Endress+Hauser Cerabar S PMC71 Manual

Pressure transmitter with ceramic and
metal sensors
Applications
The device is used for the following measuring tasks:
• Absolute pressure and gauge pressure measurement in gases, steams or liquids in
all areas of process engineering and process measurement technology
• Level, volume or mass measurements in liquids
• High process temperatures
– up to 150 °C (302 °F) without diaphragm seal
– up to 400 °C (752 °F) with typical diaphragm seals
• High pressures up to 700 bar (10 500 psi)
• MID part certificate according to OIML R117-1 Edition 2007 (E) and EN
12405-1/A1 Edition 2006
Your benefits
• Very good reproducibility and long-term stability
• High reference accuracy up to ±0.025 %
• Turn down up to 100:1, higher on request
• Used for process pressure monitoring up to SIL 3, certified to IEC 61508 by TÜV
SÜD
• High level of safety during operation thanks to function monitoring from the
measuring cell to the electronics
• The patented TempC membrane for the diaphragm seal reduces measured errors
caused by environmental and process temperature influences to a minimum
• Easy electronic replacement guaranteed with HistoROM®/M-DAT
• Uniform platform for differential pressure, hydrostatics and pressure (Deltabar S –
Deltapilot S – Cerabar S)
• Practical user navigation for quick and easy commissioning
• Extensive diagnostic functions
Products Solutions Services
Technical Information
Cerabar S
PMC71, PMP71, PMP75
Process pressure measurement
TI00383P/00/EN/28.17
71351628

Cerabar S PMC71, PMP71, PMP75
2 Endress+Hauser
Table of contents
Document information ....................... 4
Document function ............................ 4
Symbols used ................................ 4
Documentation ............................... 5
Terms and abbreviations ........................ 6
Turn down calculation .......................... 7
Registered trademarks .......................... 7
Function and system design ................... 8
Device features ............................... 8
Measuring principle ............................ 9
Product design .............................. 10
Applications suitable for custody transfer measurement ... 10
Communication protocol ........................ 11
Input .................................... 12
Measured variable ............................ 12
Measuring range ............................. 12
Output .................................. 15
Output Signal ............................... 15
Signal range 4 to 20 mA ........................ 15
Signal on alarm .............................. 15
Load ..................................... 15
Dead time, time constant ....................... 16
Dynamic behavior, current output .................. 17
Dynamic behavior Digital output(HART electronics) ...... 17
Dynamic behavior PROFIBUS PA .................. 17
Dynamic behavior FOUNDATION Fieldbus ............ 18
Damping .................................. 18
Alarm current ............................... 18
Firmware version ............................ 18
HART protocol-specific data ..................... 19
PROFIBUS PA protocol-specific data ................ 19
FOUNDATION Fieldbus protocol-specific data .......... 20
Power supply ............................. 23
Terminal assignment .......................... 23
Supply voltage .............................. 24
Current consumption .......................... 24
Electrical connection .......................... 24
Terminals ................................. 24
Cable entries ............................... 25
Device plug ................................. 25
Cable specification ............................ 26
Startcurrent ................................ 26
Residual ripple .............................. 26
Overvoltage protection (optional) .................. 26
Influence of power supply ....................... 27
Performance characteristics of PMP71/PMP75
metal pressure transmitter
(Sensor module + Electronic module) ........... 28
Preamble .................................. 28
Total performance of transmitter .................. 28
Reference accuracy [E1] ........................ 28
Total performance – Specification values ............. 29
Long-term stability ........................... 29
Detailed Performance Explanation and Calculation ...... 30
Total error ................................. 31
Performance characteristics of PMC71 ceramic
pressure transmitter
(Sensor module + Electronic module) ........... 32
Preamble .................................. 32
Total performance of transmitter .................. 32
Reference accuracy [E1] ........................ 32
Total performance – Specification values ............. 33
Long-term stability ........................... 33
Detailed Performance Explanation and Calculation ...... 34
Total error ................................. 36
Performance characteristics - calculation
example and additional information ........... 37
Calculating the total performance in 4 steps ........... 37
Installation factors ............................ 40
Reference operating conditions ................... 40
Installation ............................... 41
General installation instructions ................... 41
Measuring arrangement for devices without diaphragm
seals – PMC71, PMP71 ........................ 41
Measuring arrangement for devices with diaphragm seals
– PMP75 .................................. 41
Orientation ................................ 41
Wall and pipe mounting, transmitter (optional) ........ 42
Wall and pipe mounting, valve manifold (optional) ...... 42
Heat insulation – PMC71 high-temperature version ..... 42
Mounting of PVDF screw-in fittings ................ 43
"Separate housing" version ....................... 44
Turning the housing .......................... 45
Oxygen applications ........................... 46
Silicone-free applications ....................... 46
Ultrapure gas applications ....................... 46
Applications with hydrogen ...................... 46
Environment .............................. 47
Ambient temperature range ..................... 47
Storage temperature range ...................... 47
Degree of protection .......................... 47
Climate class ............................... 47
Electromagnetic compatibility .................... 47
Vibration resistance ........................... 48
Process .................................. 49
Process temperature limits ...................... 49
Process temperature limits of capillary armoring: PMP75 .. 50
Pressure specifications ......................... 51
Mechanical construction .................... 52
Device height ............................... 52
T14 housing, optional display on the side ............ 53
T17 housing (hygienic), optional display on the side ..... 54

