elero RolTop-868 User manual

RolTop-868 Roller Shutter Drive
138134006_EN_0319
RolTop-868 Roller Shutter Drive
1 Operating and installation instructions
Please keep these operating instructions for later use, to be
available throughout the life of the product!
The German manual is the original version.
All other documents represent the language translations of
the original text.
All rights in the case of a patent, utility model or ornamental
design registration are reserved.
2 General for instructions
The content structure is based on the life cycles of the elec-
tric motor drive (hereinafter referred to as "Product").
The manufacturer reserves the right to make changes to
the Specications stated in these Operating Instructions
at any time. These may, in individual cases, be di󰀨erent
from the respective product version, however the functional
information will not undergo signicant changes or become
invalid. The current version of the Specications may be
requested from the manufacturer at any time. No claims
may be asserted against the manufacturer as a result of the
preceding sentence. Deviations from text or picture state-
ments are possible and depend on the technical develop-
ment, features, and accessories of the products. Deviating
information on special versions will be explained by the
manufacturer in the sales documentation. Other information
shall remain una󰀨ected by these provisions.
Table Of Contents
1 Operating and installation instructions 1
2 General for instructions 1
2.1 Standards and Directives 2
2.2 Intended use 2
2.3 Foreseeable misuse 2
2.4 Warranty and liability 2
2.5 Customer service of the manufacturer 2
3 Safety 2
3.1 General safety instructions 2
3.2 Layout of the safety guidelines 2
4 Product description 3
5 Assembly 3
5.1 Mechanical fastening 4
5.2 Electrical connection 4
5.3 Connection example, RolTop-868 230 V/50 Hz 4
5.4 Parallel connection 5
5.5 Commissioning 5
5.5.1 Connection for cable assembly 5
5.5.2 Connection for radio (transmission operation) 5
5.6 Setting the end positions and the relief 5
5.6.1 Relief function for the end position(s) 5
5.6.2 Relief function at the upper stop 5
5.6.3 Relief function at the lower stop 5
5.6.4 Changing / Deleting the limit positions
and deleting the discharge function 5
5.6.5 Programme or delete further curtain
positions 6
5.6.6 Four variants of end position settings 6
5.6.7 Variant A: Upper and lower end position
freely adjustable 6
5.6.8 Variant B: Fixed upper limit stop / lower end
position freely adjustable 6
5.6.9 Variant C: Fixed upper and lower limit stop 6
5.6.10 Variant D: Upper end position freely
adjustable, xed lower limit stop 7
5.7 Programming the transmitter 7
5.8 Programming (additional) transmitter 7
5.9 Technical data 7
6 Troubleshooting 7
7 Repair 8
8 Repair 8
9 Manufacturer's address 8
10 Disassembly and disposal 8
11 Notes on the EC declaration of conformity 8
12 Technical data and dimensions 8
12.1 RevoLine S-868 9
12.2 RevoLine M-868 10
12.3 RevoLine M-868 11
12.4 RevoLine L-868 11

• Opening of the product by the customer
• Unintended use of the product
• Improper installation, commissioning, or operation of the
product
• Structural modications to the product without the written
consent of the manufacturer
• Operation of the product with improperly installed con-
nections, defective safety devices or improperly installed
safeguards
• Non-observance of the safety provisions and instructions
of these Operating Instructions
• Non-compliance with the technical data
2.5 Customer service of the manufacturer
The product should only be repaired by the manufacturer
in case of a failure. The address for sending to customer
service, see the chapter "Address".
If you have not purchased the product directly from elero,
please contact the supplier of the product.
3 Safety
3.1 General safety instructions
The general safety notes when using tubular drives can be
found in the leaet "Instructions on safety" that is enclosed
with each drive"(leaet item no. 138200001). These operat-
ing and installation instructions contain all the safety instruc-
tions that must be observed in order prevent and eliminate
hazards in the handling of the product in the individual life
cycles. The safe operation of the product can only be en-
sured when all given safety instructions are observed.
3.2 Layout of the safety guidelines
The safety instructions in this document are identied by
hazard signs and safety symbols and are designed accord-
ing to the SAFE principle. They contain information on the
nature and source of the danger of possible consequences
and to prevent the danger.
The following table denes the representation and descrip-
tion of hazard levels with possible personal injury, as used
in this manual.
Symbol Signal
word
Meaning
DANGER Warns before an acci-
dent, which will result if
instructions are not fol-
lowed, which can lead to
life-threatening, irreversi-
ble injury or death.
WARNING Warns before an acci-
dent, which can happen
if the instructions are not
followed, which can lead
to serious, possibly fatal,
irreversible injury or death.
CAUTION Warns before an accident,
which can happen if the
instructions are not fol-
lowed, which may lead to
minor reversible injury.
Fig. 1 Notation of personal injury
2 | EN © elero GmbH
Standards and Directives| Safety
2.1 Standards and Directives
During the design process, the basic health and safety
requirements of the applicable laws, Standards and Direc-
tives were complied with. The safety is conrmed by the
declaration of conformity (see "Declaration of Conformity").
All safety information in these Operating Instructions refer
to the laws and regulations currently applicable in Germany.
