Endress+Hauser Liquisys M CUM 223 User manual

BA 200C/07/en/05.99
No. 51500274
Software version 2.0 or laterLiquisys M
CUM 223 / 253
Transmitter for
Turbidity and
Solids Content
Operating Instructions
Endress Hauser
Nothing beats know-how
Quality made by
Endress+Hauser
ISO 9001
ENDRESS+HAUSER
LIQUISYS M
ENDRESS+HAUSER
LIQUISYS M

Need information on the instrument?
Please read the following chapters:
Safety
General information
You wish to install the instrument. The required steps
are described in this chapter:
Installation
You wish to operate or reconfigure the instrument. The
operating concept is explained in these chapters:
Operation
Instrument configuration
Interfaces
Need help with problems or maintenance? Please refer
to these chapters:
Diagnosis Maintenance
Accessories Technical data
Appendix Index
%Ω°C

Table of contents
1 General information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
1.1 Symbols used ............................................................. 2
1.2 Storage and transport ....................................................... 2
1.3 Unpacking ................................................................ 2
1.4 Packaging and disposal ..................................................... 2
1.5 Product structure ........................................................... 3
2 Safety ............................................................... 4
2.1 Intended application ........................................................ 4
2.2 General safety instructions ................................................... 4
2.3 Installation, start-up, operation ................................................ 4
2.4 Monitoring and safety features ................................................ 5
2.5 Immunity to interference ..................................................... 5
2.6 Certificate of conformity ...................................................... 5
3 Installation........................................................... 6
3.1 Measuring system .......................................................... 6
3.2 Dimensions ............................................................... 7
3.3 Mounting ................................................................. 8
3.4 Electrical connection ....................................................... 12
3.5 Sensor installation and measuring cable connection .............................. 14
4 Operation........................................................... 16
4.1 Operator interface ......................................................... 16
4.2 Display.................................................................. 16
4.3 Key functions ............................................................. 17
4.4 Auto / manual mode of operation.............................................. 18
4.5 Operating concept......................................................... 19
4.6 Access codes ............................................................ 21
4.7 Display during measurement................................................. 21
4.8 Calibration ............................................................... 21
5 Instrument configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
5.1 Start-up ................................................................. 24
5.2 System configuration ....................................................... 24
5.3 Current outputs ........................................................... 26
5.4 Monitoring functions........................................................ 28
5.5 Relay contact configuration .................................................. 31
5.6 Concentration measurement ................................................. 41
5.7 Service .................................................................. 42
5.8 E+H Service .............................................................. 44
5.9 Interfaces ................................................................ 45
5.10 Calibration ............................................................... 46
5.11 Offset ................................................................... 53
6 Interfaces........................................................... 54
7 Maintenance and troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
7.1 Definition of terms ......................................................... 55
7.2 Safety instructions ......................................................... 55
7.3 Troubleshooting common problems ........................................... 55
7.4 Problem elimination based on error messages ................................... 58
8 Diagnosis and corrective maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
8.1 Definition of terms ......................................................... 60
8.2 Safety instructions ......................................................... 60
8.3 Diagnosis ................................................................ 60
8.4 Corrective maintenance of Liquisys CUM 223 ................................... 62
8.5 Corrective maintenance of Liquisys CUM 253 ................................... 64
8.6 Spare parts orders ......................................................... 66
8.7 Service equipment “optoscope” .............................................. 66
8.8 Corrective maintenance of measuring system ................................... 67
9 Accessories ......................................................... 68
10 Technical data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
11 Appendix........................................................... 72
12 Index............................................................... 76
UM253E00.CHP
Liquisys M CUM 223 / 253
Endress+Hauser 1

1 General information
1.1 Symbols used
Warning:
This symbol alerts to hazards which
may cause serious injuries as well as
damage to equipment if ignored.
Note:
This symbol indicates important
items of information.
Ignoring this information may result
in malfunction.
1.2 Storage and transport
The packaging material used to store or
transport the transmitter must provide shock
protection. Optimal protection is provided by
the original packaging materials.
Conformance with the ambient conditions
(see Technical data) must be assured.
1.3 Unpacking
Verify that the packaging and contents are
undamaged! Inform the post office or freight
carrier of any damage.
Damaged merchandise must be retained until
the matter has been settled.
Check that the delivery is complete and
agrees with the shipping documents and your
order (refer to nameplate for type and variant).
The delivery includes:
•Measuring transmitter CUM 223 or
CUM 253
•Operating instructions BA 200C/07/en
•Field instrument:
- 1 plug-in screw terminal
- 1 cable gland Pg 7
- 1 cable gland Pg 16, reduced
- 2 cable glands Pg 13.5
•Panel-mounted instrument:
- 1 set of plug-in screw terminals
- 2 fastening clips
Keep the original packaging materials for
future storage or shipping of the instrument.
If you have any questions, consult your
supplier or the Endress+Hauser sales agency
in your area (see back cover of these
operating instructions for addresses).
1.4 Packaging and disposal
Package the assembly properly for reuse at a
later point in time. Optimal protection is
provided by the original packaging materials.
Observe local regulations for disposal.
General information Liquisys M CUM 223 / 253
2Endress+Hauser

