Emerson RTM-ATCA-F140 Quick start guide

Embedded Computing for
Business-Critical ContinuityTM
RTM-ATCA-F140
Installation and Use
P/N: 6806800M97A
October 2011
EA Version

© 2011 Emerson
All rights reserved.
Trademarks
Emerson, Business-Critical Continuity, Emerson Network Power and the Emerson Network Power logo are trademarks and service
marks of Emerson Electric Co. © 2011 Emerson Electric Co. All other product or service names are the property of their respective
owners.
Intel®is a trademark or registered trademark of Intel Corporation or its subsidiaries in the United States and other countries.
Java™and all other Java-based marks are trademarks or registered trademarks of Sun Microsystems, Inc. in the U.S. and other
countries.
Microsoft®, Windows®and Windows Me®are registered trademarks of Microsoft Corporation; and Windows XP™is a trademark of
Microsoft Corporation.
PICMG®, CompactPCI®, AdvancedTCA™and the PICMG, CompactPCI and AdvancedTCA logos are registered trademarks of the PCI
Industrial Computer Manufacturers Group.
UNIX®is a registered trademark of The Open Group in the United States and other countries.
Notice
While reasonable efforts have been made to assure the accuracy of this document, Emerson assumes no liability resulting from any
omissions in this document, or fromthe use ofthe information obtained therein. Emerson reserves the right to revise this document
and to make changes from time to time in the content hereof without obligation of Emerson to notify any person of such revision or
changes.
Electronic versions of this material may be read online, downloaded for personal use, or referenced in another document as a URL to
a Emerson website. The text itself may not be published commercially in print or electronic form, edited, translated, or otherwise
altered without the permission of Emerson,
It is possible that this publication may contain reference to or information about Emerson products (machines and programs),
programming, or services that are not available in your country. Such references or information must not be construed to mean that
Emerson intends to announce such Emerson products, programming, or services in your country.
Limited and Restricted Rights Legend
If the documentation contained herein is supplied, directly or indirectly, to the U.S. Government, the following notice shall apply
unless otherwise agreed to in writing by Emerson.
Use, duplication, or disclosure by the Government is subject to restrictions as set forth in subparagraph (b)(3) of the Rights in
Technical Data clause at DFARS 252.227-7013 (Nov. 1995) and of the Rights in Noncommercial Computer Software and
Documentation clause at DFARS 252.227-7014 (Jun. 1995).
Contact Address
Emerson Network Power - Embedded Computing
2900 South Diablo Way, Suite 190
Tempe, AZ 85282
USA
EA Version

Contents
RTM-ATCA-F140 Installation and Use (6806800M97A) 3
About this Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
1.1 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
1.2 Standard Compliances . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
1.3 Mechanical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
1.4 Ordering Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
2 Hardware Preparation and Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
2.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
2.2 Unpacking and Inspecting the RTM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
2.3 Environmental and Power Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
2.3.1 Environmental Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
2.4 RTM Installation and Removal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
2.4.1 Installing the RTM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
2.4.2 Removing the RTM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
3 Controls, LEDs, and Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
3.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
3.2 Face Plate Connectors and LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
3.2.1 LEDs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
4 Functional Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
4.1 Block Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
4.2 Management Resources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
4.2.1 FRU Serial EEPROM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
4.2.2 Temperature Sensors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
4.2.3 LEDs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
4.2.4 I2C Address Map . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
4.3 1 Gbps SFP Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
4.3.1 Connectivity. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
4.3.2 Front-Blade Port Mapping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
4.3.3 SFP Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Contents
EA Version

