Elite Screens Spectrum Series User manual

Rev. BR030218 www.elitescreens.com 1
Spectrum Series
Electric/Motorized Projection Screen
User Guide
Important Safety & Warning Precautions
Make sure to read this user’s guide and follow the procedure below.
Caution: The screen’s Black Top Drop is already set to its maximum drop distance. There is NO extra Black
Top Drop in the roller. Please be aware of this, as it will void your warranty with Elite Screens. Unapproved
changes or modifications (except for cutting the power cord for hardwire installations) to this unit are
prohibited and will void your warranty. For more information, please contact our Technical Support
Department at [phone] Ext. 604.
•Please retain this user’s guide for future reference.
•To avoid damaging the unit, do not use with any unauthorized accessories not recommended by the
manufacturer.
•Handle the unit carefully during transportation to avoid any damages.
•To ensure safe and reliable operation, direct connection to a properly grounded power source is advised.
•The power outlet supplying power to the unit should be close to the unit and easily accessible.
•Do not install the unit on uneven or inclined surfaces.
•Do not put heavy objects on the power cord and position it properly to avoid creating a trip obstacle.
•Never overload the power cord to prevent an electric shock or fire due to a loose contact or a short circuit.
•There are not user serviceable parts in this unit. Do not attempt to disassemble this unit by yourself. No one
except authorized technicians can open and make repairs to this unit.
•Make sure the power source this unit is connected to has a continuous power flow.
•If there is need to use an extension cord, make sure the cord has an equal rating as the appliance to avoid
overheat.
•Do not handle the power plug when your hands are wet or your feet are in contact with water.
Do not use this unit under the following circumstances.
•Disconnect the power cord under the conditions of heavy rain, wind, thunder or lightning.
•Avoid direct Sunshine, rain shower and moisture.
•Keep away from fire sources and high temperature to prevent this device from overheating.
•Cut off the power supply first before transportation or maintenance.
•Fully disconnect from the power supply when the unit is not in use for a long period of time, as should be done
with any other electric household appliance.
•To avoid possible injury and/or an electric shock, do not attempt to use the screen if there is obvious damage
or if there are any evident broken parts.

Rev. BR030218 www.elitescreens.com 2
Installation Warning
Individual modifications to this product are prohibited and will void the warranty with the manufacturer. Please
contact Elite Screens Customer Service for any questions.
NOTE:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that the interference will not occur on a particular installation. If this equipment causes
harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following measures.
Reorient or relocate the receiving antenna of the device which may be casing the interference.
Increase the separation between the screen and the device’s receiver.
Connect the equipment into a different power outlet other than the device
Pre-Installation
1. Carefully unpack the screen.
2. Always handle the screen in a leveled position on a clean surface.
3. In order to protect the screen from exposure to stains, keep the screen out of contact with foreign particles such
as dust, sawdust, and/or liquids.
Accessories List
A. IR remote x 1
B. 3-way wall
switch x 1
C. 12-volt trigger
cable x 1
D. Bubble level x 1
E. AAA batteries x 2

Rev. BR030218 www.elitescreens.com 3
Control System
1. 5-12V Trigger: The built-in 5-12V trigger input
allows your screen to synchronize its drop & rise with
the projector’s power cycle. The screen deploys when
the projector powers up and will retract when the
projector powers down. The 5-12 volt adaptor
connects to your projector’s trigger output via a
separate cable that may or may not be provided by the
manufacturer of the projector. The trigger feature will
not work without an output cable from the projector,
but it can be tested by connecting the Red (+) and
Green (-) cable to a 9-volt battery.
3-prong power cable
RJ-45 input for 5-12V Trigger
Red: DC 12 +
Green: 0 V -
5-12 Volt Trigger Cable
IR
“Eye”
Receiver
4. IR Remote Control: The Infrared
functions by direct line of sight contact
with a beam range of 30 feet.
5. RF Remote Control: (sold separately)
The radio waves eliminate the need for a direct
line of sight with a range of 150 feet.
2. 3 -Way Wall Switch: The 3-way wall
switch is a wall mount control box with an
up/stop/down button and plugs directly
into the screen’s RJ-45 input.
3. IR “Eye” Receiver: (sold separately) The IR “Eye”
Receiver plugs directly into the screen’s RJ-45 input to
present a low profile line-of-sight control option for your IR
remote control even in a recessed ceiling installation.
Installation Instructions
Please consult a professional installer. Elite Screens is not liable for any faulty installations.
1. Select the installation location for your screen. Ensure that it is within reasonable proximity from your power source.
2. For best support of your screen, it is ideal to secure your screen into the studs of your house’s internal framework. If studs are
not available, use hollow anchors for mounting your wall screws into drywall. If you’re installing in a concrete structure, use
concrete bolts to secure your screen.
Always consult a professional installer or hardware professional to ensure that the proper screws and/or hardware are being used.
3. Ensure that both brackets are in perfect level alignment with one another. Use wall/ceiling wood screws to secure to the wood
studs. Use hollow anchors if mounting in drywall.
4. The screen casing is designed to accept the wall screws directly. If not using the Optional L-Brackets
http://www.elitescreens.com/lbracket1, be sure to position the washer between the head of the wall-screw and the anchor slots on
the screen’s casing.
UP
Stop
Down
3-way Wall Switch
Note: The IR Remote
MUST be within direct
line of sight to the
sensor to function.
See figure to the left.

Rev. BR030218 www.elitescreens.com 4
For local Elite Screens contact or Technical Support, please visit
www.elitescreens.com
Fig. 1
Optional installation method using the drill holes to hang the screen from the ceiling
Note:
Wall screws included with this product are
complementary and may not be adequate for all
mounting surfaces. Consult with a professional installer
or hardware store for proper mounting screws and
anchors.
Regardless of the mounting method, the screen should be
securely supported so that the vibration or pulling on the
viewing surface will not cause the screen case to become
loose or fall. The installer must ensure that proper
mounting hardware and the fasteners used are of
adequate strength and suitable for the mounting surface.
Screws
5. Using a tape measure, mark the keyholes that are located at the back of the screen’s casing end cap.
6. After marking the area and predrilled hole, insert the screw and have at least 1/8” from the wall to mount the screen. (See
example in Figure 1.)
7. Figure 2
will show you an optional installation method using the drill holes located on top of the end caps for ceiling
installation.