1.5 Product structure
You can identify the instrument variant by the
order code on the nameplate.
131085-4B
ENDRESS+HAUSER
LIQUISYS-M
order code / Best.Nr.
serial no. / Ser.-Nr. /Codes:
:
:
:
:
:
:
:
:
:
prot. class / Schutzart
ambient temp. / Umgebungstemperatur
output 1 / Ausgang 1
output 2 / Ausgang 2
mains / Netz
measuring range / Messbereich
temperature / Temperatur
turbidity / Trübung
FNU, ppm g/l, %
–5 ... 70 °C
–10 ... + 55 °C
0/4 ... 20 mA
230 VAC
123456
7,5 VA
IP 65
50 / 50 Hz
0/4 ... 20 mA
CUM 253-TS0115
253-TYP.CDR
131085-4B
ENDRESS+HAUSER
LIQUISYS-M
order code / Best.Nr.
serial no. / Ser.-Nr. /Codes:
:
:
:
:
:
:
:
:
:
prot. class / Schutzart
ambient temp. / Umgebungstemperatur
output 1 / Ausgang 1
output 2 / Ausgang 2
mains / Netz
measuring range / Messbereich
temperature / Temperatur
turbidity / Trübung
FNU, ppm g/l, %
–5 ... 70 °C
–10 ... + 55 °C
0/4 ... 20 mA
230 VAC
123456
7,5 VA
IP 54 / IP 30
50 / 50 Hz
0/4 ... 20 mA
CUM 223-TU0110
223-TYP.CDR Fig. 1.1
left:
Nameplate of CUM 253
right:
Nameplate of CUM 223
Liquisys M CUM 223 / 253
Version
TU Turbidity and solids concentration measurement
TS Turbidity and solids concentration measurement
with additional functions (S version)
Power supply
0230VAC
1115VAC
5100VAC
8 24 V AC/DC
Measurement output
0 Turbidity / TS
1 Turbidity / TS and temperature
3 Profibus PA
5 Turbidity / TS with HART
6 Turbidity / TS, HART and temperature
Contacts
05 No additional contacts
10 2 contacts (limits / PID / timer)
15 4 contacts (limits / PID / timer / Chemoclean)
16 4 contacts (limits / PID / timer)
CUM223-
complete order code
CUM253-
UM253E01.CHP
Liquisys M CUM 223 / 253 General information
Endress+Hauser 3

2 Safety
2.1 Intended application
The CUM 223/253 transmitter is a field-tested
and reliable measuring transmitter used to
determine the turbidity and solids
concentration of liquid media.
The CUM 223/253 is particularly suitable for
use in the following areas of application:
•Chemical industry
•Pharmaceutical industry
•Drinking water treatment
•Condensate processing
•Municipal sewage treatment plants
•Water conditioning
2.2 General safety instructions
This device has been manufactured for safe
operation according to the state of the art in
engineering and conforms to the applicable
regulations and European standards (see
Technical data). It has been designed
according to EN 61010-1 and has left the
manufacturer’s works in perfect condition.
However, if used improperly or for purposes
other than the intended purpose, it may be
dangerous, e.g. due to incorrect connection.
Warning:
•Operating this instrument in any
way other than as described in
these instructions may compro-
mise the safety and function of the
measuring system and is therefore
impermissible.
•The notes and warnings in these
installation and operating
instructions must be strictly
adhered to!
2.3 Installation, start-up, operation
Warning:
•This device may only be installed,
connected electrically,
commissioned, operated and
serviced by properly trained
personnel authorized by the
system operator.
•The personnel must be familiar
with these operating instructions
and must adhere to the
instructions described therein.
•Make sure that the power supply
ratings match the data specified
on the nameplate before you
connect the instrument to a power
source.
•A clearly identified mains
disconnecting device must be
installed close to the instrument.
•Live components can be touched
through the vent slots in the
housing and the openings on the
rear of the housing. Do not insert
tools, wires, etc., in these slots
(CUM 223 only).
•Check that all connections have
been properly made before
powering up the system!
•Damaged equipment that may be
dangerous must not be operated
and should be clearly identified as
being defective.
•Any troubleshooting of the
measuring system is to be
performed exclusively by
authorized, trained personnel.
•If faults cannot be remedied, the
instrument must be removed from
service and secured to prevent
accidental start-up.
•Repairs not described in these
operating instructions may only be
performed at the manufacturer’s
works or by the Endress+Hauser
Service Organization.
Safety Liquisys M CUM 223 / 253
4Endress+Hauser

