Emerson TARTARINI BM9 User manual

Type BM9
March 2021
Type BM9 Slam-Shut Valve
Figure 1. Type BM9 Slam-Shut Valve
Figure 2. OS9/80X-APA-R Slam-Shut Controller
Table of Contents
Specifications .............................................................. 2
Introduction..................................................................3
PED Categories and Fluid Group................................ 3
ATEX Requirements .................................................... 3
Principle of Operation.................................................. 5
Transport and Handling ............................................... 7
Installation ...................................................................7
Overpressure Protection............................................ 11
Startup and Adjustment ............................................. 12
Slam-Shut Controller Adjustment .............................. 12
Shutdown...................................................................13
Maintenance..............................................................13
Parts Ordering ........................................................... 19
Spare Parts................................................................19
Parts List....................................................................19
▲ WARNING
Failure to follow these instructions or
to properly install and maintain this
equipment could result in an explosion,
fire and/or chemical contamination
causing property damage and personal
injury or death.
Tartarini™ slam-shut valve must be
installed, operated and maintained
in accordance with federal, state and
local codes, rules and regulations
and Emerson Process Management
Regulator Technologies, Inc.
(Emerson) instructions.
If the slam-shut valve vents gas or a
leak develops in the system, service
to the unit may be required. Failure
to correct trouble could result in a
hazardous condition.
Installation, operation and maintenance
procedures performed by unqualified
personnel may result in improper
adjustment and unsafe operation.
Either condition may result in equipment
damage or personal injury. Call
qualified personnel when installing,
operating and maintaining the
Type BM9 slam-shut valve.
Instruction Manual
D104439X012

Type BM9
2
Specifications
The Specications section gives some general specications for the Type BM9 slam-shut valve. The nameplates give
detailed information for a particular slam-shut valve as built in the factory.
Body Sizes and End Connection Styles
DN 200 / NPS 8: CL300 RF and CL600 RF
DN 250 / NPS 10: CL300 RF and CL600 RF
DN 300 / NPS 12: CL300 RF and CL600 RF
Maximum Allowable Pressures(1)
CL300 RF: 51.7 barg / 750 psig
CL600 RF: 103 barg / 1500 psig
Inlet Operating Pressure Range (bPu)(2)
CL300 RF: 51.7 barg / 750 psig
CL600 RF: 100 barg / 1450 psig(2)
Overpressure Set Ranges (Wdo)(1)
CL300 RF: 0.5 to 50 barg / 7.25 to 725 psig
CL600 RF: 0.5 to 90 barg / 7.25 to 1305 psig
Underpressure Set Ranges (Wdu)(1)
CL300 RF: 0.3 to 50 barg / 4.35 to 725 psig
CL600 RF: 0.3 to 80 barg / 4.35 to 1160 psig
Temperature Classes (TS)(2)
Class 1: -10 to 60°C / 14 to 140°F
Class 2: -20 to 60°C / -4 to 140°F
Working Temperature Capabilities(2)
Standard Version, Nitrile (NBR) or
Fluorocarbon (FKM): -10 to 60°C / 14 to 140°F
Low Temperature Version, Nitrile (NBR):
-20 to 60°C / -4 to 140°F
Flow Coefficients
See Table 1
Slam-Shut Controller
OS9/80X-R Series (a sub-family of
OS/80X Series)
Pressure Connection: 1/4 NPT
Slam-Shut Controller Pressure Connection
1/4 NPT
Accuracy Class (AG)
Up to ± 1%
Response Time (ta)
≤ 1 second
Construction Materials
Body: LCC
Sleeve: Steel
O-ring: Nitrile (NBR) (standard) or
Fluorocarbon (FKM) (optional)
Disk: Polytetrafluoroethylene (PTFE)
Controller: See Tables 2 and 3
Approximate Weights
CL300 RF
DN 200 / NPS 8: 313 kg / 690 lbs
DN 250 / NPS 10: 508 kg / 1120 lbs
DN 300 / NPS 12: 790 kg / 1742 lbs
CL600 RF
DN 200 / NPS 8: 351 kg / 774 lbs
DN 250 / NPS 10: 590 kg / 1301 lbs
DN 300 / NPS 12: 870 kg / 1918 lbs
Options
Body Drainage Hole and Plug
Proximity Switch for remote monitoring
Solenoid Valve for remote-controlled closure
Three-way Valve for setting control
Wireless Position Monitor
1. The pressure/temperature limits in this Instruction Manual and any applicable standard or code limitation should not be exceeded.
2. In accordance with EN14382 standard.
Table 1. Type BM9 Flow Coecients
FLOW COEFFICIENT DN 200 / NPS 8 DN 250 / NPS 10 DN 300 / NPS 12
Cg37,890 61,200 83,087
C130 32.5 31
Cv1260 1883 2680
Xt0.57 0.67 0.61
Fd0.313 0.345 0.355
Fl0.8 0.85 0.89

Type BM9
3
OS9/80X-R SERIES OS/80X SERIES
HOLDERHOLDER
PIN
SHAFT SHAFT
Figure 3. Dierences Between OS9 and OS Series
Note 1: See “Specications”
Note 2: Year of Manufacture
Note 3: Class A or Class B
Only valves with overpressure and underpressure settings
can be classied in Class A.
Note 4: Class 1: -10 to 60°C / 14 to 140°F
Class 2: -20 to 60°C / -4 to 140°F
Note 5: CL300 RF PS: 51.7 bar / 750 psig
CL600 RF PS: 103 bar / 1500 psig
Figure 4. Type BM9 Slam-Shut Valves Nameplate
Introduction
Scope of the Manual
This manual provides instructions for installation,
startup, maintenance and spare parts ordering for
the Type BM9 slam-shut valve. This document also
contains information for the OS9/80X-R Series
slam-shut controller.
PED Categories and Fluid Group
According to EN 14382, only in integral strength Type
and Class A configuration (when both over and under
pressure protections are set up), this slam-shut valve
can be classified like a safety accessory according to
Pressure Equipment Directive (PED) 2014/68/EU.
The minimum PS between SSD valve and controller
shall be the PS of the safety accessory to comply the
provisions of EN 14382 about integral strength type.
This product in its Class A and integral strength
configuration is a safety accessory for pressure
equipment in PED categories on Table 4.
Built-in pressure accessories (e.g. controllers
OS9/80X-R Series) conform to PED Article 4 section 3
and were designed and manufactured in accordance
with sound engineering practice (SEP).
Per Article 4 section 3, these “SEP” products must not
bear the CE marking.
ATEX Requirements
▲ WARNING
If the provisions of EN 12186 and
EN 12279, national regulations, or any
specific manufacturer recommendations
are not put into practice before
installation and if purge by inert gas
is not carried out before equipment’s
start-up and shut-down operations, a
potential external and internal explosive
atmosphere can be present in equipment
and gas pressure regulating, measuring
stations or installations.