Cerabar S PMC71, PMP71, PMP75
Endress+Hauser 3
Process connections for PMC71 with internal process
isolating diaphragm ........................... 55
Process connections for PMC71 with internal process
isolating diaphragm ........................... 57
Process connections for PMC71 with internal process
isolating diaphragm - height H ................... 57
Process connections for PMC71 with flush-mounted
process isolating diaphragm ..................... 58
Process connections for PMC71 with flush-mounted
process isolating diaphragm ..................... 59
Process connections for PMC71 with flush-mounted
process isolating diaphragm - height H .............. 59
Process connections for PMC71 with flush-mounted
process isolating diaphragm ..................... 60
Hygienic process connections for PMC71 with flush-
mounted process isolating diaphragm ............... 63
Process connections for PMP71 with internal process
isolating diaphragm ........................... 65
Process connections for PMP71 with internal process
isolating diaphragm ........................... 66
Process connections for PMP71 with internal process
isolating diaphragm ........................... 67
Process connections for PMP71 with flush-mounted
process isolating diaphragm ..................... 68
Process connections for PMP71 with flush-mounted
process isolating diaphragm ..................... 70
Process connections for PMP71 with flush-mounted
process isolating diaphragm ..................... 71
Process connections for PMP71 with flush-mounted
process isolating diaphragm ..................... 72
Process connections for PMP71 with flush-mounted
process isolating diaphragm ..................... 73
Process connections for PMP71 ................... 74
Process connections for PMP71 ................... 74
Valve manifold DA63M (optional) ................. 75
PMP75 basic device ........................... 76
Process connections for PMP75 with flush-mounted
process isolating diaphragm ..................... 77
Process connections for PMP75 with flush-mounted
process isolating diaphragm ..................... 78
Process connections for PMP75 with flush-mounted
process isolating diaphragm ..................... 79
Process connections for PMP75 with flush-mounted
process isolating diaphragm ..................... 80
Hygienic process connections for PMP75 with flush-
mounted process isolating diaphragm ............... 81
Hygienic process connections for PMP75 with flush-
mounted process isolating diaphragm ............... 82
Hygienic process connections for PMP75 with flush-
mounted process isolating diaphragm ............... 84
Process connections for PMP75 with flush-mounted
process isolating diaphragm ..................... 86
Process connections for PMP75 with flush-mounted
process isolating diaphragm ..................... 88
Process connections for PMP75 ................... 91
Separate housing: Wall and pipe mounting with mounting
bracket ................................... 94
Materials not in contact with process ............... 95
Weight ................................... 98
Materials in contact with process .................. 98
Fill fluid .................................. 100
Operability .............................. 101
Operating concept ........................... 101
Local operation ............................. 101
Remote operation ........................... 104
HistoROM®/M-DAT (optional) .................. 105
System integration ........................... 106
Planning instructions, diaphragm seal systems .. 107
Applications ............................... 107
Design and operation mode ..................... 108
Diaphragm seal filling oils ...................... 109
Information on cleaning ....................... 110
Installation instructions ....................... 110
Vacuum applications ......................... 112
Certificates and approvals .................. 113
CE mark .................................. 113
RCM-Tick marking ........................... 113
Ex approvals ............................... 113
EAC conformity ............................. 113
Suitable for hygiene applications ................. 113
Functional safety SIL/ IEC 61508 Declaration of
Conformity (optional) ......................... 114
Overfill protection ........................... 114
CRN approval .............................. 114
Other standards and guidelines .................. 114
Pressure Equipment Directive 2014/68/EU (PED) ...... 115
Manufacturer declarations ..................... 116
Marine approval ............................ 116
Drinking water approval ....................... 116
Approvals for custody transfer ................... 116
MID Parts Certificate ......................... 116
Classification of process sealing between electrical
systems and (flammable or combustible) process fluids in
accordance with ANSI/ISA 12.27.01 ............... 116
Inspection certificate ......................... 117
Calibration ................................ 117
Service .................................. 118
Ordering information ...................... 119
Scope of delivery ............................ 119
Configuration data sheet ....................... 119
Accessories .............................. 121
HistoROM®/M-DAT .......................... 121
Welding flanges and welding neck ................ 121
Manifolds ................................ 121
Additional mechanical accessories ................ 121
Supplementary documentation .............. 122
Field of Activities ............................ 122
Technical Information ........................ 122
Special Documentation ........................ 122
Operating Instructions ........................ 122
Brief Operating Instructions ..................... 122
Functional safety manual (SIL) ................... 122
Overfill protection ........................... 122
Safety Instructions (XA) ....................... 122
Installation/Control Drawings ................... 124

Cerabar S PMC71, PMP71, PMP75
4 Endress+Hauser
Document information
Document function The document contains all the technical data on the device and provides an overview of the
accessories and other products that can be ordered for the device.
Symbols used Safety symbols
Symbol Meaning
DANGER
DANGER!
This symbol alerts you to a dangerous situation. Failure to avoid this situation will result in
serious or fatal injury.
WARNING
WARNING!
This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in
serious or fatal injury.
CAUTION
CAUTION!
This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in
minor or medium injury.
NOTICE
NOTE!
This symbol contains information on procedures and other facts which do not result in
personal injury.
Electrical symbols
Symbol Meaning Symbol Meaning
Protective ground connection
A terminal which must be connected
to ground prior to establishing any
other connections.
Ground connection
A grounded terminal which, as far as
the operator is concerned, is
grounded via a grounding system.
Symbols for certain types of information
Symbol Meaning
Permitted
Procedures, processes or actions that are permitted.
Preferred
Procedures, processes or actions that are preferred.
Forbidden
Procedures, processes or actions that are forbidden.
Tip
Indicates additional information.
Reference to documentation
A
Reference to page
Reference to graphic
Visual inspection

