Endress+Hauser airtrol CPC 200 User manual

BA 095C/07/en/12.97
Software version: from2.01 (Airtrol)
6.06 (Mycom CPM 151-P)
No. 50061226
airtrol
CPC 200 / 210
Fully Automatic
Measuring and
Calibration System
for pH
Operating Instructions
Nothing beats know-how
Endress
Hauser
Quality made by
Endress+Hauser
ISO 9001

Table of contents
1. General............................................................. 2-3
1.1 Unpacking............................................................ 2
1.2 Application............................................................ 2
1.3 Ordering system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2. Measuring system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3. Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-10
3.1 Basics for installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
3.2 Installation overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
3.3 Pneumatic connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3.4 Compressed air connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3.5 Waterconnection...................................................... 10
3.6 Buffer and cleaner solutions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3.7 Connection to retractable pH assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
4. Electrical connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-14
4.1 Basics for connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
4.2 Connection diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
4.3 Connection of CPC 200 to CPC 210 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
4.4 Connective networking of several systems via Profibus. . . . . . . . . . . . . . . . . . . . . . . . 13
5. Start-up ..........................................................15-20
5.1 General ............................................................. 15
5.2 Start-up sequence. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
6. Operation.........................................................21-42
6.1 Modes of operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
6.2 Airtrol menustructure .................................................. 24
6.3 Singlemenus......................................................... 26
6.4 Service.............................................................. 34
6.5 “Auto(matic)” mode of operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
6.6 External start inputs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
6.7 Relaystatus.......................................................... 42
7. Error diagnosis . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43-46
7.1 List of error messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
8. Technical data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
9. Appendix.........................................................48-52
9.1 Cleaning agents for cleaner reservoir. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
9.2 Cleaning ............................................................ 48
9.3 Maintenance......................................................... 48
9.4 Bus cable properties. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
9.5 System control S5-95U – Display and operating elements and interfaces . . . . . . . . . 49
9.6 Accessories.......................................................... 50
9.7 Index............................................................... 51
BE1PC200.CHP
airtrol CPC 200 / 210 Table of contents
1

1. General
1.1 Unpacking
•Inspect for any damaged packaging!
The post office or freight carrier must be
informed of any damage.
Damaged packaging material must be
retained until the matter has been settled!
•Verify that the contents are undamaged!
Inform the post office or freight carrier as
well as the supplier of any damage.
•Check that the delivery is complete and
agrees with the shipping documents and
that the unit type and version match the
nameplate (see fig. 1.1).
If you have any questions, consult your
supplier or your competent Endress+Hauser
sales center (see back cover of these
operating instructions for addresses).
1.2 Application
The Airtrol is an automatic cleaning, pH signal
monitoring and calibration system.
When used in conjunction with the retractable
pH / redox assembly Probfit, the Airtrol
permits automatic cleaning and calibration of
pH electrodes.
These operating instructions describe the
automatic cleaning, pH signal monitoring and
calibration system of the Airtrol CPC 200 / 210.
Note:
Separate operating instructions
are required for the built-in pH
measuring transmitter Mycom
CPM 151-P and the retractable
assembly Probfit CPA 463 or
CPA 463S.
•pH / temperature measuring transmitter /
controller Mycom CPM 151-P
(BA 093C/07/en)
•Retractable assembly for pH / redox
measurement Probfit CPA 463
(BA 007C/07/en)
•Retractable assembly for pH / redox
measurement Probfit CPA 463S
(BA 151C/07/en)
ZPC200.TIF
Fig. 1.1: Nameplates
left: Airtrol CPC 200
right: Airtrol CPC 210
ZPC210.TIF
1. General airtrol CPC 200 / 210
2

1.3 Ordering system
Airtrol CPC 200 – operating unit
Power supply
0 230 V, 50 / 60 Hz
1 115 V, 50 / 60 Hz
3 24 V, 50 / 60 Hz
824VDC
9 Special version
Language versions
D German language version
E English language version
Versions
A Standard version
Y Special version
CPC 200 - ⇐complete order code
Airtrol CPC 210 – pneumatic unit
Versions
A Standard version
Y Special version
CPC 210 - ⇐complete order code
BE1PC200.CHP
airtrol CPC 200 / 210 1. General
3