Type BM9
4
If a presence of foreign material in the pipelines is
foreseen and purge by inert gas is not carried out,
the following procedure is recommended to avoid any
possible external ignition source inside the equipment
due to mechanical generated sparks:
• Drainage to safe area via drain lines of foreign
materials, if any, by inflow of fuel gas with low
velocity in the pipe-work (5 m/sec.)
In any case,
• Provisions of Directive 1999/92/EC and 89/655/EC
shall be enforced by gas pressure regulating,
measuring station or installation’s end user.
• With a view to preventing and providing protection
against explosions, technical and/or organizational
measures appropriate to the nature of the operation
shall be taken (e.g.: filling/exhausting of fuel
gas of internal volume of the isolated part/entire
installation with vent lines to safe area - 7.5.2 of
EN 12186 and 7.4 of EN 12279; monitoring of
settings with further exhaust of fuel gas to safe
area; connection of isolated part/entire installation
to downstream pipeline; ….).
• Provision in 9.3 of EN 12186 and 12279 shall be
enforced by pressure regulating/measuring station/
installation’s end user.
• External tightness test shall be carried out after
each reassembly using testing pressure in
accordance with national rules.
• Periodical check/maintenance for surveillance shall
be carried out complying with national regulations,
if any, and specific manufacturer recommendations.
Product Description
Type BM9 Slam-Shut Valve
Type BM9 slam-shut valves are axial flow type and
are used in regulating, distribution and transmission
stations of suitably filtered natural gas.
This product is designed to be used with fuel gases of
1st and 2nd family according to EN 437 and with other
non-aggressive and non-fuel gases. For any other
gases, other than natural gas, please contact your
local Sales Office.
Use of gas pressure devices (safety shut-off devices ‒
SSD slam-shut type) shall comply with EN 12186 and
EN 12279.
Safety slam-shut valves manufactured by Emerson
must use pressure accessories (e.g. controller or
filters) manufactured or approved by Emerson.
Emerson is not responsible for any possible
inefficiency due to installation of pressure accessories
not manufactured or approved by Emerson.
When pressure containing parts of safety slam-shut
device (SSD) and controller have different maximum
allowable pressures (PS), the SSD is the differential
strength type.
OS9/80X-R Series Slam-Shut Controller
OS9/80X-R Series is designed for Type BM9 and its
overpressure rating is up to 90 bar / 1305 psig.
Type BM9 slam-shut valve is operated
by either spring-loaded controllers,
Table 2. OS9/80X-R Series Spring-Loaded Slam-Shut Controller Pressure Rating
TYPE
MAXIMUM
ALLOWABLE
PRESSURE
OVERPRESSURE SET RANGE, Wdo UNDERPRESSURE SET RANGE, Wdu
BODY
MATERIAL
Minimum Maximum Minimum Maximum
bar psig bar psig bar psig bar psig bar psig
OS9/80X-MPA-D-R
100 1450
0.5 7.25 5 72.5 0.3 4.35 4 58 Steel
OS9/80X-APA-D-R 2 29 10 145 0.3 4.35 7 102
OS9/84X-R 5 72.5 41 595 4 58 16 232 Brass
OS9/88X-R 18 261 90 1305 8 116 70 1015
Table 3. OS9/80X-R Series Pilot-Loaded Slam-Shut Controller with Type PRX Pilot Pressure Rating
TYPE
MAXIMUM
ALLOWABLE
PRESSURE
OVERPRESSURE SET RANGE, Wdo UNDERPRESSURE SET RANGE, Wdu
BODY
MATERIAL
Minimum Maximum Minimum Maximum
bar psig bar psig bar psig bar psig bar psig
OS9/80X-R-PN(1)
100 1450 0.5 7.25 40 580 0.5 7.25 40 580 Steel
OS9/84X-R-PN(2) 30 435 80 1160 30 435 80 1160 Brass
Notes:
1. Made of an OS9/80X-APA-D-R set at about 0.4 bar / 5.80 psig and PRX/182-PN pilots for overpressure and PRX/181-PN for underpressure.
2. Made of an OS9/84X-R set at about 20 bar / 290 psig and PRX-AP/182-PN pilots for overpressure and PRX-AP/181-PN for underpressure.
Table 4. PED Category for Type BM9 Slam-Shut Valves
PRODUCT SIZE CATEGORY FLUID GROUP
DN 200, 250 and 300 / NPS 8, 10 and 12 IV 1

INLET PRESSURE
OUTLET PRESSURE
ATMOSPHERIC PRESSURE
INTERMEDIATE PRESSURE
PILOT SUPPLY PRESSURE
LOADING PRESSURE
STABILIZED PRESSURE
Type BM9
5
OS9/80X-R Series (see Tables 2, 7 and 8) or
pilot-loaded controllers, OS9/80X-R-PN Series
(see Tables 3, 7 and 8).
PRX/182-PN Series pilots are used for overpressure
setting and PRX/181-PN Series pilots are used for
underpressure setting with pilot-loaded controllers,
OS9/80X-R-PN Series.
Pilot-loaded controllers are used when required reset
differential pressures (ΔPwo and ΔPwu) are much
lower than spring-loaded controller’s reset differential
pressures. See Tables 7 and 8 and Figure 11.
Pilot-loaded controllers also have better accuracy than
spring-loaded controllers.
Principle of Operation
Type BM9 slam-shut valves are used to prevent
overpressure, underpressure or both overpressure
and underpressure in the system. This slam-shut
valve is a combination of an axial flow valve and an
OS9/80X Series slam-shut controller which keeps the
slam-shut valve open.
Type BM9 has a shutter valve which slides axially.
With this design, by-pass is not needed for it to open
even with the presence of pressurized gas.
The slam-shut valve can only be opened manually
by turning the eccentric shaft counterclockwise if the
upstream and downstream pressures are equal.
When the control pressure is within the set value of
the slam-shut controller, the controller prevents the
rotation of the eccentric shaft and the slam-shut valve
remains open.
When the control pressure is above or below the set
value, the slam-shut controller releases the eccentric
shaft closing the slam-shut valve.
The slam-shut controller is provided with a manual
release push-button to quickly close the slam-shut
valve in case of emergency or during maintenance/
checking operations.
Type BM9 slam-shut valve can be used with pilot.
Supply to pilot comes from the downstream of the
slam-shut valve.
Note
The downstream regulator(s) must
be rated for full inlet pressure of the
system because the regulator(s) may
see full inlet pressure when slam shut
valve is fully open in normal operating
conditions. Also, the outlet pressure
rating of the pilots and any other
components that are exposed to the
intermediate pressure must be rated for
full inlet pressure.
TYPES PSA/79, PS/79, PSA/80, PS/80, PSA/79-AP,
PS/79-AP, PSA/80-AP AND PS/80-AP:
V - SENSING PORT
M - SUPPLY PORT
R - LOADING PORT
S - BLEED PORT
INLET PRESSURE
OUTLET PRESSURE
ATMOSPHERIC PRESSURE
LOADING PRESSURE
TYPE FLR:
A - SENSING PORT
B - LOADING PORT
STABILIZED PRESSURE
TYPE OS9/80X-R
TYPE BM9 TYPE FLR
V
M
S
R
AB
A
≥4 X DN
DN
TYPE PSA/79, PS/79, PSA/80,
PS/80, PSA/79-AP, PS/79-AP,
PSA/80-AP OR PS/80-AP
Figure 5. Type BM9 and Type FLR Operational Schematic

A
BB
A
RV
MS
V
R
MS
A
≥ 6 x DN
≥ 4 x DN
DN
LL
BB
A A
RV
MS
V
R
MS
B
A
B
A
A
≥ 6 x DN
≥ 4 x DN
DN
Type BM9
6
SLAM-SHUT VALVE WITH TYPE OS9/80X-R CONTROLLER – INSTALLATION IN WIDE-OPEN MONITOR LINE
SLAM-SHUT VALVE WITH TYPE OS9/80X-R-PN CONTROLLER – OVERPRESSURE AND UNDERPRESSURE CONTROL
IN WIDE-OPEN MONITOR SYSTEM
PRX SERIES:
B - SUPPLY PORT
L - LOADING PORT
A - SENSING PORT
TYPE FLR:
A - SENSING PORT
B - LOADING PORT
TYPE FLR:
A - SENSING PORT
B - LOADING PORT
TYPES PSA/79, PS/79, PSA/80, PS/80, PSA/79-AP,
PS/79-AP, PSA/80-AP AND PS/80-AP:
V - SENSING PORT
M - SUPPLY PORT
R - LOADING PORT
S - BLEED PORT
TYPES PSA/79, PS/79, PSA/80, PS/80, PSA/79-AP,
PS/79-AP, PSA/80-AP AND PS/80-AP:
V - SENSING PORT
M - SUPPLY PORT
R - LOADING PORT
S - BLEED PORT
TYPE PSA/80, PS/80,
PSA/80-AP OR PS/80-AP
TYPE PSA/79,
PS/79, PSA/79-AP
OR PS/79-AP
TYPE OS9/80X-R-PN
TYPE PRX/181-PN TYPE PRX/182-PN
TYPE BM9 MONITOR
REGULATOR
JET
(1 mm)
TYPE PSA/80, PS/80,
PSA/80-AP OR PS/80-AP
TYPE PSA/79,
PS/79, PSA/79-AP
OR PS/79-AP
TYPE OS9/80X-R-PN
TYPE BM9 MONITOR
REGULATOR
Figure 6. Type BM9 Connection / Installation Schematics

