13.8Vdc Switch Mode Power Supply
GEN3-08-y
#
for 8Ah B ttery nd up to 1.0A* Continuous Lo d Current
GEN3-18-y
#
for 18Ah B ttery nd up to 1.5A* Continuous Lo d Current
F EATURES
High efficiency cost effective power supply suitable for use in systems designed to comply with
PD6662:2017 and EN50131-6:2017 Grade 3 and Environmental Class II. Rated to provide continuous
current to load for systems requiring 12h standby from a battery. Three independent output signals
are provided for loss of mains fault (EPS**), battery fault (APS**), and power supply fault (GEN).
Comprehensive self-diagnostics can detect blown output and battery fuses, battery fail, low battery
voltage, battery missing and low output voltage. The PSU incorporates intelligent battery
management comprising active full load battery testing, low battery voltage detection and deep
discharge protection to ensure that the battery is not permanently damaged through excessive
discharge. A brownout filter ensures that short mains voltage dips do not create a false loss of mains
alarm. Two LEDs assist with quick and easy installation by showing presence of mains, correct battery
charging or a fault condition. Comprehensive protection is built-in as standard including mains
transient filtering, electronic output overload protection and fuses on the load and battery outputs.
•PD6662:2017 and EN50131-6:2017
Type A Grade 3 Environmental Class II
Compliant
•Intelligent active battery monitoring
•Low quiescent battery monitoring current
during standby operation
•Fault signals for loss of mains, battery fail
and power supply fault
•Battery deep discharge protection
•Battery overvoltage protection
•Protection against reverse battery connection
•Electronic overload protection shuts down
output until overload or short circuit is
removed (while on mains power)
•LED for comprehensive diagnostics
•Mains transient suppression and brown-out
filter
•Fully enclosed lid and removal from wall
tamper circuit.
#
“y” Denotes enclosure size – see overleaf
* See table overleaf to determine continuous standby battery current available for given standby times
** EN50131 Definitions: EPS = External Power Source APS = Alternative Power Source
Elmdene International Ltd Tel: [phone]
3 Keel Close, Interchange Park, Fax: [phone]
Portsmouth, Hampshire, PO3 5QD, UK  Web: www.elmdene.co.uk

2
Technical Support: [phone] (option 3) PAK200546 03A Mar 2020 ©2020 ELMDENE INTERNATIONAL LTD
S PECIFICATION
M ins Input
Rated Voltage / (Operational Voltage) 100-240Vac / (90 – 265Vac)
Frequency 50/60Hz
Input current GEN3-08 & GEN3-18 < 1.0A at full load
Fuse T2A 20mm HRC
Output
GEN3
-
08
-
y
GEN3
-
18
-
y
Volt ge t full lo d
Mains power
Battery standby
13.2 –14.2Vdc (13.8Vdc nominal)
9.8 – 13.0Vdc
Ripp
le
<4
00mV
p
k
–
pk max @ Rated Voltage
Fuse:
Load
Battery
F1.0A
F1.0A
F1.6A
F1.6A
Continuous Output Current
*
Mains
Battery for 12 hours
30 hours
60 hours
1.0 A
0.60A with 8Ah Battery
0.26A with 8Ah Battery
0.13A with 8Ah Battery
1.5A
1.5A with 18Ah Battery
0.6A with 18Ah Battery
0.3A with 18Ah Battery
*See below for quiescent current of PSU under battery when calculating total system standby current resources.
Mech nic l
Product Reference
GEN3
-
08
-
A
GEN3
-
08
-
B
GEN3-18-B
GEN3
-
08
-
C
GEN3-18-C
Enclosure Dimensions
w x h x d (mm)
230 x 200 x 80
355 x 330 x 80
330x 275 x 80
Weight (kg)
excluding battery
2.0
4.0
3.3
M teri l
1.2mm steel white powder coated
Environment l
Temperature -10 to +40°C (operating) 75% RH non-condensing
-20 to +80°C (storage)
Installation environment: Intended for internal / indoor installation only.
St ndby B ttery M n gement Warning: risk of explosion if incorrect battery type fitted
Maximum Battery Size GEN3-08: 8 Ah 12V Valve Regulated Lead Acid
(Not supplied with unit) GEN3-18: 18Ah 12V Valve Regulated Lead Acid
Intelligent Battery Recharge Time: < 24 hours to 80% - If a heavily discharged battery, having a
terminal voltage > 9.0V, is connected the PSU will attempt to
charge it. If battery fails to accept charge in 24 hours it will fail
the active load test.
Minimum energy level: (EN50131-6 2017 §6.0 ref. y’) Percentage of SD (battery) rated
capacity available to support the load = 100% (8Ah or 18Ah)
Testing: Battery not Present: <9.0V battery voltage
Low battery voltage: <11.6V (no mains present)
Active load test at full rated output current
Protection: Reverse battery connection protection
Overvoltage protection - Trips at 125% of rated O/P voltage
Deep discharge protection - Battery disconnect at 10.5V battery
terminal voltage
Quiescent Current: 64mA when running on battery - less than 1mA after deep
discharge protection.
Battery Cold Start (BCS) Momentarily link BCS pins together to connect battery to load if
PSU commissioned without any mains