2. Measuring system
The complete measuring system (fig. 2.1)
comprises
•the operating unit CPC 200 and the
pneumatic unit CPC 210
•a Probfit assembly
•a pH measuring cable CPK 7
•a connecting cable from the operating unit
to the pneumatic unit (5 m, 14 wires)
•A control line from the pneumatic unit to the
Probfit assembly (5 m pneumatic hoses in
protective hose).
Connective networking of several systems
(max. 10) is possible via Profibus (fig. 2.2).
Power supply
3 remote control inputs
Water
connection
4to6bar
Probfit assembly
pH measuring
cable CPK 7
PA663-AN.EPS
3 status contacts
2 limit contacts and alarm
Compressed
air connection
4to6bar
Siemens L2
(Profibus)
Connecting
cable
Triggering
external cleaning / sterilization
4 ... 20 mA current output
Pneumatic
unit
Buffer 1
Buffer 2
Cleaning agent
e. g., tank
Control line
Operating unit
Fig. 2.1: Single system
Siemens L2
(Profibus)
PC200W12.EPS
Pneumatic unit
CPC 210
Probfit assembly
Operating unit
CPC 200
Max. of 10 systems
PC with
visualisation
software
Fig. 2.2: Connective networking
of several systems
2. Measuring system airtrol CPC 200 / 210
4

3. Installation
3.1 Basics for installation
Note:
•Outdoor installation of system
requires complete weather
protection (sun and rain
protection)!
•Ingress protection is IP 54.
•Operating unit CPC 200
– Install at eye level to facilitate operation
and assure readability of the system.
•Pneumatic unit CPC 210
– Install next to the operating unit CPC 200
if possible to facilitate troubleshooting,
maintenance, etc.
– Make sure water and compressed air
connections are easily accessible.
– The standard length of the pneumatic
connecting line between the pneumatic
unit CPC 210 and the retractable pH
assembly is 5 m.
– The cleaner and buffer bottles are
screwed onto the cabinet from below.
530
455
325
430
PC200W8M.EPS
460
200
Main switch
Door stop
35
Fig. 3.1: Dimensions CPC 200
530
455
325
PC210W8M.EPS
800
460
430
200
Required mounting
clearance:
min. 300 mm
Door stop
Fig. 3.2: Dimensions CPC 210
BE1PC200.CHP
airtrol CPC 200 / 210 3. Installation
5

3.2 Installation overview
PC200W06.EPS
Mains connection
Control inputs
and outputs
pH electrode
connecting cable
to retractable
assembly
Connecting cable to the
pneumatic unit CPC 210
Operating panel
X2
Interface cable
X1
Power
supply
unit
X3
Interface
cable
Programmable logic
controller (PLC)
Terminals
Connection for PLC
interface
Relays
Fuses
Mycom CPM 151-P
7
K
1
7
K
5
7
K
4
7
K
3
7
K
2
24 V DC
Fig. 3.3: Operating unit
CPC 200 (open)
Notes:
– Relay designations (from left to
right): 7K1, 7K2, 7K3, 7K4, 7K5
– Terminal block X3 is located inside
the pH measuring transmitter
Mycom CPM 151-P.
3. Installation airtrol CPC 200 / 210
6

PC200W77.EPS
Connecting cable
to operating unit
CPC 200
pH electrode
connection
Retractable pH assembly
e. g. Probfit CPA 463-A
Connecting lines
(multiple hose)
Compressed air supply (4 to 6 bar)
Buffer 1 Buffer 2 Cleaner
Terminal X2
Water supply (4 to 6 bar)
Pneumatic feed pumps
(delivery volume fixed in the factory)
➡
Adjuster for pressure reduction
Pressure monitoring air
Pressure monitoring water
Fig. 3.4: Pneumatic unit
CPC 210 (open)
Note:
➡The delivery volume adjustments
for buffer solutions 1 and 2 and
cleaning solution must not be
changed.
BE1PC200.CHP
airtrol CPC 200 / 210 3. Installation
7

