EOS SBM GLT KNX User manual

Druck-Nr.: 2934 5021
Stand: 1.1/2019
EN
Made in Germany
SBM GLT KNX
KNX Home-Modul for
building management systems
Installation and Operating Instructions

2 Installation and Operating Instructions - KNX Home-Modul
Documentation
EN
Documentation
Manufacturer
Original installation instructions EN
Copyright for these installation instructions remains with
EOS Saunatechnik GmbH.
Copyright as per DIN ISO 16016:
The copying and distribution of this document, as well as the use and com-
munication of its contents without express authorization, are not permit-
ted. Compensation will be claimed in the event of infringements.
All rights reserved with regard to patent claims or submission of design or
utility patent.
Characters, symbols and illustrations
Revision history
EOS Saunatechnik GmbH
Schneiderstriesch 1
35759 Driedorf, Germany
Tel. [phone]
Fax [phone]
Web www.eos-sauna.com
Additional information about an operating step
Cross-reference to a page
Read instructions
Result of a step
Table title
Title of figure
Date Version Description
January 1st 2019 01.00 First version
March 2019 01.10 Safety instructions added

KNX Home-Modul - Installation and Operating Instructions 3
Contents
Documentation......................................................................................................... 2
1 General safety instructions................................................................................. 4
1.1 Safety levels....................................................................................................... 4
1.2 Mounting and electrical installation ........................................................5
1.3 Operator instruction ...................................................................................... 5
1.4 Standards and regulations ..........................................................................7
2 Identification .............................................................................................................8
2.1 Unit specifications .........................................................................................8
2.2 Intended use.....................................................................................................9
3 Description of the unit ........................................................................................10
3.1 Housing ............................................................................................................11
3.2 Communication functions.........................................................................12
3.3 Sample installation.......................................................................................13
3.4 Circuit boards .................................................................................................14
4 Mounting and electrical installation............................................................15
4.1 Mounting the KNX Home-Modul ............................................................15
4.2 Connecting the KNX Home-Modul with the S bus ...........................17
4.2.1 Connecting the S bus cable to the relay box or module18
4.3 Configuring addresses for multi-cabin installations ........................20
4.4 KNX programming........................................................................................21
4.5 Emotec, EmoStyle, EmoStyle i, Emotec IR, InfraStyle, InfraStyle i
data communication ...................................................................................21
4.6 EmoTouch 3 data communication .........................................................24
5 General terms and conditions of service ...................................................26
6Disposal......................................................................................................................29

4 Installation and Operating Instructions - KNX Home-Modul
General safety instructions
EN
General safety instructions
1.1 Safety levels
Safety instructions and important operating instructions are clas-
sified according to ANSI Z535.6. Please familiarise yourself with the
following terms and symbols:
DANGER
Danger
Indicates a hazardous situation which, if not avoided, will result in
death.
WARNING
Warning
Indicates a hazardous situation which, if not avoided, could result
in death or serious injury.
CAUTION
Caution
Indicates a hazardous situation which, if not avoided, could result
in minor or moderate injury.
NOTICE
Notice
Indicates a hazardous situation which, if not avoided, will result in
damage to the unit.

KNX Home-Modul - Installation and Operating Instructions 5
General safety instructions
1.2 Mounting and electrical installation
These installation instructions are intended for qualified person-
nel familiar with the laws and regulations applicable to electrical
installations at the installation site. Observe the following general
safety instructions during mounting, configuration and commis-
sioning of the product.
Refer also to the installation instructions for the units to which you
connect the KNX Home-Modul. See also:
2.2 Intended use, 9
Risk to life and limb
and risk of fire
Risk to life and limb from electric shock and fire in the event of im-
proper or faulty electrical connection. This risk also applies follow-
ing completion of the installation work.
The electrical installation of the relay box and other electrical
systems or equipment with a fixed mains connection must only
be performed by a trained electrician from an authorised elec-
trical company.
Observe the stipulations in VDE 0100 part 701.
The system must be disconnected and removed entirely from
the mains supply before commencing installation and repair
work.
The housing cover must only be removed by a specialist.
Do not install control units, relay boxes and modules in en-
closed cabinets or wood panelling.
1.3 Operator instruction
During commissioning, the operator of the sauna cabin, infrared
cabin or steam room must be instructed in relation to the follow-
ing general safety instructions: The operator must be given a copy
of the instructions for use.
Risk of electric shock A risk to life and limb from electric shock and fire arises in the event
of improper repair work. This risk also applies after work is com-
pleted.
The housing cover must only be removed by a specialist.
Repairs and installations must only be performed by a trained
specialist.
The system must be disconnected and removed entirely from
the mains supply before commencing repair work.
Use only original spare parts from the manufacturer.

