Emerson Smart Wireless Gateway 1420 User manual

Quick Start Guide
00825-0200-4420, Rev GD
September 2020
Emerson Wireless 1420 Gateway

NOTICE
This guide provides basic guidelines for the Emerson Gateway. It does not provide instructions for
diagnostics, maintenance, service, or troubleshooting. Refer to the Emerson Gateway Reference
Manual for more information and instructions. This guide and the manual are available electronically
on www.emerson.com.
WARNING
Explosions could result in death or serious injury.
Installation of device in an explosive environment must be in accordance with appropriate local,
national, and international standards, codes, and practices.
Avoid contact with the leads and terminals. High voltage that may be present on leads can cause
electrical shock. Review the Product Certifications section for any restrictions associated with a safe
installation.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
conditions:
This device may not cause harmful interference.
This device must accept any interference received, including interference that may cause undesired
operation.
This device must be installed to ensure a minimum antenna separation distance of 8-in. (20 cm) from
all persons.
Contents
Wireless considerations................................................................................................................3
General considerations.................................................................................................................4
Initial connection and configuration.............................................................................................5
Physical installation.................................................................................................................... 13
Connect to the host system........................................................................................................19
Software installation (optional).................................................................................................. 21
Verify operations........................................................................................................................22
Product specifications................................................................................................................ 23
Product certifications................................................................................................................. 26
Quick Start Guide September 2020
2 Emerson.com/Rosemount

1 Wireless considerations
1.1 Power up sequence
The Emerson Wireless Gateway (Gateway) should be installed and
functioning properly before power modules are installed in any wireless field
devices. Wireless field devices should also be powered up in order of
proximity from the Gateway beginning with the closest. This will result in a
simpler and faster network installation.
1.2 Antenna position
The antenna should be positioned vertically, and be approximately 3 ft. (1
m) from large structures or buildings to allow for clear communication to
other devices.
1.3 Mounting height
For optimal wireless coverage, the Gateway or remote antenna is ideally
mounted 15 to 25 ft. (4,6 to 7,6 m) above ground or 6 ft. (2 m) above
obstructions or major infrastructure.
1.4 Gateway redundancy
If the wireless Gateway was ordered with redundancy (Gateway Redundancy
code RD), refer to Appendix D in the Emerson Wireless Gateway Reference
Manual for additional installation instructions.
September 2020 Quick Start Guide
Quick Start Guide 3

2 General considerations
2.1 PC requirements
Operating system (optional software only)
•Microsoft® Windows™ XP Professional, Service Pack 3
•Windows Server 2003 Service Pack 2
•Windows Server 2003 R2 Service Pack 2
•Windows Server 2008 (Standard Edition), Service Pack 2
•Windows Server 2008 R2 Standard Edition, Service Pack 1
•Windows 7 Professional, Service Pack 1
•Windows 7 Enterprise, Service Pack 1
Applications
•Internet Explorer® 6.0 or higher
•Mozilla Firefox® 1.5 or higher
•.Net Framework 2.0 (for OPC proxy only)
Hard disk space
•AMS Wireless Configurator: 1.5 GB
•Gateway Setup CD: 250 MB
Quick Start Guide September 2020
4 Emerson.com/Rosemount

3 Initial connection and configuration
3.1 DeltaV™ ready
If the Gateway was ordered DeltaV Ready (Data Protocols Code 5), then skip
to Physical installation, and connect the Gateway to a DeltaV 10.3 or newer
control network.
3.2 Initial connection and configuration
To configure the Gateway, a local connection between a PC/laptop and the
Gateway needs to be established.
Powering the Gateway
Bench top power will be needed to power the Gateway by wiring a 24 VDC
(nominal) power source, with at least 250 mA, to the power terminals.
Figure 3-1: Legacy Gateway Terminal Block Diagram
+
+
+
+
+
-
-
-
-
-
A B
S
S
S
S
24 VDC
(nominal)
Power Input
Serial
Modbus
Not Used
Not Used
Not Used
Not Used
Case
(Covered)
S
Ethernet 2
with Power Ethernet 2 Ethernet 1
(Secondary) (Primary)
®
Figure 3-2: Power over Ethernet (PoE) Terminal Block Diagram
+- A B
24 VDC
(nominal)
Power Input
Serial
Modbus
Case
SEthernet 2 Ethernet 1
(Secondary) (Primary)
September 2020 Quick Start Guide
Quick Start Guide 5