Cerabar S PMC71, PMP71, PMP75
Endress+Hauser 5
Symbols in graphics
Symbol Meaning
1, 2, 3 ... Item numbers
,… ,
1. 2. 3.
Series of steps
A, B, C, ... Views
A-A, B-B, C-C, ... Sections
Documentation See the "Supplementary documentation" section →  122
The document types listed are available:
In the Download Area of the Endress+Hauser Internet site: www.endress.com → Download
Safety Instructions (XA)
See the "Safety instructions" section →  122

Cerabar S PMC71, PMP71, PMP75
6 Endress+Hauser
Terms and abbreviations
URL OPLMWP
LRL
0
p
LRV URV
1
2
3
4
A0029505
Item Term/abbreviation Explanation
1 OPL The OPL (over pressure limit = sensor overload limit) for the measuring device depends on the lowest-rated element,
with regard to pressure, of the selected components, i.e. the process connection has to be taken into consideration in
addition to the measuring cell. Also observe pressure-temperature dependency. For the relevant standards and
additional information, see the "Pressure specifications"→  51 section.
The OPL may only be applied for a limited period of time.
2 MWP The MWP (maximum working pressure) for the sensors depends on the lowest-rated element, with regard to
pressure, of the selected components, i.e. the process connection has to be taken into consideration in addition to the
measuring cell. Also observe pressure-temperature dependency. For the relevant standards and additional
information, see the "Pressure specifications"→  51 section.
The MWP may be applied at the device for an unlimited period.
The MWP can also be found on the nameplate.
3 Maximum sensor
measuring range
Span between LRL and URL
This sensor measuring range is equivalent to the maximum calibratable/adjustable span.
4 Calibrated/adjusted
span
Span between LRV and URV
Factory setting: 0 to URL
Other calibrated spans can be ordered as customized spans.
p - Pressure
- LRL Lower range limit
- URL Upper range limit
- LRV Lower range value
- URV Upper range value
- TD (turn down) Turn down
Example - see the following section.

Cerabar S PMC71, PMP71, PMP75
Endress+Hauser 7
Turn down calculation
LRV URLURV LRL
1 = 2 3
A0029545
1 Calibrated/adjusted span
2 Zero point-based span
3 URL sensor
Example
• Sensor:10 bar (150 psi)
• Upper range value (URL) = 10 bar (150 psi)
Turn down (TD):
• Calibrated/adjusted span: 0 to 5 bar (0 to 75 psi)
• Lower range value (LRV) = 0 bar (0 psi)
• Upper range value (URV) = 5 bar (75 psi)
TD = URL
|URV - LRV|
TD = 10 bar (150 psi) = 2
|5 bar (75 psi) - 0 bar (0 psi)|
In this example, the TD is 2:1.
This span is based on the zero point.
Registered trademarks HART®
Registered trademark of the FieldComm Group, Austin, USA
PROFIBUS®
Registered trademark of the PROFIBUS User Organization, Karlsruhe, Germany
FOUNDATIONTMFieldbus
Registered trademark of the FieldComm Group, Austin, Texas, USA

Cerabar S PMC71, PMP71, PMP75
8 Endress+Hauser
Function and system design
Device features
PMC71 PMP71 PMP75
A0020461 A0020463
A0020464
With capacitance measuring cell and
ceramic process isolating diaphragm
(Ceraphire®)
With piezoresistive measuring cell and
metallic welded process isolating
diaphragm
With diaphragm seal
Field of
application
• Gauge pressure and absolute pressure
• Level
Process
connections
• Diverse thread
• DN 25 – DN 80
• ASME 1 ½" – 4"
• JIS 50 A – 100 A
• Diverse thread
• DN 25 – DN 80
• ASME 1 ½" – 4"
• JIS 25 A – 100 A
• Oval flange adapter
• Prepared for diaphragm seal mount
Wide range of diaphragm seals
Measuring
ranges
from –100/0 to 100 mbar (–1.5/0 to 1.5
psi)
to –1/0 to 40 bar (–15/0 to 600 psi)
from –400/0 to 400 mbar (–6/0 to 6 psi)
to –1/0 to 700 bar (–15/0 to 10500 psi)
from –400/0 to 400 mbar (–6/0 to 6 psi)
to –1/0 to 400 bar (–15/0 to 6000 psi)
OPL max. 60 bar (900 psi) max. 1 050 bar (15 750 psi) max. 600 bar (9 000 psi)
Process
temperature
range 1)
–25 to +125 °C (–13 to +257 °F)/
–20 to +150 °C (–4 to +302 °F) 2) –40 to +125 °C (–40 to +257 °F) –70 to +400 °C (–94 to +752 °F) (depends on filling oil)
Ambient
temperature
range
• Without LCD display: –40 to +85 °C (–40 to +185 °F) 3)
• With LCD display: –20 to +70 °C (–4 to +158 °F)
• Separate housing: –20 to +60 °C (–4 to +140 °F)
• Diaphragm seal systems depending on the version
Reference
accuracy
• Up to ±0.05 % of the set span
• PLATINUM version: up to ±0.025 % of the set span
Up to ±0.075 % of the set span
Supply voltage
non-Ex
• 4 to 20 mA HART: 10.5 to 45 V DC
• PROFIBUS PA and FOUNDATION Fieldbus: 9 to 32 V DC
Supply voltage
Ex ia
10.5 to 30 V DC
Output 4 to 20 mA with superimposed HART protocol, PROFIBUS PA or FOUNDATION Fieldbus
Options • Gold-rhodium coated process isolating diaphragm
• NACE-compliant materials
• Inspection certificate 3.1
• HistoROM®/M-DAT memory chip
• Separate housing
Specialties • Metal-free measurement with PVDF
connection
• Special cleaning of the transmitter to
remove paint-wetting substances, for
use in paint shops
• Process connections with minimum oil
volume
• Gas-tight, elastomer-free
• Wide range of diaphragm seals
• For high media temperatures
• Process connections with minimum oil
volume
• Completely welded versions
1) (temperature at process connection)
2) High-temperature version, see Product Configurator "Additional option 1" or 110 "Additional option 2" section, option "T"
3) PMP71 and PMP75: lower temperatures on request

