Enable-IT 828 User manual

All Rights Reserved 1997 - 2011 ENABLE-IT-Proprietary and Confidential
Ethernet Extension Experts
Enable-IT 828 Gigabit
Ethernet & PoE+ Extender
User Manual


Page 2 of 14 Ethernet Extension Experts
Copyright © 1997-2011 Enable-IT, Inc. All rights reserved. No part of this documentation
may be reproduced in any form or by any means or used to make any derivative work (such
as translation, transformation, or adaptation) without written permission from Enable-IT, Inc.
Enable-IT, Inc reserves the right to revise this documentation and to make changes in
content from time to time without obligation on the part of Enable-IT, Inc to provide
notification of such revision or change.
Enable-IT, Inc provides this documentation without warranty, term, or condition of any kind,
either implied or expressed, including, but not limited to, the implied warranties, terms or
conditions of merchantability, satisfactory quality, and fitness for a particular purpose.
Enable-IT, Inc may make improvements or changes in the product(s) and/or the
program(s) described in this documentation at any time.
If there is any software on removable media described in this documentation, it is furnished
under a license agreement included with the product as a separate document, in the hard
copy documentation. If you are unable to locate a copy, please contact Enable-IT, Inc and a
copy will be provided to you.
UNITED STATES GOVERNMENT LEGEND
If you are a United States government agency, then this documentation and the software
described herein are provided to you subject to the following:
All technical data and computer software are commercial in nature and developed solely at
private expense. Software is delivered as "Commercial Computer Software" as defined in
DFARS 252.227-7014 (June 1995) or as a "commercial item" as defined in FAR 2.101 (a)
and as such is provided with only such rights as are provided in Enable-IT, Inc's standard
commercial license for the Software.
Technical data is provided with limited rights only as provided in DFAR 252.227-7015 (Nov
1995) or FAR 52.227-14 (June 1987), whichever is applicable. You agree not to remove or
deface any portion of any legend provided on any licensed program or documentation
contained in, or delivered to you in conjunction with, this User Guide.
Unless otherwise indicated, Enable-IT, Inc registered trademarks are registered in the
United States and may or may not be registered in other countries

Page 3 of 14 Ethernet Extension Experts
CONTENTS
ABOUT THIS GUIDE 4
1 INTRODUCING THE ENABLE-IT 828 GIGABIT ETHERNET &POE+ EXTENDER 5
About the 828 Gigabit Ethernet & PoE+ Extender 5
Key Benefits 6
Summary of Features 6
Typical Use Applications 7
2 INSTALLING THE ENABLE-IT 828 GIGABIT ETHERNET &POE+ EXTENDER 8
Site Plan – Installation Design Considerations 8
Unpacking the 828 Gigabit Ethernet & PoE+ Extender 9
Perform an out of the box Test 9
Performing the On-Site Installation 9
Mounting the 828 Gigabit Ethernet & PoE+ Extender 10
Attaching cabling and devices 10
Troubleshooting & PoE+ output control (DIP switch) 11
3 TECHNICAL SUPPORT
Online Technical Services 11
World Wide Web Site 11
Returning Products for Repair 11
4ENABLE-IT INC.LIMITED WARRANTY 12
5CONTACT US 14

Page 4 of 14 Ethernet Extension Experts
ABOUT THIS GUIDE
This guide provides all the information needed to install and use the Enable-IT
828 Gigabit Ethernet & PoE+ Extender. This guide is intended for use by
technicians who are responsible for installing and setting up network equipment.
Consequently, it is assumed that the installer has a basic working knowledge of
LANs (Local Area Networks) and voice telecom wiring.
If the information in the release notes that are shipped with your product differs
from the information in this guide, follow the instructions in the release notes.
Most user guides and release notes are available in Adobe Acrobat
Reader Portable Document Format (PDF) or HTML on the Enable-IT World Wide
Web site: http://www.ethernetextender.com/manuals/828-Manual.pdf