Note
Figure 3-1 depicts the terminal block of legacy Gateways prior to the
introduction of PoE capabilities. Figure 3-2 shows the terminal block
arrangement of a PoE version of the Gateway. If the Gateway will be
powered via the standard 24 volt power input terminals, and no PSE is
desired, it is not necessary to change the default settings of the PoE jumper
matrix.
Note
The Gateway enclosure case should always grounded in accordance with
national and local electrical codes. The most effective grounding method is a
direct connection to earth ground with minimal impedance.
Quick Start Guide September 2020
6 Emerson.com/Rosemount

Figure 3-3: Emerson 1420 PoE Jumpering Matrix (Located on 1420
Board)
PoE PD on port 1
(Default jumpering for
production. Used for no
PoE also)
PoE PD on port 2
PoE PSE on port 1
PoE PSE on port 2
Black fill below indicates jumper.
Legend:
ETH1 Ethernet port 1 selected for PD or PSE
ETH2 Ethernet port 2 selected for PD or PSE
PD Gateway derived its power off the Ethernet port selected
PSE The Gateway is powered via the standard 24 volt power input
terminals and provides power via the selected Ethernet port to
another device with a compatible PD port.
EN Enabled; this enables the PSE operation
DIS Disabled; this disables the PSE operation
Note
Electrostatic discharge (ESD) protection required when swapping PoE
jumpers.
Note
Only one port and one mode of operation (PD or PSE) can be selected at a
time; any other combination of jumpers is invalid.
September 2020 Quick Start Guide
Quick Start Guide 7

Note
IEEE 802.3af-2003 PoE standard provides up to 15.4 W of DC power
(minimum 44 V DC and 350 mA) to each device. Only 12.95 W is assured to
be available at the powered device as some power is dissipated in the cable.
IEEE 802.3at-2009 PoE standard also known as “PoE+” or “PoE plus”,
provides up to 25.5 W of power. The 2009 standard prohibits a powered
device from using all four pairs for power.
For more information on PoE and frequently asked questions, reference the
Emerson Wireless Gateway white paper.
3.3 Establishing a connection
Note
For information on connecting a Windows 7 PC, see Technical Note
(document number 00840-0900-4420).
Procedure
1. Connect the PC/laptop to the Ethernet 1 (Primary) receptacle on the
Gateway.
Figure 3-4: Gateway PC/Laptop Connection
+ +
+
+
+
-
--
-
-A B S S
SS
S
24V DC
PowerInput Modbus NotUsed NotUsed
NotUsed Not Used
Case
S
POE P2 P1
A
B
APC/laptop
BEthernet 1 receptacle
CAUTION
Do not connect to the Ethernet 2 with power (covered) port. This
port supplies power and could damage the PC/laptop.
2. To establish the PC/laptop settings, navigate to Start → Settings →
Network Connections.
a) Select Local Area Connection.
Quick Start Guide September 2020
8 Emerson.com/Rosemount

b) Right click to select Properties.
c) Select Internet Protocol (TCP/IP), then select the Properties
button.
Note
If the PC/laptop is from another network, record the current
IP address and other settings so the PC/laptop can be
returned to the original network after the Gateway has been
configured.
d) Select the Use the following IP address button.
e) In the IP address field, enter 192.168.1.12.
f) In the Subnet mask field, enter 255.255.255.0.
g) In the Internet Protocol (TCP/IP) Properties window, select OK.
September 2020 Quick Start Guide
Quick Start Guide 9

h) In the Local Area Connection Properties window, select OK.
Note
Connecting to the Gateway's secondary Ethernet port
requires different network settings. Refer to Table 3-1 for
additional network settings.
Table 3-1: Default IP Addresses
Gateway PC/laptop
Ethernet 1 192.168.1.10 192.168.1.12
Ethernet 2 192.168.2.10 192.168.2.12
Ethernet 1 (DeltaV Ready) 10.5.255.254 10.5.255.200
Ethernet 2 (DeltaV Ready) 10.9.255.254 10.9.255.200
Table 3-2: Subnet Settings
Subnet mask
Default 255.255.255.0
DeltaV 255.254.0.0
3. Disable proxies.
a) Open a standard web browser (Internet Explorer, Mozilla
Firefox, or other).
b) Navigate to Tools → Internet Options → Connections →
LAN Settings.
c) Uncheck the box under Proxy Server.
Quick Start Guide September 2020
10 Emerson.com/Rosemount

