Energetics CT 210 User manual

CT 210 HEIMTRAINER
GB
D
CZ
SK
H

2
Table of contents - Inhaltsverzeichnis - Obsah - Obsah - Tájékoztató
English
P
3
Deutsch
P
14
Česky
P
25
Slovensky
P
36
Magyar
P
47
© The owner’s manual is only for the customer reference. ENERGETICS can not guarantee for mistakes occurring due to translation or
change in technical specification of the product.
©Die Gebrauchsanweisung dient nur zur Referenz für den Kunden. ENERGETICS übernimmt keine Haftung für Fehler die durch
Übersetzung oder technische Änderungen des Produkts entstehen.
©Návod k použití je pouze doporučení pro zákazníky. ENERGETICS nepřebírá žádné ručení za chyby způsobené překladem či změnami v
technické specfikaci výrobku.
© Tento návod je určený len pre potrebu zákazníkov. ENERGETICS nezodpovedá za chyby, ktoré sa môžu vyskytnúť kvôli
chybnému prekladu alebo zmenám v technickej špecifikácii produktu.
© A használati útmutató kizárólag felhasználói referenciaként szolgál. az ENERGETICS nem vállal felelősséget a fordítási
hibákból vagy a termék műszaki módosításaiból eredő hibákért.
© Copyright by ENERGETICS

3
Dear Customer,
Congratulations on your purchase of an ENERGETICS home exerciser. This product has been designed
and manufactured to meet the needs and requirements of in-home use. Please carefully read the
instructions prior to assembly and first use. Be sure to keep the instructions for reference and/ or
maintenance. If you have any further questions, please contact us. We wish you lots of success and
fun while training,
Your - Team
Warranty
ENERGETICS offers high quality home exercisers that have been tested and certified according to
European Norm EN 957.
ENERGETICS warrants to the original purchaser 3 years against possible defects in material and
workmanship. Excluded are damages caused by misuse and wearing parts. All electronic parts are
warranted for a period of 1 year. The warranty period starts at the date the product was purchased
(retain your sales receipt).
Safety Instructions
Consult your physician before starting with any exercise programme to receive advice on the
optimal training.
Warning: incorrect/ excessive training can cause health injuries. Stop using the home
exerciser when feeling uncomfortable.
Ensure that training only starts after correct assembly, adjustment and inspection of the
home exerciser.
Always start with a warm-up session.
Only use original ENERGETICS parts as delivered (see checklist).
Follow the steps of the assembly instruction carefully.
Only use suitable tools for assembly and ask for assistance if necessary.
Place the home exerciser on an even, non-slippery surface.
Use the height adjustment caps on the rear tube to ensure a stable position of the home
exerciser.
Make sure the front wheels are placed in the correct position: see assembly instruction.
For all adjustable parts be aware of the maximum position to which they can be adjusted.
Tighten all adjustable parts to prevent sudden movement while training.
This product is designed for adults. Please ensure that children only use it under the
supervision of an adult.
Ensure that those present are aware of possible hazards, e.g. movable parts during training.
The resistance level can be adjusted to your personal preference.
Do not use the home exerciser without shoes or loose shoes.
Ensure that sufficient space is available to use the home exerciser.
Be aware of non-fixed or moving parts whilst mounting or dismounting the home exerciser.
This product is made for home use only and tested up to a maximum body weight of 100
kilograms
Keep special attention to the minimum insertion depth of the seat post.
GB

4
Handling
A. After assembly, the rear stabilizer can be adjusted to accommodate slightly uneven ground.
Turn the adjustment knobs on the ends of the rear foot caps to level the rear stabilizer to the
floor.
B. The transportation wheels on the front foot caps allow for easy manoeuvring. Simply pull
back on the handlebars until the wheels touch the floor. Then roll the unit to a desired
location.
C. The handle bar can be adjusted to personal preference. Loosen the handle bar fixing tube.
Rotate the handle bar to the desired position and retighten the fixing tube.
D. The height of the seat post can be adjusted by first loosening the height adjustment knob,
moving the seat post to the desired height then tightening the height adjustment knob.
Care and Maintenance
-The home exerciser should not be used or stored in a moist area because of possible
corrosion.
-Check at least every 4 weeks that all connecting elements are tightly fitted and in good
condition.
-In case of repair please ask your dealer for advice.
-Replace defective components immediately and/or keep the equipment out of use until
repair.
-Only use original spare parts for repair.
-Use a damp cloth to clean the Home Exerciser and avoid the use of aggressive detergents
when cleaning the bike.
-After exercising, immediately wipe of the sweat; perspiration can ruin the appearance and
proper function of the Home Exerciser.