Cerabar S PMC71, PMP71, PMP75
Endress+Hauser 9
Measuring principle Devices with ceramic process isolating diaphragm (Ceraphire®)
1234
p
A0020465
1 Air pressure (relative pressure sensors)
2 Ceramic substrate
3 Electrodes
4 Ceramic process isolating diaphragm
The ceramic sensor is an oil-free sensor, i.e. the process pressure acts directly on the robust ceramic
process isolating diaphragm and causes it to deflect. A pressure-dependent change in capacitance is
measured at the electrodes of the ceramic substrate and the process isolating diaphragm. The
measuring range is determined by the thickness of the ceramic process isolating diaphragm.
Advantages:
• Guaranteed overload resistance up to 40 times the nominal pressure (see "OPL" column in table)
→  12)
• The ultrapure 99.9% ceramic (Ceraphire®, see also "www.endress.com/ceraphire") ensures:
– Extremely high chemical durability
– High mechanical durability
• Suitable for vacuums
• Secondary containment for enhanced integrity
• Process temperatures up to 150 °C (302 °F)
Devices with metallic process isolating diaphragm
p
1
3
4
2
A0016448
1 Silicon measuring element, substrate
2 Wheatstone bridge
3 Channel with fill fluid
4 Metal process isolating diaphragm
PMP71
The process pressure deflects the metal process isolating diaphragm of the sensor and a fill fluid
transfers the pressure to a Wheatstone bridge (semiconductor technology). The pressure-dependent
change in the bridge output voltage is measured and evaluated.

Cerabar S PMC71, PMP71, PMP75
10 Endress+Hauser
Advantages:
• Can be used for process pressures up to 700 bar (10 500 psi)
• High long-term stability
• Guaranteed overload resistance up to 4 times the nominal pressure
• Secondary containment for enhanced integrity
• Significantly reduced thermal effect e.g. compared to diaphragm seal systems with capillaries
PMP75
The operating pressure acts on the process isolating diaphragm of the diaphragm seal and is
transferred to the process isolating diaphragm of the sensor by a diaphragm seal fill fluid. The
process isolating diaphragm is deflected and a fill fluid transfers the pressure to a resistance
measuring bridge. The pressure-dependent change in the bridge output voltage is measured and
evaluated.
Advantages:
• Depending on the version, can be used for process pressures up to 400 bar (6 000 psi) and for
extreme process temperatures
• High long-term stability
• Guaranteed overload resistance up to 4 times the nominal pressure
• Secondary containment for enhanced integrity
Product design Level measurement (level, volume and mass):
h = p
ρg
h
A0020466
h Height (level)
p Pressure
ρ Density of the medium
g Gravitational constant
Your benefits
• Selection of the level operating mode which is optimum for your application in the device software
• Volume and mass measurements in any container shapes by means of a freely programmable
characteristic curve
• Choice of diverse level units with automatic unit conversion
• A customized unit can be specified.
• Has a wide range of uses, e.g.
– in the event of foam formation
– in containers with agitators or screen fittings
– in the event of liquid gases
Applications suitable for
custody transfer
measurement
The Parts Certificate is issued on the basis of the following standards:
• WELMEC guide 8.8 "General and Administrative Aspects of the Voluntary System of Modular
Evaluation of Measuring instruments under the MID".
• OIML R117-1 Edition 2007 (E) "Dynamic measuring systems for liquids other than water".
• EN 12405-1/A1 Edition 2006 "Gas meters – Conversion devices – Part 1: Volume conversion".

Cerabar S PMC71, PMP71, PMP75
Endress+Hauser 11
Communication protocol • 4 to 20 mA with HART communication protocol
• PROFIBUS PA
– The Endress+Hauser devices meet the requirements of the FISCO model.
– Due to a low current consumption of 13 mA ± 1 mA, the following number of devices can be
operated on one bus segment if installing as per FISCO: up to 7 devices for Ex ia, CSA IS and FM
IS applications or up to 27 devices for all other applications e.g. in non-hazardous areas, Ex nA
etc. Further information on PROFIBUS PA can be found in Operating Instructions BA00034S
"PROFIBUS DP/PA: Guidelines for planning and commissioning" and in the PNO Guideline.
• FOUNDATION Fieldbus
– The Endress+Hauser devices meet the requirements of the FISCO model.
– Due to a low current consumption of 15.5 mA ± 1 mA, the following number of devices can be
operated on one bus segment if installing as per FISCO: up to 6 devices for Ex ia, CSA IS and FM
IS applications or up to 24 devices for all other applications e.g. in non-hazardous areas, Ex nA
etc. Further information on FOUNDATION Fieldbus, such as requirements for bus system
components, can be found in Operating Instructions BA00013S "FOUNDATION Fieldbus
Overview".

