EMKO ESM-3723 User manual

ENGLISH
ESM-3723 77x35 DIN Size Temperature+Humidity
Instruction Manual. ENG ESM-3723 01 V03 02/15
- 4 Digits for Temperature Display
- 4 Digits for Humidity Display
- Temperature Sensor Input
NTC, PTC, PT-100, 0/2..10V, 0/4..20mA or ProNem Mini PMI-P
(Must be determined in order.)
- Humidity Sensor Input
0/2..10V, 0/4..20mA or ProNem Mini PMI-P
(Must be determined in order.)
- 4 Output
Heating Control Output
Heating Alarm Output
Humidification Control Output
Humidification Alarm Output
- Relay or SSR Outputs (Must be determined in order.)
- Selectable Temparature Control ( PID or ON / OFF )
- Auto-Tune PID
- Set value boundaries
- Alarm parametreters
- Adjustable internal buzzer according to the alarm situations
- Password protection for programming mode,
- Having CE mark according to European Norms
ESM-3723 77 x 35 DIN Size
Digital Temperature+Humidity Controller

ENGLISH
c
1.2. General Specifications
1.Preface
ESM-3723 series Temperature + Humidity control devices, are designed for the control of industrial
processes. PID or On / Off control form under the control of the process is a device that can
respond to your special needs.
ESM-3723
Power Supply
Input
Output
Output
Output
2
Heating Alarm
Humidifier
Humidifier Alarm
1.1 Environmental Ratings
230V ( %15)50/60HzV ±
Optional Supply
Voltage
- 30 V Z
115 V (±%15)50/60Hz
24 V (±%15)50/60Hz
24 V (±%15)50/60Hz
10
V
V
W
Standard
Output Heating
Operating Temperature : 0 to 50 °C
Max. Operating Humidity : 90% Rh (non-condensing)
Altitude : Up to 2000 m.
Forbidden Conditions
Corrosive atmosphere
Explosive atmosphere
Home applications (The unit is only for industrial applications)
Temperature Sensor
Input
Humidity Sensor Input
PTC, NTC, PT-100
0/2..10V,0/4..20mA or
ProNem Mini PMI-P
0/2..10V,0/4..20mA or
ProNem Mini PMI-P

3
A visual inspection of this product for possible damage occurred during shipment is recommended
before installation.
It is your responsibility to ensure that qualified mechanical and electrical technicians install this product.
If there is danger of serious accident resulting from a failure or defect in this unit, power off the system
and separate the electrical connection of the device from the system.
The unit is normally supplied without a power supply switch or a fuse. Use power switch and fuse as
required.
Be sure to use the rated power supply voltage to protect the unit against damage and to prevent failure
Keep the power off until all of the wiring is completed so that electric shock and trouble with the unit can
be prevented.
Never attempt to disassemble, modify or repair this unit. Tampering with the unit may results in
malfunction, electric shock or fire.
Do not use the unit in combustible or explosive gaseous atmospheres.
During putting equipment in hole on the metal panel while mechanical installation some metal burrs can
cause injury on hands, you must be careful.
Montage of the product on a system must be done with it’s fixing clamps. Do not do the montage of the
device with inappropriate fixing clamp. Be sure that device will not fall while doing the montage.
It is your responsibility if this equipment is used in a manner not specified in this instruction manual.
EMKO Elektronik warrants that the equipment delivered is free from defects in material and
workmanship. This warranty is provided for a period of two years. The warranty period starts from the
delivery date. This warranty is in force if duty and responsibilities which are determined in warranty
document and instruction manual performs by the customer completely.
Repairs should only be performed by trained and specialized personnel. Cut power to the device before
accessing internal parts.
Do not clean the case with hydrocarbon-based solvents (Petrol, Trichlorethylene etc.). Use of these
solvents can reduce the mechanical reliability of the device. Use a cloth dampened in ethyl alcohol or
water to clean the external plastic case.
1.3 Installation
1.4 Warranty
1.5 Maintenance
1.6 Manufacturer Company
Manufacturer Information:
Emko Elektronik Sanayi ve Ticaret A.Ş.
Demirtaş Organize Sanayi Bölgesi Karanfil Sk. No:6 16369 BURSA/TURKEY
Phone : [phone]
Fax : [phone]
Repair and maintenance service information:
Emko Elektronik Sanayi ve Ticaret A.Ş.
Demirtaş Organize Sanayi Bölgesi Karanfil Sk. No:6 16369 BURSA/TURKEY
Phone : [phone]
Fax : [phone]
ENGLISH

2.2 Panel Cut- Out
2. General Description
2.1 Front View and Dimensions of ESM-3723 Temperature Controller
76 mm / 3 inch
34,5 mm / 1.36 inch
4
Mounting Clamp
Panel Surface
(maximum thickness 15 mm / 0.59 inch)
Front panel
IP65 Protection
NEMA 4X
65 mm / 2.56 inch
6 mm / 0.24 inch
110 mm / 4.33 inch (min)
71 mm / 2.79 inch
29 mm / 1.14 inch
50 mm / 1.97 inch (min)
Maximum 15 mm / 0.59 inch
ESM-3723
ü
SET
P
O1
O2
A1
A2
OC
OF
ENGLISH