6 Installation and Operating Instructions - KNX Home-Modul
General safety instructions
EN
Risk of burns and
chemical burns
Touching hot parts may lead to skin burns and chemical burns of
the skin.
The operator must be familiar with the unit’s hot parts and be
able to identify them.
The operator must be familiar with the settings for the heating
period and understand how it is controlled.
Health risks Spending time in a sauna cabin, infrared cabin or steam room can
lead to serious health risks or even death for persons with health
impairments.
Persons with health impairments must consult a doctor before
using a sauna cabin, infrared cabin or steam room.
Equipment damage
due to overuse
Excessive humidity in commercial sauna cabins, infrared cabins or
steam rooms can lead to property damage.
In a commercial sauna cabin, infrared cabin or steam room, the
heating period must be set so that the heating switches off au-
tomatically after a specific period of time.
If the heating does not switch off automatically after a defined
heating period, cabin use must be supervised at all times.
Inspect the cabin before each use.
Operation by
children or persons
with reduced mental
capacity
Children and persons with reduced mental capacity can be a risk.
Children must be supervised to ensure they do not play with
the unit.
Operation of a sauna cabin, infrared cabin or steam room must
not be started by children under 8 years of age.
The settings for the heating period must only be used by chil-
dren under 8 years of age if they are supervised by an adult.
Operation of a sauna cabin, infrared cabin or steam room must
not be started by persons with reduced mental capacity or lim-
ited physical or sensory abilities unless they are supervised or
unless they have already been instructed in its use and under-
stand the risks.
Children and persons who have not received proper instruction
must not clean or service the system.

KNX Home-Modul - Installation and Operating Instructions 7
General safety instructions
1.4 Standards and regulations
The following standards, in their currently applicable versions, were
observed during design and construction.
Local regulations also apply to the installation and operation of heating,
sauna, and steam room systems.
Standard Title
DIN EN 60335-1 Household and similar electrical appliances – Part 1: General requirements
DIN EN 60335-2-30 Household and similar electrical appliances – safety – Part 2-30: Particular require-
ments for room heaters
DIN EN 60335-2-53 Household and similar electrical appliances – safety – Part 2-53: Particular require-
ments for sauna heating appliances and infrared cabins
DIN EN 60335-2-96 Household and similar electrical appliances – safety – Part 2-96: Particular require-
ments for heating equipment
DIN EN 55014-1 Electromagnetic compatibility – Requirements for household appliances, electric
tools and similar apparatus – Part 1: Emission
DIN EN 55014-2 Electromagnetic compatibility – Requirements for household appliances, electric
tools and similar apparatus – Part 2: Immunity

8 Installation and Operating Instructions - KNX Home-Modul
Identification
EN
Identification
The KNX sauna bus module for building management systems (SBM GLT
KNX), also referred to as the KNX Home module, is used to connect sauna
cabins, infrared cabins and steam rooms to a building management
system.
2.1 Unit specifications
Nameplate
The nameplate is attached to the front of the upper part of the housing.
Nameplate (example)
Requirements for operation and storage
The KNX Home module must only be mounted outside of sauna cabins,
infrared cabins and steam rooms. The mounting location must fulfil the fol-
lowing climate conditions:
Ambient temperature during operation -10°C to 40°C
Storage temperature -20°C to 60°C
A Name E Manufacturer
B Model F Protection class
C Item number G Manufacturing date
D Country of origin H Serial number
Saunabusmodul
Type SBM GLT KNX
Art.-Nr. 94 7078 00
Made in Germany
EOS-SAUNATECHNIK GmbH, 35759 Driedorf
S-No. 17.18 00001
IPX4
TP
S
R
A
B
C
D
E
F G H

KNX Home-Modul - Installation and Operating Instructions 9
Identification
2.2 Intended use
The KNX Home module is intended to be connected to a building manage-
ment system. It serves to remotely control selected functions in sauna cab-
ins, infrared cabins and steam rooms.
The following control units support this control:
Emotec, Emotec IR (software release R. 3.44 or higher)
EmoStyle, InfraStyle (software release R. 3.44 or higher)
EmoStyle i, InfraStyle i (software release R. 3.44 or higher)
EmoTouch 3 (also SteamRock Premium, software release R. 2.08 or
higher)
Check the software release of your control unit. Perform an update if nec-
essary.
Foreseeable misuse
The following are considered instances of foreseeable misuse:
The connecting cables are connected incorrectly.
The cabin addresses are programmed incorrectly.
The unit is operated after technical or other modifications are made to
the relay box.
The unit is operated by children or persons with reduced mental capac-
ity or by persons who have not been thoroughly instructed in its use.