3
Technical Support: [phone] (option 3) PAK200546 03A Mar 2020 ©2020 ELMDENE INTERNATIONAL LTD
S IGNALLING O UTPUTS
Rating: 0.10A @ 60Vdc 16Ω solid state relay contacts, volt free.
EPS Fault: Open if Loss of mains for >10s
GEN Fault: Open if Output voltage < 9.0V, or
Output short circuit, or Output fuse blown
APS Fault: Open if Battery terminal voltage < 11.6V, or
Active Battery Monitoring detects a failed battery, battery fuse blown or
battery not present.
Tamper: 0.5A @ 30Vdc volt free contact. Open when lid is open or
unit removed from mounting surface.
C ONNECTIONS
O/P +, - Connection to equipment to be powered (Observe polarity)
EPS (FAULT) Relay output for mains fail. Open if loss of mains.
GEN (FAULT) Relay output for General Fault. Open in fault condition
BATT +, - Connection to standby battery. Use cables provided (Observe polarity)
APS (FAULT) Relay output for battery fail. Open if battery fail or low voltage
I NSTALLATION AND C OMMISSIONING
This unit is only suitable for installation as permanently connected equipment. This PSU is NOT SUITABLE for
external installation. EQUIPMENT MUST BE EARTHED. Before installation, ensure that external disconnect
device is OFF.The PSU should be installed according to all relevant safety regulations applicable to the
application.
Fig 1 Mounting of Power Supply
L E N
Min 10cm clearance
Fasten cables
using cable tie
3A min
FUSED
SPUR
Load output cable:
Current rating to
match maximum load
Mains Input cable rated:
3A, 300Vac minimum

4
Technical Support: [phone] (option 3) PAK200546 03A Mar 2020 ©2020 ELMDENE INTERNATIONAL LTD
Mounting
1) Site power supply unit allowing minimum clearance – see Fig. 1.0
2) Ensure that the rear tamper is not in a position that will affect its operation, for example over a mortar
course, recess or raised area on the wall.
3) Route mains and LV output cables via different knockouts and/or cable entry holes.
4) Use bushes and cable glands rated to UL94 HB minimum.
M ins Power Up
5) Attach correctly rated mains cable (minimum 0.5mm
2
[3A], 300/500Vac). Fasten with cable ties.
6) Apply mains power.
Check for 13.8V on load outputs.
Check green Mains LED is ON.
7) Disconnect mains power.
Lo d Output
8) Loop correctly rated load cable through supplied ferrite (1 turn) and attach to terminal block, note
polarity. Fasten with cable ties.
Fig 2 Position of ferrite
9) Apply mains power.
Check Green Mains LED is ON.
NOTE: Red Fault LED may flash to indicate no battery has been connected, this is normal, refer to
diagnostic table on page 7.
Verify load is operating correctly.
10) Disconnect mains power.
Sign lling
11) Connect EPS, APS and GEN fault outputs to appropriate inputs of control and indicating equipment (CIE).
St ndby B ttery
12) Attach supplied battery cables to terminal block and batteries.
NOTE: ensure correct polarity of battery connections: +ve use Red lead, -ve use Bl ck lead.
13) Position the battery as shown in Figures 3 - 7 below, avoiding the cover earth connection spades and
the cover retaining screws. Fold up ‘Tabs’ to locate battery and secure with the rubber band supplied.
Fig 3 GEN3-08-A
Battery
Fold up ‘Tabs’ to locate
battery and secure with the
rubber band supplied

5
Technical Support: [phone] (option 3) PAK200546 03A Mar 2020 ©2020 ELMDENE INTERNATIONAL LTD
Fold up ‘Tabs’ to locate
battery and secure with
the rubber band supplied
Fold up ‘Tabs’ to locate
battery and secure with the
rubber band supplied
Fig 4 GEN3-18-B Fig 5 GEN3-08-B
Fig 6 GEN3-18-C Fig 7 GEN3-08-C
14) Apply mains power.
Check that Green Mains LED is ON.
Check there is no fault indicated by the Red Fault LED, refer to diagnostic table on page 7.
15) Disconnect mains power.
Check that the battery continues to supply voltage and current to the output load.
Check that Green Mains LED is OFF and the control panel displays a Loss of Mains (EPS) fault
NOTE: The battery must have sufficient charge to supply the output load
16) Reconnect mains power.
Check that Green LED is ON.
17) Disconnect battery.
Check that Red Fault LED is indicating a fault, refer to diagnostic table on page 7, and that the
control panel is showing an APS fault.
18) Reconnect battery.
Check there is no fault indicated by the Red Fault LED, refer to diagnostic table on page 7, and
that the control panel is not showing an APS fault.
19) Remove Output fuse.
Check that Red Fault LED is indicating a fault, refer to diagnostic table on page 7, and that the
control panel shows a General PSU fault.
20) Replace Output fuse.
Check that Red Fault LED is OFF
Check that EPS, APS and GEN Fault signals (if connected) are cleared at the control panel.
Battery
Battery
Battery
Fold up ‘Tabs’ to locate
battery and secure with
the rubber band supplied
Fold up ‘Tabs’ to locate
battery and secure with
the rubber band supplied
Battery