ENGLISH
2.3 Panel Mounting and Removing
3. Electrical Wiring Diagram
3.1 Supply Voltage Input Connection of the Device
5
1-Before mounting the device in your panel, make
sure that the cut-out is of the right size.
2-Insert the device through the cut-out. If the
mounting clamps are on the unit, put out them
before inserting the unit to the panel.
3- Insert the mounting clamps to the fixing sockets
that located left and right sides of device and
make the unit completely immobile within the
panel
1-Pull mounting clamps from left and right
fixing sockets.
2-Pull the unit through the front side of the
panel
Before starting to remove the unit
from panel, power off the unit and
the related system.
c
Make sure that the power supply voltage is the same indicated on
the instrument.
Switch on the power supply only after that all the electrical
connections have been completed.
Supply voltage range must be determined in order. While installing
the unit, supply voltage range must be controlled and appropriate
supply voltage must be applied to the unit.
c
There is no power supply switch on the device. So a power supply
switch must be added to the supply voltage input.
Power switch must be two poled for seperating phase and neutral,
On/Off condition of power supply switch is very important in
electrical connection.
External fuse that on Vpower supply inputs must be on phase
connection.
External fuse that on Z power supply inputs must be on (+)
connection.
c
Power Supply Input
c
a
External
Fuse
(1A T)
Note-1
Supply
Switch
78
L
N
Supply Voltage
230V ( %15) 50/60Hz ,
115V ( %15) 50/60Hz ,
24V ( %15)50/60Hz ,
24V ( %15) 50/60Hz ,
Z
V ±
V ±
V ±
W ±
10...30 V 1.5 W
Must be determined in order.
Relay Outputs
2
13 54 6 87 9 10
P/N : ESM-3723
L
N
a
Power Supply Voltage
230V ( %15) 50/60Hz ,
115V ( %15) 50/60Hz,
24V ( %15) 50/60Hz ,
24V ( %15) 50/60Hz ,
Z
V ±
V ±
V ±
W ±
10...30 V 1.5 W
1112
Temperature Sensor Input
NTC, PTC, PT-100,
or ProNem Mini PMI-P
0/2..10V, 0/4..20mA
Humidity Sensor Input
0/2..10V, 0/4..20mA or
ProNem Mini PMI-P
Must be determined in order.
3
2
1
1
2
Must be determined in order.
Must be determined in order.
Note-1: External Fuse is recommended
78910
a
3x3A@ 250V V
5A @250VV
230 VV ± 15%
50/60Hz - 1.5VA
2341 56 11 12
HEAT.
ALARM
HUM.
HUM.
ALARM/
HEAT

ENGLISH
6
3.2 Device Label and Connection Diagram
230VV CONNECTION DIAGRAM
PTC Temperature and 0/4 @20mA Humidity Sensor Input connection
ProNem Mini PMI-P Temperature and Humidity Sensor Input Connection
N
L
78910
a
3x3A@ 250V V
5A @250VV
L
N
230 VV ± 15%
50/60Hz - 1.5VA
2341 56 11 12
14A T Fuse
+
-
HEAT. ALARM
HUM.
HUM. ALARM/
HEAT
230 VV ± 15%
50/60Hz - 1.5VA
N
L
78910
a
3x3A@ 250V V
5A @250VV
L
N
230 VV ± 15%
50/60Hz - 1.5VA
2341 56 11 12
14A T Fuse
+
-
VCC GND SCL SDA
WHITE
YELLOW
BROWN
GREEN
ProNem Mini
PMI-P
BLACK
Shield
230 VV ± 15%
50/60Hz - 1.5VA
HEAT
ALARM
HUM.
HEAT
HUM. ALARM/
Note : (Black) pin must be connected to number 10 (GND) of the terminal block.Shield

4.Front Panel Definition and Accessing to the Menus
7
BUTTON DEFINITIONS
1. Increment Button :
** In main operation screen, press this button to change display temperature and humidity sensor
value.
** It is used to increase the value in the Temperature and Humidity Set screens and Programming mode.
2. Decrement, Silencing Buzzer Button :
** It is used to decrease the value in the Set screen and Programming mode.
** It is used to silence the buzzer.
3. Set Button:
** In the main operation screen; if this button pressed for the first time, Temperature set value will be
displayed. Value can be changed using increment and decrement buttons. When Enter button is
pressed again, value is saved and Humidty set value will be displayed next. Value can be changed using
increment and decrement buttons. When Enter button pressed again, value is saved and returns back
to main operating screen.
4.Enter Button:
** To access the programming screen; in the main operation screen, press and hold this button for 5
seconds.
** It is used to save value in the Set screens (Temperature or Humidity) and programming screen.
5.A1 led :
**
6. O1 Led :
** This led indicates that heating output is active.
7.Celcius led :
o
** Indicates that device is in C mode.
8.Fahrenheit led :
o
** Indicates that device is in F mode.
9. O2 Led :
** This led indicates that output is active.
10.A2 Led :
** This led indicates that Alarm is active.
11.Precent Sign ledi :
output is active
12.Program led :
** Indicates that device is in programming mode .
LED DEFINITIONS
It is active when Temperature alarm statuses.
Humidifier
Humidifier
** Indicates that device is in Humidity Set screen or Humidifier .
3
4
1
2
56
910
78
11 12
ESM-3723
ü
SET
P
O1
O2
A1
A2
OC
OF
ENGLISH