3.3 Pneumatic connection
Note:
•Please read chapters 3.2 and 3.4
of the Probfit operating instructions
before connecting the pneumatic
unit CPC 210 to the retractable
assembly Probfit.
•The distance between the pneumatic unit
CPC 210 and the retractable assembly
Probfit must not exceed 5 m.
Fig. 3.5: Pneumatic connection
diagram
left: Connection to
retractable pH assembly
right: Connection to
pneumatic unit
Airtrol CPC 210
5 Pneumatic feedback signal:
Electrode in measuring position
3 Control signal (continuous signal):
Electrode in service position
6 Pneumatic feedback signal:
Electrode in service position
2 Control signal (continuous signal):
Electrode in measuring position
➡
➭
➳
➺
➱
➑
♥
❺
❿
❿
❺
♥
➑➱
➺
➳
➭➡
PC200W09.EPS
Closure
Multiple
hose coupling
Protective hose
Pneumatic
hoses
Fig. 3.6: Pneumatic connecting line
for connection of Probfit
to pneumatic unit
Airtrol CPC 210
Rinse water
1
Rinse air
Cleaner
Buffer 2
Buffer 1
Airtrol
CPC 210
Feedback
measuring
Assembly
service
Feedback
service
Assembly
measuring
5
3
6
2
4
7
8
9
PNEU_210.EPS
5
2
6
3
PA463ST1.EPS
Probfit CPA 463S-A
5
3
6
2
PNEU463N.EPS
Connection block
Probfit CPA 463-A
3. Installation airtrol CPC 200 / 210
8

3.3.1 Flow diagram
PLAN.EPS
1 Rinse water
2 Assembly to measuring position
3 Assembly to service position
4 Rinse air
5 Feedback limit position measuring
6 Feedback limit position service
7 Cleaner
8 Buffer 2
9 Buffer 1
Buffer 1 Buffer 2 Cleaner
6Y4 Buffer pump 1
6Y5 Buffer pump 2
Compressed air monitoring
PLC
6Y1 Measuring
6Y2 Service
6Y6 Cleaner pump
Water pressure monitoring
Pump 1
Compressed air
6Y3
Rinse air valve
Pump 2
6Y7
Water valve
Pump 3
Rinse water
Multiple hose coupling
Fig. 3.7:
Flow diagram for the
pneumatic unit CPC 210
BE1PC200.CHP
airtrol CPC 200 / 210 3. Installation
9

3.4 Compressed air
connection
The compressed air is supplied via an
ID4 / OD6 hose (4 mm inside diameter,
6 mm outside diameter).
The compressed air is to be supplied to the
pneumatic unit CPC 210 via a line with a large
diameter.
•Air quality: filtered (5 µm),
water and oil-free
•Air pressure: 4 to 6 bar
•Air flow
requirement: max. 20 l/min
Note:
•Compressed air pressures below
4 bar produce the error message
“Air pressure too low”.
•Please note the applicable
regulations for accident prevention
and safety for compressed air
systems.
•We recommend installing a
stopcock close to the
compressed air connection.
3.5 Water connection
Screw-type couplings (SERTO system) are
used for the water connections (both hoses
and pipes with an inside diameter of 4 mm
and an outside diameter of 6 mm).
•Water quality: city water,
free of solid particles
•Water pressure: 4 to 6 bar
Note:
•Water pressures below 4 bar
will produce the error message
“Water pressure too low”.
•We recommend installing a
stopcock close to the water
connection.
3.6 Buffer and cleaner
solutions
The suction lines for the buffer and cleaning
solutions go through the cabinet floor directly
into the buffer and cleaner solution bottles
screwed onto the cabinet.
The suction hoses can be extended if larger
buffer and cleaning solution containers are to
be used.
The suction height of the pumps is max. 1.5 m.
Warning:
Mechanical shocks on the buffer
and cleaner solution bottles or
horizontal position of the cabinet
may cause penetration of fluid.
3.7 Connection to
retractable pH assembly
•Connect the pneumatic hoses 1 to 9 to the
retractable pH assembly Probfit CPA in
accordance with the pneumatic connection
diagram (see fig. 3.5).
Also refer to the operating instructions for
the retractable pH assembly.
•The connections for rinse air, buffer, cleaning
agent and rinse water are connected on the
assembly.
•Plug in the multiple hose coupling when
connecting the pneumatic unit CPC 210
and lock the closure in the “Lock” position.
3. Installation airtrol CPC 200 / 210
10

