Emerson Smart Wireless Gateway 1410 User manual

Reference Manual
00809-0200-4410, Rev BA
February 2014
Emerson Smart Wireless Gateway 1410

Reference Manual
00809-0200-4410, Rev BA
Title Page
February 2014
iii
Smart Wireless Gateway
PlantWeb is a registered trademark of one of the Emerson Process Management group of companies.
Modbus is a registered trademark of Schneider Automation, Inc.
All other marks are the property of their respective owners.
NOTICE
Read this manual before working with the product. For personal and system safety, and for
optimum product performance, make sure you thoroughly understand the contents before
installing, using, or maintaining this product.
Within the United States, Emerson Process Management has
two toll-free assistance numbers:
Global Service Center
Software and Integration Support
1-800-833-8314 (United States)
[phone] (International)
Customer Central
Technical support, quoting, and order-related questions.
1-800-999-9307 (7:00 am to 7:00 pm CST)
North American Response Center
Equipment service needs.
1-800-654-7768 (24 hours—includes Canada)
Outside of the United States, contact your local Emerson Process Management
representative.
The products described in this document are NOT designed for nuclear-qualified
applications. Using non-nuclear qualified products in applications that require
nuclear-qualified hardware or products may cause inaccurate readings.
For information on Rosemount nuclear-qualified products, contact your local Emerson
Process Management Sales Representative.

1
Reference Manual
00809-0200-4410, Rev BA
Table of Contents
February 2014
Table of Contents
1Section 1: Overview
1.1 Safety messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
1.2 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
1.3 Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
1.4 Service support. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
1.5 Return of materials . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
1.6 Product recycling/disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
2Section 2: Initial connection
2.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
2.2 System requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
2.3 Initial connection and configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
2.3.1 Prepare PC/Laptop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
2.3.2 Connections and power. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
2.3.3 Configure the gateway . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
2.3.4 System backup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
2.3.5 Web page usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
2.3.6 Resetting to factory defaults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
3Section 3: Mounting and connection
3.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
3.1.1 General considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
3.1.2 Physical description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
3.2 Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
3.3 Remote antenna. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
3.4 Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
3.4.1 Grounding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
3.4.2 Ethernet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
3.4.3 RS-485. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
3.4.4 Terminating resistors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
3.4.5 Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Contents

2
Reference Manual
00809-0200-4410, Rev BA
Table of Contents
February 2014
Table of Contents
4Section 4: Software setup
4.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
4.2 System requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
4.3 Software installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
4.4 Security setup utility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
4.4.1 Setup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
4.5 AMS Wireless Configurator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
4.5.1 Setup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
4.6 Licensing and credits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
5Section 5: Host integration
5.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35
5.2 Network architecture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35
5.3 Internal firewall. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
5.4 Modbus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37
5.4.1 Communication settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37
5.4.2 Register mapping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39
5.5 EtherNet/IP™. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44
6Section 6: Troubleshooting
7Section 7: Glossary
AAppendix A: Product specifications
A.1 Ordering information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55
A.2 Functional specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .57
A.3 Physical specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .58
A.4 Communication specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .58
A.5 Self-organizing network specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .59
A.6 System security specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .59
A.7 Dimensional drawings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .60
A.8 Accessories and spare parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .62

3
Reference Manual
00809-0200-4410, Rev BA
Table of Contents
February 2014
Table of Contents
BAppendix B: Product Certifications
B.1 Approved Manufacturing Locations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63
B.2 Telecommunications Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63
B.3 FCC and IC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63
B.4 European Directive Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63
B.5 Ordinary Location Certification from FM Approvals . . . . . . . . . . . . . . . . . . . . . . . .63
B.6 Hazardous Locations Certifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .64