Cerabar S PMC71, PMP71, PMP75
12 Endress+Hauser
Input
Measured variable Measured process variables
• Absolute pressure
• Gauge pressure
Calculated process variables
Level (level, volume or mass)
Measuring range PMC71 – with ceramic process isolating diaphragm (Ceraphire®) for gauge pressure
Nominal value Range limit Lowest
calibratable
Span 1)
MWP OPL Vacuum resistance Option 2)
lower (LRL) upper (URL)
[bar (psi)] [bar (psi)] [bar (psi)] [bar (psi)] [bar (psi)] [barabs (psiabs)]
100 mbar (1.5 psi) –0.1 (–1.5) +0.1 (+1.5) 0.005 (0.075) 2.7 (40.5) 4 (60) 0.7 (10.5) 1C
250 mbar (3.75 psi) –0.25 (–4) +0.25 (+4) 0.005 (0.075) 3.3 (49.5) 5 (75) 0.5 (7.5) 1E
400 mbar (6 psi) –0.4 (–6) +0.4 (+6) 0.005 (0.075) 5.3 (79.5) 8 (120) 0 1F
1 bar (15 psi) –1 (–15) +1 (+15) 0.01 (0.15) 6.7 (100.5) 10 (150) 0 1H
2 bar (30 psi) –1 (–15) +2 (+30) 0.02 (0.3) 12 (180) 18 (270) 0 1K
4 bar (60 psi) –1 (–15) +4 (+60) 0.04 (0.6) 16.7 (250.5) 25 (375) 0 1M
10 bar (150 psi) –1 (–15) +10 (+150) 0.1 (1.5) 26.7 (400.5) 40 (600) 0 1P
40 bar (600 psi) –1 (–15) +40 (+600) 0.4 (6) 40 (600) 60 (900) 0 1S
1) Turndown > 100:1 on request or can be set on device
2) Product Configurator, order code for "Sensor range; sensor over pressure limit"
PMC71 – with ceramic process isolating diaphragm (Ceraphire®) for absolute pressure
Nominal value Range limit Lowest
calibratable
Span 1)
MWP OPL Vacuum resistance Option 2)
lower (LRL) upper (URL)
[barabs (psiabs)] [barabs (psiabs)] [bar (psi)] [barabs (psiabs)] [barabs (psiabs)] [barabs (psiabs)]
100 mbar (1.5 psi) 0 +0.1 (+1.5) 0.005 (0.075) 2.7 (40.5) 4 (60) 0 2C
250 mbar (3.75 psi) 0 +0.25 (+4) 0.005 (0.075) 3.3 (49.5) 5 (75) 0 2E
400 mbar (6 psi) 0 +0.4 (+6) 0.005 (0.075) 5.3 (79.5) 8 (120) 0 2F
1 bar (15 psi) 0 +1 (+15) 0.01 (0.15) 6.7 (100.5) 10 (150) 0 2H
2 bar (30 psi) 0 +2 (+30) 0.02 (0.3) 12 (180) 18 (270) 0 2K
4 bar (60 psi) 0 +4 (+60) 0.04 (0.6) 16.7 (250.5) 25 (375) 0 2M
10 bar (150 psi) 0 +10 (+150) 0.1 (1.5) 26.7 (400.5) 40 (600) 0 2P
40 bar (600 psi) 0 +40 (+600) 0.4 (6) 40 (600) 60 (900) 0 2S
1) Turndown > 100:1 on request or can be set on device
2) Product Configurator, order code for "Sensor range; sensor over pressure limit"