Type BM9
7
Transport and Handling
▲ WARNING
Only qualied personnel in rigging may
use lifting equipment to transport and
handle this unit. If violated, personal injury
and/or equipment damage may result.
Do not exceed the specication of
lifting equipment and its accessories
for transport and handling of this unit. If
violated, personal injury and/or equipment
damage may result.
Never stand, work or crawl under the load.
The load could swing, pieces could drop
or the load could fall or slip. Allow for this
possibility by establishing a safe distance
between yourself and the load, and
never lift the load over others. If violated,
personal injury and/or equipment damage
may result.
△ CAUTION
Eyebolts are provided to aid in the
transport and handling of this unit.
When lifting this unit, use both
the eyebolts.
The load should never be applied
at more than 45 degree angles
from the bolt center line. Refer to
Figure 7 for proper orientation of lifting
line and eyebolts.
Eyebolts are designed just for handling
the weight of this unit. Do not attempt
to lift more weight than that of this unit
with these eyebolts.
Loads must be applied only in the plane
of the lifting eyebolt. If the plane of the
eyebolt is not aligned with the load,
estimate the amount of unthreading
necessary to properly align the eye.
Remove the eyebolt and add shims to
adjust the angle of the plane of the eye.
Weight on the lifting straps may cause
them to unwind, which can cause a
hanging load to rotate. Make sure the
straps are not twisted before lifting, or
if necessary use a tag line attached to
one of the eyebolts, to which a person
can grip and stabilize the weight
during lifting.
Installation
▲ WARNING
Personal injury or equipment damage,
due to bursting of pressure-containing
parts may result if this slam-shut
valve is overpressured or is installed
where service conditions could exceed
the limits given in the Specification
section and on the appropriate
nameplate or where conditions exceed
any rating of the adjacent piping or
piping connections.
To avoid such injury or damage, provide
pressure-relieving or pressure-limiting
devices to prevent service conditions
from exceeding those limits.
Also, be sure the installation is in
compliance with all applicable codes
and regulations.
Additionally, physical damage to
the slam-shut valve could break the
slam-shut controller off the main valve,
causing personal injury and property
damage due to bursting of pressure-
containing parts. To avoid such injury
and damage, install the slam-shut valve
in a safe location.
Installation procedures performed
by unqualified personnel may result
in improper adjustment and unsafe
operation. Either condition may result in
equipment damage or personal injury.
Only a qualified person shall install or
service the Type BM9 slam-shut valve.
When selecting Type OS9/80X-R-PN or
Type OS9/84X-R-PN controller, the JET
must direct to or be piped to safe area,
shown in Figures 6, 15 and 16. If violated,
serious injury may occur due to sudden
release of extremely high pressure.
△ CAUTION
Eyebolts are installed to aid in the
handling and installation of the
slam-shut valve assembly only. Always
utilize both eyebolts and do not attempt
to lift more weight than the slam-shut
valve with these eyebolts.

Type BM9
8
Before Installation:
• Unpack the slam-shut valve and remove
the protective shipping covers from the end
connections of the body.
• Check the slam-shut valve and make sure it has
not been damaged or collected foreign material
during shipping.
• Remove any debris or dirt in the tubing and
the pipeline.
• Use suitable line gaskets and approved piping and
bolting practices.
• Make sure gas flow through the slam-shut valve is
in the same direction as the arrow on the body.
• Under enclosed conditions or indoors, escaping
gas may accumulate and be an explosion hazard.
In this case, the vent should be piped outdoors.
• For slam-shut valve and accessories with vents,
the vent should be kept open to permit free flow of
gas to the atmosphere. Protect openings against
entrance of rain, snow, insects or any other foreign
material that may plug the spring case vent or
vent line.
Connect a downstream control line to a straight run
of pipe 4 to 5 pipe diameters from the regulator outlet
as shown in Figures 5 and 6. If such a distance is not
practical, connect the control line away from elbows,
swages, nipples or any area where abnormal flow
velocities occur. See Figures 5 and 6.
Pilot-Loaded Controllers
▲ WARNING
A pilot may vent some gas to
the atmosphere. In hazardous or
flammable gas service, vented gas may
accumulate, causing personal injury,
death or property damage due to fire
or explosion. Install vent line(s) from
the pilot(s) to a remote, safe location
away from air intakes or any hazardous
location. The end of the vent line or
stack opening must be pointed down
and protected against condensation
or clogging.
△ CAUTION
To avoid freeze-up because of pressure
drop and moisture in the gas, use
anti-freeze practices, such as heating
the supply gas or adding a de-icing
agent to the supply gas.
Type BM9 slam-shut valve bleeds no gas to
atmosphere during normal operation, thus making
it suitable for installation in enclosed locations
without elaborate venting system, if the bleed lines
are connected to the downstream pipeline. Further,
the pilot spring case vent shall be referenced to
atmospheric pressure so that the pilot can be set.
The PRX pilots have a 1/4 NPT vent connection at the
spring case and at the side of the body respectively.
To remotely vent the pilots:
1. Remove the screened vent and install obstruction-
free tubing or piping into the 1/4 NPT vent tapping.
2. Install a screened vent cap onto the remote
end of the vent pipe to provide protection on a
remote vent.
Note
The piping or tubing should vent to a
safe location, have as few elbows as
possible and have a screened vent on
its exhaust.
3. Install the pilot and any remote vent piping
or tubing so that the vent is protected from
condensation, freezing or any substance that
could clog it.
4. Install a full flow hand valve, such as a full port ball
valve, in the control line.
MAXIMUM LIFTING ANGLE IS 45°
RECOMMENDED
EYEBOLT ORIENTATION
AVOID THIS
EYEBOLT ORIENTATION
Figure 7. Lifting Lugs: Illustration of Lateral Loading

BRACKET
REACTION
ARM
7
Align the groove with
the step surface
16
Type BM9
9
ALWAYS AGAINST LOWER
SURFACE OF BRACKET (KEY 32)
(PINCH POINT: KEEP HAND
AND FINGERS AWAY FROM
REACTION ARM AND BRACKET)
Figure 8. Resetting Operation
(a) (b)
Figure 9. Shaft Maintenance on Closed Position
Figure 10. Main Valve Disk Ring Replacement
(a) (b)
PIPELINE
BOLT
LENGTH <
80 mm /
3.15 IN.