RTM-ATCA-F140 Installation and Use (6806800M97A)
Contents
4
Contents
Contents
4.3.3.1 I2C Bus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
4.3.3.2 SFP Status Signals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
4.3.3.3 SFP Control Signals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
4.4 10 Gbps SFP+ Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
4.4.1 Connectivity. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
4.4.2 Front-Blade Port Mapping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
4.4.3 BCM8727 Configuration Flash . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
4.4.4 Transmitter Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
4.4.5 BCM8727 Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
4.4.6 SFP+ Connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
4.4.6.1 I2C Bus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
4.4.6.2 SFP+ Status Signals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
4.4.6.3 SFP Control Signals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
4.4.6.4 PHY Management Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
4.5 10Gbps Fabric Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
4.5.1 Fabric Connectivity. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
4.5.2 Fabric Front Blade Port Mapping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
4.5.3 BCM84754 Configuration Flash . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
4.5.4 Transmitter Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
4.5.5 BCM84754 Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
4.5.6 Fabric SFP+ Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
4.5.6.1 SFP+ I2C Bus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
4.5.6.2 SFP+ Status Signals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
4.5.6.3 SFP+ Control Signals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
4.5.7 PHY Management Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
4.6 40Gbps Fabric Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
4.6.1 Fabric Connectivity. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
4.6.2 Fabric Front Blade Port Mapping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
4.6.3 BCM84740 Configuration Flash . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
4.6.4 Transmitter Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
4.6.5 BCM84740 Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
4.6.6 Fabric QSFP+ Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
4.6.6.1 QSFP+ I2C Bus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
4.6.6.2 QSFP+ Status Signals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
4.6.6.3 QSFP+ Control Signals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
4.6.7 PHY Management Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
EA Version

Contents
RTM-ATCA-F140 Installation and Use (6806800M97A) 5
4.7 GPS Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
4.7.1 1PPS Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
4.7.2 10MHz Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
4.7.3 Time-Of-Day Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
4.8 FPGA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
4.8.1 Front-blade Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
4.8.2 SFP/SFP+/QSFP+ Control and Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
4.8.3 BCM8727 Control and Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
4.8.4 BCM84754 Control and Status. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
4.8.5 BCM84740 Control and Status. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
4.8.6 Reset Handling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
4.8.7 Synchronous Ethernet Clock Recovery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
4.8.8 SPI Flash . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
4.8.9 FPGA Register Map . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
4.8.10 FPGA Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
4.9 Reset Scheme . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
4.10 Zone 3 Isolation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
4.11 Power Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
4.11.1 Power Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
A Related Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
A.1 Emerson Network Power - Embedded Computing Documents . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Safety Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Sicherheitshinweise . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
EA Version

RTM-ATCA-F140 Installation and Use (6806800M97A)
Contents
6
Contents
Contents
EA Version

List of Tables
RTM-ATCA-F140 Installation and Use (6806800M97A) 7
Table 1-1 Standard Compliances . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Table 1-2 RTM-ATCA-F140 Mechanical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Table 1-3 Blade Variants - Ordering Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Table 2-1 Environmental Conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Table 4-1 Temperature Sensor Thresholds . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Table 4-2 PCF 8574 Port Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Table 4-3 I2C Bus Address Map . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Table 4-4 Front-Blade Port Mapping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Table 4-5 SFP Connector Pin Assignment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Table 4-6 SFP+ Connector Pin Assignment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Table 4-7 BCM8727 PHY Addressing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Table 4-8 BCM84754 PHY Addressing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Table 4-9 QSFP+ Connector Pin Assignment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Table 4-10 BCM84740 PHY Addressing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Table 4-11 1PPS Input Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Table 4-12 10MHz Input Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Table 4-13 Time-Of-Day RJ45 Pinout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Table 4-14 FPGA Configuration Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Table 4-15 Power Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Table A-1 Related Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
EA Version

RTM-ATCA-F140 Installation and Use (6806800M97A)
8
List of Tables
EA Version

List of Figures
RTM-ATCA-F140 Installation and Use (6806800M97A) 9
Figure 1-1 Declaration of Conformity - TBD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Figure 3-1 Face Plate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Figure 4-1 Block Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Figure 4-2 1GB Base Channel Interconnect . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Figure 4-3 Fabric 10 GB Interconnect . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Figure 4-4 Fabric 10Gb Interconnect . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Figure 4-5 Fabric 40Gb Interconnect . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Figure 4-6 Synchronous Ethernet Reference Recovery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
EA Version