ENGLISH
5. Changing and Saving Temperature and Humidity Set Value
5.1 Changing and Saving Humidity Set Value
Main Operating Screen
When SET button pressed ‘’S’’ led will
be active and temperature set value will
be displayed.
Temperature Set Value Screen
Temperature set value can
be changed with increment
and decrement buttons.
When SET button pressed
temperature set value can be saved.
Goes Humidity SET
value screen.
Temperature set value parameter ( Default =50 )
Temperature set value, can be programmed between minimum temperature set value and
maximum temperature set value .
°C
When SET button pressed
set value can be saved.
Humidity
Goes back to main operation screen.
Main Operating Screen
Humidity Set Value Screen
If no operation is performed in Humidity set value changing mode and temperature set value
changing mode for 20 seconds, device turns to main operation screen automatically.
i
Humidity Set Value Screen
8
Nem Set Parametresi (Default = 60%)
Humidity set value, can be programmed between minimum Humidity set value and maximum
temperature set value .
Temperature Set Value Screen Humidity Set Value Screen
Humidity set value can be
changed with increment
and decrement buttons.
O1
ESM-3723
ü
SET
O1
ESM-3723
ü
SET
ESM-3723
SET
ü
ESM-3723
SET
ü
ESM-3723
SET
ü
ESM-3723
SET
ü
ESM-3723
SET
ü

ENGLISH
5.1 Programming Mode Parameter List
9
Decimal Seperator Enabling Parameter ( Default = 0 )
None.
Only Temperature parameters with decimal seperator.
Temperature Unit Selection Parameter ( Default = 0 )
°C selected.
°F selected.
Only Humidity parameters with decimal seperator.
Only Temperature and Humidity parameters with decimal seperator.
Temperature Control Selection Parameter On/Off or PID ( Default = 0 )
On - Off selected.
PID selected.
PID - Proportional Control Parameter ( Default =50 )
This parameter value can be adjusted form 0 to 100.
PID - Integral Parameter( Default = 1000 )
This parameter value can be adjusted form 0 to 3600.
PID - Derivative Parameter ( Default = 250 )
This parameter value can be adjusted form 0 to 3600.
PID -Period Time Parameter ( Default = 1 )
This parameter value can be adjusted form 1 to 50 second.
Note: If this parameter is select 0, PID parameters ( , , , , ) will be not observed.
If this parameter select 1, parameter will be not observed.
Auto Tune (Limit Cycle Tuning) Selection Parameter ( Default = )
Device does not do(Limit cycle Tuning) operation.
Device does operation.
Note : When value of or parameters are changed , the values of , , , ,
, , , , , , , , , , , , and parameters
should be changed accordingly.
It is valid, if the device type 0/2...10V
It is valid, if the device type 0/4...20mA
Z Sensor Input.
Z Sensor Input
Temperature
Temperature .
(1)
(2)
i
0..10V veya 0..20mA Z Z
2..10V veya 4..20mA Z Z
Temperature Sensor Scale Selection Parameter ( Default = 0 )
(1) (2)
(2)(1)
Analogue (T input range is determined with this parameter.emperature)
Temperature
or
or
Sensor Scale Low Limit Parameter : ( Default = 0 )
It can be adjusted from -1999 to ( -1). At this value analogue input becomes;
If =0, according to the device type 0V 0mA
If =1, according to the device type 2V 4mA
Z Z
Z Z
(1) (2)
(1) (2)
Temperature
or
Sensor Scale High Limit Parameter : ( Default = 100 )
It can be adjusted from ( +1) to 9999. At this value analogue input becomes;
According to the device type10V 20mA
ZZ
(1) (2)
Note : , parameters are shown, if the Temperature sensor analogue input type is selected .
Note : , and parameters are shown, if the Temperature sensor input type
( 0/2..10V or 0/4..20mA ) is selected.
analogue