Overpressure set value
Underpressure set value
Downstream pipeline pressure
∆PWU ∆PWO
Type BM9
10
CLOSED POSITION RESET STAGE
RED MARK
RESET COMPLETED
RED MARK IS JUST AT “ON”
RED MARK
Figure 11. OS9/80X-R Series Slam-Shut Controller Resetting Position
OVERPRESSURE SET VALUE
DOWNSTREAM PIPELINE PRESSURE
UNDERPRESSURE SET VALUE
Figure 12. OS9/80X-R Series Slam-Shut Controller Range Setting

Type BM9
11
Overpressure Protection
The recommended maximum allowable pressures are
stamped on the slam-shut valve nameplate.
Upstream overpressure protection shall be provided
if the inlet pressure is likely to go higher than the
maximum operating inlet pressure (Pumax).
Downstream pressure after slam-shut valve’s
intervention shall stay within the allowable pressure
range to avoid anomalous backpressures that can
damage the slam-shut controller.
Downstream overpressure protection shall also be
provided if the slam-shut valve outlet pressure is likely
to go higher than the PS of the slam-shut controller
(differential strength type).
Slam-shut valve operation below the maximum
pressure limitations does not preclude the possibility of
damage from external sources or debris in the line.
The slam-shut valve should be inspected for damage
after any intervention.
Underpressure Protection
▲ WARNING
In order for the Underpressure Shutoff
(UPSO) of slam-shut valve to be
triggered, the downstream pipe pressure
must drop below the UPSO setpoint.
In the case of a downstream line
break, numerous factors can prevent
the downstream pipe pressure from
decreasing below the slam-shut valve’s
UPSO setpoint. These factors include
the distance of pipe to the break, the
diameter of the pipe, size of the break
and the number of restrictions, such as
valves, elbows and bends, downstream
of the regulator and/or slam-shut
valve. Due to these factors additional
protections should be installed to stop
flow in the event of a line break.
Table 5. Torque Specications(1)
KEY PART NAME
TORQUE
DN 200 / NPS 8 DN 250 / NPS 10 DN 300 / NPS 12
N•m Ft-lbs N•m Ft-lbs N•m Ft-lbs
4 Bolt (End cap) 25 to 28 18 to 21 50 to 54 36.9 to 39.8 80 to 85 59 to 63
20
Locknut 22 to 25 16.2 to 18.4 22 to 25 16.2 to 18.4 22 to 25 16.2 to 18.4
Hex Screw (Locknut) Initial: 1.5
Final: 4.5
Initial: 1.1
Final: 3.3
Initial: 1.5
Final: 4.5
Initial: 1.1
Final: 3.3
Initial: 1.5
Final: 4.5
Initial: 1.1
Final: 3.3
21 Screw Rod 80 to 100 59.0 to 73.8 80 to 100 59.0 to 73.8 80 to 100 59.0 to 73.8
30 Nut 90 to 100 66.4 to 73.8 90 to 100 66.4 to 73.8 90 to 100 66.4 to 73.8
40 Screw (Ring, Clamping) 7 to 8 5 to 5.9 6.3 to 8 4.6 to 5.9 6.3 to 8 4.6 to 5.9
49 Bolt (Seal Ring) - - - - - - - - - - - - - - - - 4 to 6 3 to 4.4
50 Cam Roller 10 to 12 7.4 to 8.9 10 to 12 7.4 to 8.9 10 to 12 7.4 to 8.9
52 Screw (Bonnet) 2.5 to 2.9 1.8 to 2.1 2.5 to 2.9 1.8 to 2.1 2.5 to 2.9 1.8 to 2.1
62 Nut (Bonnet) 140 to 150 103.3 to 110.6 140 to 150 103.3 to 110.6 140 to 150 103.3 to 110.6
70 Nut 20 to 22 14.7 to 16.22 20 to 22 14.7 to 16.22 20 to 22 14.7 to 16.22
101 Lower Cover 40 to 50 29.5 to 36.8 40 to 50 29.5 to 36.8 40 to 50 29.5 to 36.8
105 Screw 3 to 5 2.5 to 3.7 3 to 5 2.5 to 3.7 3 to 5 2.5 to 3.7
114 Nut 30 to 40 22.1 to 29.5 30 to 40 22.1 to 29.5 30 to 40 22.1 to 29.5
115 Handle 20 to 30 17.8 to 22.1 20 to 30 17.8 to 22.1 20 to 30 17.8 to 22.1
33(2) Type PRX Pilot Plug
NPT Thread(3)(4)
37 Main Valve Plug
38(2) Special Connection
74 Main Valve Fitting Elbow
74(2) Controller Silencer
75 Fitting Tee
- - - - End Connections
1. Overtightening may be detrimental to the sealing function of the joint.
2. Optional parts according to customer requirement.
3. Joints should be tightened beyond the hand-tight engagement position.
4. Advancing the joint past hand-tight creates interference between external and internal thread anks, produces a seal (with the use of a sealant), and helps prevent loosening of the joint.

Type BM9
12
Slam-shut valve can also be used to shut off a gas
system when system pressure falls below a set
value which may occur due to various reasons such
as severing of gas pipeline or drop in inlet pressure
or flow.
If system pressure or flow drops too low, it may not
meet the minimum operating pressure required for
safe operation of downstream equipment such as
burners due to which the gas may not get ignited. This
may be result in gas build up and explosion.
For these reasons, underpressure protection is also
considered in system design.
Startup and Adjustment
Pre-startup Considerations
△ CAUTION
Do not apply the reaction arm against
slam-shut controller.
Make sure to remove handle from reset
stem of controller after reset and hang it
on the bracket (key 32).
Possible hand and finger pinch point
between reaction arm and bracket.
Reaction arm closes quickly and with
extreme force. Keep hands and fingers
away from reaction arm and bracket, as
the reaction arm closes.
When red mark in controller gets to
“ON”, resetting has been completed.
Further operation will damage the
controller. Based on structural
characteristics, the torque for resetting
rst increases then decreases with the
increase of rotation of handle. The nal
torque is about 15 to 20 N•m / 11.1 to
14.7 lb-ft (the force is 43 to 57 N / 9.67 to
12.8 lbf) for all Type BM9 size when red
mark is at “ON”.
▲ WARNING
The valve must be reset completely
and forbid opening partly. Otherwise,
that may affect the sealing performance
and even cause injury because of the
rebound of the resetting handle.
Each slam-shut valve is factory-set for set pressure(s)
specied on the order. If no setting was specied, it
will be factory-set at the mid-range of the controller
spring range. Before beginning the startup procedure
in this section, make sure the following conditions are
in e󰀨ect:
• Block valves to isolate the slam-shut valve
• Vent valves are closed
• A bypass, if any, is in operation
In all cases, check the controller spring setting to
make sure it is correct for the application.
1. The slam-shut valve is factory set at approximately
the midpoint of the spring range or at the customer
specified set pressure; however, a field adjustment
may be required to obtain desired results.
2. Completely close the isolation valve or block valve
located downstream of the regulator.
3. Slowly and slightly open the isolation valve or
block valve upstream of the slam-shut valve.
4. Put the handle on reset stem of controller, apply
the reaction arm securely against lower surface of
the bracket. See Figure 8 for resetting operation.
5. From the position where the change of resistance
force could be obviously felt, slowly turn the
handle counterclockwise to the degree of 45° to
60° and wait until the inlet and outlet pressures
are balanced, then continue to turn the handle
until the red mark is at ON position to complete
the reset operation (see Figure 11). The handle
may need to be turned certain degrees: 445° for
DN 200 / NPS 8, 455° for DN 250 / NPS 10 and
480° for DN 300 / NPS 12.
6. Slowly open the block valve upstream of the
Type BM9 slam-shut valve completely, then slowly
open the block valve downstream of the regulator.
Slam-Shut Controller Adjustment
To change spring-loaded slam-shut controller setpoints
(overpressure and/or underpressure), remove the
spring closing cap of the controller and turn the
adjusting screw clockwise to increase outlet pressure
or counterclockwise to decrease pressure.
Figure 13. Optional Drainage Hole and Plug
(Do not remove plug while unit is pressurized.)