3.4 Configure the Gateway
To complete initial configuration for the Gateway:
Procedure
1. Access the default web page for the Gateway at https://
192.168.1.10.
a) In the User name field, enter admin.
b) In the Password field, enter default.
Figure 3-5: Gateway Log In Screen
2. Navigate to System Settings → Gateway → → Ethernet
Communication to enter the Network Settings.
a) Configure a static IP Address or set for DHCP and enter a
Hostname.
b) Restart application at System Settings → Gateway →
Backup And Restore → Restart App.
3. Disconnect the power and Ethernet from the Gateway.
September 2020 Quick Start Guide
Quick Start Guide 11

Quick Start Guide September 2020
12 Emerson.com/Rosemount

4 Physical installation
4.1 Pipe mount
Tools needed:
•2-in. (51 mm) mounting pipe or mast
•Two 5/16-in. (7,9 mm) u-bolts supplied with Gateway
•1/2-in. socket-head wrench
For installing the Gateway with a pipe mount:
Procedure
1. Insert one u-bolt around the pipe, through the top mounting holes of
the Gateway enclosure, and through the washer plate.
2. Use a 1/2-in. socket-head wrench to fasten the nuts to the u-bolt.
3. Repeat Step 1 and Step 2 for the second u-bolt and lower mounting
holes.
4.1.1 Best practice
If the Gateway was ordered with output code 2, run a secondary Ethernet
cable when installing cable conduit from the Gateway to a convenient
indoor location to simplify future configuration changes.
4.2 Remote antenna (optional)
The remote antenna options provide flexibility for mounting the Gateway
based on wireless connectivity, lightning protection, and current work
practices.
September 2020 Quick Start Guide
Quick Start Guide 13

WARNING
When installing remote mount antennas for the Gateway, always use
established safety procedures to avoid falling or contact with high-power
electrical lines.
Install remote antenna components for the Gateway in compliance with
local and national electrical codes and use best practices for lightning
protection.
Before installing consult with the local area electrical inspector, electrical
officer, and work area supervisor.
The Gateway remote antenna option is specifically engineered to provide
installation flexibility while optimizing wireless performance and local
spectrum approvals. To maintain wireless performance and avoid non-
compliance with spectrum regulations, do not change the length of cable or
the antenna type.
If the supplied remote mount antenna kit is not installed per these
instructions, Emerson is not responsible for wireless performance or non-
compliance with spectrum regulations.
The remote mount antenna kit includes coaxial sealant for the cable
connections for the lightning arrestor and antenna.
Find a location where the remote antenna has optimal wireless
performance. Ideally this will be 15–25 ft. (4,6 to 7,6 m) above the ground or
6 ft. (2 m) above obstructions or major infrastructure. To install the remote
antenna use one of the following procedures:
4.3 Installation of WL2/WN2 option (outdoor applications)
Procedure
1. Mount the antenna on a 1.5 to 2-in. pipe mast using the supplied
mounting equipment.
2. Connect the lightning arrestor directly to the top of the Gateway.
3. Install the grounding lug, lock washer, and nut on top of the lightning
arrestor.
4. Connect the antenna to the lightning arrestor using the supplied
coaxial cable ensuring the drip loop is not closer than 1 ft. (0,3m)
from the lightning arrestor.
5. Use the coaxial sealant to seal each connection between the wireless
field device, lightning arrestor, cable, and antenna.
6. Ensure the mounting mast, lightning arrestor, and Gateway are
grounded according to local/national electrical code.
7. Place any spare lengths of coaxial cable in 12-in. (0,3 m) coils.
Quick Start Guide September 2020
14 Emerson.com/Rosemount

Figure 4-1: Installation of WL2/WN2 Option
B
C
D
E
F
A
G
H
G
AControl building
BRemote antenna
CCable
DDrip loop
ELightning arrestor
FGateway
GGround
HEarth
4.4 Installation of WL3/WL4 option (indoor to outdoor
applications)
Procedure
1. Mount the antenna on a 1.5 to 2-in. pipe mast using the supplied
mounting equipment.
2. Mount the lightning arrestor near the building egress.
3. Install the grounding lug, lock washer, and nut on top of the lightning
arrestor.
September 2020 Quick Start Guide
Quick Start Guide 15