1
Reference Manual
00809-0200-4410, Rev BA
Section 1: Overview
February 2014
Overview
Section 1 Overview
Safety messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 1
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 2
Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 2
Service support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 3
Return of materials . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 4
Product recycling/disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 4
1.1 Safety messages
Instructions and procedures in this manual may require special precautions to ensure the safety
of the personnel performing the operations. Information that potentially raises safety issues is
indicated by a warning symbol ( ). Please refer to these safety messages before performing an
operation preceded by this symbol.
Failure to follow these installation guidelines could result in death or
serious injury.
Make sure only qualified personnel perform the installation.
Explosions could result in death or serious injury.
Verify that the operating atmosphere of the device is consistent with the appropriate
hazardous locations certifications.
Electrical shock could cause death or serious injury.
Use extreme caution when making contact with the leads and terminals.
Warning - Potential Electrostatic Charging Hazard
The 1410 enclosure is engineered polymer. Use care in handling and cleaning when in
explosive environments to avoid an electrostatic discharge.
Warning - Explosion Hazard
Do not make or break any connections to the 1410 while circuits are live unless area is
known to be non-hazardous.

2
Reference Manual
00809-0200-4410, Rev BA
Section 1: Overview
February 2014
Overview
1.2 Introduction
The Emerson Smart Wireless Gateway 1410 (Gateway) connects WirelessHART™ self-organiz-
ing networks with host systems and data applications. Modbus communications over RS-485 or
Ethernet provide universal integration and system interoperability. The optional OPC or
EtherNet/IP functionality from the Gateway offers a means to connect to newer systems and
applications while providing a richer set of data.
The Smart Wireless Gateway provides industry leading security, scalability, and data reliability.
Layered security ensures that the network stays protected. Additional devices can be added at
any time. There is no need to configure communication paths because the Gateway manages
the network automatically. This feature also ensures that WirelessHART field devices have the
most reliable path to send data.
What is Included?
The box containing the Gateway will contain several items essential to the complete installation
and operation of the Gateway.
Smart Wireless Gateway
Quick Installation Guide
Software pack, 2 disk set
Informational side label for IP address
Basic antenna (if no remote antenna is required)
Terminal block (black)
If an optional remote antenna has been ordered, it will be in a separate box containing:
Remote mount antenna
Mounting hardware
Lightning arrestor
Cable (50/25 ft. (15,2/7,62 m) in length)
Coaxial sealant tape
Right angle SMA to N-Type adapter cable
1.3 Manual
This manual will help to install, configure, operate, and maintain the Gateway.
Section 1: Overview
This section introduces the product and describes what components may be found in the box. It
also includes details for services and support as well as return and disposal of the product.
Section 2: Initial connection
This section describes how to connect to the Gateway for the first time and what settings should
be configured before placing it on a live control network. It is important to note that some
Gateways are used in stand-alone applications and do not reside on a network. In these cases, it
is still important to configure the items outlined in this section.

3
Reference Manual
00809-0200-4410, Rev BA
Section 1: Overview
February 2014
Overview
Section 3: Mounting and connection
This section describes how to properly mount the Gateway and make electrical connections,
including electrical wiring, grounding, and host system connections. This section also describes
how to mount the optional remote antenna.
Section 4: Software setup
This section describes the installation and setup of the optional software included with the
Smart Wireless Gateway. This software will aid in secure host integration as well as wireless field
device configuration.
Section 5: Host integration
This section describes how to connect the Gateway to a host system and integrate data
gathered from the field device network. It covers network architectures, security, and data
mapping.
Section 6: Troubleshooting
This section provides troubleshooting tips as well as information to contact technical support
over the phone or through email.
Section 7: Glossary
The glossary defines terms used throughout this manual or that appear in the web interface of
the Smart Wireless Gateway.
Appendix A: Product specifications and Appendix B: Product Certifications
The appendices provide additional and more specific information on a variety of subjects
including Product Specifications and Product Certifications.
1.4 Service support
Global Service Center
Software and Integration Support
United States 1 800 833 8314
International 63 2 702 1111
Customer Central
Technical Support, quoting, and order related questions
United States1 800 999 9307 (7:00 a.m. to 7:00 p.m. CST)
Asia Pacific 65 6777 8211
Europe/Middle East/ Africa 49 8153 9390