RTM-ATCA-F140 Installation and Use (6806800M97A)
10
List of Figures
EA Version

RTM-ATCA-F140 Installation and Use (6806800M97A) 11
About this Manual
Overview of Contents
This manual is divided into the following chapters and appendices.
Introduction describes the main features of the RTM.
Hardware Preparation and Installation installation prerequisites and the installation itself.
Controls, LEDs, and Connectors describes external interfaces such as connectors and LEDs.
Functional Description contains a block diagram of the RTM and provides some information
on the IPMI functionality of the RTM.
Related Documentation lists further Emerson user manuals that are related to the RTM and
the ATCA-F140.
Safety Notes summarizes the safety instructions in the manual.
Sicherheitshinweise is a German translation of the Safety Notes chapter.
Abbreviations
This document uses the following abbreviations:
Abbreviation Definition
AMC Alarm Management Controller
ARP Address Resolution Protocol
ATCA Advanced Telecom Computing Architecture
BIX Base Interface Switch
CP-TA Communications Platforms Trade Association
FIX Fabric Interface Switch
IO Input/Output
PICMG PCI Industrial Computer Manufacturers Group
PCI Peripheral Component Interconnect
RTM Rear Transition Module
SPI Serial Peripheral Interface
EA Version

RTM-ATCA-F140 Installation and Use (6806800M97A)
About this Manual
12
About this Manual
Conventions
The following table describes the conventions used throughout this manual.
Notation Description
0x00000000 Typical notation for hexadecimal numbers (digits are
0 through F), for example used for addresses and
offsets
0b0000 Same for binary numbers (digits are 0 and 1)
bold Used to emphasize a word
Screen Usedfor on-screenoutputand coderelatedelements
or commands in body text
Courier + Bold Used to characterize user input and to separate it
from system output
Reference Used for references and for table and figure
descriptions
File > Exit Notation for selecting a submenu
<text> Notation for variables and keys
[text] Notation for software buttons to click on the screen
and parameter description
... Repeated item for example node 1, node 2, ..., node
12
.
.
.
Omission of information from example/command
that is not necessary at the time being
.. Ranges, for example: 0..4 means one of the integers
0,1,2,3, and 4 (used in registers)
|LogicalOR
EA Version

About this Manual
RTM-ATCA-F140 Installation and Use (6806800M97A) 13
Summary of Changes
This manual has been revised and replaces all prior editions.
Indicates a hazardous situation which, if not avoided,
could result in death or serious injury
Indicates a hazardous situation which, if not avoided,
may result in minor or moderate injury
Indicates a property damage message
No danger encountered. Pay attention to important
information
Notation Description
Part Number Publication Date Description
6806800M97A August 2011 First edition
EA Version

RTM-ATCA-F140 Installation and Use (6806800M97A)
About this Manual
14
About this Manual
EA Version

Chapter 1
RTM-ATCA-F140 Installation and Use (6806800M97A) 15
Introduction
1.1 Features
The RTM-ATCA-F140 provides the I/O connection for the ATCA-F140 switch blade towards the
back of the system. RTM-ATCA-F140 is directly connected to and powered by the front board.
The RTM-ATCA-F140 is a rear transition module (RTM) as defined in PICMG 3.0 Revision 3.0
Advanced TCA Base Specification and PICMG 3.1 Revision 1.0 Specification Ethernet/Fiber
Channel for AdvancedTCA Systems. It provides several Base and Fabric Channel Ethernet
interfaces connected to the front board through the Zone 3 connector.
The main features of the RTM-ATCA-F140 are:
Single slot RTM form factor (70mm x 322mm)
1x 40Gbit Ethernet uplink (FIX) according to IEEE 802.3ba with 1 QSFP+ type connector
4x 10Gbit Ethernet uplinks (FIX) according to IEEE 802.3ap with 4 SFP+ type connectors
2x 10Gbit Ethernet uplinks (BIX) according to IEEE 802.3ap with 2 SFP+ type connectors
4x 1Gbit Ethernet interfaces (BIX) with 4 SFP type connectors
GPS 1PPS SMA input
GPS 10MHz SMA input
GPS time-of-day and optional 1PPS with RJ45 connector
Hot-plug ability
Serial EEPROM accessible by front-blade IPMC
Four status LEDs and ejector handle switch accessible by front-blade IPMC
EA Version