All instructions in the Operating Instructions shall be ob-
served without limitation and at any time. Beside the safety
instructions contained in these Operating Instructions, the
provisions for accident prevention, environmental protection
and occupational safety, which are applicable for the op-
erating site, must be observed. Provisions and Standards
for the safety rating can be found in the EC Declaration of
Conformity
2.2 Intended use
The product is intended for use in façade engineering to
drive electrically powered and regular roller shutters.
The determining factor for the drive is the elero drive com-
putation program
www.elero.com/drive-calculation
Further elds of application have to be arranged with the
manufacturer, elero GmbH Antriebstechnik (see Address).
The operator will be solely responsible for damages result-
ing from improper use of the product. The manufacturer
cannot be held liable for personal or material damages
caused by misuse or procedural errors, and by improper
operation and commissioning.
The product may be operated only by trained and author-
ized personnel under observance of all safety.
Only if used according to the specications of these operat-
ing and installation instructions for the safe and proper use
and safe operation of the product are guaranteed.
Only use radio receivers with equipment and units approved
by the manufacturer. The operator does not benet from
any protection whatsoever against interference from other
remote control equipment and terminal equipment (e.g.
also from radio equipment which is correctly operated in
the same frequency range). Please note that radio systems
must not be operated in areas with an increased risk of
interference (e.g. hospitals, airports,....). The radio control is
only permitted for devices and units with which a functional
interference in hand-held/wall transmitters or receivers
poses no danger for persons, animals or materials or where
this risk is covered by other safety appliances.
Intended use includes the observance and compliance with
all safety instructions with regards to this operating manual
and all applicable regulations, and professional associations
of applicable laws for environmental protection. Intended
use includes the observance of prescribed operating rules
in these operating and installation instructions.
2.3 Foreseeable misuse
A use which deviates from the intended use stated by the
manufacturer, elero GmbH Antriebstechnik (see "Address"),
is deemed as foreseeable misuse.
2.4 Warranty and liability
Principally, the General Terms and Conditions of the man-
ufacturer, elero GmbH Antriebstechnik (see "Address"),
apply. The terms and conditions are part of the sales
documents and handed over to the operator upon deliv-
ery. Liability claims for personal or material damages are
excluded when they can be attributed to one or more of the
following causes:

The following table describes the icons used in these op-
erating instructions that are used for imaging of the dan-
gerous situation in connection with the symbol of the threat
level.
Symbol
Meaning
Danger of electric voltage, electric
shock:
This symbol indicates a risk of electric
shock.
Fig. 2 Notation-specic hazard
The following table denes the representation used in the
operating instructions and description of situations where
damage can occur to the product or refers to important
facts, conditions, tips and information.
Symbol Signal
word
Meaning
NOTE This symbol warns of a
possible property dam-
age.
Important: This symbol points out
important facts and con-
ditions as well as to addi-
tional information in these
operating and installation
instructions. It also refers
to certain statements that
give additional information
or help you perform a task
easily.
Symbol for earthing in
protection class I
(protective ground sys-
tem)
Fig. 3 Notation of property damage as well as additional
information
The following example represents the basic structure of a
safety warning:
SIGNAL WORD
Type and source of danger
Explanation of the type and source of the danger
►Measures to prevent the danger.
4 Product description
The RolTop 868 is a radio-controlled electromechanical
tubular motor drive. It performs parallel axial movements.
Commissioning of the RolTop 868 with elero assembly
cable or radio transmitter for setting di󰀨erent functions.
Venetian blind with free ride (torque deactivation)
Relief function for the Venetian blind (Venetian blind
protection)
Type s_onro-868 with soft stop downwards
The relief function and free ride with sunblind are only
active in radio mode.
• The variant-dependent values of your RolTop-868 can be
removed from the type label.
• The di󰀨erent versions of the RolTop-868 contain di󰀨erent
types of brake systems depending on size and torque.
The result may yield di󰀨erent performance e.g. regarding
access to end an position.
5 Assembly
CAUTION
Personal injury from hot surfaces.
Drive heats up during operation, the drive housing can be
hot. Possible burning of the skin.
►Wear personal protective equipment (gloves).
Triggered by a possible material errors may occur or
impact shock and injury due to a gearbox break, bud break
or a clutch defect.
►Suitable materials are to be used for the construction as
well as perform a sampling inspection by double load test
according to DIN EN 60335-2-97.
Risk of injury due to impact or shock caused by not prop-
erly mounted or latched motor bearings. Hazards caused
by insufficient stability or stability and stored energy (grav-
ity).
►Selection of engine bearing torque specications.
►Drive must be backed up with all attached backup devic-
es.
►Check for proper latching on engine mounts and correct
tightening torques.
WARNING
Danger of injury due to electric current.
Electric shock possible.
►Electrical work can only be performed by an authorized
electrician.
Danger of injury due to electric current.
Hazardous possibly by parts that have become live in the
error state.
►Electrical connection is described in the operating and
installation instructions including cable bushing.
CAUTION
Risk of injury due to malfunctions due to improper installa-
tion.
Driven by winds and possibly destroyed parts of the appli-
cation.
►For safe operation, the end positions must be set / pro-
grammed.
►Training program of the manufacturer for specialist com-
panies.
Note
Loss of power supply, termination of machine parts and
other malfunctions.
