MULTISPAN UTC-121G User manual

UTC-121G
PV = Process Value
SV = Set Value
TEMPERATURE CONTROLLER
DISPLAY AND KEYS:
CONTROL METHOD:
DIMENSION:
OUTPUT SPECIFICATION:
POWER SUPPLY:
ENVIRONMENT CONDITION:
Display
Heating
Size
Keys
Cooling
Panel Cutout
Power Consuption
(VA Rating)
Relative Humidity
Protection Level
Relay
Output Signal
Supply Voltage
Operating Temp.
Relay Type
Rating
Upper: 4 digit, 7 segment, 0.70”
1) PID control with Auto-Tuning
Lower: 4 digit, 7 segment, 0.50”
2) ON-OFF control
96 (H) x 96 (W) x 52 (D) mm
100 to 270V AC, 50-60Hz
0°C to 55°C
UP to 95% RH
(non-condensing)
IP-65 (Front side) As per IS/IEC
60529 : 2001
1 Nos
12V DC, 30mA DC
(On-Off condition)
Relay parallel to SSR
1C/O (NO-C-NC)
10A, 230V AC / 28V DC
SET, INC, DEC, ENT
ON-OFF control
92 (H) x 92 (W) mm
4VA @ 230V AC MAX
Relay Output
SSR Drive Output
TECHNICAL SPECIFICATION
MECHANICAL INSTALLATION
TERMINAL CONNECTION
Outline Dimension (mm) Panel Cutout
Dimension (mm)
11
13
12
3-Wire RTD 2-Wire RTD
Thermocouple
Install jumper
when using
2 Wire RTD
+
Sensor Input
Input Types
Resolution
Indication
Input Range
0 to 600°C
0.0 to 400.0°C
0 to 1200°C
-50 to 400°C
0.0 to 500.0°C
-50.0 to 400.0°C
J
J.1
K
PT-100
K.1
PT.1
J,K,PT-100 = 1°C
±1% of FSD ± 1°C
J.1,K.1,PT.1 = 0.1°C
INPUT SPECIFICATION:
Accuracy
96 52
92
92
3
96
ENTSET
UTC 121G
TUNE
ºC
PV
SV
32 4
235
R1
17 8 9
12
1314
10
11
1617181920 15
23456
NC
C
NO
T/C
+
-
+
-
RELAY
!
LN
O/P
S.S.R RTD
100
270V AC
~
50/60 HZ
4VA
Made in India
www.multispanindia.com
11
13
12
11
12
Display Color:
Upper : White Or Red
Lower : Green
Page 1

Read complete instructions prior to installation
and operation of the unit.
WARNING : Risk of electric shock.
SAFETY PRECAUTION
!
All safety related codifications, symbols and instructions that
appear in this operating manual or on the equipment must be
strictly followed to ensure the safety of the operating personnel
as well as the instrument.
If all the equipment is not handled in a manner specified by
the manufacturer, it might impair the protection provided by the
equipment.
STATUS LED DESCRIPTION
KEY OPERATION
To enter in parameter setting
For start/stop PID auto tuning Press
6 sec
Press 3 sec
+
To go in factory setting mode
PRESS KEY
FUNCTION
OPERATOR MODE
PARAMETER SETTING MODE
To set parameter value
To increment parameter value.
To decrement parameter value.
Set parameter to be save & exit.
WARNING GUIDELINES
WARNING : Risk of electric shock.
1. To prevent the risk of electric shock, power supply to the
equipment must be kept OFF while doing the wiring
arrangement. Do not touch the terminals while power is
being supplied.
2. To reduce electro magnetic interference, use wire with
adequate rating and twists of the same of equal size shall
be made with shortest connection.
3. Cable used for connection to power source, must have a
cross section of 1mm or greater. These wires should have
insulations capacity made of at least 1.5kV.
4. When extending the thermocouple lead wires, always use
thermocouple compensation wires for wiring for the RTD
type, use a wiring material with a small lead resistance
(5 max per line) and no resistance differentials among
three wires should be present.
5. A better anti-noise effect can be expected by using
standard power supply cable for the instrument.
Ω
INSTALLATION GUIDELINES
1. This equipment, being built-in-type, normally becomes a
part of main control panel and in such case the terminals
do not remain accessible to the end user after installation
and internal wiring.
2. Do not allow pieces of metal, wire clippings, or fine metallic
fillings from installation to enter the product or else it may
lead to a safety hazard that may in turn endanger life or
cause electrical shock to the operator.
3. Circuit breaker or mains switch must be installed between
power source and supply terminal to facilitate power ‘ON’
or ‘OFF’ function. However this mains switch or circuit
breaker must be installed at convenient place normally
accessible to the operator.
4. Use and store the instrument within the specified ambient
temperature and humidity ranges as mentioned in this
manual.
MECHANICAL INSTALLATION GUIDELINES
1. Prepare the panel cutout with proper dimensions as shown
above.
2. Fit the unit into the panel with the help of clamp given.
3. The equipment in its installed state must not come in close
proximity to any heating source, caustic vapors, oil steam,
or other unwanted process Byproducts.
4. Use the specified size of crimp terminal (M3.5 screws) to
wire the terminal block. Tightening the screws on the
terminal block using the tightening torque of the range of
1.2 N.m.
5. Do not connect anything to unused terminals.
MAINTENANCE
1. The equipment should be cleaned regularly to avoid blockage
of ventilating parts.
2. Clean the equipment with a clean soft cloth. Do not use
isopropyl alcohol or any other cleaning agent.
3. Fusible resistor must not be replaced by operator.
Page 2
1 - Control output indication
2 - Auto tuning “ON” indication
3 - Blinking DP Will Indicate Delay time Count
1
2
3
2345
2500