Type BM9
13
To change pilot-loaded slam-shut controller setpoints
(overpressure and/or underpressure), adjust the
pilot setpoints. Refer to pilot’s instruction manuals
for details.
Monitor outlet pressure with a test gauge during
the adjustment.
Range Setting
The reset differential indicates the minimum value to
be considered with respect to downstream pipeline
pressure set point for proper resetting of the controller.
See Figure 12.
Example: Downstream pipeline pressure set point
15 bar / 218 psig.
Choose OS9/84X-R with blue spring for overpressure
and red spring for underpressure, see Tables 7 and 8.
The reset differential ∆Pwo is 3.0 bar / 43.5 psig and
∆Pwu is 6.0 bar / 87.0 psig.
So, the overpressure set value should be
18 bar / 261 psig (15 bar + 3 bar = 18 bar or
218 psig + 43.5 psig = 261 psig) or higher, and
underpressure set value should be 9 bar / 131 psig
(15 bar - 6 bar = 9 bar or 218 psig - 87 psig = 131 psig)
or lower.
Shutdown
▲ WARNING
To avoid personal injury resulting from
sudden release of pressure, isolate the
slam-shut valve from all pressure before
attempting disassembly and release
trapped pressure from the equipment
and pressure line.
△ CAUTION
In any installation, it is important to
slowly open and close the valves and to
vent the outlet pressure before venting
the inlet pressure to prevent damage
caused by reverse pressurization of the
pilot or main valve.
1. Slowly close the valves in the following order:
a. Inlet block valve
b. Outlet block valve
c. Control line valve(s), if used.
2. Open the vent valves to depressurize the system.
Maintenance
▲ WARNING
To avoid personal injury resulting
from sudden release of pressure,
isolate the slam-shut valve from the
system pressure and release trapped
pressure from the equipment and
pressure line before attempting
maintenance operation.
Use proper lifting techniques, when
lifting the body and spacer (keys 1
and 17).
The optional drainage plug at the bottom
of the valve, shown in Figure 13, must
not be removed unless the pressure
in the valve is completely released.
If violated, serious injury may occur
due to sudden release of extremely
high pressure.
The slam-shut valve parts are subject to normal wear
and must be inspected periodically and replaced
as necessary. The frequency of inspection and
replacement depends on the severity of service
conditions and on applicable federal, state and local
codes and regulations. Use Torque Specifications
(Table 5) for proper torque values.
Main Valve (See Figures 14, 15 and 16)
▲ WARNING
Installation, operation and maintenance
procedures performed by unqualified
personnel may result in improper
Table 6. Troubleshooting Type BM9 Slam-Shut Valve
SYMPTOMS CAUSE ACTIONS
Slam-shut device does not remain set
The sensing line to port (A) of slam-shut controller
is not connected properly Check the sensing line connections (A)
Downstream pressure coincides with
the maximum or minimum slam-shut settings Check slam-shut controller settings
Damaged Diaphragm (key 62) on Type OS9/80X-R
Lip seal (key 66) on Types OS9/84X-R and OS9/88X-R
Replace the diaphragm on Type OS9/80X-R
Replace the lip seal on Types OS9/84X-R and OS9/88X-R
Sleeve does not seal properly
Worn seal gaskets Check gaskets and replace if necessary
Dirt deposit on sleeve Check sleeve and clean / replace if necessary
Shaft and Roller (keys 7 and 50) are damaged Check shaft and roller and replace if necessary

Type BM9
14
adjustment and unsafe operation. Either
condition may result in equipment
damage or personal injury. Call qualified
personnel when installing, operating
and maintaining the unit.
△ CAUTION
Eyebolts are installed to aid in the
handling and installation of the
slam-shut valve assembly only. Do not
attempt to lift more weight than the
slam-shut valve with these eyebolts.
Do not use another type of eyebolt,
slam-shut controller or pilot on this
slam-shut valve. Only Emerson parts
can be used to maintain the unit.
See Table 6 for troubleshooting and corrective action
for Type BM9.
Disk Ring Maintenance (See Figure 14)
▲ WARNING
When removing disk holder, ensure
to handle with care to avoid dropping
which may result in equipment damage
or personal injury.
△ CAUTION
Before removing line bolting connecting
the pipeline and body, ensure adequate
support is provided to prevent body
and/or spacer from dropping and
damaging and/or deforming the piping
and accessories.
1. Remove all piping bolts connecting to pipeline and
body inlet flange.
2. Take out spacer (key 17).
3. Screw in two bolts or screws into two threaded
holes on disk holder (key 18). Bolt dimensions
are M12 for DN 300 / NPS 12, M10 for DN 250 /
NPS 10 and M8 for DN 200 / NPS 8. Apply torque
counterclockwise on both bolts to slowly back out
the disk holder (key 18). Use a crowbar or wrench
for ease of rotating.
Note
The bolts could be substituted with
studs, screws or eyebolts. The
recommended length should not exceed
80 mm / 3.15 in. The strength of the
bolt should be equal to or greater than
that of class 8.8 material. The thread
engagement between bolt and threaded
hole on disk holder should be at least
10 mm / 0.4 in.
4. When the disk holder (key 18) is completely
unscrewed as shown in Figure 10 (a), remove the
bolt from the disk holder (to avoid damaging the
pipe flange) and then remove the disk holder from
the valve body as shown in Figure 10 (b).
Seat ring (key 47) will be taken out along with the
disk holder.
Note
When maintaining Type BM9 online, if the
seat ring (key 47) is not taken out along
with the disk holder (key 18), please slowly
reset about 60° and slowly closed. Then
the Seat Ring (key 47) can be pushed out.
In the process of resetting, do not put
hands near the inlet to avoid injury.
5. For DN 300 / NPS 12, unscrew the six screws
(key 49) from seal ring retainer (key 46),
disassemble disk holder (key 18) and seal ring
retainer (key 46), and replace the old disk (key 47)
and O-ring (key 42).
For DN 200 and 250 / NPS 8 and 10, separate the
disk (key 47) and O-ring (key 42) from disk holder
(key 18), and replace them.
6. Reinstall the seal ring retainer (key 46) to disk
holder (key 18) in reverse order.
7. Reinstall the disk holder (key 18) and seal ring
retainer (key 46) subassembly into the body
(key 1). Apply anti-seize lubricant on the disk
holder and body threads to lubricate. Screw in
disk holder clockwise on body (key 1) until the
top surface of disk holder is perfectly aligned with
mating surface of body. Ensure that the surface
of the disk holder is not projecting outside of body
flange surface.
General Maintenance
(See Figures 14, 15 and 16)
△ CAUTION
Protect gasket surfaces on the body
flanges and spacer from scratches
and damage.
Make sure the larger ring of thrust
ball bearing (key 53) connects with
cam (key 55) for size DN 300 / NPS 12,
otherwise more resistance may hinder