ENGLISH
In ON/OFF control algorithm, temperature
value is tried to keep equal to set value by
opening or closing the last control element.
ON/OFF controlled system, temperature
value oscillates continuously. Temperature
value’s oscillation period or amplitude
around set value changes according to
controlled system. For reducing oscillation
period of temperature value, a threshold
zone is formed below or around set value
and this zone is named hysteresis.
Temperature Sensor Offset Parameter ( Default = 0 )
10
Humidity Sensor Scale Selection Parameter ( Default = 0 )
ON
OFF
Temperature
Control
Output
Set
thSt
Time
thSt
Time
Hysteresis Parameter for Temperature ( Default = 0.1 °C )
From 1 to 10°C for NTC,PTC, PT-100 (0°C, 100°C)
From 1 to 18°F for NTC,PTC ,PT-100 (32°F, 212°F)
From 0.1 to 10.0°C for NTC, PTC, PT-100 (0.0°C,100.0°C)
From 0.1 to 18.0°F for NTC, PTC, PT-100 (32.0°F,212.0°F)
From 1 to 10°C for ProNem Mini PMI-P (-20°C, 80°C) ,From 1 to 18°F for ProNem Mini
PMI-P (-4°F,176°F),From 0.1 to 10.0°C for ProNem Mini PMI-P (-20.0°C,80.0°C)
From 0.1 to 18.0°F for ProNem Mini PMI-P (-4.0°F,176.0°F).
Minimum Temperature Set Value Parameter ( Default = 10.0°C)
Temperature set value can not be lower than this value. This parameter value can be
adjusted from minimum value of device scale to maximum temperature set value
parameter
Maximum Temperature Set Value Parameter ( Default = 40.0 °C )
Temperature set value can not be greater than this value.
This parameter value can be adjusted from minimum temperature set value parameter
to maximum value of the device scale.
From -10 to 10°C , NTC,PTC , PT-100 (0°C, 100°C)
From -18 to 18°F, NTC,PTC , PT-100 (32°F, 212°F)
From -10.0 to 10.0°C , NTC ,PTC , PT-100 (0.0°C,100.0°C)
From -18.0 to18.0°F NTC, PTC , PT-100 (32.0°F,212.0°F)
From -10 to 10°C ,ProNem Mini PMI-P ( -20°C, 80°C ),From -18 to 18°F,ProNem Mini
PMI-P ( -4°F, 176°F ),From -10.0 to 10.0°C, ProNem Mini PMI-P ( -20.0°C, 80.0°C ),
From -18.0 to18.0°F, ProNem Mini PMI-P ( -4.0°F,176.0°F )
0..10V 0..20mA Z or Z
2..10V 4..20mA Z or Z
(1) (2)
(2)(1)
It is valid, if the device type 0/2...10V
It is valid, if the device type 0/4...20mA
Z Humidity Sensor Input.
Z Humidity Sensor Input .
(1)
(2)
i
Humidity input range is determined with this parameter.
Note : parameter ProNem Mini PMI- type device are not observed.P
Hysteresis Parameter for Humidity ( Default = 1 )
From 1 to 10 for Humidity Sensor (0%RH, 100%RH)
From 0.1to 10.0 for Humidity Sensor (0.0%RH,100.0%RH)
In ON/OFF control algorithm,
value is tried to keep equal to set value by
opening or closing the last control element.
ON/OFF controlled system, temperature
value oscillates continuously. Temperature
value’s oscillation period or amplitude
around set value changes according to
controlled system. For reducing oscillation
period of temperature value, a threshold
zone is formed below or around set value
and this zone is named hysteresis.
Humidity
ON
OFF
Humidity
Control
Output
Set
hhSt
Time
hhSt
Time

ENGLISH
11
Humidity Alarm Function Selection Parameter ( Default = 0 )
Maximum Humidity Set Value Parameter (Default = Maximum Value of Device Scale)
This parameter value can be
adjusted from minimum humidity set value parameter to maximum value of the
device scale.
Humidity set value can not be greater than this value.
Minimum Humidity Set Value Parameter (Default = Minimum Value of Device Scale)
set value can not be lower than this value. This parameter value can be adjusted
from minimum value of device scale to maximum set value parameter
Humidity
Humidity
Humidity Sensor Offset Parameter ( Default = 0.0 )
From -10 to 10%RH for Humidity Sensor (0%RH-100%RH)
From -10.0 to 10.0%RH for Humidity Sensor (0.0%RH-100.0%RH)
Temperature Alarm is inactive.
Temperature Alarm Set Parameter
This parameter value can be programmed between temperature minimum alarm set
parameter and temperature alarm set maximum parameter.
( Default = 50.0 °C )
Temperature Alarm Function Selection Parameter ( Default = 0 )
Process High alarm selected.
Process Low alarm selected.
Deviation Band alarm selected.
Deviation Range alarm selected.
Alarm Set Maximum Parameter ( Default = Maximum Value of Device Scale)
if temperature alarm is active, this parameter value can be adjusted from temperature
alarm set value parameter to maximum value of the device scale.
Alarm Set Minimum Parameter (Default = Minimum Value of Device Scale)
if temperature alarm is active, this parameter value can be adjusted from minimum value of
device scale to temperature alarm set maximum parameter value.
Temperature Alarm Parameter
This parameter value can be adjusted form 0 to %50 of the device scale.
Hysteresis ( Default = 0)
Temperature Alarm On Delay Time Parameter
Temperature Alarm On Delay Time can be defined with this parameter. It can be
adjusted from 0 to 99 minutes.
( Default = 0)
Temperature Alarm Delay After Power On Parameter
It can be adjusted from 0 to 99 minutes.
( Default = 0)
When power is first applied to the device, this time delay must be expired for activation of
temperature alarm.
Process High alarm selected.
Process Low alarm selected.
Deviation Band alarm selected.
Deviation Range alarm selected.
Humidity Alarm is inactive.
Note : If this parameter is select 0, Temperature Alarm parameters , , , , and
will be not observed.
Note : If this parameter is select 0, Humidity Alarm parameters , , , , and
will be not observed.

