SEL O choice of FM circuits
8 FM-PGM O control signal for FM programming
9 VPP-GEN O signal of program voltage control for FM
10 NC NC
11 GND I 0 V power supply
12 TXD0 O serial data output, channel 0
13 TXD1 O serial data output, channel 1
14 RXD0 I serial data input, channel 0
15 RXD1 I serial data input, channel 1
16 EKB-DAT I/O data conductor for communication with external keyboard
17 EKB-CLK O clock signal for external keyboard
18 FD0 I/O 0.bit FM data
19 FD1 I/O 1.bit FM data
20 FD2/RW2 I/O 2.bit FM data / scanning keyboard
21 FD3/RW3 I/O 3.bit FM data / scanning keyboard
22 GND I 0 V power supply
23 FD4/RW4 I/O 4.bit FM data / scanning keyboard
24 FD5/JP4 I/O 5.bit FM data / scanning JP4 jumper condition
25 FD6/JP5 I/O 6.bit FM data / scanning JP5 jumper condition
26 FD7/JP6 I/O 7.bit FM data / scanning JP6 jumper condition
27-34 D0-D7 I/O data bus
35 VRAMx I +5 V power supply
36-43 A0-A7 O address bus
44 GND I 0 V power supply
45-55 A8-A18 O address bus
56 NC NC
57 GND I 0 V power supply
58 LCD-SEL O activation signal of display controller
59 LCD-CLK O clock impulse generation for LCD controller
60 LCD-DATA O datas for processor which control LCD displays
61 SYSCLK O system clock output of processor for next usage
62 STBY I input for hardware standby mode
63 RST I input for reset signal
64 NMI I unmasked interference input
65 GND I 0 V power supply
66 EXTAL I input for external oscillator
67 XTAL I input for external oscillator
68 VRAMx I +5 V power supply
69 NC NC
70 RD O signal for reading data from activated circuit
71 HWR O signal for recording data to activated circuit
72 NC NC
73-75 MD0-MD2 I choice of processor operating mode
76 VRAMx I feeding of internal D/A and A/D converter
77 VRAMx I reference voltage of internal D/A and A/D converter
78 TS I input for scanning printer head temperature
79 POWER I scanning presence and voltage value of primary supply
Tab. 2.1 Description of the E-500TXN microcontroller signals (cntd.)

Euro-500TX Handy © Elcom, s. r. o.
Service manual
14
Euro-500TX Handy © Elcom, s. r. o.
Service manual
15
2.2.2 Memory circuits
The memory used by the microcontroller is divided into the two parts:
• programme memory
• data memory
The EPROM memory with the capacity of 256 kB serves as the programme memory. The data memory is
built on the static RAM memory (68C1000, 66C1024) and is expandable to 512 kB. The programme memory
(EPROM) is activated using the CS0 signal and the data memory (SRAM) is activated using the CS1 signal.
The ECR Euro-500TX handy uses
the ultra low power input memory
circuits that allow the lower power
supply demands and signicantly
prolongs the backup of memory data
using the backup accumulator. The
exchange of said memory circuits
for other types with same capacity
can result in worse performance of
memory operations, increase of the
bus interference, and the memory
back-up time is shorter. It is recom-
mended to use only manufacturer
approved memory circuits.
In order to preserve the data in RAM
memory while the ECR is off, the
RAM memory is backed up from the
reserve accumulator.
Note: The chapter 4.7 describes how
to expand ECR memory to 512 kB.
Pin #. Signature Type Signal description
80 P-LOW I scanning voltage value of internal connecting accumulator
81 PS1 I scanning paper ribbon presence
82 PS2 I scanning paper ribbon presence
83 HS I scanning printer head position
84 DRAWER O control signal for drawer opening
85 BUZZER O buzzer control
86 GND I 0 V power supply
87 RDKEYB O signal for reading keyboard and JP4 - JP6 jumper condition
88 RW1 I scanning keyboard
89 CS2 O current time circuit activation
90 CS1 O RAM memory activation
91 CS0x O program memory activation
92 GND I 0 V power supply
93 PR-SEL O activation of circuit for production of STB1 – STB4, W-MOT and PLATCH
signals
94 PR-SET O control output for number of check bits written in one cycle to fast print circuit
95 A O 1. phase of printer stepping motor
96 B O 2. phase of printer stepping motor
97 SAVEPWR O signal of switching between normal and saving mode
98 EN O activation signal of stepping motor drivers
99 CS4 O signal of data recording to circuit for production of STB1 – STB4, WMOT and
PLATCH signals
100 NC NC
Tab. 2.1 Description of the E-500TXN microcontroller signals (cntd.)
A0
12
A1
11
A2
10
A3
9
A4
8
A5
7
A6
6
A7
5
A8
27
A9
26
A10
23
A11
25
A12
4
CS1 22
A17
30
WE 29
OE 24
D0 13
D1 14
D2 15
D3 17
D4 18
D5 19
D6 20
D7 21
A13
28
A14
3
A15
31
A16
2
A18
1
U2
KM681000A
A0
A1
A2
A3
A4
A5
A6
A7
A8
A9
A10
A11
A12
A13
A14
A15
A16
S17
A18
D0
D1
D2
D3
D4
D5
D6
D7
CS1
RD
HWR
R25
0R(opt. 4000)
A17 S17
A0
12
A1
11
A2
10
A3
9
A4
8
A5
7
A6
6
A7
5
A8
27
A9
26
A10
23
A11
25
A12
4
A13
28
A14
29
A15
3CE 22
OE 24
DQ0 13
DQ1 14
DQ2 15
DQ3 17
DQ4 18
DQ5 19
DQ6 20
DQ7 21
A16
2
A17
30
VPP 1
PGM 31
U3
27C2001+Socket
D0
D1
D2
D3
D4
D5
D6
D7
A0
A1
A2
A3
A4
A5
A6
A7
A8
A9
A10
A11
A12
A13
A14
A15
A16
A17
VCC
CS0
RD
R27
10k
VRAM CS1
R26
10k
VRAM
Fig. 2.9 Memory connexion

