Energetics XT 1010 User manual

XT 1010 Crosstrainer
Assembly manual
EN
Aufbauanleitung
DE
Montažni přiručka
CS
Manual na montaž
SK
Felhasznaloi kezikonyv
HU
60 -80 Min
120 kg
A: 160 cm
B: 159 cm
C: 51 cm
71 kg

2
Table of contents - Inhaltsverzeichnis -Obsah - Obsah - Tájékoztató
English
P
3
Deutsch
P
22
Česky
P
42
Slovensky
P
62
Magyar
P
83
Serial Decal / Seriennummeraufkleber / Štitek se seriovym čislem / Seriovy štitok / Cimke
EN
The product sticker is placed on the rear stabilizer on
bikes and ellipticals and next to the power inlet on
treadmills
DE
Der Aufkleber für die Serien-nummer ist bei
Heimtrainer oder Ellipticals auf der hinteren Quer-
stütze angebracht, bei Laufbändern in der Nähe des
Stromanschlusses.
CZ
Štitek vyrobku se nachazi na zadnim tabilizatoru kol a
eliptickych trenažerůa vedle elektrickeho přivodu na
běžeckych trenažerech.
SK
Štitok vyrobku je umiestneny na zadnej strane
stabilizatora na bicykloch a kolesach a blizko pri
napajani na bežeckom pase.
HU
A termek ontapados cimkeje a kerekparok es
szobakerekparok hatso stabilizatoran van elhelyezve es
a pedalokon a tapbemenet mellett.
EN
© The owners manual is only for the customer reference. ENERGETICS can not guarantee for mistakes occurring due to translation
or change in technical specification of the product. Wherever pictograms are used they may differ from your product, it’s for
reference only.
DE
© Die Gebrauchsanweisung dient nur zur Referenz für den Kunden. ENERGETICS übernimmt keine Haftung für Fehler die durch
Übersetzung oder technische Änderungen des Produkts entstehen. Falls Piktogramme verwendet werden, können diese von Ihrem
Produkt abweichen und dienen nur als Referenz.
CZ
© Navod k použiti je pouze doporučeni pro zakazniky. ENERGETICS nepřebira žadne ručeni za chyby způsobene překladem či
změnami v technicke specifikaci vyrobku. Použiti piktogramův tomto navodu se může lišit od skutečneho použiti na vašem vyrobku,
rozmistěni v tomto navodu slouži pouze pro informaci.
SK
© Tento návod je určený len pre potrebu zákazníkov. ENERGETICS nezodpovedá za chyby, ktoré sa môžu vyskytnúť kvôli chybnému
prekladu alebo zmenám v technickej špecifikácii produktu. Všade, kde sa používajú piktogramy, sa tieto môžu líšiť od vášho produktu
a sú určené len na referenčné účely.
HU
© A vásárlók számára a jelen használati utasításnak csak ajánló jellege van. Az ENERGETICS cég nem vállal kezességet olyan jellegű
hibákért, amelyek az eredeti szöveg fordításából, illetve a termék módosított műszaki specifikációjából származnak. A használt
piktogramok eltérhetnek a termék piktogramjaitól. Ezek csak
tájékoztató jellegűek.

3
Corporate Social Responsibility
EN
INTERSPORT is a participating company in the BSCI (Business Social Compliance Initiative) based in
Brussels. Through BSCI, INTERSPORT is committed to implement the BSCI Code of Conduct in its supply
chain and to gradually achieve better working conditions at the involved suppliers’ workplaces. The BSCI
system is based on three pillars: monitoring of non-compliances by external independent audits;
empowering of supply chains’ actors through various capacitybuilding activities; and engagement with
all relevant stakeholders via constructive dialogue in Europe and supplying countries. Our social audits
are conducted by neutral, internationally recognized auditing companies with the aim of monitoring the
social compliance of our supplier factories.
For more information on the BSCI please visit: www.bsci-intl.org
Norms & Regulations
Consumer safety is the number one priority for ENERGETICS products. This means that all of our products
comply with national and international legal requirements (such as the EU Regulation (EC No.
1907/2006) concerning the Registration, Evaluation, Authorization and Restriction of Chemicals
[REACH]).
This product is also CE certified and has been tested by an internationally
recognized institute and certified against the industry standard EN 957.
Disposal of electrical waste products (Directive 2002/96/EC WEEE):
All products that contain electrical and electronic equipment must be marked
with the logo. These products shall not be disposed in municipal waste. Instead
please check local regulations regarding these types of products.
Disposal of batteries (Directive 2006/66/EG):
Batteries must be marked with the logo including the chemical symbols Hg, Cd
or Pb if the battery contains mercury, cadmium or lead above the threshold limits
mentioned in the directive and its amendments. Batteries used in products shall
not be disposed in municipal waste.
Directive 2011/65/EU:
Restriction of the use of certain hazardous substances in electrical and electronic
equipment (RoHS).