2.4 Monitoring and safety features
Safety features
The transmitter is protected against external
influences and damage by the following
design measures:
•Rugged housing
•Degree of protection provided by
enclosure: IP 65 (CUM 253)
•UV resistance
Monitoring features
In the event of a system error or power failure,
an alarm condition is signalled via a fail-safe
fault signalling contact.
2.5 Immunity to interference
This instrument has been tested according to
the applicable European standards for
industrial applications with regard to
electromagnetic compatibility. It is protected
against electromagnetic interference by the
following design measures:
•Cable screen
•Interference suppressor filter
•Interference suppression capacitors
Warning:
The specified immunity to
interference only applies for devices
connected as outlined in these
operating instructions.
2.6 Certificate of conformity
The CUM 223/253 transmitter has been
developed and manufactured in accordance
with currently valid European standards and
directives.
Note:
An EC certificate of conformity is
supplied.
UM253E02.CHP
Liquisys M CUM 223 / 253 Safety
Endress+Hauser 5

3 Installation
The following procedure should be followed
for a complete measuring system installation:
•Installation or attachment of transmitter
(see chpt. 3.3)
•Selection and connection of cable and
sensor (see chapters 3.4, 3.5 and 9)
•Installation is followed by start-up (see
chpt. 5).
3.1 Measuring system
The complete measuring system comprises:
•The Liquisys M CUM 223 or CUM 253
transmitter
•A sensor with an integrated temperature
sensor and a permanently attached cable
•An installation assembly
Optional:
•Extension cable CYK 8
•Junction box VBM or RM
ENDRESS+HAUSER
LIQUISYS
CAL REL
REL 1
REL 1
ALARM
REL 2
REL 2
E
ENDRESS+HAUSER
LIQUISYS
CAL REL
REL 1
REL 1
ALARM
REL 2
REL 2
E
Sensor cable
Liquisys M CUM 253
Flow assembly with
turbidity sensor CUS 31
Retractable
assembly
CUA 461
UM2X3SYS.CDR
Liquisys M CUM 223
Immersion assembly
CYA 611
Fig. 3.1
Complete measuring
systems consisting of
Liquisys M CUM 223 /
253 with measuring cable,
assembly and turbidity
sensor
Installation Liquisys M CUM 223 / 253
6Endress+Hauser

3.2 Dimensions
ENDRESS+HAUSER
LIQUISYS
CAL REL
REL 1
REL 1
ALARM
REL 2
REL 2
E
FELD1.CDR
11
170
247
115
∅6
157
154
70
70
Fig. 3.3
Dimensions of Liquisys M
CUM 253
FELD2.CDR
1
2
3
4
Fig. 3.2
Inside of housing of
Liquisys M CUM 253:
1 Removable
electronics box
2 Partition plate
3 Terminal blocks
4 Fuse
GEHAEUS1.CDR
UM253E03.CHP
Liquisys M CUM 223 / 253 Installation
Endress+Hauser 7

3.3 Mounting
3.3.1 Field instrument
Several mounting options are available for the
Liquisys M in the field instrument version:
•Post mounting on cylindrical pipes
•Post mounting on a square post
•Wall mounting with fastening screws
Weather protection cover CYY 101 can be
used for outdoor installation in conjunction
with all mounting variants.
Weather protection cover CYY 101
Weather protection cover for outdoor
installation, to be mounted on field instrument;
material: stainless steel 1.4301 (SS 304);
order no.: CYY101-A
EINBAU2.CDR
96
6
139
90
Fig. 3.4
Liquisys M CUM 223,
panel-mounted version
DACH.CDR
300
270
320
Fig. 3.5
Weather protection cover
for field instrument
EINBAU1.CDR
Installation Liquisys M CUM 223 / 253
8Endress+Hauser