Page 5 of 14 Ethernet Extension Experts
INTRODUCING THE 828 GIGABIT ETHERNET &POE+ EXTENDER
Congratulations on purchasing the Enable-IT’s 828 Gigabit Ethernet & PoE+ Extender
— the fastest and simplest method to stretch your broadband solutions for in-building
deployment in commercial office buildings, hotels, and multi-tenant residential units.
The 828 Gigabit Ethernet & PoE+ Extender offers the Lowest Cost Solution in a simple
design for rapid install using existing Category 5, 5e or 6 wiring (All 4-pairs required).
This chapter contains introductory information about The 828 Gigabit Ethernet & PoE+
Extender and how it can be used in your network. It covers the following topics:
•About the 828 Gigabit Ethernet & PoE+ Extender
•Key Benefits
•Summary of Features
•Typical Applications
About the 828 Gigabit Ethernet & PoE+ Extender
The 828 Gigabit Ethernet & PoE+ Extender solves the problem of high costs associated
with stretching your backbone with traditional fiber or a series of hubs/repeaters.
In many office buildings, preferred network access is a dedicated Ethernet line,
however Ethernet over twisted pair wiring has its distance limitations of just 328 ft.
Gigabit Ethernet requires all 4-pair (8 wires) found in Category rated 5, 5e and 6
wiring. In order to drive Ethernet signal further, one would have to add repeaters to
each segment of 328ft twisted pair cabling; this is often insufficient and to costly in
multi-story buildings. Fortunately, the Enable-IT 828 Gigabit Ethernet & PoE+
Extender can push the reach of Ethernet to more than (6) six times the typical
Ethernet distance over existing Category 5, 5e or 6 wiring (All 4-pairs required).
To increase the durability and use of the product providing maximum future technology
protection, the 828 Gigabit Ethernet & PoE+ Extender meets the challenge of modern
switched LANs and allows you to add features and capacity as your network expands.
The Enable-IT 828 Gigabit Ethernet & PoE+ Extender has been tested to provide full
duplex transport up to 1,000MB/s over CAT5 cabling regardless of distance up to 2,000ft
/ 610m.
* Actual throughput rate will vary on the quality of the copper wire, twisted pair and environmental
factors – but you can expect full wire speed regardless of distance or number of 828 Extenders
used.
Model
Wiring
LAN Data Rate
Max. Distance
828 (4) pair CAT 5 up to CAT6 1,000Mbps FD 2,000ft / 610m

Page 6 of 14 Ethernet Extension Experts
Key Benefits
The following list identifies the 828 Gigabit Ethernet & PoE+ Extender key benefits.
•Dramatic cost reduction over any competing technology (Copper or Fiber)
•Extreme Broadband technology that delivers Full Speed Gigabit Ethernet up to
five times the IEEE 802.3 distance limit over Category 5 wiring or better.
•Provides one scalable infrastructure for Internet access, POTS, VoIP, video, and
virtual private networking.
•Rapid installation with small box profile, no programming and no firmware to
upgrade.
•Low profile box for extending your (10/100/1000) Ethernet and PoE+
•Option for disabling PoE output on remote end for supporting non-PoE devices.
Summary of Features
The Enable-IT 828 Gigabit Ethernet & PoE+ Extender has the following features:
•Full Gigabit Ethernet speed over existing CAT 5e up to CAT 6 wiring
•Uses LAN standard RJ-45 ports (10/100/1000Mbps data and PoE+ 56vdc)
•Rapid Plug and Go installation – no programming required
•Optional 2.1mm DC power jack or PoE powered (Standard)
•Drives Ethernet 1000 Mbps full-duplex service delivery with native PoE+ (60w-56vdc)
•Network Equipment independence – Transparent to protocols/applications/MAC
Specifications: Functionality:
Power Indicator LED Data Rates 10/100/1000Mbps Full Duplex
100Mbps Link status/Activity LED Full Duplex/Half Duplex status/Collisions
1000Mbps Link status/Activity LED Protocol independent
Dimensions: 828 LAN port pins:
Height: 3.5" (88.9mm) Pins 1 & 2 – 10/100/1000Mbs Data
Depth: 1.0 " (25.4mm) Pins 3 & 6 – 10/100/1000Mbs Data
Width: 4.5” (114.3mm) Pins 4 & 5 – 1000Mbs Data & PoE+
Pins 7 & 8 – 1000Mbs Data & PoE+
Environment
Operating temp: -32°F to 176°F (-35°to 80°C) Interfaces
Storage temp: -32°F to 180°F (-35°to 83°C) (3) RJ-45 10/100/1000 LAN Auto negotiate
Humidity 5% to 95%, non-condensing (1) 5v 2A DC Power jack 2.1mm (optional use)
(4) DIP Switches for disabling PoE output