Type BM9
15
smooth rotation. For size DN 200 /
NPS 8 and DN 250 / NPS 10, the rings of
thrust needle bearing (key 53) have the
same size.
The hex head of stem (key 19)
must be held firmly when screwing
screw (key 21), otherwise parts may
be damaged.
1. Remove the slam-shut valve from the pipeline.
Use the eyebolts to lift it. Place the slam-shut
valve on flat surface. Refer to Figure 7 for
lifting instructions.
2. Loosen the screws (key 52) and dismount the
slam-shut controller.
3. Loosen nuts (key 62) and remove bonnet (key 8).
Replace O-rings (keys 11, 58 and 63) and anti-
friction rings (key 59).
4. Take out disk holder (key 18) together with seal
ring retainer (key 46) (if any). See “Disk Ring
Maintenance” section for details.
5. If needed, place the slam-shut valve vertical on
flat surface with inlet flange facing up. Take care to
protect the gasket surfaces on body flanges from
scratches and damage while carrying out this task.
6. Separate disk holder (key 18) and seal ring
retainer (key 46). Replace disk (key 47) and
O-rings (keys 42, 43 and 48).
7. Pull out shaft (key 7) to the position shown in
Figure 9 to allow pull out of internal components.
8. Loosen 3 screws of locknut (key 20) then remove
it, slowly loosen screw (key 21) to release spring
(key 26). Remove sleeve (key 24) and cage
(key 15). Replace O-ring (keys 44 and 45) and
anti-friction rings (key 43), and for size DN 200
also need to replace seal retainer (key 78).
Loosen screws (key 40) to remove ring (key 14).
Replace O-ring (key 42).
9. Hold shaft (key 7) and remove retainer ring
(key 57). Remove shaft and cam (key 55) from
body (key 1). Separate shaft and wiper (key 51)
from cam. Check bearing (key 53) and replace it
if necessary.
10. Loosen bolts (key 4) to remove end cap (key 2),
replace O-ring (key 3).
11. Check all moving parts, paying attention to
plated surfaces.
12. Clean the parts for reuse. Replace worn out parts,
if any.
Reassembly
Note
When the word “lubricate” is used in
this document it is implied that the
amount of lubricate used should be
just enough to cover the surface of the
part being lubricated. Using an excess
amount of lubricant should be avoided
unless otherwise stated.
Precautions for the use of anti-
loose washer (keys 5 and 41): It is
recommended the use of a lubricant.
Lubricate the thread and the outer
surface area of the anti-loose washer
(the area in contact with the fastener)
prior to installation.
Lubricate all seals with silicone-based grease. Be sure
not to damage them while reassembling.
Reassemble in reverse order.
During reassembly, make sure that parts move
smoothly with respect to one another without friction.
Note
The shaft (key 7) must be rotated 5°
to 20° anti-clockwise referring the
mark hole on shaft (key 7) for smooth
assembly. See Figure 9.
1. Pull out bushing and shaft (keys 6 and 7) until
the groove aligned with the step surface (see
Figure 9) before inserting cage (key 15), stem
(key 19) and sleeve (key 24) into body (key 1), for
smooth assembly.
2. Reassemble shaft (key 7) into cam (key 55). Make
sure the mark hole on the end face of shaft faces
the pawl of cam roller (key 50).
3. Before reinstalling the slam-shut controller, make
sure that the mark hole of shaft (key 7) is facing
the inlet flange.
4. Make sure that the line connecting two centers of
bonnet (key 8) used to mount controller is parallel
to axis of body (key 1).
5. Check if the slam-shut sleeve (key 24) opens
when shaft (key 7) is rotated counterclockwise.
Handle Unit Maintenance (See Figure 17)
Handle unit maintenance entails checking of O-ring
(key 106) and the movement of gear train (key 103)
and adapter (key 111). They should move freely with
a minimum friction. If necessary, lubricate them with
silicone-based grease.

Type BM9
16
Maintenance
1. Remove screw (key 105) and lever (key 116).
2. Loosen upper and lower cover (keys 101 and
102), remove washer (key 107) and adapter
(key 111).
3. Remove gear train (key 103) and washer
(key 107).
4. Remove connector (key 104) and O-ring
(key 106).
5. Clean the parts for reuse. Check O-ring and
washers (keys 106 and 107) for wear.
6. Replace worn out parts if any.
Reassembly
△ CAUTION
Ensure to uniformly tighten all
screws and nuts to the recommended
torque values. See Table 5 for
torque requirements.
Reassemble in reverse order.
During reassembly, make sure that parts move
smoothly with respect to one another without friction.
Slam-Shut Controller Maintenance
(See Figures 18 and 19)
△ CAUTION
Slam-shut controller must be mounted
upright as shown in Figure 15. If
mounted any other way, the controller
will not function properly.
Possible hand and finger pinch point
between reaction arm and bracket.
Reaction arm closes quickly and with
extreme force. Keep hands and fingers
away from reaction arm and bracket, as
the reaction arm closes.
Periodical Checks
It is recommended to periodically check the efficiency
of the slam-shut controller.
Cut-off Test
1. Cut-off the circuit by means of inlet and outlet
block valves and disconnect the pressure sensing
line to port A of the slam-shut controller. The slam-
shut controller should cut-off at minimum pressure
(only if so set).
2. Raise the pressure to normal operating level by
using a small pump or other appropriate means
to port A connection in the controller. Reset
slam-shut controller if it was cut-off in step 1.
3. Simulate pressure increase until maximum
pressure cutoff value is reached.
4. Connect the sensing line back to port A of the
controller and set the circuit back to operating
conditions by following the instructions described
in the Startup section.
Valve-seal Check
1. Close downstream isolation valve.
2. Press the “EMERGENCY” button. This will cause
the immediate closing of slam-shut valve.
3. Release the pressure in the line section between
slam-shut valve and downstream isolation valve.
The pressure should drop and eventually become
zero. If pressure does not fall down to zero, it is a
sign that the unit is not closing tight. Proceed with
necessary maintenance as required.
OS9/80X-R Series Maintenance
(See Figures 18 and 19)
▲ WARNING
All maintenance procedures must be
carried out only by qualified personnel.
If necessary, contact our local
Sales Office.
Maintenance procedures performed
by unqualified personnel may result
in improper adjustment and unsafe
operation. Either condition may result
in equipment damage or personal
injury. Call qualified personnel when
maintaining the unit.
Before starting the maintenance,
disconnect sensing line (connection
at port A) and ensure that
pressure in slam-shut controller is
completely released.
Failure to follow these instructions
could result in property damage and/or
personal injury or death.
Slam-shut controller maintenance entails checking
of the diaphragm on the Type OS9/80X-R (the piston
Gaco flex on the Type OS9/84X-R) and the movement
of the levers, i.e. they should move freely with a
minimum of friction. If necessary, lubricate pins with
silicone-based grease.

Type BM9
17
Replacing Diaphragm
(OS9/80X-R Series only)
1. Remove screws (key 27) and cover (key 61).
2. Replace diaphragm (key 62).
3. To remount diaphragm, coat it with grease, set
it in place around the edge of cover (key 61)
and evenly tighten screws (key 27) to ensure
proper sealing.
Replacing O-ring (Types OS9/84X-R and
OS9/88X-R only)
1. Remove plug (key 61) and extract piston (key 68)
from body (key 60).
2. Replace O-ring (key 67) and Gaco flex (key 66).
3. Reassemble in reverse order.
General Maintenance
1. Remove screws (key 40) and casing (key 47).
2. Remove dowels (key 12) and bushing (key 13).
3. Slide off stem (key 6), lever assembly
(keys 17 and 2), rollers for Type OS9/80X-R
(key 10), and shim ring (key 15). Clean the parts
for reuse. Replace worn out parts if any.
4. Remove nuts (key 18), levers (keys 20 and 36)
and springs (keys 37 and 21).
5. Remove nut (key 30), screw (key 29) and
lever (key 33).
6. Remove minimum adjusting screw (key 49),
maximum adjusting nut (key 50) and springs
(keys 53 and 54).
7. Remove cover (key 61) on OS9/80X-R Series,
or plug on Types OS9/84X-R and OS9/88X-R,
and proceed as directed in replacing diaphragm/
O-ring section.
8. Remove nut (key 70) and locknut (key 69), then
slide off stem unit (key 57).
9. Loosen screw (key 3), unscrew nut (key 9),
remove balls holder (key 5) and check seals
(keys 4 and 8) for wear.
10. Clean the parts for reuse. Replace worn out parts,
if any.
Reassembly
△ CAUTION
The lever (key 33) is in proper position
when it is exactly horizontal and in the
center of the groove of lever (key 36).
Reassemble in reverse order.
During reassembly, make sure that parts move
smoothly with respect to one another without friction.
Make sure to:
1. Narrow the gap between nuts (keys 30 and 18)
so that levers (keys 33, 36, and 20) move freely
without friction.
2. Register position of lever (key 33) by locking the
nut (key 70) into place with locknut (key 69) before
mounting minimum spring (key 54).
3. Remount lever assembly (keys 17 and 2), rollers
for Type OS9/80X-R (key 10), keeping them in
their seat with grease and stem (key 6), which is
to be turned so the rollers enter their seats. The
stem and lever assembly should now be tightly
fitted together.
4. Remount bushing (key 13), make sure that
the dowels are firmly set in the grooves of the
stem (key 6).
5. Repeatedly check if pilot resets properly, then,
remount minimum spring (key 54).
6. Always check controller setting.
Minimum and Maximum Setting
△ CAUTION
Whenever minimum or maximum
pressure setting is not required, omit
corresponding steps.
Possible hand and finger pinch point
between reaction arm and bracket.
Reaction arm closes quickly and with
extreme force. Keep hands and fingers
away from reaction arm and bracket, as
the reaction arm closes.
1. Make sure that the lever (key 33) is in horizontal
position when slam-shut controller is reset. If
necessary, use nut and locknut (keys 69 and 70)
to adjust (see step 2, Reassembly section).