4
Dear Customer,
Congratulations on your purchase of an ENERGETICS home fitness equipment. This product
has been designed and manufactured to meet the needs and requirements of in-home use.
Please carefully read the assembly- and user manual. Be sure to keep the instructions for
reference and/or maintenance. If you have any further questions, please contact us. We wish
you lots of success and fun while training.
Your ENERGETICS - Team
Product Safety
ENERGETICS offers high quality home fitness equipment. All products have been tested and
certified according to the latest European Norm ISO EN 20957-1, EN 957-5.
Important Safety Instructions for all home fitness equipment
Do not assemble or operate this home fitness equipment outdoors or in a wet or moist
location.
Before you start training on your home fitness equipment product, please read the
instructions carefully.
Be sure to keep the instructions for information, in case of repair and for spare part
delivery.
This training equipment is not suitable for therapeutic purposes.
Consult your physician before starting with any exercise programs to receive advice on
the optimal training.
Warning: incorrect/excessive training can cause health injuries. Stop using the home
fitness equipment when feeling uncomfortable.
Warning: The safety level of the training equipment can only be maintained if it is
examined regularly on damage or wear.
Please follow the advice for correct training as detailed in the training instructions.
Ensure that training only starts after correct assembly, adjustment and inspection of the
home fitness equipment.
Always start with a warm-up session.
Only use original ENERGETICS parts as delivered (see partslist).
Follow the steps of the assembly instruction carefully.
Only use suitable tools for assembly and ask for assistance if necessary.
Place the home fitness equipment on an even, non-slippery surface for immobilization,
reducing noise and vibration.
To protect the floor or carpet from damage, place a mat under the product.
For all adjustable parts be aware of the maximum position to which they can be adjusted.
Tighten all adjustable parts to prevent sudden movement while training.
This product is designed for adults. Please ensure that children only use it under the
supervision of an adult.
Do not use the home fitness equipment without shoes or loose shoes.
Be aware of non-fixed or moving parts whilst mounting or dismounting the home fitness
equipment.
Search for noisy parts: If you should notice unusual noises, like grinding, clacking etc. try
to locate it and have it repaired by a professional. Make sure the home fitness equipment
is not used until after repairs have been made.

5
This device is not meant to be used by persons (including children) with limited physical,
sensory or mental capabilities or lacking experience and/or the knowledge to use this
device, unless under the supervision of another person in charge of their safety or having
been given prior instruction on the operation of this device.
Children should always be under supervision, to assure they are not playing with this
device.
The resistance level can be adjusted to your personal preference: see operations.
This product is made for home use only and tested up to a maximum body weight of: see
front page or serial decal on product.
WARNING: Heart rate monitoring systems may be inaccurate. Over exercising may result
in serious injury or death. If you feel faint stop exercising immediately.
Cleaning, Care & Maintenance on fitness equipment
Important
Frequent cleaning of your home fitness equipment will extend the product’s life.
Use of a home fitness equipment mat is recommended for ease of cleaning.
Use clean and proper sport shoes only.
Use a damp cloth to clean the home fitness equipment and avoid the use of
abrasives or solvents.
To prevent damage to the computer, keep liquids away and keep it out of direct
sunlight.
The home fitness equipment should not be used or stored in a moist area because
of possible corrosion.
In case of repair please ask your dealer for advice.
Replace defective components immediately and/or keep the equipment out of use
until repair.
Use original spare parts for repair only.
Daily
Monthly
Immediately wipe of the sweat;
perspiration can ruin the appearance
and proper function of the home
fitness equipment.
Check that all connecting elements
are tightly fitted and in good
condition.