Post mounting kit
Mounting kit for installation of field housing on
horizontal or vertical pipes (max. ∅60 mm);
material: stainless steel VA;
order no.: 50086842
Universal mounting post CYY 102
Square tube for mounting of measuring
transmitters; material: 1.4301 (SS 304);
order no.: CYY102-A
MONT5.CDR
60
90
70
∅6
70
∅8
70
90
M6
∅8
30
90
60 x 60
1495
150
120
∅max. 60
Fig. 3.6
Left:
Mounting kit for post
mounting on cylindrical
pipes
Right:
Square mounting post
UM253E03.CHP
Liquisys M CUM 223 / 253 Installation
Endress+Hauser 9

3.3.2 Mounting examples
MONT10.CDR
Fig. 3.7
Pipe mounting of Liquisys
M field instrument
MONT2.CDR
Fig. 3.8
Liquisys M field instrument
Left:
Wall mounting
Right:
Mounting with universal
post and weather
protection cover
Installation Liquisys M CUM 223 / 253
10 Endress+Hauser

3.3.3 Panel-mounted instrument
The instrument is attached using the supplied
tensioning screws (see Fig. 3.9).
The required overall installation depth is
approx. 165 mm.
MONT9.CDR
92+0.5
92+0.5
90
57
33
approx.
25
max. 45
96
92
1
2
3
139 6
Fig. 3.9
Attachment of
panel-mounted instrument
1 Wall of control
cabinet
2 Gasket
3 Tensioning screws
UM253E03.CHP
Liquisys M CUM 223 / 253 Installation
Endress+Hauser 11

3.4 Electrical connection
Connection diagram
The connection diagram depicted in Fig. 3.10
shows the instrument connections for turbidity
sensor CUS 31 or CUS 41. The connection of
the various sensors is shown in more detail in
Figs. 3.13 and 3.14.
47
48
49
57
58
59
L+
L-
L
N
∼=
41
42
43
15 V
85
86
10-50 V
81
93
82
94
10-50 V
TU
mA
31
32
mA
33
34
51
52
53
54
55
56
97
88
87
96
S
gn
wt
bn
ye
ANU01E.CDR
Aux. voltage
output
Digital input 2
(Chemoclean)
Digital input 1
(hold)
Signal output 2
temperature
Signal output 1
turbidity
Sensor
Alarm
(de-energized
contact
position)
Relay 1
(de-energized
contact
position)
Relay 2
(de-energized
contact
position)
Relay 3
(de-energized
contact
position)
Relay 4
(de-energized
contact
position)
Mains
*optional
*
*
Fig. 3.10
Electrical connection of
Liquisys M CUM 223/253
(all inputs and outputs
connected)
Installation Liquisys M CUM 223 / 253
12 Endress+Hauser

Connections of field instrument
For connection, the measuring cables are
introduced through the cable glands on the
field instrument and connected according to
the diagrams in Figs. 3.10, 3.11 and 3.12.
Connections of panel-mounted instrument
U-AN01.CDR Fig. 3.11
Connection compartment
sticker for field instrument
CUM 253
REL1
REL2
REL3
REL4
NC
NC
49
COM
COM
COM
COM
59
54
55
56
52
51
53
58
57
48
47
131084-4B
U-AN02.CDR Fig. 3.12
Connection compartment
sticker for panel-mounted
instrument CUM 223
UM253E03.CHP
Liquisys M CUM 223 / 253 Installation
Endress+Hauser 13

3.5 Sensor installation and measuring cable connection
Measuring cable connection
The sensor is connected via a special
screened, multi-core cable which is
completely terminated and permanently
connected to the sensor.
Use junction box, e.g. VBM (see chpt. 9) to
extend the measuring cable.
Termination instructions are supplied with the
measuring cables.
Note:
•Connectors, cable ends and termi-
nals are to be protected against
moisture to prevent inaccurate
measurement!
•The instrument is approved for
protection class II and is generally
connected without protective earth.
Structure and termination of measuring cables
Special measuring cables required for connection of turbidity sensors
Sensor type Cable Extension
Turbidity sensor CUS 31 Non-detachable cable
on sensor VBM box + CYK 8
Turbidity sensor CUS 41 Non-detachable cable
on sensor VBM box + CYK 8
Maximum cable length
with turbidity sensors
CUS 31 / CUS 41 max. 200 m using CYK 8
KABELTU.CDR
Com A
Screen
–UB
CYK 8
+UB
Com B
87 88 96 97 S
bn wt gn ye
CYK 8
87 88 96 97 S
bn wt gn ye
Fig. 3.13
Structure of special
measuring cable CYK 8
Left:
CYK 8 for extension,
non-terminated
Right:
Terminated cable
permanently attached to
sensor
Installation Liquisys M CUM 223 / 253
14 Endress+Hauser