4. Connect the antenna to the lightning arrestor using the supplied
coaxial cable ensuring the drip loop is not closer than 1 ft. (0,3m)
from the lightning arrestor.
5. Connect the lightning arrestor to the Gateway using the supplied
coaxial cable.
6. Use the coaxial sealant to seal each connection between the Gate-
way, lightning arrestor, cable, and antenna.
7. Ensure the mounting mast, lightning arrestor, and Gateway are
grounded according to local/national electrical codes.
8. Place any spare lengths of coaxial cable in 12-in. (0,3 m) coils.
Figure 4-2: Installation of WL3/WL4 Option
A
B
C
D
E
F
G
H
G
AControl building
BRemote antenna
CCable
DDrip loop
ELightning arrestor
FGateway
GGround
HEarth
Quick Start Guide September 2020
16 Emerson.com/Rosemount

Note
Weather proofing is required! The remote mount antenna kit
includes coaxial sealant for the cable connections for the lightning
arrestor, antenna, and Gateway. The coaxial sealant must be applied
to guarantee performance of the wireless field network. See Figure
4-3 for details on applying weather proofing.
Figure 4-3: Applying Coaxial Sealant to Cable Connections
Table 4-1: Remote Antenna Kit Options
Kit
option
Antenna Cable 1 Cable 2 Lightning
arrestor
WL2 1/2 Wavelength
Dipole Omni-
Directional +6 dB
Gain
50 ft. (15,2
m) LMR–
400
N/A Head mount, jack
to plug Gas
discharge tube 0.5
dB insertion loss
WL3 1/2 Wavelength
Dipole Omni-
Directional +6 dB
Gain
30 ft. (9,1
m) LMR–
400
20 ft. (6,1
m) LMR–
400
In-line, jack to jack
Gas discharge tube
0.5 dB insertion
loss
WL4 1/2 Wavelength
Dipole Omni-
Directional +6 dB
Gain
40 ft. (12,2
m) LMR–
400
10 ft. (3,0
m) LMR–
400
In-line, jack to jack
Gas discharge tube
0.5 dB insertion
loss
WN2 1/2 Wavelength
Dipole Omni-
Directional +8 dB
Gain
25 ft. (7,6
m) LMR–
400
N/A Head mount, jack
to plug Gas
discharge tube 0.5
dB insertion loss
September 2020 Quick Start Guide
Quick Start Guide 17

AAntenna
B20 ft. (6,1 m) cable
C10 ft. (3,0 m) cable
DLightning arrestor
EInterchangeable cables
F50 ft. (15,2 m) cable
G30 ft. (9,1m) cable
H40 ft. (12,2 m) cable
I25 ft. (7,6m) cable
Note
The coaxial cables on the remote antenna options WL3 and WL4 are
interchangeable for installation convenience.
Quick Start Guide September 2020
18 Emerson.com/Rosemount

5 Connect to the host system
Procedure
1. Wire the Gateway’s Ethernet 1 (Primary) or Serial Output connection
to the Host System Network or Serial I/O.
2. For serial connections, connect A to A, B to B, making sure all
terminations are clean and secured to avoid wiring connection
problems.
Figure 5-1: Legacy Gateway Terminal Block Diagram
+
+
+
+
+
-
-
-
-
-
A B
S
S
S
S
24 VDC
(nominal)
Power Input
Serial
Modbus
Not Used
Not Used
Not Used
Not Used
Case
(Covered)
S
Ethernet 2
with Power Ethernet 2 Ethernet 1
(Secondary) (Primary)
Figure 5-2: PoE Terminal Block Diagram
+- A B
24 VDC
(nominal)
Power Input
Serial
Modbus
Case
SEthernet 2 Ethernet 1
(Secondary) (Primary)
CAUTION
Do not connect the Host System to the Ethernet 2 with power
(covered) port on the Gateway to avoid damaging the system.
September 2020 Quick Start Guide
Quick Start Guide 19

5.1 Best practice
In accordance with Emerson WirelessHART® security guidelines, the Gateway
should be connected to the Host System via a LAN (Local Area Network) and
not a WAN (Wide Area Network).
Twisted shielded pair cable is generally used to wire the serial connection,
and it is standard practice to ground the shield on the serial host side leaving
the shield floating on the Gateway side. Insulate the shield to avoid
grounding issues.
5.2 Power
Power the Gateway as directed in Powering the Gateway.
Quick Start Guide September 2020
20 Emerson.com/Rosemount