4
Reference Manual
00809-0200-4410, Rev BA
Section 1: Overview
February 2014
Overview
1.5 Return of materials
To expedite the return process outside of North America, contact your Emerson Process
Management representative.
Within the United States, call the Emerson Process Management Response Center toll-free
number 1 800 654 7768. The center, which is available 24 hours a day, will assist you with any
needed information or materials.
The center will ask for product model and serial numbers, and will provide a Return Material
Authorization (RMA) number. The center will also ask for the process material to which the
product was last exposed.
1.6 Product recycling/disposal
Recycling of equipment and packaging should be taken into consideration and disposed of in
accordance with local and national legislation/regulations.
Individuals who handle products exposed to a hazardous substance can avoid injury if they
are informed of, and understand, the hazard. If the product being returned was exposed to
a hazardous substance as defined by OSHA, a copy of the required Material Safety Data
Sheet (MSDS) for each hazardous substance identified must be included with the returned
goods.

Reference Manual
00809-0200-4410, Rev BA
Section 2: Initial Connection
February 2014
5Initial Connection
Section 2 Initial connection
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 5
System requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 6
Initial connection and configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 6
2.1 Overview
This section describes how to connect to the Gateway for the first time and what settings should
be configured before placing it on a live control network. It is important to note that some
Gateways are used in stand-alone applications and do not reside on a network. In these cases, it
is still important to configure the items outlined in this section.
Before the Gateway can be permanently mounted and connected to a live control network, it
needs to be configured with an IP address. This is done by forming a private network between
the Gateway and a PC/Laptop. The following items are required to complete this section:
Gateway
PC/Laptop
Ethernet Cable
24 VDC (nominal) power supply
Failure to follow these installation guidelines could result in death or serious injury:
Only qualified personnel should perform the installation
Explosions could result in death or serious injury.
Verify that the operating atmosphere of the gateway is consistent with the appropriate
hazardous locations certifications
Do not make or break connections to the 1410 while circuits are live unless the area is
know to be non-hazardous
Potential electrostatic charging hazard. Enclosure is a polymer, use care when handling
or cleaning
Electrical shock could cause death or serious injury.
Use extreme caution when making contact with the leads and terminals
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
conditions: This device may not cause harmful interference. This device must accept any
interference received, including interference that may cause undesired operation.
This device must be installed to ensure a minimum antenna separation distance of 20 cm
from all persons.

6
Reference Manual
00809-0200-4410, Rev BA
Section 2: Initial Connection
February 2014
Initial Connection
2.2 System requirements
The following requirements apply to the PC/Laptop used to configure the Gateway. Additional
requirements may apply if using the Security Setup Utility or AMS Wireless Configurator. See
Section 4: Software setup on page 27 for more information.
Web browser applications
Microsoft Internet Explorer®6.0 - 10.0
Ethernet
10/100 base-TX Ethernet communication protocol
2.3 Initial connection and configuration
2.3.1 Prepare PC/laptop
The PC/Laptop will need to be configured to form a private network before communicating to
the Gateway. The network settings can be found in the control panel of the PC/Laptop running a
Microsoft platform based operating system. To configure these settings:
1. Find and open the Control Panel. (It is generally found from the Start Menu.)
2. Open Network Connections.
3. Select Local Area Connection.
4. Right click the mouse and select Properties from the list.
5. Select Internet Protocol (TCP/IP), and choose the Properties button.
6. From the General tab, select Use the following IP address button.
7. Set the IP Address to 192.168.1.12 and press the Tab button.
8. A Subnet mask of 255.255.255.0 should fill in automatically.
9. Click OK to close the Internet Protocol (TCP/IP) window.
10. Click Close on the Local Area Connection window.