Connection examples
S87889697
CYK 8
U2X3AN.CDR
bn wt gn ye
Sensor
Fig. 3.14
Connection of turbidity
sensors CUS 31 and
CUS 41
UM253E03.CHP
Liquisys M CUM 223 / 253 Installation
Endress+Hauser 15

4 Operation
4.1 Operator interface
4.2 Display
LED indicators
Liquid crystal display
185 NTU
R262
Setpoint
DISPL1-E.CDR
Liquid crystal display
for display of measured
values and
configuration data
4 main control keys for
calibration and
instrument configuration Key for switching
between automatic /
manual operation
LED indicators for
limit contactor relays
(switching state)
LED indicator for alarm
function
Display of active
contact and key for
relay switching in
manual mode
Field for user labelling
Fig. 4.1
Operating elements of
Liquisys M
Indication of current operating mode: “auto”(green LED) or “manual”(yellow LED)
Indication for relay controlled in “manual”mode (red LED)
Indicates the state of relays 1 and 2.
LED green: measured value is within permissible limits, relay is inactive.
LED red: measured value is outside permissible limits, relay is active.
Alarm indication for continuous limit violation, temperature sensor failure or system errors
(see error list in chapter 7.1, p. 55)
185
NTU
R262
Setpoint
DISPL3-E.CDR
Measuring mode
indicator (normal
operation)
Calibration mode
indicator
Setup mode
indicator
(configuration)
Automatic
temperature
compensation
display
Sensor symbol
(flashes during
calibration)
Error indicator
In measuring mode:
main measurement
value. In setup / calibr.
mode: e.g. parameter
In measuring mode:
secondary measured value.
In setup / calibr. mode: e.g.
parameter setting
In measuring mode:
quantity measured.
In setup mode:
parameter adjusted
Function coding display
Rel 3/4 state indicators
active inactive
‘Hold’mode
indicator (outputs
reflect last current
status)
Fig. 4.2 Liquid crystal display
Operation Liquisys M CUM 223 / 253
16 Endress+Hauser

4.3 Key functions
CAL key
When the CAL key is pressed, the instrument
prompts for the calibration access code (fixed
setting: 22 for calibration or any other number
to view the calibration data). Acknowledge
with the CAL key to proceed. Use the CAL
key to continue through the calibration
process.
Hinweis:
The calibration data set in function
group C are used for calibration.
ENTER key
The ENTER key has several functions:
- It calls up the setup menus from the
measuring mode
- It is used to store (acknowledge) data
entered in setup mode
- It is used to start calibration (same
function as CAL key)
PLUS key
MINUS key
The PLUS and MINUS keys have the following
functions:
- They are used to select function groups;
to set parameters and numeric values
(the setting speed increases when the
key is held down); and
- to operate the relays in manual mode
(see chapter 4.2).
- In the measuring mode, the PLUS key
switches to °F and disables the
temperature display (see chapter 4.7),
- while
the MINUS key selects the error display
(see chapter 4.7)
REL key
The REL key is used in manual mode to
switch between the relays and the manual
start cleaning function.
AUTO key
This key is used to toggle between the
automatic and manual modes of operation.
Escape function
Press the PLUS and MINUS keys
simultaneously to return to the main menu,
in calibration mode: at the end of calibration.
Press the PLUS and MINUS keys again to
return to the measuring mode.
Locking the hardware
Access to field operation can be locked for
communication via HART or PROFIBUS.
Press the PLUS key and the ENTER key at the
same time to lock the instrument. The code
prompt displays the code 9999.
Unlocking the hardware
To unlock, press the CAL and MINUS keys at
the same time. The code prompt displays the
code 0.
UM253E04.CHP
Liquisys M CUM 223 / 253 Operation
Endress+Hauser 17

4.4 Auto / manual mode of operation
Auto mode
In this mode of operation, the relays
are controlled by the transmitter.
REL key
The REL key is used to select one of
the relays present in the instrument.
Switching to manual mode
The instrument is switched to the
manual mode pressing the following
keys:
Press AUTO key.
Enter code 22.
Select relay or function. Press the
REL key to toggle between the
relays. The display shows the
selected relay in the second line.
Set the relays. Switch on with PLUS,
switch off with MINUS. The relay
state remains in effect until it is
actively reset.
Press AUTO key for returning to the
measuring mode.
Note:
•Enable the manual mode by
entering access code “22”.
•The operating mode remains in
effect even after a power failure.
•The manual mode takes
precedence over any other
automatic function (hold).
•Hardware locking in the manual
mode is not possible.
•The manual settings remain in
effect until they are actively reset.
•Error code 22 is signalled in the
manual mode.
Operation Liquisys M CUM 223 / 253
18 Endress+Hauser