6
Handling
Leveling
Transportation
After assembly, the rear stabilizer can be
adjusted to accommodate slightly uneven
ground. Turn the adjustment knobs at the ends
of the rear foot caps to level the rear stabilizer
to the floor.
The transportation wheels on the front foot caps
allow for easy manoeuvring. Simply pull back on
the handlebars until the wheels touch the floor.
Then roll the unit to a desired location.
Pedal Adjustment (where applicable)
A correct pedal adjustment will ensure you can do your exercise more efficiently and comfortable. It also
will reduce the risk of any injury while using.
1. Loosen the two screws underneath the pedal.
2. Slide the pedal back or forth until you found the
correct position.
3. Re-enter the two screws and tighten the nuts
securely.
4. You can start your exercise.
Make sure all screws are tightened well after you have made your adjustments.
Operations
Proper Training Clothes
Please make sure you always wear proper training shoes while working out. It is recommended that you
wear training appropriate exercise clothing’s that allow you to move freely whilst exercising.
Exercise Level
Please contact a physician before your exercise program. Immediately stop exercising if you feel any pain
or tightness in your chest, become short breathed of faint. Please contact your doctor before you start
using your fitness product again.
Resistance Adjustment
Manual adjustment
The resistance can be changed by turning the
resistance knob. To increase the resistance
turn the knob clockwise, to decrease it counter
clockwise.
Computer controlled adjustment
The resistance can be Increased or decreased on the console (if applicable). Please consult the computer
manual for further information.

7
Exploded drawing

8
Part list
Part
Description
Qty
Part
Description
Qty
1
Main Frame
1
38
Power Adaptor
1
2
Pedal Arm (L)
1
39
Ø82_Slide Wheel , Urethane
2
3
Pedal Arm (R)
1
40~1
3/8" × 2"_Flat Head Socket Bolt
3
4
Lower Handle Bar (L)
1
40~2
Ø35 × 10m/m_Rubber Foot
3
5
Lower Handle Bar (R)
1
41
Console Mast Cover(L)
1
6
Bushing Housing, Pedal Arm
2
41~1
Console Mast Cover(R)
1
7
Connecting Arm (L)
1
42
Side Case (L)
1
8
Connecting Arm (R)
1
43
Side Case (R)
1
9
Cross Bar
2
44
Round Disk
2
10
Console Mast
1
45
Round Disk Cover
2
11
Idler Wheel Assembly
1
47
Pedal Arm Cover (L)
1
12
Crank Axle
1
48
Pedal Arm Cover (R)
1
13
Swing Arm (L)
1
50
Pedal (L)
1
14
Swing Arm (R)
1
51
Pedal (R)
1
15
Rail Assembly
1
52
Slide Wheel Cover
2
16
Rail Tube
2
53
Ø32(1.8T)_Button Head Plug
4
17
Axle for Pedal
2
54
Front Handle Bar Cover (L)
1
18
Axle for Slide Wheel
2
55
Rear Handle Bar Cover (L)
1
19
Ø11.9 × Ø8.5 × 15m/m_Rod End
Sleeve
3
56
Front Handle Bar Cover (R)
1
20
6005_Bearing
2
57
Rear Handle Bar Cover (R)
1
21
6203_Bearing
2
58
32 × 2.5T_Round Cap
2
22
6003_Bearing
8
59
Connecting Arm Cover A (L)
2
23
M12 × P1.75_Rod End Bearing
2
60
Connecting Arm Cover B (R)
2
24
Ø31 × Ø25.5 × Ø19 × 16+3T_Bushing
4
61
Middle Stabilizer Cover
2
25
Steel Cable
1
62
Rear Stabilizer Cover (L)
1
26
Drive Belt
1
63
Rear Stabilizer Cover (R)
1
27
Ø330_Drive Pulley
1
64
Ø40 × Ø80_Oval End Cap
2
28
Flywheel
1
65
Ø60_Transportation Wheel
2
29
Magnet
1
66
Ø31.8 × 3T × 420m/m_Handgrip
Foam
2
30
25 × 7 × 7m/m_Woodruff Key
2
67
Ø32 × 28T_Rubber Foot
2
31
Console Assembly
1
69
Bushing
1
32
1000m/m_Computer Cable
1
70
5/16" × 15m/m_Hex Head Bolt
14
33
600m/m_DC Power Cable
1
71
5/16" × 32m/m_Hex Head Bolt
2
34
Gear Motor
1
72
1/4" × 3/4"_Hex Head Bolt
4
35
300m/m_Sensor W/Cable
1
73
3/8" × 2-1/4"_Socket Head Cap Bolt
2
37
800m/m_Handpulse W/Cable
Assembly
2
74
M8 × 25m/m_Socket Head Cap Bolt
2