4. Electrical connection
4.1 Basics for connection
Caution:
•The unit must be grounded before
start-up!
•If faults cannot be remedied, the
unit must be removed from service
and secured to prevent accidental
start-up.
•Before carrying out any installation
or maintenance work, the system
is to be shut down and the pressure
in the hoses is to be released, i. e.
set the main switch to OFF and
shut off the media (caution: hoses
may contain cleaner solution!).
Warning:
•The notes and warnings in these
operating instructions must be
strictly adhered to!
•Maintenance work may only be
carried out by qualified personnel
if the unit remains energised!
•Local power supply company
regulations are to be observed!
•Use conductor cross sections in
accordance with VDE 0100!
•Retighten all screw terminals
before starting up the system!
Note:
•This system has been built
and tested in accordance with
VDE 0660 T500 and left the
manufacturer’s works in perfect
condition.
•Any faults in the system may be
remedied with the aid of the error
list in chapter 7.1.
•Interventions in or changes to the
system are impermissible and will
void the warranty.
•After installing and connecting the
system and assemblies, the entire
system should be checked for
proper function.
4.2 Connection diagram
CPC 200 / 210 and
external connections
Refer to the nameplate for the mains power
requirements.
The internal supply voltage of the Airtrol
is 24 V DC.
BE2PC200.CHP
airtrol CPC 200 / 210 4. Electrical connection
11

Operating unit CPC 200
Pneumatic unit CPC 210
Supply
unit
24 V +
Cleaning
Mains connection
7K1
7K2
7K3
Status contact 7K1 (function)
Status contact 7K2 (maintenance)
Status contact 7K3 (trouble)
L (+)
N (–)
PE
Control contact 7K4 for
external cleaning system
24 V DC +
Measuring position
Service position
Air pressure
Water pressure
Assembly in meas. pos.
Assembly in service pos.
Rinse air valve
Buffer pump 1 valve
Buffer pump 2 valve
Cleaner pump valve
Water valve
24 V DC –
Mycom CPM 151-P
pH signal output 0 / 4 … 20 mA
HOLD input
Temperature
sensor Pt 100
pH input
Error signalling contact
(closed circuit connection)
Limit 2, pH
To retractable
pH assembly
J
PC200W14.EPS
PM / PMC
Ref.
pH
Limit 1, pH
HQSS
Autocal
+24 V
7K4
Start cleaning
Start HQSS
Start autocal
PE
External
start inputs
7K5 Control contact 7K5 for
sterilization
PE
Fig. 4.1: Connection diagram for
Airtrol CPC 200 / 210,
Mycom CPM 151-P and
retractable pH assembly
4. Electrical connection airtrol CPC 200 / 210
12

4.3 Connection of
CPC 200 to CPC 210
The operating unit CPC 200 is connected to
the pneumatic unit CPC 210 by means of a
14-wire cable.
4.3.1 Connection type selection
for pH transmitter
Mycom CPM 151-P
•When a retractable Probfit assembly
made of PVC or PVDF material is used,
the asymmetrical high-impedance type
of connection must be chosen on the
measuring transmitter.
•When a retractable Probfit assembly made
of 1.4571 material is used, the symmetrical
high-impedance type of connection must be
chosen on the measuring transmitter and an
additional connected potential matching.
Note:
Please note the separate operating
instructions for the pH measuring
transmitter Mycom CPM 151-P and
the retractable pH assembly Probfit.
4.4 Connective networking
of several systems
via Profibus
A maximum of 10 systems, each comprising
one control unit CPC 200 and one pneumatic
unit CPC 210, can be connected via Profibus.
Shielded twisted-pair bus cable is used for
bus system wiring (for properties see table in
chapter 9). The bus connectors are installed
in the PLC at the factory.
Procedure
•Route and split the bus cable as required.
•Connect the bus cable.
•Enable the terminating resistor on the first
and last stations by switching it to the “ON”
position.
•Plug in the bus connectors.
Bus cable connection
•Strip the wires according to fig. 4.2.
•Connect the bus cable.
Always connect through
A – A – A … and
B – B – B …
•Connect the bare screen to the metal guide.
OFFON ON
Bus connector
6ES5762-1AA12 Bus connector 6ES5762-1AA12 Bus connector 6ES5762-1AA12
PC200X3.EPS
Bild 4.2: Bus cable connection
diagram
BE2PC200.CHP
airtrol CPC 200 / 210 4. Electrical connection
13

Note:
Do not twist, stretch or pinch the
cables during routing.
Warning:
When routing lines outside buildings,
the applicable lightning protection
and grounding measures must be
taken.
•Lines outside buildings are to be run
– in metal pipes grounded on both
sides, or
– in concrete armouring
•Signal lines are to be protected
against overvoltage by
– varistors, or
– inert gas-filled lightning arresters
•Install these protective devices
where the cable enters the building.
approx. 6 mm
approx. 12 mm
approx.
12 mm
Cable screen
PC200X2.TIF
Fig. 4.3: Bus cable stripping
(left)
Fig. 4.4: Bus cable connection
(right) in opened connector
PC200X4.TIF
Switch position “OFF”
(terminating resistor disabled)
Bare screen
must contact
metal guide
4. Electrical connection airtrol CPC 200 / 210
14