10 Installation and Operating Instructions - KNX Home-Modul
Description of the unit
EN
Description of the unit
The KNX Home module allows you to monitor and control cabin-control
functions using a building management system. This enables monitoring
of individual cabins or a complete multi-cabin installation.
In a multi-cabin installation, a KNX Home module is connected for each
cabin.
The KNX Home module transfers data between the sauna bus and the KNX
bus in both directions. Its use is configured using the building manage-
ment system. The KNX Home-Modul should be operated with software ver-
sion ETS5 or higher.
Scope of delivery
The SBM GLT KNX is encased in a plastic housing. The housing completely
encloses the circuit board and the electronics.
The following components are included in the scope of delivery:
KNX Home-Modul
Wood screws 4 x 25 mm
4 anchors
S bus cable 10 m, with 2 RJ12 plugs

KNX Home-Modul - Installation and Operating Instructions 11
Description of the unit
3.1 Housing
Two circuit boards are used to establish a connection from the sauna bus
to the KNX bus. The plastic housing completely encloses the circuit boards.
Power is supplied via the bus line.
Top piece of KNX Home module
A KNX circuit board
B Terminals for KNX lines
C Cable feed opening
D S bus connection (S bus)
E S bus circuit board (bottom)
B
D
E
A
C

12 Installation and Operating Instructions - KNX Home-Modul
Description of the unit
EN
3.2 Communication functions
The KNX Home module provides the following communication functions.
The data type is defined by the KNX association.
Settings made using a setpoint enable changes during operation. The
actual value supplies current data from the cabin. A feedback mechanism
sends a signal when changes are made in the cabin.
No. Name Function Data type Selection Setting
0Cabin lighting Switch 1 bit ON/OFF Control > cabin light On/Off or 0–100%
1Sauna Switch 1 bit ON/OFF Control >
Temperature in the
sauna
On/Off or SET-
POINT
2Vaporiser tank Switch 1 bit ON/OFF Control >
Vaporiser tank
On/Off or SET-
POINT
3Light setpoint Setpoint 1 byte Control > cabin light 0–100%
4Temperature setpoint Setpoint 2 bytes Control >
Temperature in the
sauna
SETPOINT
0–65,535
5Humidity setpoint Setpoint 2 bytes Control >
Vaporiser tank
SETPOINT
0–65,535
6Actual light value Measurement 1 byte Measurements > cabin
light
On/Off
7Actual temperature value Measurement 2 bytes Measurements > Tem-
perature in the sauna
On/Off
8Actual humidity value Measurement 2 bytes Measurements > Tem-
perature in the sauna
On/Off
9Light feedback Switch feedback 1 bit ON/OFF Control > cabin light On/Off or 0–100%
10 Sauna feedback Switch feedback 1 bit ON/OFF Control >
Temperature in the
sauna
On/Off or SET-
POINT
11 Vaporiser tank feedback Switch feedback 1 bit ON/OFF Control >
Vaporiser tank
On/Off or SET-
POINT
12 Potential-free contact
(PFC) switch
Switch 1 bit ON/OFF Control >
Potential-free
contact
On/off
13 PFC feedback Switch feedback 1 bit ON/OFF Control >
Potential-free
contact
On/Off