ENGLISH
12
Buzzer Function Selection Parameter( Default = 0 )
Button Protection Parameter ( Default = 0 )
Programming Mode Accessing Password
It is used for accessing to programming mode. It can be adjusted from 0 to 9999. If it is 0,
password is not entered for accessing to the parameters. When the password screen is not
set as “12” , If the user enters ‘12’ in password screen and parameters are
accessed and they can changed.
( Default = 0 )
Humidity (Default = 0)
When power is first applied to the device, this time delay must be expired for activation of
Humidity alarm.
Alarm Delay After Power On Parameter
It can be adjusted from 0 to 99 minutes.
Humidity Set Maximum Parameter(Default =Maximum Value of Device Scale)
if humidity alarm is active, this parameter value can be adjusted from humidity alarm set
minimum parameter to maximum value of the device scale.
Alarm
Humidity (Default = 0)
Humidity
Alarm On Delay Time Parameter
Alarm On Delay Time can be defined with this parameter. It can be adjusted
from 0 to 99 minutes.
Buzzer is inactive.
Buzzer is active during temperature alarm
Buzzer is active during humidity alarm
Buzzer is active during Temperature sensor failures.
Buzzer is active during Humidity sensor failures.
Buzzer is active during Temperature sensor failures or temperature alarm.
Buzzer is active during Humidity sensor failures or Humidity alarm.
Buzzer is active during Temperature sensor failures or Humidity sensor failures
Buzzer is active during Temperature sensor failures or Humidity sensor failures
or temperature alarm or humidity alarm.
There is no protection.
Temperature set value can not be changed.
Humidity set value can not be changed.
Temperature set value and Humidity set value can not be changed
Humidity Alarm Set Parameter
This parameter value can be programmed between humidity minimum alarm set
parameter and humidity alarm set maximum parameter.
( Default = 60 )
Humidity Set Minimum Parameter(Default =Minimum Value of Device Scale)
if humidity alarm is active, this parameter value can be adjusted from minimum value of
device scale to humidty alarm set maximum parameter value.
Alarm
Humidity Alarm Parameter
This parameter value can be adjusted form 0 to %50 of the device scale.
Hysteresis ( Default = 0)
Buzzer Active Time
If buzzer function selection parameter
Buzzer active time can be define with this parameter. It can be adjusted from 1 to 99
minutes. When this parameter is 1, if decrement button is pressed, is observed. In
this condition buzzer is active till buzzer silence button is pressed.
( Default = )
value = 0, this parameter is not observed.

ENGLISH
13
5.2 Alarm Output Graphics of ESM-3723
i
Process High Alarm
ON
OFF
Alarm
Output
Process Value
Process Low Alarm
ON
OFF
Alarm
Output
Process Value
Deviation Band Alarm
ON
OFF
Alarm
Output
( - Alarm Set)
Process Set Value (Temperature or Humidity)
Deviation Range Alarm
ON
OFF
Alarm
Output
Process Value
Alarm Set Alarm Set
( +Alarm Set)
( - Alarm Set) ( +Alarm Set)
Process Value
1-
connection. While this message shown on this display,if buzzer function selection is 3, 5, 7 or 8
internal buzzer starts to operate.
Screen Blinking Temperature Sensor failure . Sensor connection is wrong or there is no sensor
5.3 Failure Messages in ESM 3723
2Screen Blinking H Sensor failure . Sensor connection is wrong or there is no sensor
connection. While this message shown on this display,if buzzer function selection is 4, 6,7 or 8
internal buzzer starts to operate.
- umidity
3- In main operating screen if the upper display is blinking, it means that temperature alarm exits and
alarm output is active .if buzzer function selection is 1, 5 or 8 internal buzzer starts to operate.
4- In main operating screen if the lower display is blinking, it means that humidity alarm exits and alarm
output is active .if buzzer function selection is 2, 6 or 8 internal buzzer starts to operate.
=