Cerabar S PMC71, PMP71, PMP75
Endress+Hauser 13
PMP71 and PMP75 – metallic process isolating diaphragm for gauge pressure
Nominal value Range limit Lowest
calibratable
Span 1)
MWP OPL Vacuum resistance 2) Option 3)
lower (LRL) upper (URL) Silicone oil/
Inert oil
[bar (psi)] [bar (psi)] [bar (psi)] [bar (psi)] [bar (psi)] [barabs (psiabs)]
400 mbar (6 psi) –0.4 (–6) +0.4 (+6) 0.005 (0.075) 4 (60) 6 (90)
0.01/0.04 (0.15/0.6)
1F
1 bar (15 psi) –1 (–15) +1 (+15) 0.01 (0.15) 6.7 (100) 10 (150) 1H
2 bar (30 psi) –1 (–15) +2 (+30) 0.02 (0.3) 13.3 (200) 20 (300) 1K
4 bar (60 psi) –1 (–15) +4 (+60) 0.04 (0.6) 18.7 (280.5) 28 (420) 1M
10 bar (150 psi) –1 (–15) +10 (+150) 0.1 (1.5) 26.7 (400.5) 40 (600) 1P
40 bar (600 psi) –1 (–15) +40 (+600) 0.4 (6) 100 (1500) 160 (2400) 1S
100 bar (1 500 psi) –1 (–15) +100 (+1500) 1.0 (15) 100 (1500) 400 (6000) 1U
400 bar (6 000 psi) –1 (–15) +400 (+6000) 4.0 (60) 400 (6000) 600 (9000) 1W
700 bar (10 500 psi) 4) –1 (–15) +700 (+10500) 7.0 (105) 700 (10500) 1050 (15750) 1X
1) Turndown > 100:1 on request or can be set on device
2) The vacuum resistance applies to the measuring cell under reference operating conditions. In the case of the PMP75, the pressure and
temperature application limits of the selected filling oil must also be observed →  109.
3) Product Configurator, order code for "Sensor range; sensor over pressure limit"
4) PMP71 only, PMP75 on request
PMP71 and PMP75 – metallic process isolating diaphragm for absolute pressure
Nominal value Range limit Lowest
calibratable
Span 1)
MWP OPL Vacuum resistance 2) Option 3)
lower (LRL) upper (URL) Silicone oil/
Inert oil
[barabs (psiabs)] [barabs (psiabs)] [bar (psi)] [barabs (psiabs)] [barabs (psiabs)] [barabs (psiabs)]
400 mbar (6 psi) 0 +0.4 (+6) 0.005 (0.075) 4 (60) 6 (90)
0.01/0.04 (0.15/0.6)
2F
1 bar (15 psi) 0 +1 (+15) 0.01 (0.15) 6.7 (100) 10 (150) 2H
2 bar (30 psi) 0 +2 (+30) 0.02 (0.3) 13.3 (200) 20 (300) 2K
4 bar (60 psi) 0 +4 (+60) 0.04 (0.6) 18.7 (280.5) 28 (420) 2M
10 bar (150 psi) 0 +10 (+150) 0.1 (1.5) 26.7 (400.5) 40 (600) 2P
40 bar (600 psi) 0 +40 (+600) 0.4 (6) 100 (1500) 160 (2400) 2S
100 bar (1 500 psi) 0 +100 (+1500) 1.0 (15) 100 (1500) 400 (6000) 2U
400 bar (6 000 psi) 0 +400 (+6000) 4.0 (60) 400 (6000) 600 (9000) 2W
700 bar (10 500 psi) 4) 0 +700 (+10500) 7.0 (105) 700 (10500) 1050 (15750) 2X
1) Turndown > 100:1 on request or can be set on device
2) The vacuum resistance applies to the measuring cell under reference operating conditions. In the case of the PMP75, the pressure and
temperature application limits of the selected filling oil must also be observed →  109.
3) Product Configurator, order code for "Sensor range; sensor over pressure limit"
4) PMP71 only, PMP75 on request

Cerabar S PMC71, PMP71, PMP75
14 Endress+Hauser
PMP71 - metallic process isolating diaphragms for absolute pressure with MID parts certificate
Nominal
value
Range limit Min. WP for gas
applications suitable
for custody transfer
measurement
Min. WP for liquid
applications suitable
for custody transfer
measurement
MWP OPL Vacuum
resistance 1) Option 2)
lower
(LRL) 3) upper (URL) 4) Silicone oil/ Inert oil
[bar (psi)] [barabs
(psiabs)]
[barabs
(psiabs)]
[bar (psi)] [bar (psi)] [barabs
(psiabs)]
[barabs
(psiabs)]
[bar (psi)]
10 (150) 0 +10 (150) 0.5 (7.5) 0.5 (7.5) 26.7
(400.5)
40 (600) 0.01/0.04
(0.15/1)
MP
50 (750) 0 +50 (750) 10 (150) 2.5 (37.5) 100
(1500)
400
(6000)
0.01/0.04
(0.15/1)
MT
100 (1500) 0 +100
(1500)
5 (75) 5 (75) 100
(1500)
400
(6000)
0.01/0.04
(0.15/1)
MU
1) The vacuum resistance applies to the measuring cell under reference operating conditions
2) Product Configurator, order code for "Sensor range; sensor over pressure limit"
3) By default, the device is set to a lower range limit of 0 bar. Please specify in the order if the lower range limit is to be set to a different default
value.
4) Max. WP for gas and liquid applications suitable for custody transfer measurement

Cerabar S PMC71, PMP71, PMP75
Endress+Hauser 15
Output
Output Signal • 4 to 20 mA with superimposed digital communication protocol HART, 2-wire
• Digital communication signal PROFIBUS PA (Profile 3.0), 2-wire
– Signal coding: Manchester Bus Powered (MBP): Manchester II
– Transmission rate: 31.25 KBit/s voltage mode
• Digital communication signal FOUNDATION Fieldbus, 2-wire
– Signal coding: Manchester Bus Powered (MBP): Manchester II
– Transmission rate: 31.25 KBit/s voltage mode
Output Internal + LCD External + LCD Internal
on on
off off
damp. damp.
Display Display
Sensor Sensor
HART HAR T
R R
FIELDCOMMUNICATI ON PROTOCOL FIELDCOMMUNICATI ON PROTOCOL
SW /min SW /min
E
+
–
E
+
–
A0021280
Option 1)
4 to 20mA HART B A C
4 to 20mA HART, Li=0 E D F
PROFIBUS PA N M O
FOUNDATION Fieldbus Q P R
1) Product Configurator, order code for "Display, operation: "
Signal range 4 to 20 mA 3.8 mA to 20.5 mA
Signal on alarm 4 to 20 mA HART
As per NAMUR NE43.
• Max. alarm: can be set from 21 to 23 mA (factory setting: 22 mA)
• Hold measured value: last measured value is held
• Min. alarm: 3.6 mA
PROFIBUS PA
As per NAMUR NE43.
Can be set in the Analog Input Block.
Options:
• Last Valid Out Value (factory setting)
• Fail Safe Value
• Status bad
FOUNDATION Fieldbus
As per NAMUR NE43.
Can be set in the Analog Input Block.
Options:
• Last Good Value
• Fail Safe Value (factory setting)
• Wrong Value
Load 4 to 20 mA HART
In order to guarantee sufficient terminal voltage in two-wire devices, a maximum load resistance R
(including line resistance) must not be exceeded depending on the supply voltage U0 of the supply
unit. In the following load diagrams, observe the position of the jumper and the explosion protection:

Cerabar S PMC71, PMP71, PMP75
16 Endress+Hauser
U – 11.5 V
U – 12 V
23 mA
23 mA
[ ]W
[ ]W
30
30
20
20
11.5
12
40
40
45
45
1239
1217
1456
1434
804
782
369
347
Test
£
£
B
B
U – 10.5 V
U – 11 V
R
R
L
L
max
max
23 mA
23 mA
£
£
30
30
20
20
10.5
11
U
U
U
U
[V]
[V]
[V]
[V]
40
40
45
45
1282
1260
1500
1478
847
826
413
391
[ ]W
[ ]W
R
R
L
L
max
max
Test
4
4
A
A
1
2
3
1
2
3
R
R
L
L
max
max
4
4
R
R
L
L
max
max
A0020467
A Jumper for 4 to 20 mA test signal set to "Non-test" position
B Jumper for 4 to 20 mA test signal set to "Test" position
1 Power supply 10.5 (11.5) to 30 V DC for 1/2 G, 1 GD, 1/2 GD, FM IS, CSA IS, IECEx ia, NEPSI Ex ia
2 Power supply 10.5 (11.5) to 45 V DC for devices for non-hazardous areas, 1/2 D, 1/3 D, 2 G Ex d, 3 G Ex nA,
FM XP, FM DIP, FM NI, CSA XP, CSA dust ignition-proof, NEPSI Ex d
3 Power supply 11 (12) to 45 V DC for PMC71, Ex d[ia], NEPSI Ex d[ia]
4 RLmax maximum load resistance
U Supply voltage
When operating via a handheld terminal or via a PC with an operating program, a minimum
communication resistance of 250 Ω must be taken into account.
Dead time, time constant Presentation of the dead time and the time constant:
I
63 %
100 %
t
t1t2
90 %
t3
A0019786

Cerabar S PMC71, PMP71, PMP75
Endress+Hauser 17
Dynamic behavior,
current output
Type Measuring cell Dead time (t1) [ms] Time constant T63 (t2) [ms] Time constant T90 (t3) [ms]
PMC71 max. All 90 120 276
PMP71 max. • 400 mbar (6 psi)
• ≥1 bar (15 psi)
45 • 70
• 35
• 161
• 81
PMP75 max. PMP71 + influence of the diaphragm seal
Dynamic behavior
Digital output
(HART electronics)
A typical burst rate of 300 ms results in the following behavior:
Type Measuring cell Dead time (t1) [ms] Dead time (t1) [ms] +
Time constant T63 (t2) [ms]
Dead time (t1) [ms] +
Time constant T90 (t3) [ms]
PMC71 Min. All 250 370 436
max. 1050 1170 1236
PMP71 Min. • 400 mbar (6 psi)
• ≥1 bar (15 psi)
205 • 275
• 240
• 321
• 241
max. • 400 mbar (6 psi)
• ≥1 bar (15 psi)
1005 • 1075
• 1040
• 1121
• 1041
PMP75 max. PMP71 + influence of the diaphragm seal
Reading cycle
• Acyclic: max. 3/s, typically 1/s (depending on command # and number of preambles)
• Cyclic (burst): max. 3/s, typically 2/s
The device commands the BURST MODE functionality for cyclical value transmission via the HART
communication protocol.
Cycle time (update time)
Cyclic (burst): min. 300 ms
Response time
• Acyclic: min. 330 ms, typically 590 ms (depending on command # and number of preambles)
• Cyclic (burst): min. 160 ms, typically 350 ms (depending on command # and number of
preambles)
Dynamic behavior
PROFIBUS PA
A typical PLC cycle time of 1 s results in the following behavior:
Type Measuring cell Dead time (t1) [ms] Dead time (t1) [ms] +
Time constant T63 (t2) [ms]
Dead time (t1) [ms] +
Time constant T90 (t3) [ms]
PMC71 Min. All 125 245 311
max. 1325 1445 1511
PMP71 Min. • 400 mbar (6 psi)
• ≥1 bar (15 psi)
80 • 150
• 115
• 196
• 116
max. • 400 mbar (6 psi)
• ≥1 bar (15 psi)
1280 • 1350
• 1315
• 1396
• 1316
PMP75 max. PMP71 + influence of the diaphragm seal
Reading cycle (PLC)
• Acyclic: Typically 25/s
• Cyclic: Typically 30/s (depending on the number and type of the function blocks used in the
closed-control loop)