Page 7 of 14 Ethernet Extension Experts
Typical Use Applications
Enable-IT 828 Gigabit Ethernet & PoE+ Extender can be quickly installed on existing or
new Category rated wiring infrastructures where extension of backbone services is
required and expensive fiber options are prohibitive. The 828 Gigabit Ethernet & PoE+
Extender allows a standard Ethernet segment to be deployed quickly over existing
Category 5, 5e or 6 wiring (All 4-pairs required).
Installers have the convenience of a 10/100/1000Mbps LAN Ethernet Extender for peace
of mind connectivity and no device maintenance. Rapid installation allows for minimal
interruption and the Broadband technology allows for investment protection up to 10 -15
years with no firmware or replacement issues. Carriers and Access Providers can came
and go, but the 828 Gigabit Ethernet & PoE+ Extender technologies continue to provide
lasting value such as the other utilities like Water, gas and electricity.
The Enable-828 Gigabit Ethernet & PoE+ Extender is suited for the following key environments:
•Commercial Buildings (Multi-Tenant Extender)
•Business Parks (Multi-Tenant Extender)
•Apartments (Multi-Residential Extender)
•Hotels (Multi-Hospitality Extender)
•Business Suites (Multi-Hospitality Extender)
•School Campuses (University, K-12)
•College Housing (Multi-Residential Extender)
•Mining Operations – Quarries, Mine shafts
•Nautical Infrastructure – Cruise ships, Marinas, dive operations, subs
•Video Surveillance/Security
•WiFi Deployment – ISP’s, RV Parks, Construction sites
•Manufacturing – Foundries, pharmaceutical, aerospace, automotive,
petroleum, concrete plants, etc.
•Retail POS – Department stores, Bars, restaurants, retail spaces
•Government – Naval ships, FEMA, Housing, USGS, National Parks, Forestry,
Research stations, NASA, utilities, etc.
•Education – outdoor camps, college campuses
•Healthcare – Hospitals, elder care, outpatient facilities
•Entertainment – Movie theaters, home entertainment, fairs, outdoor venues

Page 8 of 14 Ethernet Extension Experts
INSTALLING THE 828 GIGABIT ETHERNET &POE+ EXTENDER
The Enable-IT 828 Gigabit Ethernet & PoE+ Extender units have an individual distance
restriction of approximately 900ft or 275m over existing Category 5, 5e or 6 wiring (All 4-
pairs required) from device extension to device extension. The 828 units can
communicate 400ft / 122m distance out each LAN port – so placing the 828 in the
middle of your run is ideal. 828 units are designed to be daisy chained in a series to
further extend distance. Up to (4) 828 units can be used in series to reach 2,000ft /
610m. Optional DIP switch setting for the last end 828 is selectable for disabling the
PoE output if installing a non-PoE powered device.
This chapter describes the recommended installation process for the Enable-IT 828
Gigabit Ethernet & PoE+ Extender. It covers the following topics:
•Site Plan – Installation Design Considerations
•Unpacking the Enable-IT 828 Gigabit Ethernet & PoE+ Extender
•Perform an out of the box Test
•Performing the On-Site Installation
Site Plan - Installation Design Considerations
The planning process should involve a site walkthrough and discovery survey. Electrical
Cable measurement tools are the most reliable method to determine the longest run of
hidden wiring. Estimate the best locations to position the 828 unit to adequately reach
desired connectivity for your overall run. Document your findings to use in designing a
network topology to support the Ethernet Switches and backbone connectivity. Key
points to remember in your Site Survey.
•Individual distance limitation of 800ft or 240m from end to end.
•Daisy Chain distance limitation of 2,000ft or 610m from end to end.
•4 Pair CAT 5 wiring up to CAT 6 .30 Gage or better cabling is required for the
Gigabit Ethernet transmission.
Options for installation include standalone use or daisy chain configurations with the
ability to disable the PoE output. Here is a list of possible installation options:
1) Standalone 828 unit with optional 5v-2A power adapter.
2) Standalone 828 unit powered by your PoE injector or PoE switch.
3) 828P Kit with 60w-56v PoE+ injector
4) 828P Kit with 60w-56v PoE+ injector and multiple 828 units for maximum extension.
For details see diagrams of each option under the Installation section.