7
Reference Manual
00809-0200-4410, Rev BA
Section 2: Initial Connection
February 2014
Initial Connection
Internet proxies will need to be disabled through the PC/Laptop’s default internet browser.
Disable the proxies with the following procedure:
1. Find and open the default internet browser.
2. Find the Tools menu and select Internet Options.
3. From the Connections tab, click the LAN Settings button.
4. Under Proxy Server, the boxes for Automatically Detect Settings and Use a proxy server for
your LAN should be unchecked.
5. Click OK to close the Local Area Network (LAN) Settings window.
6. Click OK to close the Internet Options window.
The PC/Laptop is now set up to form a private network and to communicate with the Gateway.
Note
Connecting to the Gateway's secondary Ethernet port will require different network settings.
Please see Table 2-1 for additional network settings.
Table 2-1. Default IP Addresses
2.3.2 Connections and power
Physically connect the PC/Laptop to the Gateway with an Ethernet cable by connecting one end
to the Ethernet port on the back of the PC/Laptop. Connect the other end to the Ethernet 1 port
on the Gateway. “Configure the gateway” on page 9 shows the standard terminal block
diagram. Once the Gateway and PC/Laptop are connected, wire a 24 VDC (nominal) power
supply with a capacity of at least 250 mA to the Gateway power input terminals.
Gateway PC/laptop Subnet
Ethernet 1 192.168.1.10 192.168.1.12 255.255.255.0
Ethernet 2 192.168.2.10 192.168.2.12 255.255.255.0

8
Reference Manual
00809-0200-4410, Rev BA
Section 2: Initial Connection
February 2014
Initial Connection
Figure 2-1. Emerson Smart Wireless Gateway 1410 Housing Diagram
A. DIN rail clip.
B. SMA connector.
C. Power and Reset indicator lights. During normal operation the power indicator will be green. During a reset
the reset light will turn red. The reset switch should not be enabled during normal operation.
D. Ethernet port 2. This secondary port must be enabled when ordering to access the device. When this port is
activated, the factory IP address is 192.168.2.10. See Table 2-1.
E. Ethernet port 1. Use for standard communication to the webserver or other protocols enabled on the gateway.
The factory IP address is 192.168.1.10. See Table 2-1.
F. Five screw terminal block.
+-AB
24 VDC
(nominal)
Power Input
Serial
Modbus
S
Power
Reset
A
B
C
D
E
F

9
Reference Manual
00809-0200-4410, Rev BA
Section 2: Initial Connection
February 2014
Initial Connection
2.3.3 Configure the gateway
It is now possible to log into the Gateway for the first time and begin configuration for
placement on a live control network. The following items need to be configured:
Security Passwords
Time Settings
TCP/IP Network Settings
Use the following procedure to log in to the Gateway:
1. Open a standard web browser.
2. Enter https://192.168.1.10 in the address bar.
3. Continue though the security message.
4. Enter admin for User Name.
5. Enter default for the Password.
The web browser will now be directed to the Gateway’s default home page. There is a navigation
menu located on the left hand side with four main areas.
Diagnostics: View status of communications, client server parameters, and more
Monitor: Screens created by the user to view data from field devices
Explorer: Basic view of values from field devices
Setup: Configure the Gateway for operations, security, and host system integration
Security passwords
There are four role based user accounts for the Gateway with varying levels of access. Table 2-2
below describes this access.
Table 2-2. Role Based Access User Accounts
Role User name Web interface access
Executive exec Read-only access
Operator oper Read-only access
Maintenance maint Configure HART®device settings
Configure Modbus communications
Configure Modbus register mapping
Configure OPC browse tree
Configure Active Advertising
Administrator admin Includes all maintenance privileges
Configure Ethernet network settings
Configure WirelessHART network settings
Set passwords
Set time settings
Set home page options
Configure custom point pages
Restart applications