9
75
5/16" × 15m/m_Button Head Socket
Bolt
6
106
3.5 × 16m/m_Tapping Screw
3
76
3/8" × 2-1/4"_Button Head Socket Bolt
6
108
Combination M5 Allen Wrench &
Phillips Head Screw Driver
1
78
M5 × 10m/m_Phillips Head Screw
6
110
12m/m_Wrench
1
79
M5 × 15m/m_Phillips Head Screw
14
111
13.14m/m_Wrench
1
80
5 × 16m/m_Tapping Screw
7
112
5 × 19m/m_Tapping Screw
2
81
5 × 25m/m_Tapping Screw
2
114
3/8" × 23 × 2T_Curved Washer
5
82
4.8 × 38m/m_Sheet Metal Screw
1
119
3/8" × 2"_Hex Head Bolt
2
83
5 × 16m/m_Tapping Screw
12
120
3/8" × 2T_Split Washer
2
84
Ø3.5 × 12m/m_Sheet Metal Screw
14
121
3/8" × 3/4"_Hex Head Bolt
1
85
Ø25_C Ring
1
133
M5 × 10m/m_Phillips Head Screw
8
86
Ø17_C Ring
1
135
M8 × 9T_Nyloc Nut
1
87
M8 × 7T_Nyloc Nut
1
137
3/8" × 11T_Nyloc Nut
2
88
1/4"_ Nyloc Nut
4
142
3.5 × 16m/m_Sheet Metal Screw
8
89
3/8" × 7T_Nyloc Nut
4
143
Inner Slide
1
90
3/8" -UNF26 × 4T_Nut
3
144
Outer Slide
1
91
3/8" -UNF26 × 9T_Nut
2
145
Locking Knob
1
92
3/8" × 7T_Nut
6
146
Hook
2
94
3/8" × 19 × 1.5T_Flat Washer
12
147
Hook Sleeve
2
96
5/16" × 35 × 1.5T_Flat Washer
2
148
Hook Fixing Block (L)
1
97
5/16" × 23 × 1.5T_Flat Washer
10
149
Hook Fixing Block (R)
1
98
5/16" × 20 × 1.5T_Flat Washer
6
150
Hook Hanging Cap (Top)
1
99
1/4" × 19m/m_Flat Washer
13
151
Hook Hanging Cap (Bottom)
1
100
M8 × 170m/m_J Bolt
1
152
Bushing
4
101
Ø17_Wave Washer
4
153
M6 × 15m/m_Hex Head Bolt
2
103
M8 × 20m/m_Carriage Bolt
1
154
Ø6.5 × Ø25 × 1.5T_Flat Washer
2
104
Ø17 × Ø23.5 × 2T_Flat Washer
2
155
3/8" × 1-1/2"_Button Head Socket
Bolt
1
105
5/16" × 7T_Nyloc Nut
2
156
3/8" × 2"_Button Head Socket Bolt
1

10
Checklist
#120. 3/8" × 2T Split Washer (1pcs)
#94. 3/8" × 19 × 1.5T Flat Washer (2pcs)
#114. 3/8" × 23 × 2T Curved Washer
(5pcs)
#78. M5 × 10m/m Phillips Head Screw
(4pcs)
#121. 3/8" × 3 /4”Hex Head Bolt (1pcs)
#89. 3/8" × 7T Nyloc Nut (2pcs)
#76. 3/8" × 2-1/4”Button Head Bolt
(6pcs)
#119. 3/8" × 2" Hex Head Bolt (1pcs)
#75 5/16" × 15m/m Button Head Socket
Bolt (6pcs)
#84. Ø3.5 × 12m/m Sheet Metal Screw
(6pcs)
#70. 5/16" × 15m/m Hex Head Bolt
(2pcs)
#97. 5/16“x23x1,5T Flat Washer (2pcs)
#101. Ø 17 Wave Washer (2pcs)
#98. 5/16 × 20 × 1.5T Flat Washer
(2pcs)
#94. 3/8" × 19 × 1.5T Flat Washer (2pcs)
#71. 5/16" × 32m/m Hex Head Bolt
(2pcs)
#105. 5/16 × 7T Nyloc Nut (2pcs)
#89. 3/8" × 7T Nyloc Nut (2pcs)
#155. 3/8" × 1-1/2”Button Head Bolt
(1pcs)
#156. 3/8" × 2”Button Head Bolt (1pcs)
#84. Ø3.5 × 12m/m Sheet Metal Screw
(6pcs)
#79. M5 × 15m/m Phillips Head Screw
(12pcs)
Tools
#110. 12 mm Wrench (1pcs)
#111. 13 &14 mm Wrench (1pcs)
#108. Combination 5mm Allen Wrench
& Phillips Head Screw Driver (1pcs)