KNX Home-Modul - Installation and Operating Instructions 13
Description of the unit
3.3 Sample installation
Individual functions can be activated in a standard installation, e.g. Sauna
on/off, Cabin light on/off.
Installation for switch functions
In an advanced installation, the data can be transferred to an app via a
router and the activated functions can then be operated using the app.
Installation with monitoring and switch functions
A Switch, e.g. at reception
B KNX interface
C Power supply
D Circuit board/KNX module
10
1 2
1
16
J1
LED1
R53
SW1
R5
C12
C7
C1 IC4
IC6
R4
R7
R9
R10
R24 OK2
R45
SL1
IC2
D1
D2
L1
L3
R11
R12
C3
KL1
IC8
R13
R15
R16
R18 C6
C10 IC7
L4
C5
D5
OK4
C13
C14
C15
C16
C17
C18 R1
R2
IC1
243-211
LED2mA rt
SKHUAKE010
10nF/50V
1uF/50V
NCP4641H050T1G
ADUM1251
ACPL214
PVL10
LTC2862CS 8-1
SMBJ30CA
SMBJ30CA
742792693
742792693
100nF/50V
210-A-111/03 ADUM5201W
1uF/50V
NCP4641H033T1G
742792641
1uF/50V
SMBJ33A
LTV208
100nF/50V
100nF/50V
100nF/50V
100nF/50V
10μF/16V10μF/16V
KIMAIP
A B C D
2
KNX TP
2
A Touch panel/smartphone
B Switch/router
C KNX IP router
D KNX power supply
E Circuit board/KNX module
10
1 2
1
16
J1
LED1
R53
SW1
R5
C12
C7
C1 IC4
IC6
R4
R7
R9
R10
R24 OK2
R45
SL1
IC2
D1
D2
L1
L3
R11
R12
C3
KL1
IC8
R13
R15
R16
R18 C6
C10 IC7
L4
C5
D5
OK4
C13
C14
C15
C16
C17
C18 R1
R2
IC1
J1A
243-211
LED2mA rt
SKHUAKE010
10nF/50V
1uF/50V
NCP4641H050T1G
ADUM1250
ACPL214
PVL10
LTC2862CS8-1
SMBJ30CA
SMBJ30CA
742792693
742792693
100nF/50V
210-A-111/03 ADUM5201W
1uF/50V
NCP4641H033T1G
742792641
1uF/50V
SMBJ33A
LTV208
100nF/50V
100nF/50V
100nF/50V
100nF/50V
10μF/16V10μF/16V
KIMAIP
n.b.
A DB C E
82
2
24 C VC
KNX TP

14 Installation and Operating Instructions - KNX Home-Modul
Description of the unit
EN
3.4 Circuit boards
The housing contains two combined circuit boards. The upper circuit
board establishes a connection to the building management system, while
the lower circuit board is used for sauna control.
KNX module circuit boards
A Upper circuit board for KNX bus connection E KNX programming LED
B Terminals for KNX bus F KNX programming button
C Lower circuit board for S bus connection G LEDs for S bus status display
D S bus connection H Programming button for S bus cabin address
10
1 2
C31
R8
R14
C33
D9
D17 IC3
L2
L5
L6
L7
C8
R47
D29
D28
C26
D24
C2
D3
D4
R1
R17
C9
SW2
R2 R6C4
LED2
R3
LED3
R58
C22
SL2
R19 R20
R21
R22
R23
R25
R26
C11
C6
C10
IC7
J1
IC6
0R
10
1 2
1
16
J1
LED1
R53
SW1
R5
C12
C7
C1 IC4
IC6
R4
R7
R9
R10
R24 OK2
SL1
IC2
D1
D2
L1
L3
R11
R12
C3
KL1
IC8
R13
R15
R16
R18 C6
C10 IC 7
L4
C5
D5
OK4
C13
C14
C15
C16
C17
C18 R1
R2
IC1
F
A
H
B
D
C
E
G

KNX Home-Modul - Installation and Operating Instructions 15
Mounting and electrical installation
Mounting and electrical installation
This chapter describes how to mount and wire the SBM GLT KNX.
NOTICE
Equipment damage
Corrosive environments or environments with high levels of saline
in the air could damage lines and circuit boards.
Only use the KNX Home-Modul in a non-corrosive environment.
4.1 Mounting the KNX Home-Modul
Tools + hardware
Drill
Wood screws 4 x 25 mm
Mounting on a fixed wall: Screws 4 x 25 mm and suitable anchors
The KNX Home-Modul is intended to be mounted on the outer wall of the
cabin or in the utility room. The maximum cable length between the relay
box and the KNX Home-Modul is 10 m.
Mounting the housing
1Drill 2 holes at the top and another 2 at the bottom of the wall.
The housing can be mounted either vertically or horizontally.
2Use anchors if necessary.
3Loosen the housing screws on the cover.
Horizontal distance between drill holes: 63.5 mm
Vertical distance between drill holes: 113.5 mm

16 Installation and Operating Instructions - KNX Home-Modul
Mounting and electrical installation
EN
4Attach the bottom piece to the mounting location using the screws pro-
vided.
Bottom piece of SBM GLT KNX housing
Wiring the connections
1Feed the connection cable through the opening on the top piece of the
housing.
Upper piece of SBM GLT KNX housing
2Plug the S bus line into the RJ12 jack.
3Plug the KNX lines into the terminal block.
Carefully pull back any excess cable length or place it in a loop in the
bottom piece of the housing.
A Terminal block for KNX lines C Cable feed opening
B RJ12 jack for sauna bus line
A
B
C