►For safe operation, no false mount must be made and the
end position settings must be carried out during commis-
sioning.
Damage to the RolTop-868 due to moisture penetration.
►For devices with protection class IP44, the ends of all
cables or connectors must be protected against the
ingress of moisture. This measure must be implemented
immediately after removal of the RolTop-868 from the
original packaging.
►The drive may only be installed so that it is not irrigated.
© elero GmbH EN | 3
Safety | Product description | Assembly

Electric shock possible.
►Before commissioning check the correct connection of
the PE conductor.
NOTE
Damage to the RolTop-868 by faulty electrical connection.
►Before commissioning check the correct connection of
the PE conductor.
Damage or destruction of RolTop-868 by the penetration of
moisture.
►For units with protection class IP 44, the customer con-
nection of the cable ends or connector (cable bushing)
must also be carried out in accordance with protection
class IP 44.
Damage or destruction of RolTop-868 for variants with 230
V AC 1 due to faulty control.
►Switch with OFF setting (Dead man) for drives must be
installed within sight of the RolTop-868, but away from
any moving parts and amounting to about 1.5 m.
Important
For electric connection no transmission and retransmission
of the access line or connector is required as a rule.
Depending upon used mounting plate and/or adapter plate
it is necessary in particular with the RolTop-868 Type S to
remove this screwed plate before a cable exchange.
Connection only in free of tension status, in addition
drive line without tension
1 Using a suitable screwdriver, press out the lock of the
device connector to the line.
2 Disconnect the plug.
3 Insert connector until the latch engages.
Removal and insertion of the device plug
Delivery status Remove plug Insert plug
Fig. 4 Removal and insertion of the device plug
5.3 Connection example, RolTop-868 230 V/50 Hz
→
1
→
2
→
3
1Winding thermostat
2Device plug
3Junction box
(outside of roller shutter case)
4Electronics
5Capacitor
sw black
br brown
bl blue
gr/ge green yellow
4 | EN © elero GmbH
Assembly | Mechanical attachment | Electrical connection
Important
In the delivery status (factory setting), the RolTop-868 in
commissioning mode.
►You have to set the end positions (see chapter 5.6).
Best utilisation of the radio signal.
►Place the aerial as freely as possible; in case of bad
reception, move the aerial.
►Do not kink, shorten or extend the aerial.
►Do not undercut the minimum distance of 15 cm between
two radio drives.
5.1 Mechanical fastening
Important preliminary consideration:
The working space around the built-in drive is usually very
small. Therefore, before the mechanical installation provide
an overview of the implementation of the electrical connec-
tion (see Section 5.2) and make any necessary changes
right away.
NOTE
Damage to the electrical wiring by squeezing or tensile
loading.
►Route all electrical cables so that they are not subjected
to crushing or tensile load.
►Note the bending radius of the cables (at least 50 mm).
►Lay the connection cable in a loop downwards to prevent
water running into the drive.
Damage to the drive by the action of impact forces.
►Insert the drive into the shaft, never thrust the drive into
the shaft or smash onto the drive!
►Never allow the drive to fall!
Damage or destruction of the drive by drilling.
►Never drill into the drive!
Important
Attach the RolTop-868 only at the appropriate fasteners.
Permanently installed control devices shall be clearly dis-
played.
• The curtain must be fastened to the winding shaft.
• The prole tube must have enough distance to the motor
tube.
• Look for an axial clearance (1-2 mm).
Installation in prole tubes
ⒶInsert the drive with a suitable adapt-
er and traction ring into the prole
tube.
Lay the motor cable protected in or-
der to prevent damage by the driven
component.
ⒷSecure the counter bearings against
axial displacement, e.g. screw shaft
spider or rivet.
Secure drive in axial storage!
ⒸSecure hanging on the shaft!
Only operate the drive horizontally, as intended, with the
connection cable leading out from the side and out of the
blind winding area.
5.2 Electrical connection
WARNING
Danger to life due to faulty electrical connection.

3
2
1
Fig. 5 Circuit diagram RolTop-868 230 V / 50 Hz and
wiring at use with Hirschmann plug STAS 3 (with
jumper)
Important
The motor control must be interlocked in up / down direction.
A reversing delay of at least 0,5 seconds must be ensured.
5.4 Parallel connection
Important
You can connect several parallel RolTop-868. Note the
maximum switching capacity of switching.
5.5 Commissioning
Important
The drive is in the delivery in commissioning mode.
►Setting of the end positions is required with the elero
assembly cable (see Fig. 6) or an elero wall or hand
transmitter (see Fig. 7).
►Connection of the assembly cable is only admissible for
commissioning of the drive and the setting processes.
5.5.1 Connection for cable assembly
%ODX1HXWUDOOHLWHU
6FKZDU]
%UDXQ
*UQJHOE
HOHUR
HOHUR
%ODX1HXWUDOOHLWHU
6FKZDU]
%UDXQ
*UQJHOE
Fig. 6 Connection for cable assembly
►Switch on mains.
►You can now set the end positions with the elero assem-
bly cable.