5. Start-up
5.1 General
Note:
•The applicable regulations for
safety and accident prevention
must be observed.
•Prior to power-up, verify that the
mains ratings match the ratings
on the nameplate.
•Make sure the media – air and
water – are available (stopcocks
open).
•The electrode must be installed in
the assembly, and the measuring
cable must be connected.
•The hoses for air and liquid media
must be connected to the assembly.
•The multiple hose coupling in the
pneumatic connecting line must
be in the “LOCK” position.
•The bottles are filled with the buffer
solutions and cleaning agent.
•Switch on the PLC:
The switch must be set to “RUN”
(LED RUN is on).
Warning:
•Prior to performing installation or
repair work, release air and water
pressure from system sections.
•Do not perform installation or
maintenance work while the
system is energised.
•Please be aware that the hoses
may contain caustic cleaner
solutions.
5.2 Start-up sequence
Note:
•The following steps must be taken
before starting up the Airtrol.
•Refer to chapter 6 for a detailed
listing of the parameter setting
steps.
•Refer to the following tables for a
listing of the factory settings.
BE2PC200.CHP
airtrol CPC 200 / 210 5. Start-up
15

Start-up sequence
Step 1:
Settings on Airtrol system
Set main switch to “ON”. The operating panel goes through a start-up
routine.
Afterwards, the operating display is shown
according to fig. 6.2.
Note:
The version number displayed during the
start-up sequence is an internal variable of
the operating unit which is independent,
however, of the Airtrol version number.
Step 2:
Settings on pH measuring transmitter Mycom CPM 151-P
(see chapter 8 of operating instructions for Mycom CPM 151-P)
Unlocking the start-up level
(Matrix field V8 / H9: “Code 2222” + “Enter”)
For measurement and calibration
Matrix field Function Parameter settings
Factory User
V0 / H3
V0 / H4
V0 / H6
Toggle 0 / 4 … 20 mA
0=0…20mA
1=4…20mA
pH at 0 / 4 mA
pH at 20 mA
1
2.00
12.00
V1 / H3
V1 / H4
V1 / H5
V8 / H3
Determine the temperature
compensation:
automatic (1 = ATC) or
manual (0 = MTC)
Entry of reference temperature
for MTC
Determine the calibration type:
AUTOmatic (= 1)
Toggle the pH input
0 = symmetric
1 = asymmetric
(1 for use of assemblies without
potential matching pin)
1
25 °C
1
0
1
For limit function or control and alarm
V4 / H0 and V5 / H0
V4 / H1 and V5 / H1
V7 / H1
Determine the controller type
0 = controller OFF
1 = limit contacter
Control characteristic for
pulse-length or pulse-frequency
controller
Alarm delay time
1
30
Warning:
The interface parameters of the pH
transmitter must not be modified,
5. Start-up airtrol CPC 200 / 210
16

Note:
•When using external buffer and
cleaner solution containers, these
must not be placed more than
1.5 m below the pneumatic unit
CPC 210 in order for the pump to
deliver the fluid in question.
•The filling of buffer and cleaner solution
bottles must be acknowledged with the
following function keys:
+or +or
+
Step 3:
Settings via operating panel
(main menu: “PASSWORD”, “CONFIGURATION”)
Function description Value range Parameter settings Descriptio nin
chapter:
Factory User
Password
– Determination of passwords
– level 9 = complete
operation and configuration
– level 3 = complete
operation with calibration
and configuration,
not, however,
password editing, service,
Profibus address and clock
– level 1 = menu item
“language / contrast”
of the main menu
levels 1, 3 and 9 2222
1111
(must be
entered by
Superuser!)
—
6.3.8
Buffers
– 2 values for buffer solution
– upper value
– lower value 0.00 to 14.00 pH 0.00 to 14.00 pH 7.00 4.00
6.3.5
Volumes
– Volume of bottle with
– buffer solution 1
– buffer solution 2
– cleaner solution
– Pump delivery volume for
– buffer pump 1
– buffer pump 2
– cleaner pump
– Typical volumes for the rinse
chambers:
– Probfit CPA 463
– Probfit CPA 463S
– Probfit CPA 465
– 1 m hose with 6 mm inside
diameter
0.3 to 20.0 l
0.3 to 20.0 l
0.3 to 20.0 l
10 to 70 ml
10 to 70 ml
10 to 70 ml
30 ml
25 ml
30 ml
13 ml
1.0
1.0
1.0
30
30
30
—
—
—
—
6.3.6
BE2PC200.CHP
airtrol CPC 200 / 210 5. Start-up
17