Cerabar S PMC71, PMP71, PMP75
18 Endress+Hauser
Cycle time (update time)
Min. 200 ms
The cycle time in a bus segment in cyclic data communication depends on the number of devices, on
the segment coupler used and on the internal PLC cycle time. A new measured value can be
determined up to five times a second.
Response time
• Acyclic: Approx. 60 ms to 70 ms (depending on Min. Slave Interval)
• Cyclic: Approx. 10 ms to 13 ms (depending on Min. Slave Interval)
Dynamic behavior
FOUNDATION Fieldbus
A typical configuration for the macro cycle time (host system) of 1 s results in the following
behavior:
Type Measuring cell Dead time (t1) [ms] Dead time (t1) [ms] +
Time constant T63 (t2) [ms]
Dead time (t1) [ms] +
Time constant T90 (t3) [ms]
PMC71 Min. All 135 255 321
max. 1135 1255 1321
PMP71 Min. • 400 mbar (6 psi)
• ≥1 bar (15 psi)
90 • 160
• 125
• 206
• 126
max. • 400 mbar (6 psi)
• ≥1 bar (15 psi)
1090 • 1160
• 1125
• 1206
• 1126
PMP75 max. PMP71 + influence of the diaphragm seal
Reading cycle
• Acyclic: Typically 10/s
• Cyclic: max. 10/s (dependent on the number and type of function blocks used in a closed-control
loop)
Cycle time (update time)
Cyclic: Min. 100 ms
Response time
• Acyclic: Typically 100 ms (for standard bus parameter settings)
• Cyclic: max. 20 ms (for standard bus parameter settings)
Damping A damping affects all outputs (output signal, display):
• Via onsite display, handheld terminal or PC with operating program, continuously 0 to 999 s
• Also for HART and PROFIBUS PA: Via DIP switch on the electronic insert,
switch position "on" = set value and "off"
• Factory setting: 2 s
Alarm current Description Option 1)
Min alarm current J
HART burst mode PV J
Min alarm current + HART burst mode PV J
1) Product Configurator, order code for "Additional options 1" and "Additional options 2"
Firmware version Description Option 1)
02.20.zz, HART 7, DevRev22 72
02.11.zz, HART 5, DevRev21 73
04.00.zz, FF, DevRev07 74
04.01.zz, PROFIBUS PA, DevRev03 75

Cerabar S PMC71, PMP71, PMP75
Endress+Hauser 19
Description Option 1)
02.10.zz, HART 5, DevRev21 76
03.00.zz, FF, DevRev06 77
04.00.zz, PROFIBUS PA 78
1) Product Configurator, order code for "Firmware version"
HART protocol-specific data Manufacturer ID 17 (11 hex)
Device type code 24 (18 hex)
Device revision • 21 (15 hex) - SW version 02.1y.zz - HART specification 5
• 22 (16 hex) - SW version 02.2y.zz - HART specification 7
HART specification • 5
• 7
DD revision • 4 (Russian in language selection) for device revision 21
• 3 (Dutch in language selection) for device revision 21
• 1 for device revision 22
Device description files (DTM, DD) Information and files at:
•www.endress.com
•www.hartcomm.org
HART load Min. 250 Ω
HART device variables The measured values are assigned to the device variables as follows:
Measured values for PV (primary variable)
• Pressure
• Level
• Tank content
Measured values for SV, TV (second and third variable)
Pressure
Measured values for QV (fourth variable)
Temperature
Supported functions • Burst mode
• Additional transmitter status
• Device locking
• Alternative operating modes
PROFIBUS PA protocol-
specific data Manufacturer ID 17 (11 hex)
Identification number 1541 hex
Profile version 3.0
• SW version 03.00.zz
• SW version 04.00.zz
3.02
SW version 04.01.zz ( device revision 3)
Compatibility with SW version 03.00.zz and higher.
GSD revision • 4 (SW version 3.00.zz and 4.00.zz)
• 5 (device revision 3)
DD revision • 1 (SW version 3.00.zz and 4.00.zz)
• 1 (device revision 3)
GSD file Information and files at:
•www.endress.com
•www.profibus.org
DD files

Cerabar S PMC71, PMP71, PMP75
20 Endress+Hauser
Output values Measured value for PV (via Analog Input Function Block)
• Pressure
• Level
• Tank content
Measured value for SV
• Pressure
• Temperature
Input values Input value sent from PLC, can be shown on display
Supported functions • Identification & maintenance Simplest device identifier on the
control system and nameplate
• Condensed status (only with Profile Version 3.02)
• Automatic ID number adjustment and switchable to the following ID
numbers (only with Profile Version 3.02):
– 9700: Profile-specific transmitter identification number with the
"Classic" or "Condensed" status".
– 1501: Compatibility mode for the old Cerabar S generation
(PMC731, PMP731, PMC631, PMP635).
– 1541: Identification number for the new Cerabar S generation
(PMC71, PMP71, PMP75).
• Device locking: The device can be locked by hardware or software.
FOUNDATION Fieldbus
protocol-specific data Manufacturer ID 452B48 hex
Device type 1007 hex
Device revision • 6 - SW version 03.00.zz
• 7 - SW version 04.00.zz (FF-912)
DD revision • 3 (device revision 6)
• 2 (device revision 7)
CFF revision • 4 (device revision 6)
• 1 (device revision 7)
DD files Information and files at:
•www.endress.com
•www.fieldbus.org
CFF files
Device tester version (ITK version) • 5.0 (device revision 6)
• 6.01 (device revision 7)
Number of ITK test campaign • IT054600 (Device Revision 6)
• IT085500 (Device Revision 7)
Link Master (LAS) capable Yes
Choice of "Link Master" and "Basic
Device"
Yes, factory setting is Basic Device
Node address Factory setting: 247 (F7 hex)
Supported functions Field diagnostics profile (only with FF912)
The following methods are supported:
• Restart
• Configure error as warning or alarm
• HistoROM
• Peakhold
• Alarm info
• Sensor trim
Number of VCRs • 44 (device revision 6)
• 24 (device revision 7)
Number of link objects in VFD 50