5.5.2 Connection for radio (transmission operation)
%ODX1HXWUDOOHLWHU
6FKZDU]
%UDXQ
*UQJHOE
HOHUR
HOHUR
%ODX1HXWUDOOHLWHU
6FKZDU]
%UDXQ
*UQJHOE
Fig. 7 Connection for radio (transmission operation)
►Switch on mains.
►The drive travels upwards and downwards for a short
time.
The drive is in radio mode.
You can now program the transmitter/s.
5.6 Setting the end positions and the relief
The setting of the end positions and the relief can be done
alternatively
• by elero mounting cable (observe proper connection
according to chapter 5.5.1) or
• with the help of a taught-in transmitter.
Teaching in a transmitter onto a drive is described in
chapter 5.7.
Important preliminary consideration:
Decide on a specic relief function before setting the end
positions (di󰀨erent combination options according to the
following statements):
This will save unnecessary setting e󰀨ort!
Press the travel key until the drive signals the transition into
the setting mode, by a short automatic stop. You can now
program the end positions. After setting the two end posi-
tions, the setting mode is completed.
5.6.1 Relief function for the end position(s)
At the same time as programming an end position to stop,
the relief function for the hanging can be activated optional-
ly in one work step.
Important
The relief function is only active in radio mode.
For details, follow the next subchapters.
5.6.2 Relief function at the upper stop
For variant C (see chapter 5.6.8)
and variant D (see chapter 5.6.9):
Activate relief function at the upper stop.
1 Push and hold the UP button ▲ from instruction ①
(chapters 5.6.7 and 5.6.8) and actuate the DOWN
button ▼ with the assembly cable or a taught-in
transmitter (at the same time). Keep both buttons
pushed until the Venetian blind stops.
The relief function at the upper stop is activated.
5.6.3 Relief function at the lower stop
For version C (see chapter 5.6.8)
and version D (see chapter 5.6.9):
Activate relief function at the lower stop
1 Push and hold the DOWN button ▼ from instruction
③(chapters 5.6.8 and 5.6.9) and actuate the UP
button ▲ with from a middle hanging position with
the assembly cable or a taught-in transmitter (at
the same time). Keep both buttons pushed until the
Venetian blind stops.
The relief function at the lower stop is activated.
Important
The Venetian blind is adjusted only after a complete and
uninterrupted access and exit to the blind.
5.6.4 Changing / Deleting the limit positions
and deleting the discharge function
A change or deletion of a single end position is not possible.
This is always done in pairs (upper and lower end position
simultaneously).
By the deletion of the end positions and the adjustment of
the optional discharge function is lost.
The prerequisite for changing or deleting the end positions
and deleting the relief function is interruption of the voltage
supply.
After brief separation from the supply network, the end
positions can be deleted within 5 minutes.
© elero GmbH EN | 5
Assembly | Electrical connection | Relief function

Variant A:
Upper and lower end position freely adjustable
Setting of the end positions variant A is now complete.
5.6.8 Variant B: Fixed upper limit stop / lower end
position freely adjustable
Variant B: Fixed upper limit stop / lower end posi-
tion freely adjustable
①  From a middle Venetian blind position with the as-
sembly cable or a taught-in transmitter, push the UP
button ▲ until the Venetian blind has reached the
desired end position (run to the upper stop).
The drive starts, stops briey and then moves on
(while the UP button ▲ is pushed).
The drive switches o󰀨 automatically when the upper
limit stop is reached.
②  Press the AB button ▼ until the drive stops auto-
matically.
The upper end position has been set.
Optional: Activation of the relief function for the
upper stop; see chapter 5.6.2
③  Press the AB button ▼ again until the Venetian blind
has reached the desired lower end stop.
The drive starts, stops briey and then moves on
(while the button is pushed).
Correction is possible with the buttons ▲ and ▼ .
④Press the AUF button ▲ until the drive stops auto-
matically.
Setting of the end positions variant B is now complete.
5.6.9 Variant C: Fixed upper and lower limit stop
Variant C: Fixed upper and lower limit stop
① From a middle Venetian blind position with the as-
sembly cable or a taught-in transmitter, push the UP
button ▲ until the Venetian blind has reached the
desired end position (run to the upper stop).
The drive starts, stops briey and then moves on
(while the UP button ▲ is pushed).
The drive switches o󰀨 automatically when the upper
limit stop is reached.
②  Press the AB button ▼ until the drive stops auto-
matically.
The upper end position has been set.
Optional: Activation of the relief function for the
upper stop; see chapter 5.6.2
③ Press the AB button ▼ again until the Venetian blind
has reached the lower end stop (run to lower end
stop).
The drive starts, stops briey and then moves on
(while the DOWN button ▼ is pushed).
The drive switches o󰀨 automatically when the lower
limit stop is reached.
④Press the AUF button ▲ until the drive stops auto-
matically.
The lower end position has been set.
Optional: Activation of the relief function for the
lower stop; see chapter 5.6.3
Setting of the end positions variant C is now complete.
6 | EN © elero GmbH
Relief function | End position settings
Changing / Deleting the end positions
1 Restore voltage supply after mains interruption.
2 From a middle Venetian blind position with the as-
sembly cable or a taught-in transmitter, push and
hold both direction buttons (▲ and ▼) at the same
time until the drive moves up and down briey.
The deletion of the setting of end position is completed.
The end positions can be programmed again.