Page 9 of 14 Ethernet Extension Experts
Unpacking the Enable-IT 828 Gigabit Ethernet & PoE+ Extender
Carefully remove the Enable-IT 828 Gigabit Ethernet & PoE+ Extender and all packing
materials from the box. Verify that the items listed below are present. Make sure that the
equipment supplied matches what you ordered. If any items are missing or damaged,
please contact Enable-IT or your distributor for assistance.
•(1) The Enable-IT 828 Gigabit Ethernet & PoE+ Extender Unit
•(1) Enable-IT 828 Gigabit Ethernet & PoE+ Extender User Manual (this manual)
Perform an out of the box Test
We highly recommend a quick test to ensure the working order of you 828 Gigabit
Ethernet & PoE+ Extender. To perform this test, attach the 828 Input port to your
PoE LAN switch, PoE Injector, or if using an optional 5v power adapter – your LAN
device. On power up the 828 will show power and connectivity LED’s. Next
connect your PoE device to the output port of the 828 or if using a non-PoE
powered device – Make sure to set the DIP switch to disable PoE output.
Test your connectivity from end to end.
LED indicators will provide visual operational status of the 828 Extender.
Input RJ-45 Port:
Power LED - Solid Green LED (left side of RJ-45 port) indicates the
5v power source is on and good.
Input LED - Solid Yellow LED (right side of RJ-45 port) indicates
Gigabit Ethernet connectivity detected.
- No LED lit (right side of RJ-45 port) indicates 10Mbs
or 100Mbs Ethernet connectivity detected.
Output RJ-45 Port:
Gigabit LED - Solid Yellow LED (left side of RJ-45 port) indicates
Gigabit Ethernet connectivity and activity.
10/100 LED - Solid Green LED (right side of RJ-45 port) indicates
100Mbs Ethernet connectivity and activity.
- No LED lit (right side of RJ-45 port) indicates
10Mbs Ethernet connectivity.
Performing the On-Site Installation
After removing the Enable-IT 828 Gigabit Ethernet & PoE+ Extender from the box and
performing the out of the box testing all that remains to install the Extender on-site is to
mount the Extender and attach the LAN device cabling.
Choose your installation type desired from the following list of options:
Option 1: Standalone 828 unit with optional 5v-2A power adapter.

Page 10 of 14 Ethernet Extension Experts
Option 2: Standalone 828 unit powered by your PoE injector or PoE switch.
Option 3: 828P Kit with 60w-56v PoE+ injector.
Option 4: 828P Kit with 60w-56v PoE+ injector and multiple 828 units.
Mounting the Enable-IT 828 Gigabit Ethernet & PoE+ Extender
The Enable-IT 828 Gigabit Ethernet & PoE+ Extenders are designed for quick wall
mounting. Choose a location to mount the Enable-IT 828 where the inline midpoint
is no further than 400ft / 122m from your source Ethernet LAN and destination
endpoint. When wall-mounting the Enable-IT 828 Gigabit Ethernet & PoE+ Extender
it is recommended that you use the appropriate screw anchors for your mounting
surface. If mounting on existing plywood use wood screws; if mounting onto drywall
or sheetrock, use plastic drywall anchors to secure your installation.
Before applying power, determine if your end device requires PoE power. The default
DIP switch setting has PoE output Disabled. To enable PoE output change the DIP
switch position to ON – DOWN position.
Depending on distance you can safely power PoE devices requiring 6v to 48v.
Attach your cabling and devices and apply power. Your equipment should now be
powered up and functioning.