Type BM9
18
Table 7. Overpressure Shut-o Spring Ranges and Information
CONTROLLER
TYPE
SPRING RANGE RESET
DIFFERENTIAL
SPRING
DIAMETER
SPRING
LENGTH PART
NUMBER MATERIAL SPRING COLOR
bar psig bar psig mm In. mm In.
OS9/80X-MPA-D-R
0.50 to 0.70 7.25 to 10.15 0.15 2.17 3.00 0.12 75.0 2.95 M0105140X12 Steel Yellow
0.70 to 2.50 10.15 to 36.25 0.30 4.35 4.00 0.16 75.0 2.95 M0197070X12 Steel Blue
2.50 to 5.00 36.25 to 72.51 0.50 7.25 5.00 0.20 75.0 2.95 M0197080X12 Steel Red
OS9/80X-APA-D-R 2 to 4 29 to 58 0.40 5.80 4.00 0.16 75.0 2.95 M0197070X12 Steel Blue
4 to 10 58 to 145 1 14.50 5.00 0.20 75.0 2.95 M0197080X12 Steel Red
OS9/84X-R 5.0 to 25 72 to 362 3 43.50 4.00 0.16 75.0 2.95 M0197070X12 Steel Blue
24 to 41 348 to 594 5 72.50 5.00 0.20 75.0 2.95 M0197080X12 Steel Red
OS9/88X-R
18 to 50 261 to 725 8 116.00 3.00 0.12 75.0 2.95 M0105140X12 Steel Yellow
40 to 80 580 to 1160 12 174.00 4.00 0.16 75.0 2.95 M0197070X12 Steel Blue
70 to 90 1088 to 1305 15 217.50 5.00 0.20 75.0 2.95 M0197080X12 Steel Red
OS/80X-PN with
PRX/182-PN
0.5 to 1.1 7.3 to 16 0.2 2.90 2.50 0.10 51 2.01 M0255250X12 Steel White
1 to 1.8 14.5 to 26 0.3 4.35 2.80 0.11 55 2.17 M0255240X12 Steel Yellow
1.6 to 3 23 to 44 0.3 4.35 3.20 0.13 55 2.17 M0255230X12 Steel Green
2.8 to 5.5 41 to 80 0.4 5.80 3.50 0.14 55 2.17 M0255180X12 Steel Blue
5 to 8.5 73 to 123 0.4 5.80 4.00 0.16 55 2.17 M0255220X12 Steel Black
8 to 14.5 116 to 210 0.5 7.25 4.50 0.18 55 2.17 M0255210X12 Steel Silver
14 to 23 203 to 334 0.6 8.70 5.50 0.22 51 2.01 M0255200X12 Steel Gold
22 to 30 319 to 435 0.6 8.70 6.00 0.24 51 2.01 M0255860X12 Steel Aluminum
29 to 42 421 to 609 0.6 8.70 6.50 0.26 50 1.97 M0255190X12 Steel Red
OS/84X-PN with
PRX-AP/182-PN 30 to 80 435 to 1160 0.8 11.60 8.50 0.33 100 3.94 M0273790X12 Steel Neutral
Table 8. Underpressure Shut-o Spring Ranges and Information
CONTROLLER
TYPE
SPRING RANGE RESET
DIFFERENTIAL
SPRING
DIAMETER
SPRING
LENGTH PART
NUMBER MATERIAL SPRING COLOR
bar psig bar psig mm In. mm In.
OS9/80X-MPA-D-R
0.3 to 0.40 4.35 to 5.80 0.15 2.17 1.75 0.07 60.0 2.36 M0174340X12 Steel Yellow
0.40 to 0.90 5.80 to 13.05 0.30 4.35 2.25 0.09 60.0 2.36 M0197060X12 Steel Blue
0.90 to 4 13.05 to 58.01 0.70 10.15 3.00 0.12 60.0 2.36 M0197820X12 Steel Red
OS9/80X-APA-D-R
0.3 to 0.8 4.35 to 11.6 0.25 3.62 1.75 0.07 60.0 2.36 M0174340X12 Steel Yellow
0.8 to 2.0 11.6 to 29 0.50 7.25 2.25 0.09 60.0 2.36 M0197060X12 Steel Blue
2.0 to 7.0 29 to 101.52 1.50 21.7 3.00 0.12 60.0 2.36 M0197820X12 Steel Red
OS9/84X-R 4.0 to 8.0 58.01 to 116.03 3 43.50 2.25 0.09 60.0 2.36 M0197060X12 Steel Blue
7.0 to 16 101.52 to 232.06 6 87.00 3.00 0.12 60.0 2.36 M0197820X12 Steel Red
OS9/88X-R 8.0 to 30 116.03 to 435.11 8 116.00 1.75 0.07 60.0 2.36 M0174340X12 Steel Yellow
20 to 70 290.07 to 1015.26 15 217.50 2.25 0.09 60.0 2.36 M0197060X12 Steel Blue
OS/80X-PN with
PRX/181-PN
0.5 to 1.1 7.3 to 16 0.3 4.35 2.50 0.10 51 2.01 M0255250X12 Steel White
1 to 1.8 14.5 to 26 0.4 5.80 2.80 0.11 55 2.17 M0255240X12 Steel Yellow
1.6 to 3 23 to 44 0.4 5.80 3.20 0.13 55 2.17 M0255230X12 Steel Green
2.8 to 5.5 41 to 80 0.6 8.70 3.50 0.14 55 2.17 M0255180X12 Steel Blue
5 to 8.5 73 to 123 0.6 8.70 4.00 0.16 55 2.17 M0255220X12 Steel Black
8 to 14.5 116 to 210 0.6 8.70 4.50 0.18 55 2.17 M0255210X12 Steel Silver
14 to 23 203 to 334 0.8 11.60 5.50 0.22 51 2.01 M0255200X12 Steel Gold
22 to 30 319 to 435 0.8 11.60 6.00 0.24 51 2.01 M0255860X12 Steel Aluminum
29 to 42 421 to 609 0.8 11.60 6.50 0.26 50 1.97 M0255190X12 Steel Red
OS/84X-PN with
PRX-AP/181-PN 30 to 80 435 to 1160 1 14.50 8.50 0.33 100 3.94 M0273790X12 Steel Neutral