KNX Home-Modul - Installation and Operating Instructions 17
Mounting and electrical installation
4Configure the S bus address if necessary. See:
4.3 Configuring addresses for multi-cabin installations, 20
5Program the KNX address and user software. See:
4.4 KNX programming, 21
6When all settings have been completed, place the top piece of the hous-
ing on top and attach it using the 4 housing screws.
4.2 Connecting the KNX Home-Modul with the
Sbus
On the circuit board of the relay box or add-on module, you will find
2 connection jacks for the S bus lines. Four connection jacks are provided
with the SteamRock Premium.
Sample installation:
In a standard installation, the control unit and the KNX Home-Modul are
plugged into the relay box.
Standard installation
In the advanced installation, the control unit and the add-on module
are connected to the relay box. The KNX Home-Modul is connected to
the add-on module.
A Relay box circuit board C KNX Home-Modul
B Control unit
S
-Bus
S
-Bus
B
C
A

18 Installation and Operating Instructions - KNX Home-Modul
Mounting and electrical installation
EN
Advanced installation
In the case of a multi-cabin installation with the EmoTouch 3 control
unit, the KNX Home-Modul must be installed in the same S bus seg-
ment as the relay box that is to be controlled. It may also be necessary
to use an S bus plug-in module. The S bus address of the cabin to be
controlled must be configured in the KNX Home-Modul.
4.2.1 Connecting the S bus cable to the relay box or module
NOTICE
Incorrect data transfer due to incorrect installation
The software does not recognise the KNX Home-Modul. Data is
transferred incorrectly.
Only plug S bus cables into S bus jacks on the circuit board.
Only connect one KNX Home-Modul per cabin.
A Relay box circuit board C Add-on module circuit board
B Control unit D SBM GLT KNX
S
-Bus
S
-Bus
S
-Bus
S
-Bus
C
A
D
B

KNX Home-Modul - Installation and Operating Instructions 19
Mounting and electrical installation
Connecting the S bus
1DANGER! Ensure that there is no voltage present on the circuit board.
Disconnect the circuit board entirely from the mains supply.
2Remove the housing cover.
3Plug the plug into an S bus jack on the circuit board.
Circuit board sections for S bus jacks
4Replace the housing cover on the relay box and switch the power supply
back on.
SENSOR
SENSOR
SENSOR
SENSOR
S-BUS
SENSOR
SENSOR
SENSOR
S-Bus
S-Bus
SENSOR
SENSOR
SENSOR
S-Bus
S-Bus
Sauna relay box IR relay box
IR module
SteamRock

20 Installation and Operating Instructions - KNX Home-Modul
Mounting and electrical installation
EN
4.3 Configuring addresses for multi-cabin
installations
You only need to configure S bus addresses in a multi-cabin installation
with an EmoTouch 3 control unit. The S bus address of the cabin you want
to control must be configured in the KNX Home-Modul for this purpose.
The Emotec, EmoStyle, EmoStyle i, Emotec IR, InfraStyle and InfraStyle i
always require the cabin address 1.
Programming the address
1Keep the programming button pressed for approx. 5-6 seconds until the
red LED lights up.
Programming mode is then active. The green LED light goes off.
2Quickly press the programming button once for each new address. As
delivered (address 1), this means:
a) Press once for cabin 2. The LED flashes twice.
b) Press twice for cabin 3. The LED flashes three times.
c) Press three times for cabin 4. The LED flashes four times.
d) Press four times for cabin 5. The LED flashes five times.
e) Press five times for cabin 6. The LED flashes six times.
f) Press six times for cabin 7. The LED flashes seven times.
g) Press seven times for cabin 8. The LED flashes eight times.
Note that each time you press the programming button, the cabin
address increases by one. Once address 8 is reached, the count start
over with address 1.
The green LED flashes 1 to 8 times, depending on the new cabin
address.
If power is lost, the most recent address setting is automatically
saved.
If the button is not pressed for approx. 15 seconds, programming
mode ends. The red LED goes off and the green LED starts flashing. The
new address is saved.
C
3
1
R
8
R
1
4
C
3
3
D
9
D
1
7
I
C
3
L
2
L
5
L
6
L
7
C
8
R
4
7
D
2
9
D
2
8
C
2
6
D
2
4
C
2
D
3
D
4
C
9
L
R
C
2
2
R
1
9
R
2
0
R
2
1
R
2
2
R
2
R
2
R
2
6
C
6
C
1
0
I
C
7
J
1
I
C
6
0
R
R
R17
SW2
R2 R6C4
C11
R1
R17
SW2
R2 R6C4
C11
