Manual Pull-Down Screen
Elite Manual Series
USER’S GUIDE

www.elitescreens.co
m
/
eliteinfo
@
elitescreens.com
Rev. 1.3
MATTE WHITE
Pre-installation
1. Carefully unpack the screen
2. Always handle the screen on a clean and level surface.
OPTIONAL ACCESSORIES: L-Brackets and Mounting Screws.
a: Vertical hooks suspend the screen from the L-bracket wall mounts” They are secured in place
with a nut. (c)
b: Wall-screw secures the L- bracket to either drywall or wall-studs.
c: Nut secures the end of the vertical hook (a) and holds it into place.
d: D-bolts allow the option to mount the L-bracket to concrete walls. These are to be used in
lieu of the wall-screw when mounting on concrete surfaces or hanging up larger screens greater
than or equal to 3.05m (120”) in diagonal screen width.
e: Hollow wall (or drywall) anchors receive the wall-screw (b) when mounting the L-bracket
directly to drywall only.
f: Washers are used between the L-bracket and the head of the wood-screw (b) or D-bolt (d) to
spread out the weight on the L-bracket and provide additional stability
Warning: The L-brackets, and mounting screws are
an optional accessory. Models may vary and anchors
will not support all models. Elite will not be liable for
improper installation. Please visit your local hardware
store for additional dry wall anchors.

www.elitescreens.co
m
/
eliteinfo
@
elitescreens.com
Rev. 1.3
Installation
Flush Wall Mounting
1. Using a tape measure, mark the keyholes that are located at the back of the screen’s case
end cap. 2. After marking the area and predrilled hole, insert the screw and leave the
screw’s head out about 4mm (1/8”) from the wall to mount the screen on. (Fig. 1)
Fig. 1
Ceiling Mounted (additional hardware required)
Optional installation using a chain to hang the screen from the ceiling.
Fig. 2
2. You can also hang the screen on a ceiling by using a chain with s-hooks (not included)
through the two loops located on each end of the case as shown on (Fig. 2).
Loops

www.elitescreens.co
m
/
eliteinfo
@
elitescreens.com
Rev. 1.3
Optional “L” Bracket diagram
“L” Bracket accessories
6-3/4” Length
1” Width
6 3/4”
Height
Top of “L” bracket from top view
Find the studs on
your wall or use
drywall anchors to
install L brackets to
the desired location.
Masonry/Cement wall installation:
Use “D” bolts provided for installing
your screen on a cement wall as shown
on Fig. 4.
Wood/Dry Wall installation: Use “B”
wood screws provided for installation on
wood studs on wall. Or use “E” hollow wall
anchors provided in conjunction with the
wood screws for dry wall installation as
shown on Fig. 3.
Fig. 3
Fig. 4
Use the hooks (A)
provided with the L
bracket kit to hang the
screen by its suspension
rings on its end caps.
Use the hooks (A)
provided with the L
bracket kit to hang the
screen by its suspension
rings on its end caps.

www.elitescreens.co
m
/
eliteinfo
@
elitescreens.com
Rev. 1.3
SCREEN OPERATION
Note: Always pull the screen down or let it up in either a steep incline or a 90-degree vertical
angle. Do not allow the screen to touch the screen case when the screen goes up or comes down
to avoid damaging the screen material.
1. Pull the screen down with the lanyard or by the handle at either a sharp incline or in a 90-
degree angle. Do not attempt to pull the screen down by its material or touch the screen, as it will
cause damage and likely void the warranty. (Fig. 5)
Note: An internal auto-lock mechanism system will cause the screen to stop and lock on the
desired position at intervals.
2. If you want the screen to retract back, simply pull the screen down more than 5cm (2”) and
retract the screen back by guiding the retracting material in a swift but gentle motion. (Fig. 6) (It
is ideal to release at a 90-degree angle and do not let go until the screen is entirely inside the case)
Note: Improperly bringing the screen up/down will damage the screen material or rolling
system.
Fig. 6
Fi
g
. 5

www.elitescreens.co
m
/
eliteinfo
@
elitescreens.com
Rev. 1.3
Maintenance
Clean matte white screen material with a soft cloth and mild soap with water.
When not in use, retract screen in its housing to keep the surface clean.
NOTE:
Regardless of mounting method, the screen should be securely supported so that
vibration or even abusive pulling on the viewing surface will not cause the case to work
loose or fall. The installer must insure that the fasteners used are of adequate strength
and suitable for the mounting surface chosen.
Warranty Policy - Manual, Tripod, Pull-up Floor, and Fixed Frame Screens
*Warranty policy applies to claims made in the United States of America. Warranty issues outside of the
US must go through their international distributor.
•Two (2) year warranty parts and labor from purchase date as follows (except for refurbished units as
specified below):
•Refurbished units carry a 90-day parts and labor warranty.
•Demo units or open box items are AS IS items and do not carry a warranty.
•Elite Screens will cover ground shipping charges on warranty claims made within 7 days of receiving
per our DOA (Defective On Arrival) policy
•Each party will be responsible for one way shipping during the regular warranty period if the claim
is made after the 7 day DOA period.
•An RMA (Return Merchandise Authorization) number must be issued in order to process a
replacement. Elite Screens will either replace or repair the defective unit with a brand new
replacement *(see exceptions below) after the defective unit is received and/or confirmed defective.
Once the product is received, Elite Screens will send out a new *unit to the customer by ground
service (subject to inventory availability).
•Missing Parts must be reported within the 7-days of receipt. If reported after 7 days, customer will
only be responsible for shipping and handling fees. If reported after 30 days of receipt, the customer
is responsible for cost of the parts and shipping & handling fees.
Please visit the link below for full warranty information
http://www.elitescreens.com/service.htm
*A new or refurbished replacement will be sent out to the customer depending on the type of purchase (new or
refurbished) and is based on stock availability.

www.elitescreens.co
m
/
eliteinfo
@
elitescreens.com
Rev. 1.3
TWO WAY TO REGISTER YOUR WARRANTY WITH ELITE SCREENS INC.
A. On Line (Faster and Easier) www.elitescreens.com/register.html
B. Fill out & Fax to [phone], Attn: Customer Service Dept.
*Your Name: _______________________________________________________
Address: ____________________________________________________________
City/State/Zip ________________________________________________________
*Email Address: ______________________________________________________
*Phone: _____________________________________________________________
*Screen Model: _______________________________________________________
*Serial Number: _______________________________________________________
*Date of Purchase: _____________________________________________________
*Dealer / Reseller Purchased from (name of the reseller): _____________________
What is your Projector Model :____________________________________________
Application: ___ Home ___ Education ____ Corporation _____ Government
___ Others
How would you rate this screen? ___ Excellent ___ Good ___ Ok ___ Improvement needed
Comments:
Contact info:
If you have pictures of your screen you’d like to share with us, please email your pictures to [e-mail]
or call us at 877-511-1211
www.elitescreens.com
For any technical inquiries,
[email protected]