10
Reference Manual
00809-0200-4410, Rev BA
Section 2: Initial Connection
February 2014
Initial Connection
Each of the initial passwords for the user accounts is default. It is recommended, for security
purposes, that these passwords are changed. The administrator password should be
appropriately noted when changed. If it is lost, do not return the Gateway to the factory, see
“Resetting to factory defaults” on page 15.
To change the User Accounts Passwords:
1. Navigate to Setup>Security>User accounts.
2. Set the new password for each role based user account, and confirm.
3. Choose Submit.
Note
It is suggested that the default security settings in Setup>Security>User Options be changed to
the local IT best practices or the “Normal” setting after initial login. Strong or custom settings
are available for more robust passwords. For more information on this screen and others please
see the User Interface Terminology Guide (00809-0600-4420).
Antivirus
Antivirus and other software tools are not included in the Gateway firmware. These software
tools should be installed on any machine connected to the Gateway. Emerson bundles the latest
software patches into our standard Gateway firmware updates. These software patches are not
anti-malware or antivirus tools in any sense of the word, but do provide the latest in security
protection.
Password complexity
The browser front-end of the Gateway supports many customizable password rules
(Setup>Security>User Options). All of the following rules are customizable:
Minimum overall password length
Minimum lowercase character count
Minimum uppercase character count
Minimum digit count
Minimum symbol count
Idle session timeout time
Maximum session lifetime to force a user to re-enter their password
Minimum password lifetime to prevent a user from changing their password too often
Maximum password lifetime to periodically force a user to change their password.
Password failure limit at which point the account is locked and the user must wait for a
specified period of time prior to additional attempts to enter their password
Password failure lock to lock an account after a specified number of incorrect
passwords
Require a wait period after the specified number of incorrect passwords have been
entered
Password history depth to limit reuse of passwords

11
Reference Manual
00809-0200-4410, Rev BA
Section 2: Initial Connection
February 2014
Initial Connection
Logging
The Gateway monitors many security events automatically. A complete list of events can be
viewed from the Log Settings (Setup>Log Settings) area in the Gateway interface. The Gateway
also supports the optional use of a Syslog server. This provides significant flexibility and allows
the user to determine how log messages are handled and how long logs are kept. It is possible
for the user to configure the Syslog server to issue automated alerts for various messages.
Time settings
The Gateway is the timekeeper for the WirelessHART network, so it is imperative that the
Gateway’s time is accurate for timestamp data to be meaningful. Time settings can be found by
navigating to Setup>Time as shown in Figure 2-2 on page 12.
Gateway time settings and time stamps are stored internally as UTC time. The appropriate web
browser being used displays the time as per the local browser settings.
There are three ways to set the Gateway time:
1. Network Time Protocol (recommended).
This option uses a Network Time Protocol (NTP) server to slowly adjust the Gateway’s
time in order to match the time of the control network. Enter the IP address for the NTP
server and select the packet version (1, 2, 3, or 4).
2. Set with PC Time.
This option will match the Gateway’s time to that of the PC/Laptop.
3. Manual Entry.
This option allows the user to enter a specific date (MM:DD:YY) and time (HH:MM:SS).
Note
Network Time Protocol (NTP) is recommended for the best network performance because it
always adjusts time to match the network time server.
Failure to provide regular time synchronization over a long period of time (months) can cause
the Gateway network to drift off time.

12
Reference Manual
00809-0200-4410, Rev BA
Section 2: Initial Connection
February 2014
Initial Connection
Figure 2-2. Setup>Time Settings
TCP/IP network settings
Prior to the Gateway being installed and connected to a live control network, it should be
configured with an IP address, as well as other TCP/IP network settings. This specific page can be
found in “System backup” on page 14.
Figure 2-3. Ethernet Settings
Use caution when making changes to the TCP/IP network settings. If they are lost or
entered incorrectly, the Gateway will require a factory reset (see“Resetting to factory
defaults” on page 15). Contact the network administrator for information on the proper
TCP/IP network settings to apply.