Euro-500TX Handy © Elcom, s. r. o.
Service manual
16
Euro-500TX Handy © Elcom, s. r. o.
Service manual
17
2.2.3 Start-up and turning off of the system
The two most important states of the system are its start-up and turning off. During the start-up it is neces-
sary to ensure the correct initialisation of the microcontroller and all of the logical circuits. The turning off
conversely requires the saving of all vital data and reliable transfer of the microcontroller and logic circuits
into the safe mode.
The E-500TXN microcontroller connexion is designed so that the E-500TXN is powered from the reserve
NiCd accumulator using the VRAM voltage (current consumption is approx. 500 nA) even when the ECR is
turned off. In order for the system to start up and turn off properly, it is necessary to correctly issue RESET
and STBY (stand-by mode activation) signals. The reset and stand-by controllers handle these signals.
Reset signal controller is a circuit that provides:
• reliable initialisation of the E-500TXN microcontroller during the start-up using the active level of
the RESET signal,
• RESET signal activation during the VCC voltage drop below the circuit threshold level.
The active level of the RESET signal is “log.0”. The active signal level duration is 150 ms minimum. The
threshold level is the voltage level that causes the RESET signal to be generated. This level is very impor-
tant for proper functionality of the logical circuits. The V6309/L circuit that is used in this ECR type has the
threshold voltage value equal to 4.5 V. Voltages below 4.5 V cause the V6309/L circuit to reset the CPU.
Stand-by signal controller is a circuit that provides:
• reliable leaving of the E-500TXN microcontroller stand-by mode during the ECR start-up,
• STBY signal activation in order to turn on the E-500TXN stand-by mode if the VCC voltage drops
to the circuit threshold level.
The active level of the STBY signal is “log.0”. The V6340/F circuit that is used in this ECR type has the
threshold value equal to 4.5 V. If the voltage drops below 4.5 V the V6340/F activates the microcontroller
stand-by mode.
2.2.4 Real-time circuit
The ECR requires the reliable real-time capability i. e. always to retain and calculate the current date and
time. The V3021 circuit provides these functions.
The V3021 circuit contains:
• reader
• shift register
• voltage regulator
• voltage detector
• communication interface
The communication between V3021
and E-500TXN is provided via the
D0 data line and RD and HWR con-
trol signals. The circuit is activated
using the CS2 signal.
The circuit is powered from the re-
serve NiCd accumulator in order to
ensure its functionality even when
the ECR is turned off. Memory back-
-up voltage has to be at least 2.5
V. The real-time circuit consumes
maximum 500 nA from the reserve
accumulator.
VCC 2
GND
RST
1
U10
V6309/L
3
VCC
RST
4.25
t [ms]
VCC
4.5
t [ms]
0150
RST
VCC
2
GND
OUT 1
U11
V6340/F
3
VCC
STBY
4.25
t [ms]
VCC
4.5
t [ms]
0
STBY
Fig. 2.10 Reset controller Fig. 2.11 Standby controller
1
2
1
2
XO 7
5
6
3
XI
U4
R72
10k
VRAM
U [V]
0.8
0.4
0 31 62
t [ s]�
U [V]
0.4
0
-0.4
31 62
Q2
32k768
CS2
RD
HWR
C52
15p
C53
15p
2WR
I/O
RD
CS
1
V3021
D0
Fig. 2.12 Real-time circuit

Euro-500TX Handy © Elcom, s. r. o.
Service manual
16