5.6.5 Programme or delete further curtain
positions
Programme or delete interim positions:
see transmitter instructions
Programme or delete venting position:
see transmitter instructions
5.6.6 Four variants of end position settings
Four di󰀨erent combinations of end position settings are
possible. They must be selected sensibly according to the
technical requirements of the Venetian blind.
End position settings
(4 versions)
possible with
AUpper and lower end posi-
tion freely adjustable
T-strap, tapes,
belt
BFixed upper limit stop /
lower end position freely
adjustable
T-strap, tapes,
belt, limit plugs,
angle bracket
CFixed upper and lower limit
stop
Anti push-up device,
sti󰀨 shaft connector,
limit plugs, angle
bracket
DUpper end position freely
adjustable, xed lower limit
stop
Anti push-up device
5.6.7 Variant A: Upper and lower end position
freely adjustable
Variant A:
Upper and lower end position freely adjustable
① From a middle Venetian blind position with the
assembly cable or a taught-in transmitter, push the
UP button ▲ until the Venetian blind has reached
the desired end position.
The drive starts, stops briey and then moves on
(while the UP button ▲ is pushed).
Correction is possible with the buttons ▲ and ▼ .
② Press the AB button ▼ until the drive stops auto-
matically.
The upper end position has been set.
③ Press the AB button ▼ again until the Venetian
blind has reached the desired lower end stop.
The drive starts, stops briey and then moves
on (while the AB button ▼ is pushed).
Correction is possible with the buttons ▲ and ▼ .
④Press the AUF button ▲ until the drive stops
automatically.
The lower end position has been set.

5.6.10Variant D: Upper end position freely
adjustable, xed lower limit stop
Variant D: Upper end position freely adjustable,
xed lower limit stop
① From a middle Venetian blind position with the
assembly cable or a taught-in transmitter, push the
UP button ▲ until the Venetian blind has reached
the desired end position.
The drive starts, stops briey and then moves on
(while the button is pushed).
Correction is possible with the buttons ▲ and ▼ .
② Press the DOWN button ▼ until the drive stops
automatically.
The upper end position has been set.
③ Press the DOWN button ▼ again until the Venetian
blind has reached the lower end stop (run to lower
end stop).
The drive starts, stops briey and then moves on
(while the DOWN button ▼ is pushed).
The drive switches o󰀨 automatically when the lower
limit stop is reached.
④ Press the UP button ▲ until the drive stops
automatically.
The lower end position has been set.
Optional: Activation of the relief function for the
lower stop; see chapter 5.6.3
Setting of the end positions variant D is now complete.
5.7 Programming the transmitter
Important
Condition: The drive is in radio mode.
►If the end positions have not been taught-in, remove the
blind from the coiling shaft.
Programming (rst) transmitter
Instructions for action Result
1 Switch the mains o󰀨 and on
again.
The drive is then ready
to teach-in
for about 5 minutes.
2 Push the teaching button
Pon the transmitter to be
taught in for about 1 sec-
ond.
The status indicator
is lit. The drive is now
ready to teach-in
(running up/down) (for
about 2 minutes).
3 Press the UP button ▲ as
soon as the blind starts
moving in upwards direc-
tion (within 1 second at the
most).
The status indicator
is lit briey. The blind
stops briey, starts
moving again and then
moves downwards.
4Press the DOWN button
▼ as soon as the blind
starts moving in downwards
direction (within 1 second at
the most).
The status indicator is
lit briey. The drive will
stop.
The (rst) transmitter has been through the teach-in
procedure.
5.8 Programming (additional) transmitter
Programming possible for max. 16 transmitters
Programming (additional) transmitter
Instructions for action Result
1 On an already taught-in
transmitter, push the but-
tons UP ▲, DOWN ▼ and
the teaching button Pat
the same time for approx. 3
seconds.
The status indicator
is lit. The drive is in
programming mode
(movements up and
down).
(alternative to the above
line)
Switch the mains o and on
again.
The drive is then ready
to teach-in
for about 5 minutes.
2 Push the teaching button
Pon the transmitter to be
taught in (additionally).
The status indicator
is lit briey. The drive
is in teach-in mode
(running up/down) (for
about 2 minutes).
4Press the UP button ▲ on
the transmitter to be taught
in (additionally) as soon as
the blind starts moving in
upwards direction (within 1
second at the most).
The status indicator
is lit briey. The blind
stops briey, starts
moving again and then
moves downwards.
5Press the DOWN button
▼ on the transmitter to be
taught in (additionally) as
soon as the blind starts
moving in downwards
direction (within 1 second at
the most).
The status indicator is
lit briey. The drive will
stop.
The additional transmitter has been through the teach-in
procedure.
Stop bidirectional radio teaching mode:
Keep the STOP button pushed for at least 6 seconds until
the status display lights up (depending on transmitter).
5.9 Technical data
A summary of the main technical parameters, see the sepa-
rate overview "Technical Specications".