Introduction
RTM-ATCA-F140 Installation and Use (6806800M97A)
16
1.2 Standard Compliances
The product is designed to meet the following standards.
Table 1-1 Standard Compliances
Standard Description
ANSI Fire Spread Criteria The product is designed to pass the ANSI T1.319-2002 fire
spread test method as well as the NEBS GR-63-CORE fire spread
test method.
AS/NZS CISPR 22 Class A
(Australia/New Zealand)
The product complies with AS/NZS CISPR 22 Class A
(Australia/New Zealand), Limits and Methods of Measurement
of Radio Disturbance Characteristics of Information Technology
Equipment.
AT&T Document ATT-TP-76200 The product is designed to comply with the latest version of the
AT&T Document ATT-TP-76200: Network Equipment Power,
Grounding, Environmental, And Physical Design Requirements.
EN 55024 (EU) The product complies with EN55024 (EU) Information
Technology Equipment - Immunity Characteristics - Limits and
Methods of Measurements.
EN 60950-1 This product complies with EN 60950-1 Safety of Information
Technology Equipment.
EN55022 Class A (EU) The product complies with EN55022 Class A (EU), Information
Technology Equipment - Radio Disturbance Characteristics -
Limits and Methods of Measurements.
ETSI Acoustic Noise ETS 300 753
Class 3.1 The product will not prevent the system from complying
with the ETSI acoustic noise requirements per Class 3.1 of ETSI
ETS 300 753, Equipment Engineering (EE); Acoustic noise
emitted by telecommunications equipment.
ETSI Stationary Use: EN 300 019-
2-3 Class 3.1
The product is designed to comply with ETSI Stationary Use: EN
300 019-2-3, Class 3.1 equipment (temperature controlled
locations).
ETSI Storage EN 300 019-2-1
Class 1.2
The product is designed to comply with ETSI Storage: EN 300
019-2-1, Class 1.2 equipment (not temperature controlled
storage locations).
ETSI Transportation: EN 300 019-
2-2 Class 2.3
The product is designed to comply with ETSI Transportation: EN
300 019-2-2, Class 2.3 equipment (public transportation).
EA Version

Introduction
RTM-ATCA-F140 Installation and Use (6806800M97A) 17
FCC 47 CFR Part 15 Subpart B
(US), Class A
The product complies with FCC 47 CFR Part 15 Subpart B (US),
Class A.
GR-1089 - Ports and Intra-
building Lightning
All externally accessible ports shall be designed to comply with
the applicable GR-1089 requirements for Telecommunication
Ports.
GR-1089-CORE Products are designed to comply with all applicable
requirements for Type 2 Equipment referenced in Telcordia
Document GR-1089-CORE.
GR63-CORE The product is designed to comply with all applicable
requirements of Telcordia GR-63-CORE, NEBS Requirements:
Physical Protection.
IEC 60950-1 CB Scheme The product complies with IEC 60950-1 CB Scheme including all
National Deviations Safety of Information Technology
Equipment. Testing shall be by an accredited lab.
NEBS Level 3 Module is designed to pass all testing to Criteria Level 3 per
Telcordia SR-3580.
Safety Mark for U.S. and Canada The product is designed to certify to UL/CSA No. 60950-1 with
no deviations and shall bear the Recognition Mark of an NRTL for
US and Canada.
UL/CSA No. 60950-1 The product complies with UL/CSA 60950-1Safety of
Information Technology Equipment.
VCCI Class A (Japan) The product complies with VCCI Class A (Japan), Voluntary
Control Council for Interference by Information Technology
Equipment.
Verizon CHECKLIST The product is designed to comply with the latest version of the
Verizon Document VZ.NEBS.TE.NPI.2004.015: NEBS Checklist.
Table 1-1 Standard Compliances (continued)
Standard Description
EA Version

Introduction
RTM-ATCA-F140 Installation and Use (6806800M97A)
18
Figure 1-1 Declaration of Conformity - TBD
EA Version

Introduction
RTM-ATCA-F140 Installation and Use (6806800M97A) 19
1.3 Mechanical Data
1.4 Ordering Information
The following table lists the blade variants that were available as of the time of writing this
manual. Consult your local Emerson sales representative for the availability of further variants.
Table 1-2 RTM-ATCA-F140 Mechanical Data
Data Value
Dimensions 8U x 6 HP form factor - 30mm x 351 mm x143 mm (including face plate
handles and alignment posts)
Weight 0.725 Kg
Table 1-3 Blade Variants - Ordering Information
Part Number Description
RTM-ATCA-F140 RTM for the ATCA-F140 with SFP and SFP+ sockets
EA Version

Introduction
RTM-ATCA-F140 Installation and Use (6806800M97A)
20