6
Technical Support: [phone] (option 3) PAK200546 03A Mar 2020 ©2020 ELMDENE INTERNATIONAL LTD
T mper
21) Connect tamper switch to appropriate inputs of control and indicating equipment (CIE).
Fig 8 Position of tamper assembly on ‘hinged lid’ style enclosures
Fig 9 Position of tamper assembly on ‘clam shell’ style enclosures
22) Close the lid and fasten with screw supplied. Alternatively for ‘clam shell’ style fit the cover in place,
the correct orientation is with the cover retaining feature engaging over the bottom lip of the base,
fasten with screws supplied.
23) With the unit mounted on the wall check that the rear tamper is not in a position that will affect its
operation, for example over a mortar course, recess or raised area on the wall.
Check that the tamper switch is:
CLOSED when the lid/cover is closed and the retaining screws are fitted,
OPEN when the retaining screws are removed and the lid/cover is open.
Use fine adjustment screw if necessary to align indicator with set point.
24) Close the lid/cover and fasten.
25) Re-check tamper circuit is closed at the control panel.
Lid Fixing Screw
(Sets tamper switch)
Tamper
Switch
Connections
Lid Fixing Screw
(Sets tamper switch)
Tamper
switch
Connection
s
Fine adjustment screw
Set position indicator
Set position indicator
Fine adjustment scre
w

7
Technical Support: [phone] (option 3) PAK200546 03A Mar 2020 ©2020 ELMDENE INTERNATIONAL LTD
O PERATING I NSTRUCTIONS
In the event of loss of mains, a battery fault or a GEN fault, the corresponding Fault signal contacts will open.
If the output of the PSU fails, the cause of the failure should be investigated e.g. short circuit load,
connection of a deeply discharged battery. The fault should be rectified before restoring power to the PSU. If
any of the fuses require replacing, ensure the correct fuse rating and type is used.
M AINTENANCE
This unit is intended for use by Service Personnel only. There are NO USER SERVICEABLE parts inside.
There is no regular maintenance required of the PSU other than periodic testing, and replacement of the
standby battery. Reference should be made to the battery manufacturer's documentation to determine
typical/expected battery life with a view to periodic replacement of the battery.
D IAGNOSTICS
Loc l Di gnostics
Green LED On = Mains Present
Red LED Fault Diagnostics according to table:
Red LED
(f ult)
Green LED
(m ins) St tus
OFF ON Norm l: Battery fully charged
One short f
lash
every second ON Norm l: Battery charging but not fully charged
Flashing:
1second On
1 second Off
ON
F ult:
Output fuse or battery fuse blown, or
battery/PSU fault
OFF F ult: No mains, output fuse blown
One short flash
every 3 seconds OFF F ult: No mains, battery supplying load.
OFF OFF
F ult:
No mains, No output, battery disconnected
or completely discharged
C OMPLIANCE
This power supply unit meets the essential requirements of the following EU Directives:
EMC: 2014/30/EU Low Voltage: 2014/35/EU WEEE: 2012/19/EU RoHS2: 2011/65/EU
This product is suitable for use in systems designed to comply with
PD6662:2017 at Grade 3 and Environmental Class II
EN50131-6:2017 Type A Security Grade 3
Environmental Class II
Certification Body: Telefication B.V.
Edisonstraat 12A
Zevenaar, 6902 PK
The Netherlands
+31 (0) 316 - 583 180
http://www.telefication.com

8
Technical Support: [phone] (option 3) PAK200546 03A Mar 2020 ©2020 ELMDENE INTERNATIONAL LTD
D ISPOSAL OF P RODUCT AT E ND OF L IFE
This product falls within the scope of EU Directives 2012/19/EU Waste Electrical and Electronic Equipment
(WEEE) and 2013/56/EU (Battery). At the end of life, the product must be separated from the domestic
waste stream and disposed via an appropriate approved WEEE disposal route in accordance with all national
and local regulations.
Before disposal of the product, any batteries must be removed, and disposed separately via an appropriate
approved battery disposal route in accordance with all national and local regulations. Package used batteries
safely for onward transport to your supplier, collection point or disposal facility.
Caution: Risk of fire or explosion
if bare battery wires are allowed to touch.
See Specification for battery type information. The battery is marked with the crossed-out wheelie bin
symbol, which may include lettering to indicate cadmium (Cd), lead (Pb), or mercury (Hg).
For more information see: www.re y lethis.info
The pa kaging supplied with this produ t may be re y led.
Please dispose of pa kaging a ordingly.