ENGLISH
When SET button is pressed for 3
seconds, “P” led turn. If programming
mode entering password is different
from 0, programming mode entering
screen will be observed.
Main Operation Screen
Programming Screen
Change the value with increment
and decrement buttons.
Press SET button for accessing to the
parameter value. Press increment
button for accessing to the next
parameter, press decrement button for
accessing to the previous parameter.
Press set button for saving the
parameter.
Press increment button for accessing to
the next parameter, press decrement
button for accessing to the previous
parameter.
Programming Mode
Entering Screen
Press SET button for
accessing to the
password entering
Password Entering Screen
Enter programming mode accessing
password with increment and
decrement buttons.
Note2: If programming mode accessing password is 0, only three parameters are accessible, and the
parameter values can be changed.
Press SET/OK button for
entering the password.
Note1: If programming
mode accessing password
is 0, Temperature Unit
screen is observed
instead of programming
screen
If no operation is performed in programming mode for 20 seconds, device turns to main
operation screen automatically.
i
Decimal Separator Enabling
Selection Screen
5.4 Entering To The Programming Mode, Changing and Saving Parameter
14
Password Entering Screen
Temperature Unit Selection
Parameter Value
Temperature Unit Selection
Parameter Value
ESM-3723
SET
ü
O1
ESM-3723
SET
ü
O1
ESM-3723
SET
ü
O1
ESM-3723
SET
ü
O1
ESM-3723
SET
ü
O1
ESM-3723
SET
ü
O1
ESM-3723
SET
ü
O1
ESM-3723
SET
ü
O1

ENGLISH
15
7. Specifications
Device Type : Temperature+Humidity Controller
Housing&Mounting : 76 mm x 34.5 mm x71 mm Plastic housing for panel
Panel cut out is 71 x 29 mm.
Protection Clas : Ip65 at front, Ip20 at rear.
Weight : Approximately 0.2 Kg
Enviromental Ratings : Standart,indoor at an altitude of less than 2000 meters with
none condensing humidity.
oooo
Storage / Operating Temperature : -40 C to +80 C / -30 C to +80 C
Storage / Operating Humidity : 90 % max. (None condensing)
Installation : Fixed installation
Overvoltage Category : II.
Pollution Degree : II, office or workplace, none conductive pollution
Operating Conditions : Continuous
Supply Voltage and Power :
: 115
: 24
: 24
: 10-30
Temperature Sensor Input : NTC, PTC, PT-100,0/2..10VZ,0/4..20mAZ or
ProNem Mini PMI-P
NTC input type : NTC (10 kW @25 °C )
230V ( %15) 50/60Hz - 1.5VA
V ( %15) 50/60Hz - 1.5VA
V ( %15) 50/60Hz - 1.5VA
V ( %15) 50/60Hz - 1.5VA
VZ 1.5W
V ±
V ±
V ±
W ±
6. Auto Tune Metod
Starting Auto Tune (Limit Cycle Tuning)
Operation by the user :
• Adjust t
• Adjust auto tune selection parameter ( = )
• In the main screen “Atun” and Temperature value
are should alternately.
emperature control on/off or PID parameter
( =1)
Auto Tune method is used for determining PID parameters used by the device.
If Auto Tune operation is finished without any
problem, the device saves the new PID coefficients,
calculated using the previously found “T” and “B”
values, to memory and continue to run.
parameter is adjusted automatically.
Temperature
Value
Time
Heating
Output
Time
B
T
Cancelling Auto Tune (Limit Cycle Tuning) operation :
1 - If sensor breaks;
2 - If auto tune operation can not be completed in 8 hours ;
3 - If user adjusts parameter ;
4- During auto tune operation if the user changes the temperature control from pid to on/off;
5 - If process set value is changed while auto tune operation is being performed;
Auto tune is canceled. “Atun” is not displayed. Then, without doing any changes in PID
parameters, device continues to run with previous PID parameters.