6 Troubleshooting
Problem /
Error
Possible
cause
Cure
Remedy
• Drive stops
during travel
• End positions
are not set
• Drive is in
setting mode
• Set end posi-
tions
• Drive stops
after a short
time
• End position
programmed
• Sluggish
shutter
• Set second
end position
• Check smooth
running of the
Venetian blind
• Drive runs only
in one direction
• Connection
error
• Check connec-
tion
• Drive not
responding
• No mains
voltage
• Temperature
limiter has
tripped
• Check mains
voltage
• Allow drive to
cool
© elero GmbH EN | 7
Relief function | End position settings | Programming transmitter

WARNING
Danger of injury due to electric current.
Electric shock possible.
►Physically disconnect power supply lines and discharge
charged energy storage. Wait for at least 5 minutes after
deactivation for the motor to cool down and the capaci-
tors to lose their voltage.
►Use suitable, tested and stable climbing aids when per-
forming disassembly work above body height.
►All work at the electrical system must only be performed
by the sta󰀨 described in the chapter "Safety instructions
for electrical installation".
Scrapping
During the scrapping of the product, the international,
national and regional-specic laws and regulations are to be
complied with.
Please make sure to consider material recyclability, ease of
dismantling, and separability of materials and components
as well as environmental and health hazards during recy-
cling and disposal.
CAUTION
Environmental damage at incorrect disposal
►Electronic scrap and electronic components are subject
to the hazardous waste rules and must only be disposed
of by approved specialist operation.
►Groups of materials such as plastics and metals of vari-
ous kinds are sorted for recycling and disposal process.
Dispose electrical and electronic components
Disposal and recycling of electric and electronic compo-
nents must comply with the applicable national laws and
regulations.
11 Notes on the EC declaration of
conformity
elero GmbH hereby declares that the tubular drive Rol-
Top-868 complies with the basic prerequisites and the other
relevant provisions of the EC directives. The complete
declaration of conformity can be found in the download area
of our website www.elero.com/downloads-service.
12 Technical data and dimensions
The indicated technical data are subject to tolerances (ac-
cording to the respective applicable standards).
8 | EN © elero GmbH
Troubleshooting | Manufacturer's address
Problem /
Error
Possible
cause
Cure
Remedy
• Drive does not
learn any end
positions
• Random travel
• Travel to end
position or limit
stop too short
• Delete end
positions
Reset end
positions
• Drive must run,
stop briey and
run on (while
a button is
pushed at the
elero assem-
bly cable or a
programmed
transmitter).
Fig. 8 Troubleshooting at the RolTop-868
7 Repair
The RolTop-868 is maintenance free.
8 Repair
Please contact your dealer if you have any questions.
Please always provide the following information:
• Item number and name on the type plate
• Type of fault
• Previous and unusual events
• Surrounding circumstances
• Own assumption
9 Manufacturer's address
elero GmbH
Antriebstechnik
Maybachstr. 30
73278 Schlierbach
Deutschland / Germany
Phone: [phone]
Fax: [phone]
[email protected]
www.elero.com
Please visit our website if you require a contact outside
Germany.
10 Disassembly and disposal
Dispose of the packaging according to current regulations.
Dispose the product after previous use in accordance with
applicable regulations. Disposal is partially subject to stat-
utory provisions. The goods to be disposed of must only be
delivered to authorised acceptance points.
Environmental information
No unnecessary packaging was used. The packaging can
be easily divided into three material types: Cardboard (box),
Styrofoam (padding) and polyethylene (bag, foam material
protective foil).
The device is made up of materials that can be reused if it
is disassembled by a specialist operation. Please observe