Type BM9
19
2. Use maximum adjusting nut (key 50) to completely
load maximum pressure spring (key 53). Loosen
minimum adjusting screw (key 49) to completely
relieve minimum pressure spring (key 54).
3. Disconnect sensing line to port (A) of slam-
shut controller.
4. Through the pressure control connection, use a
small pump or other appropriate means to raise
the pressure to normal operating level.
5. Reset slam-shut controller and reduce the
pressure until it reaches minimum cutoff level.
6. Use minimum adjusting screw (key 49) to load
spring (key 54) slowly until pilot is triggered.
7. Repeat steps 4 and 5 above, making any
necessary adjustment in the setting.
8. Bring pressure back to normal values.
9. Reset controller and raise the pressure until it
reaches maximum cutoff level.
10. Using maximum adjusting nut (key 50), slowly
unload spring (key 53) until cutoff point is reached.
11. Repeat steps 8 and 9 above, making any
adjustment necessary in the setting.
Parts Ordering
Contact your local Sales Office when ordering
replacement parts. Repair kits containing all
recommended spare parts are available.
The serial number, type number, spring range, the
date of manufacture and other pertinent information
are stamped on the nameplate. Always provide
this information in any correspondence with your
local Sales Office regarding replacement parts or
technical assistance.
Spare Parts
Spare parts storage shall be done by proper
procedures according to national standard/rules to
avoid over aging or any damage.
Parts Lists
▲ WARNING
Use only genuine Emerson replacement
parts. Components that are not supplied
by Emerson should not, under any
circumstances, be used in any Emerson
slam-shut valve, because they will void
your warranty, might adversely affect the
performance of the slam-shut valve and
could give rise to personal injury and
property damage.
Type BM9 Slam-Shut Valve
DN 200 / NPS 8 Body Size
Key Description Part Number
Parts Kit
Static and Dynamic (included are keys 3, 11,
25, 42, 43, 44, 45, 47, 51, 58, 59, 63,
78, 106 and 107)
Nitrile (NBR) ERAA48400A0
Fluorocarbon (FKM) ERAA48401A0
Dynamic (included are keys 25, 42, 43, 44,
47, 51, 58, 59 and 106)
Nitrile (NBR) ERAA48402A0
Fluorocarbon (FKM) ERAA48403A0
1 Body, LCC steel
CL300 RF
With Drainage Hole ERAA47144A1
Without Drainage Hole ERAA47145A1
CL600 RF
With Drainage Hole ERAA47142A1
Without Drainage Hole ERAA47143A1
2 End Cap, LCC steel ERAA47160A0
3* O-ring
Nitrile (NBR) ERAA43958A0
Fluorocarbon (FKM) ERAA43958A1
4 Bolt, steel (6 required) JI1H6080020
5 Washer (6 required) ERAA42959A1
6 Bushing, Stainless steel ERAA47775A0
7 Shaft, steel ERAA47776A0
8 Bonnet, steel ERAA47777A0
9 Controller - - - - - - - - - - -
10 Label - - - - - - - - - - -
11 O-ring ERAA43953A2
12 Barrel, steel ERAA47778A0
13 Bushing, steel ERAA47779A0
14 Ring, Stainless steel ERAA47780A0
15 Cage, steel ERAA47781A0
16 Gasket
CL300 RF JI2B9650200
CL600 RF JI2B9611200
17 Spacer, steel
CL300 RF ERAA43758A1
CL600 RF ERAA43759A1
- continued -
*Recommended Spare Parts

Type BM9
20
18 Disk Holder, steel
CL300 RF ERAA43744A1
CL600 RF ERAA43745A1
19 Stem, steel ERAA47782A0
20 Locknut, steel ERAA27830A0
21 Screw, steel ERAA22999A0
22 Bearing ERAA27834A0
23 Plug Retainer, steel ERAA23452A0
24 Sleeve, steel ERAA47783A0
25* Ring ERAA47784A0
26 Spring, steel ERAA47785A0
27 Ring (Barrel) ERAA43764A0
28 End Plate, steel ERAA47786A0
29 Tab Washer, Stainless steel ERAA47787A0
30 Nut, steel JI1E2000M20
31 Eyebolt, steel JG11000BM12
32 Bracket, steel
Standard Option ERAA44093A0
Wireless Transmitter ERAA48399A0
33 Handle Unit See Handle Unit section
34 Eyebolt, steel (2 required) ERAA45560A0
35 Bushing ERAA44787A0
36 Pin, Limit ERAA44788A0
37 Plug, steel ERAA03131A0
38 Bushing ERAA47788A0
39 Cap Fixation, Stainless steel ERAA47789A0
40 Screw, Stainless steel (12 required) JI1H6050016
41 Washer (12 required) ERAA47790A0
42* O-ring (2 required)
Nitrile (NBR) ERAA43959A0
Fluorocarbon (FKM) ERAA43959A1
43* Backup Ring (2 required) ERAA43742A0
44* O-ring
Nitrile (NBR) ERAA43952A0
Fluorocarbon (FKM) ERAA43952A1
45* O-ring (2 required)
Nitrile (NBR) ERAA43957A0
Fluorocarbon (FKM) ERAA43957A1
47* Disk, PTFE ERAA48872A0
50 Cam Roller ERAA35456A0
51* Wiper ERAA47791A0
52 Screw, Stainless steel (3 required) M0220650X12
53 Thrust Ball Bearing ERAA47792A0
55 Cam, Stainless steel ERAA47793A0
56 Bushing (2 required) ERAA47794A0
57 Retainer Ring ERAA47795A0
58* O-ring
Nitrile (NBR) ERAA47161A0
Fluorocarbon (FKM) ERAA47161A1
59* Backup Ring, PTFE ERAA47796A0
60 Pin (2 required) M4500187X12
61 Stud (8 required) JI1B8160055
62 Nut (8 required) JI1E2000M16
63* O-ring
Nitrile (NBR) ERAA35462A0
Fluorocarbon (FKM) ERAA35462A1
64 Flow Arrow - - - - - - - - - - -
65 Drive Screw (4 required) - - - - - - - - - - -
66 Nameplate Sticker - - - - - - - - - - -
67 Nameplate Support - - - - - - - - - - -
70 Nut - - - - - - - - - - -
71 Washer - - - - - - - - - - -
73 Tee, Pipe (2 required) - - - - - - - - - - -
74 Fitting Elbow
Type PRX/182-PN or PRX/181-PN (2 required) - - - - - - - - - - -
Types PRX/182-PN and PRX/181-PN (4 required) - - - - - - - - - - -
75 Fitting Tee
Type PRX/182-PN or PRX/181-PN (1 required) - - - - - - - - - - -
Types PRX/182-PN and PRX/181-PN (2 required) - - - - - - - - - - -
76 Tube - - - - - - - - - - -
77 Bracket ERAA46711A0
78 Seal Retainer ERAA43763A0
79 Washer (8 required) JI1J1000016
84 Spring Washer (8 required) JI1J3000016
Type BM9 Slam-Shut Valve
DN 250 / NPS 10 Body Size
Key Description Part Number
Parts Kit
Static and Dynamic (included are keys 3, 11,
25, 42, 43, 44, 45, 47, 51, 58, 59,
63, 68, 69, 78, 106 and 107)
Nitrile (NBR) ERAA48506A0
Fluorocarbon (FKM) ERAA48507A0
Dynamic (included are keys 25, 42, 43, 44,
47, 51, 58, 59 and 106)
Nitrile (NBR) ERAA48508A0
Fluorocarbon (FKM) ERAA48509A0
1 Body, LCC steel
CL300 RF
With Drainage Hole ERAA47134A1
Without Drainage Hole ERAA47135A1
CL600 RF
With Drainage Hole ERAA47132A1
Without Drainage Hole ERAA47133A1
2 End Cap, LCC steel ERAA48380A0
3* O-ring
Nitrile (NBR) ERAA44420A0
Fluorocarbon (FKM) ERAA44420A1
4 Bolt, steel (6 required) M5011046X12
5 Washer (6 required) ERAA34047A1
6 Bushing, Stainless steel ERAA48381A0
7 Shaft, steel ERAA48473A0
8 Bonnet, steel ERAA47777A0
9 Controller - - - - - - - - - - -
10 Label - - - - - - - - - - -
11 O-ring ERAA43953A2
12 Barrel, steel ERAA48382A0
13 Bushing, steel ERAA48383A0
14 Ring, Stainless steel ERAA48384A0
15 Cage, steel ERAA50358A0
*Recommended Spare Parts
Key Description Part Number
Type BM9 Slam-Shut Valve
DN 200 / NPS 8 Body Size (continued)
Key Description Part Number
Type BM9 Slam-Shut Valve
DN 200 / NPS 8 Body Size (continued)
- continued -