ENGLISH
All order information of ESM-3723 Temperature+Humidity Controller are given on the table at above.
User may form appropriate device configuration from information and codes that at the table and
convert it to the ordering codes.Firstly, supply voltage then other specifications must be determined.
Please fill the order code blanks according to your needs. Please contact us, if your needs are out of the
8. Other Informations
Note-1: If input type is selected PTC or NTC (BC= 2, 3), Temperature sensor is given with the
device.For this reason, if input type is selected as PTC,sensor type (V = 0,1 or 2) or if input type is
selected as NTC, sensor type (V = 0, 3 or 4) must be declared in ordering information.
7. Specifications
16
Your Technology Partner
www.emkoelektronik.com.tr
Thank you very much for your preference to
use Emko Elektronik products, please visit our
web page to download detailed user manual.
PTC input type : PTC (1000 W @25 °C )
Termoresistance input type : PT-100 IEC751 (ITS90 )
Humidity input type : 0/2..10VZ,0/4..20mAZ or ProNem Mini PMI-P
Accuracy : ± 1 % of full scale
Sensor Break Protection : Upscale
Control Form : PID or ON / OFF
Relay Outputs : 5 A@250 V V at Resistive Load (Heating Output)
: 3 A@250 V V at Resistive Load ((Heating , (Heating
Alarm), (Humidifier ), (Humidifier Alarm ))
Optional SSR Driver Output : Maximum 30mA, Maximum 15V
Temperature Display : 8 mm Red 4 digit LED Display
Humidity Display : 8 mm Green 4 digit LED Display
oo
LED Displays : P (Green), % (Green),C (Red), F(Red),
Humidifier Output (Red), Humidifier Alarm Output (Red)
Heating Output (Red), Heating Alarm (Red)
Internal Buzzer : 83dB
Upprovals : ,
B C D E FG HI /
/
UV W Z/
/0
Power Supply VoltageA
Temperature Sensor Input
BScale(°C/°F)
ESM-3723 (77x35 DIN Size)
4
-20°C/-4°F ; 80°C/176°F
115V ( %15) 50/60Hz - 1.5VAV ±
ProNem Mini PMI-P
PT 100, IEC751(ITS90)
1
PTC (Not-1)
2
5230V ( %15) 50/60Hz - 1.5VAV ±
810 - 30 V Z 1.5W
0°C/32°F ;100°C/212°F
0°C/32°F ;100°C/212°F
NTC (Not-1)
3
0°C/32°F ;100°C/212°F
324V ( %15) 50/60Hz - 1.5VAV ±
0
224V ( %15) 50/60Hz - 1.5VAW ±
0% - 100%
0% - 100%
0% - 100%
0/2 @ 10VW Voltage Input
4
50/4@ 20mA Current Input
6
Humidity Sensor Input
CScale (%)
ProNem Mini PMI-P
0/2 @ 10VW Voltage Input
4
50/4@ 20mA Current Input
6
01 Relay Output ( 3A@250 V V,at Resistive Load ,1 NO )
Humidifier Output
FG
1Relay Output ( 5 A@250 V V,at Resistive Load 1NC ,1 NO )
Heating Output
E
2SSR Drive Output ( Maximum 30mA,Maximum 15V )
01 Relay Output ( 3A@250 V V,at Resistive Load ,1 NO )
Heating Alarm Output
HI
1Relay Output ( 3A@250 V V,at Resistive Load ,1 NO )
Humidifier Alarm Output
U
Temp.Sensor which is given with ESM-3723
V
0None
3NTC-M5L20.K1.5 (NTC Probe thermoplastic moulded with
1.5m cable for cooling application)
4NTC-M6L50.K1.5 (NTC Probe stainless steel housing with
1.5m cable for cooling application)
9
ProNem Mini PMI-P (2.5m cable for Temperature and Humidity
application)
6
Customer
1PTC-M6L40.K1.5 (PTC Air Probe 1.5 m silicon cable)
2PTCS-M6L30.K1.5.1/8”(PTC Liquid Probe with 1.5 m silicon cable)
A
User defined
User defined

DEUTCH
ESM-3723 77x35 DIN-Größe Temperatur+Feuchtigkeit
Bedienungsanleitung. DE ESM-3723 01 V03 02/15
- 4-stellige Temperaturanzeige
- 4-stellige Feuchtigkeitsanzeige
- Temperatursensoreingang
NTC, PTC, PT-100, 0/2..10V, 0/4..20mA oder ProNem Mini PMI-P
(Muss der Reihenfolge nach bestimmt werden.)
- Feuchtigkeitssensoreingang
0/2..10V, 0/4..20mA oder ProNem Mini PMI-P
(Muss der Reihenfolge nach bestimmt werden.)
- 4 Ausgang
Heizungsregler-Ausgang
Heizalarmausgang
Befeuchtungsreglerausgang
Befeuchtungsalarmausgang
- Relais oder SSR-Ausgänge
(Müssen der Reihenfolge nach bestimmt werden.)
- Wählbare Temperaturregelung (PID oder EIN/AUS)
- Autotune PID
- Sollwertgrenzen
- Alarmparameter
- Einstellbarer interner Summer je nach Alarmsituationen
- Passwortschutz für Programmierbereich
- CE-Kennzeichnung gemäß Europäischen Normen
ESM-3723 77 x 35 DIN-Größe
Digitaler Temperatur+Feuchteregler

DEUTCH
c
1.2. Allgemeine Spezifikationen
1. Einleitung
Die Temperatur- und Feuchtigkeitssteuergeräte der Serie ESM-3723 dienen zur Steuerung von
Industrieprozessen. PID oder Ein-/Aus-Steuerungsform unter der Steuerung des Prozesses ist eine
Vorrichtung, die Ihre besonderen Bedürfnisse ansprechen kann.
ESM-3723
Stromversorgungs-
eingang
Ausgang
Ausgang
Ausgang
2
Heizalarm
Befeuchter
Befeuchteralarm
1.1 Umgebungsbedingte Leistungsfähigkeit
230V ( %15)50/60HzV ±
Optionale
Versorgungsspannung
- 30 V Z
115 V (±%15)50/60Hz
24 V (±%15)50/60Hz
24 V (±%15)50/60Hz
10
V
V
W
Standard
Ausgang Heizen
Betriebstemperatur : 0 bis 50 °C
Max. Luftfeuchtigkeit bei Betrieb : 90% Rh (nicht kondensierend)
Höhe : Bis zu 2000 m.
Verbotene Bedingungen
Korrosive Atmosphäre
Explosionsfähige Atmosphäre
Heimbereich (Das Gerät ist nur für industrielle Anwendungen)
Temperatursensor-
eingang
Feuchtigkeitssensor-
eingang
PTC, NTC, PT-100
0/2..10V, 0/4..20mA oder
ProNem Mini PMI-P
0/2..10V,0/4..20mA oder
ProNem Mini PMI-P