the local provisions on disposal of packaging material and
old devices.
Always expect additional danger that does not occur in
operation during disassembly.

12.1 RevoLine S-868
© elero GmbH EN | 9
Technical data and dimensions
Type S1,5/70
-868
S3/30
-868
S5/30
-868
S5
-868
S8
-868
S10
-868 FL
S12
-868 FL
S12/11
-868 FL
Rolller shutter ■ ■ ■ ■ ■ ■
Roller blind ■ ■ ■ ■ ■ ■ ■ ■
Noiseless soft brake ■ ■ ■ ■ ■ - - -
Operating Voltage [V] 1 ~ 230 1 ~ 230 1 ~ 230 1 ~ 230 1 ~ 230 1 ~ 230 1 ~ 230 1 ~ 230
Frequency [Hz] 50 50 50 50 50 50 50 50
Max. torque [Nm] 1,5 3 5 5 8 10 12 12
Speed [1/min] 70 30 30 17 17 17 17 11
Current [A] 0,55 0,55 0,73 0,55 0,73 0,55 0,73 0,55
Power [W] 130 130 168 130 168 130 168 130
Shaft Ø [mm] 38 38 38 38 38 38 38 38
Max. limit switch range
in revolutions of the shaft 160 80 40 40 40 40 40 40
Ingress protection (IP-Code) 44 44 44 44 44 44 44 44
Operating mode (min S2) 5 5 4 5 4 4 4 4
Transmission frequency [MHz] 868 band
Transmission power [mW] |
[dBm ] ≤ 500 | ≤ 10
Length C [mm] 534 534 534 534 534 514 534 514
Length D [mm] 517 517 517 517 517 497 517 497
Length E [mm] 11 11 11 11 11 11 11 11
Weight [kg] 1,3 1,2 1,3 1,2 1,3 1,2 1,4 1,2
Temperature range [°C] -20 ... 60 -20 ... 60 -20 ... 60 -20 ... 60 -20 ... 60 -20 ... 60 -20 ... 60 -20 ... 60
Protection class I
■ ■ ■ ■ ■ ■ ■ ■
Conformity (CE marking) ■ ■ ■ ■ ■ ■ ■ ■
VDE seal of approval ■ ■ ■ ■ ■ ■ ■ ■
EMV proof ■ ■ ■ ■ ■ ■ ■ ■
Item Number (round head /
star head) 302220006 302120006 302320006
302340006 302540006 308240006 308140006 30816006
C
E
D
33
CDE
Drehzahl
RolTop/V ari Eco S1,5 70/84 534 517 11
RolTop/V ari Eco S3 30/36 534 517 11
RolTop/V ari Eco S5 (17)/19/20 534 517 11
RolTop S7 30
RolTop/V ari Eco S8 (17)/-/- 534 517 11
RolTop/V ari Eco S12 (17)/19/20 534 517 11
RolTop/V ari Eco S10 514 497 11
Baugröße Typ
Maße mit und ohne Funk
C
E
D
33
35
O
35
O
O
39
O
39

10 | EN © elero GmbH
Technical data and dimensions
12.2 RevoLine M-868
Build / Type RolTop
M4/60-868
RH
RolTop
M6/35-868
RH
RolTop
M7/23-868
RH
RolTop
M9/35-868
RH
RolTop
M10-868
RH
RolTop
M12/23-868
RH
RolTop
M20-868
RH
RolTop
M30-868
RH
Rated voltage (V) 1 ~ 230
Rated frequency (Hz) 50
Noiseless soft brake – • –
High-speed door • – • –
Rated torque (Nm) 4 6 7 9 10 12 20 30
Rated speed (rpm) 60 35 23 35 14 23 14
Rated current (A) 0.9 0.6 0.9 0.6 0.9
Rated power consumption (W) 200 140 200 140 200
Shaft diameter (mm) 50
Protection class (IP) 44
Limit switch range (turns) 40
Operating duration (min S2) 4 5 4 5 4
Transmission frequency [MHz] 868
Transmission power [mW] ≤ 500
Length A (mm) 540 480 530 480 530 540 530
Length B (mm) 523 462 512 462 513 523 512
Weight (kg) 2.2 1.9 2.3 1.9 2.2 2.3
Operating environment temperature
(°C) – 20 to +60
Conformity
Emission sound pressure level
(dBA) < 70
Protection class I •
Plug-in connecting cable (m) 2.0
Item number 38 460.0006 38 438.0006 38 226.0006 38 448.0006 38 222.0006 38 236.0006 38 232.0006 38 242.0006
Baugröße / Typ M6
-868
M7/23
-868
M10
-868
M10-K
-868
M12/23
-868
M20
-868
M30
-868
M40
-868
M50
-868
Rated torque [Nm] 6 7 10 10 12 20 30 40 50
Rated speed [1/min] 14 23 14 14 23 14 14 14 14
Rated voltage [V] 1 ~ 230 230 ... 240 1 ~ 230 1 ~ 230 1 ~ 230 1 ~ 230 1 ~ 230 1 ~ 230 1 ~ 230
Rated frequency [Hz] 50 50 50 50 50 50 50 50 50
Noiseless soft brake ■ ■ ■ ■ ■ ■ - - -
Rated current [A] 0,52 0,60 0,60 0,60 0,90 0,90 0,90 1,20 1,30
Rated power consumption
[W] 118 140 140 140 200 200 200 270 300
Shaft diameter [mm] 50 50 50 50 50 50 50 50 50
Ingress protection (IP-Code) 44 44 44 44 44 44 44 44 44
Limit switch range (turns) 40 40 40 40 40 40 40 40 40
Operating duration (min S2) 4 5 5 4 4 4 4 5 4
Transmission frequency
[MHz] band 868 868 868 868 868 868 868 868 868
Transmission power
[mW] | [dBm]
≤ 500 |
≤ 10
≤ 500 |
≤ 10
≤ 500 |
≤ 10
≤ 500 |
≤ 10
≤ 500 |
≤ 10
≤ 500 |
≤ 10
≤ 500 |
≤ 10
≤ 500 |
≤ 10
≤ 500 |
≤ 10
Length C [mm] 446 466 466 391 526 526 516 546 546
Length D [mm] 429 449 449 374 509 509 499 529 529