SRE
Check the sensor and the input wiring. If problem still exists,
replace the sensor. And still if problem is not solved yet by the
user, then please contact company person
Sensor connection is reversed
FACTORY SETTING
PARAMETER RANGE
FACTORY SETTING
PARAMETER
IT
CT
Offset
PB
DT
MR
Hysteresis
Delay time
VALUES
300
15 Sec
20.0°C
75
0°C
0°C
3°C
6 sec
SR.
2
4
6
1
3
5
7
8
ENT
SET
Press key for 3 sec to
enter password
Set Point
Press key
Password Message
PB
IT
Sr.
1
2
0.0 to 999.9 0.0 to 999.9
0 to 9999 0 to 9999
Parameter Range for J, K, PT100 Range for J.1,K.1,PT.1
SET
Basic Configuration
Press key
To ENTER BASIC
CONFIGURATION
SETTING, ENTER “73”
Message
Password
Input
Relay Mode
Control Action Hysterisis
Delay Time
Set Low Limit
Set High Limit
CORRECTIVE ACTION:
34
fCst
234
YES
Press + key
for 3 sec
yes
: Press key to apply factory set
values as shown in table.
: Press key to escape
from factory setting.
ENT
ENT
no
no
ERROR
OPEN
MEANING
When an error has occurred the display indicates error codes
as given below.
Sensor is not connected or
ERROR DISPLAY
Set Point Setting
Process Value
Set Value
PARAMETER SETTING
Over range condition or
sensor break
DT
CT
MR
OffSet
Hysteresis
Delay Time
3
4
5
6
7
8
0 to 9999 0 to 9999
4 to 99 Sec 4 to 99 Sec
1 to 999 Sec 1 to 999 Sec
-9°C to +9°C -9.0°C to +9.0°C
-20°C to +20°C -20.0°C to +20.0°C
1°C to 100°C 0.1°C to 100.0°C
ENT
Offset
Press key to save & exit
Page 3

PID AUTO-TUNING
Press key for 6 sec to start/stop
PID auto-tuning
SET
ENT
Press key
Integral
time
Derivative
time
Cycle time
Manual Reset
Press key to save & exit
Proportional
Band
CONTROL FUNCTION
RLY-OFF
RLY-ON
RLY-ON
RLY-ON
RLY-OFF
RLY-OFF
Temp.
S.V
HYST
Time
OFF OFF
ON - OFF control (Heating)
ON - OFF control (Cooling)
ON ON
°C
PV
Tuning
LED Indication
SV
234
34
Auto Tuning:-
The Auto-tuning function automatically computes
and sets the Proportional band (Pb) , Integral time (It),
Derivative time (dt), and cycle time as per process
characteristics.
Tuning LED will turn “ON” during Auto-Tuning
If the power goes off before auto-tuning is completed,
auto-tuning will be restarted at next power ON.
SET
Control Parameter
Password
Message
PID
Parameters
IF PID SELECTED
To ENTER CONTROL
PARAMETER
SETTING, ENTER “37”
delay delay delay
Time Time Time
RLY-ON
RLY-OFF
Temp.
HYST
S.V
Time
OFF OFF OFF
ON ON ON
Specifications are subject to change, since development is a continuous process,
So for more updated operating information and Support,
Please contact our Helpline: 9978991474/9978991476/9978991482 or
Email at Ver:011220[email protected]
PARAMETER SETTING