Start-up sequence
Step 3:
Settings via operating panel
Function description Value range Parameter settings Descriptio nin
chapter:
Factory User
Times
– Cleaning
– stand by time until rinse t0
– rinse time t1
– soak time for cleaner t2
– rinse after cleaner t3
– 8 start times
– weekday
– enable
(activation of start time)
– HQSS (quick test)
– 4 start times
– weekday
– enable
– time for measured value
stabilization t9
– Autocal
– 4 start times
– weekday
– enable
– Sterilization
– sterilization time t5
– Interval mode
– stand by time t4
– measuring time t6
– General
– air rinse time t7
(blowing out of pH
measuring chamber;
for HQSS and autocal)
– time for external
cleaning t8
(for cleaning, HQSS
and autocal)
– rinse time after buffer t10
(for HQSS and autocal)
– current output
delay time t11
(When the pH assembly
has returned to the
measuring position after
HQSS or autocal, the
current output stays on
“HOLD” for the duration
of the delay time.)
0 to 999 s
0 to 999 s
0 to 999 s
0 to 999 s
00:00 to 23:59 hours
0 = daily
1 to 7 = Mon to Sun
0=OFF,1=ON
00:00 to 23:59 hours
0 = daily
1 to 7 = Mon to Sun
0=OFF,1=ON
10 to 999 s
00:00 to 23:59 hours
0 = daily
1 to 7 = Mon to Sun
0=OFF,1=ON
0 to 99 min
0 to 999 min
0 to 999 min
5 to 999 s
0 to 999 s
1 to 999 s
1 to 999 s
5
5
10
5
—
0
0
—
0
0
30
—
0
0
0
10
2
5
0
1
1
6.3.3
5. Start-up airtrol CPC 200 / 210
18

Step 3:
Settings via operating panel
Function description Value range Parameter settings Descriptio nin
chapter:
Factory User
Limits
– Alarm
– pH: upper limit
lower limit
– temp.: upper limit
lower limit
– Calibration
– slope: upper level
lower level
– zero point: upper level
lower level
– 2 pH windows for HQSS
– window 1: upper limit
lower limit
– window 2: upper limit
lower limit
0.00 to 14.00 pH
0.00 to 14.00 pH
–15.0 to +150.0 °C
–15.0 to +150.0 °C
65.0 to 110.0%
65.0 to 110.0%
5.50 to 9.50 pH
5.50 to 9.50 pH
0.00 to 14.00 pH
0.00 to 14.00 pH
0.00 to 14.00 pH
0.00 to 14.00 pH
10.00
2.00
50.0
0.0
110.0
65.0
9.50
5.50
7.50
6.50
4.50
3.50
6.3.2
Cleaning
– Number of cleaning cycles
for cleaning, HQSS and
autocal
– Toggle between internal and
external cleaning system 1
– Switch on back-pressure
water 2
1to9
0 = internal
1 = external
0 = OFF, 1 = ON
1
0
0
6.3.4
PLC clock
– Date
– Time
– Weekday
01.01.00 to 31.12.99
00:00 to 23:59 hours
1 to 7 = Mon to Sun
—
—
—
6.3.7
Remark:
1Toggle cleaning system
0 = Internal cleaning system
1 = External cleaning system
2Switch on back-pressure water
When the pH electrode is retracted
or moved into the process, a
short-time overlap between process
and outlet occurs with some
retractable assemblies, e. g. Probfit
CPA 463. To prevent intrusion of
fibrous or abrasive media into the
seal and rinse area of the assembly,
back-pressure water can be
switched on when the assembly is
retracted or moved into the process.
An additional outlet valve
(accessory for the assembly)
ensures that the back-pressure
does not escape through the outlet.
Note:
The back-pressure must exceed the
process pressure.
BE2PC200.CHP
airtrol CPC 200 / 210 5. Start-up
19