5
Exploded drawing
14
13
12
15
16
64
51
19 66
67
38
34
26
35
62
61
18
17
39
40
33
36
37L
37R
63
45
44
43
42
41
60R
60L
59R
59L
58R
58L
29
28
31
30
32
11
21
22
10
6
1
52
50
49
46
48
53
47
56
55
50
54
20
22
21
24 25
57
65
68
2
8
9
3
7
4
27
23
69

6
Part list
Part
Description
Qty
Part
Description
Qty
1
Main frame
1
37L
Left crank
1
2
Front stabilizer
1
37R
Right crank
1
3
Rear stabilizer
1
38
Magnetic
1
4
Seat support
1
39
Anti-loosen Nut M6
4
5
Handlebar post
1
40
Bolt M6*15L
4
6
Handlebar
1
41
Sea washer D21*D16* 0.3T
2
7
Rear foot cap
2
42
Flat washer D24*D16*1.5T
1
8
Front foot cap
2
43
C-shaped ring
1
9
Foot roller
2
44
Bolt M8*25L
2
10
Square neck bolt M8*75L
4
45
Screw cap D23*6.5
2
11
Domed nut M8*1.25*15L
4
46
Flat washer D50*D10*1.0T
2
12
Seat
1
47
Spacer (small)
2
13
Flat washer M8
3
48
Flat washer D30*D10*3.2T
1
14
Nut M8
3
49
Idle wheel fixing plate
1
15
Spring knob
1
50
Nut D9.5x5T(3/8"-26UNF)
2
16
Inner tube
1
51
Club knob
1
17
Foam 530L
2
52
Spring
1
18
Round cap D7/8’’*17L
2
53
Idle wheel
1
19
Flat washerD28*D8.5*D3T
1
54
Anti-loosen Nut M10
2
20
Allen Bolt M8*20L
4
55
Flat washer D21*D10.5*2T
1
21
Spring washer D15.4*D8.2*2T
8
56
Magnetic system
1
22
Curved washer D22*D8.5*1.5T
8
57
Rubber ring
1
23
Computer ST8324
1
58L
Left chain cover
1
24
Upper computer cable
1
58R
Right chain cover
1
25
Lower computer cable
1
59L
Left decorative cover
1
26
Upper tension cable
1
59R
Right decorative cover
1
27
Handle pulse
2
60
L/R
Pedal set
1
Handle pulse cable
2
61
Screw ST4.2x1.4x20L
8
28
Protective cover
1
62
Screw ST4*10L
2
29
Bushing
1
63
Axle crank
1
30
Spring washer D15.4*D8.2*2T
1
64
Belt
1
31
Flat washer D16*D8.5*1.2T
1
65
Spacer
1
32
T-shaped knob
1
66
Oval cap
2
33
Bearing #99502
2
67
Seat adjustable tube
1
34
Lower tension cable
1
68
Flat washer D50*D10*2.0T
1
35
Screw M5*10L
1
69
Plastic cover
2
36
Belt wheel
1

7
Assembly instruction
Step 1
Assemble the front stabilizer (2) and rear stabilizer (3) to the main frame (1) by using the carriage
bolt (10), the curved washer (22), the spring washer (21) and domed nut (11).
Please note: You can adjust the height of the rear foot cap (7) if needed.
10
11
21
22
7
3
10
2
1
(x4)
AM8*1.25*75L
D22*D8.5*1.5T
D15.4*D8.2*2T
M8*1.25*15L
DOWN
UP
DOWN
UP
a
8
9

8
Step 2
1. Loose the three nylon nuts (14) and the three flat washers (13) under the seat (12). Fix the
seat (12) to the seat adjustable tube (67).
2. Assemble the adjustable tube onto the seat support (4) by Flat washer(19) and Club knob(51)
3. Loose the Adjustable knob (15) on the main frame and Slide the seat support (4) onto the
rear stem of the main frame and secure with the knob (15) in a proper height.
13
14
12
67
1
15
(x3)
B
M8*1.25*8T
D16*D8.5*1.2T
C
BACKWARD
FRONTWARD
AB
UP DOWN
4
51
19
67

9
Step 3
1. Connect the computer cable (24&25) and tension cable (34 & 26).
2. Assemble the handlebar post (5) to the main frame (1) by using the bolt (20), the spring
washer (21) and curved washer (22).
1
C(x4)
D15.4*D8.2*2T
D22*D8.5*1.5T
M8*1.25*20L
34
26
5
25
24
21
20
22
(A)(B)
A-1
A-2
A-3
A-4

10
Step 4
Assemble the handlebar (6) to the handlebar post (5) by the protector cover (28), the bushing (29),
the spring washer (30), the flat washer (31) and T-shaped knob (32).
6
30
29
32
31
28
5
DOWN
UP
a