3
Eine Sichtprüfung dieses Produkts auf mögliche Transportschäden wird vor der Installation empfohlen. Es
liegt in Ihrer Verantwortung dafür zu sorgen, dass qualifizierte Maschinenbau- und Elektrotechniker dieses
Produkt installieren.
Bei Gefahr eines schweren Unfalls durch Ausfall oder Defekt dieser Einheit, schalten Sie das System aus
und trennen Sie die elektrische Verbindung des Geräts vom System.
Die Einheit wird normalerweise ohne Stromschalter oder Sicherung geliefert. Verwenden Sie Netzschalter
und Sicherung nach Bedarf.
Stellen Sie sicher, dass Sie die Nennversorgungsspannung verwenden, um die Einheit vor Schäden zu
schützen und einen Ausfall zu verhindern.
Lassen Sie den Strom abgeschaltet, bis die gesamte Verkabelung abgeschlossen ist, damit Stromschläge
und Probleme mit dem Gerät verhindert werden können.
Versuchen Sie niemals die Einheit zu zerlegen, zu verändern oder zu reparieren.
Die Manipulierung des Geräts kann zu Fehlfunktion, Stromschlag oder Brand führen.
Verwenden Sie die Einheit nicht in brennbaren oder explosionsgefährdeten gashaltigen Atmosphären.
Beim Einsetzen des Geräts in die Öffnung der Metallplatte während der mechanischen Installation, können
Metallgrate Verletzungen an den Händen verursachen. Seien Sie vorsichtig.
Die Montage des Produkts in einem System muss mit dessen Befestigungsklammern erfolgen. Führen Sie
die Montage des Geräts nicht mit ungeeigneten Befestigungsklammern durch. Achten Sie darauf, dass das
Gerät während der Montage nicht herunterfällt.
Es liegt in Ihrer Verantwortung, wenn das Gerät auf eine nicht in dieser Bedienungsanleitung
vorgeschriebenen Art und Weise benutzt wird.
EMKO Elektronik garantiert, dass das gelieferte Gerät keinerlei Material- oder Verarbeitungsmängel
aufweist. Diese Garantie beschränkt sich auf einen Zeitraum von zwei Jahren. Die Garantiezeitbeginnt
mit dem Lieferdatum. Diese Garantie ist gültig, wenn die im Garantieschein und in der
Bedienungsanleitung festgelegten Pflichten und Verantwortlichkeiten vollständig durch den Kunden
erfüllt werden.
Reparaturen dürfen nur von geschultem Fachpersonal durchgeführt werden. Trennen Sie das Gerät
von der Stromversorgung, bevor Sie Innenteile manipulieren. Reinigen Sie das Gehäuse nicht mit
Kohlenwasserstoff-Lösemitteln (Benzin, Trichloräthylen usw.). Die Verwendung dieser Lösemittelkann
die mechanische Zuverlässigkeit des Geräts beeinträchtigen. Verwenden Sie ein mit Ethylalkohol oder
Wasser angefeuchtetes Tuch, um das externe Kunststoffgehäuse zu reinigen.
1.3 Installation
1.4 Garantie
1.5 Wartung
1.6 Herstellerfirma
Herstellerangaben:
Emko Elektronik Sanayi ve Ticaret A.Ş.
Demirtaş Organize Sanayi Bölgesi Karanfil Sk. No:6 16369 BURSA/TURKEY
Telefon : [phone]
Fax : [phone]
Reparatur und Wartungsservice:
Emko Elektronik Sanayi ve Ticaret A.Ş.
Demirtaş Organize Sanayi Bölgesi Karanfil Sk. No:6 16369 BURSA/TURKEY
Telefon : [phone]
Fax : [phone]
DEUTCH

2.2 Tafelausschnitt
2. Allgemeine Beschreibung
2.1 Frontansicht und Abmessungen des ESM-3723 Brutreglers
76 mm / 3 Zoll
34,5 mm / 1.36 inch
4
Befestigungsklammer
Tafeloberfläche
(maximale Dicke 15 mm / 0,59 Zoll)
Bedienfeld
IP 65 Schutz
NEMA 4X
65 mm / 2,56 Zoll
6 mm / 0,24 Zoll
110 mm / 4,33 Zoll (min)
71 mm / 2,79 Zoll
29 mm / 1,14 Zoll
50 mm / 1,97 Zoll (min)
Maximum 15 mm / 0,59 Zoll
ESM-3723
ü
SET
P
O1
O2
A1
A2
OC
OF
DEUTCH