Length E [mm]
(elero, round head, starhead) 14 | 12 | 19 14 | 12 | 19 14 | 12 | 19 14 | 12 | 19 14 | 12 | 19 14 | 12 | 19 14 | 12 | 19 14 | 12 | 19 14 | 12 | 19
Weight [kg] 1,6 1,7 1,7 1,5 1,9 2,1 2,3 2,6 3,1
Operating environment
temperature [°C] -20 ... 60 -20 ... 60 -20 ... 60 -20 ... 60 -20 ... 60 -20 ... 60 -20 ... 60 -20 ... 60 -20 ... 60
Protedction class I
■ ■ ■ ■ ■ ■ ■ ■ ■
Conformity , ■, ■ ■, ■ ■, ■ ■, ■ ■, ■ ■, ■ ■, ■ ■, ■ ■, ■
Connecting cable pluggable
[m] 2,0 2,0 2,0 2,0 2,0 2,0 2,0 2,0 2,0
Item number (elero,
round head,
starhead)
343020006
393020006
342260006
382260006
342220006
382220006
392220006
341120006
381120006
342350001
382350001
342320006
382320006
392320006
342420006
382420006
392420006
342520006
392520006
342620006
392620006
33
D
C
E
Stator FE C D E Motorrohr
Rol/Sun/Vari
381 364 elero=14 339
391 374 RH=12 349
456 439 SH=19 414
466 449 424
486 469 444
526 509 484
546 529 504
RolTop M1,8/138 RH Neher 384493401 120 556 539 514
RolTop M1,8/138-868 RH Nehe r 384403406 120
D= C-17mm (halbe Kupplung)
Baugröße Typ
55
C
D
E
E
45
O
55
C
D
33
33
C
D
33
E
45
O
45
O
45
O
C
D
33
45
O
O
57,5
E
C
D
33
45
O
O
57,5
E
29
O
49,5
O
49,5
33
D
C
E
Stator FE C D E Motorrohr
Rol/Sun/Vari
381 364 el e ro=14 339
391 374 RH=12 349
456 439 SH=19 414
466 449 424
486 469 444
526 509 484
546 529 504
RolTop M1,8/138 RH Neher 384493401 120 556 539 514
RolTop M1,8/138-868 RH Nehe r 384403406 120
D= C-17mm (halbe Kupplung)
Baugröße Typ
55
C
D
E
E
45
O
55
C
D
33
33
C
D
33
E
45
O
45
O
45
O
C
D
33
45
O
O
57,5
E
C
D
33
45
O
O
57,5
E
29
O
49,5
O
49,5

© elero GmbH EN | 11
Technical data and dimensions
12.3 RevoLine M-868
12.4 RevoLine s_onro M-868
33
D
C
E
Stator FE C D E Motorrohr
Rol/Sun/Vari
381 364 elero=14 339
391 374 RH=12 349
456 439 SH=19 414
466 449 424
486 469 444
526 509 484
546 529 504
RolTop M1,8/138 RH Neher 384493401 120 556 539 514
RolTop M1,8/138-868 RH Nehe r 384403406 120
D= C-17mm (halbe Kupplung)
Baugröße Typ
55
C
D
E
E
45
O
55
C
D
33
33
C
D
33
E
45
O
45
O
45
O
C
D
33
45
O
O
57,5
E
C
D
33
45
O
O
57,5
E
29
O
49,5
O
49,5
Baugröße/Typ RolTop s_onro
M10-868
RolTop s_onro
M20-868
RolTop s_onro
M30-868
Rated voltage (V) 230 - 240 1 ~ 230 1 ~ 230
Rated frequency (Hz) 50 50 50
Noiseless soft brake • • –
Rated torque (Nm) 10 20 30
Rated speed (1/min) 14 14 14
Rated current (A) 0,60 0,90 0,90
Rated power consumption (W) 140 200 200
Shaft diameter (mm) 50 50 50
Protection class (IP) 44 44 44
Limit switch range (turns) 40 40 40
Transmission frequency [MHz] band 868 868 868
Transmission power [mW] | [dBm] ≤ 500 | ≤ 10 ≤ 500 | ≤ 10 ≤ 500 | ≤ 10
Operation duration (min S2) 5 4 4
Length C (mm) 466 526 516
Lenght D (mm) 449 509 499
Length E (mm) elero head 14 14 14
Weight (kg) 1,9 2,2 2,3
Operation environment temperature (°C) – 20 bis +60 – 20 bis +60 – 20 bis +60
Confomity • | • • | • • | •
Emission sound pressure level (dBA) < 70 < 70 < 70
Protection class I • • •
Plug-in connecting (m) 2,0 2,0 2,0
Item number elero head 34 222.5606 34 232.5606 342425606

We reserve the right to make technical changes
elero GmbH
Antriebstechnik
Maybachstr. 30
73278 Schlierbach
[email protected]
www.elero.com
Build / Type RolTop
L60-868
RolTop
L80-868
Rated voltage (V) 1 ~ 230
Rated frequency (Hz) 50
Noiseless soft brake –
Sunblind with free ride • – • –
Rated torque (Nm) 60 80
Rated speed (rpm) 14
Rated current (A) 1.9 2.0
Rated power consumption (W) 430 470
Shaft diameter (mm) 63
Protection class (IP) 44
Limit switch range (turns) 40
Operating duration (min S2) 4
Transmission frequency [MHz] band 868
Transmission power [mW] | [dBm] ≤ 500 | ≤ 10
Length C (mm) 575
Length D (mm) 558
Length E (mm) 14
Weight (kg) 3.3 3.6
Operating environment temperature
(°C) – 20 to +60
Emission sound pressure level
(dBA) < 70
Protection class I •
Plug-in connecting cable (m) 2.0
Item number 36 732.0006 36 732.0076 36 742.0006 36 742.0076
C
D
14E=
55
O
L60-80
C
D
14E=
55
O
C
D
16E=
58,6
O
L40 DC
(Rohrdurchmesser!)
33
555555
33
33
12.5 RevoLine L-868
