Epoch Design Peyton 5149 User manual

Congratulations on the purchase of your Peyton Storage Trundle Platform Bed. This bed has been crafted to the highest
standards of quality and safety and will give you many years of enjoyment and practical use.
On this insert you will nd a list of the hardware, platform bed and trundle parts as well as detailed assembly instructions.
Assembly is quite simple and requires only a at head screwdriver and a Phillips head screwdriver. The use of a power drill
with Phillips head attachment is helpful but not necessary. Assembly will be most easily accomplished if you take the time
to carefully sort the hardware and familiarize yourself with the function of each piece.
If you need assistance with assembly, part replacement or any other matter, please contact the toll-free Epoch Design
Customer Service Team from Monday through Friday, 9 AM-5 PM PST at 1 [phone]. You may also email your
request or comments to [e-mail] and a customer service representative will respond.
Thank you and Enjoy
EPOCH DESIGN , LLC Peyton Storage Trundle
Platform Bed
5149: PN-FU-XB-ES
01-Oct-20181/4
HARDWARE LIST
16x 35mm bolts
Used to connect front
& back panels
48x 30mm slat screws
Used to secure
slats to rails
1x Hex key
Used to tighten
bolt hardware
98x 20mm wood screws
Used to attach wheels,
bottom planks &
bottom panels
4x 15mm wood screws
Used to secure
center support
1x Slat bundle
Rest on side rails and supports
mattress (strap side down)
PARTS
HAVE QUESTIONS OR CONCERNS? CALL US FIRST: 1-800-589-7990
Copyright © 2018 Epoch Design™ All rights reserved
1x Headboard
2x Side rails
To connect end boards
2x Trundle Bed
End Panels (Long)
2x Storage Drawer
End Panels (Short)
2x Left & Right Trundle Brace
(Long)
2x Trundle Bottom Planks
(Left & Right)
1x Trundle Bottom Plank
(center)
2x Storage Drawer
Bottom Planks (Left & Right)
2x Storage Drawer
Dividers (Short)
1x Trundle Divider
(Long)
9x Non Marring Wheels
1x Middle Trundle
Brace (Long)
2x Front Panels
For Trundle
& Storage Drawer
6x Wire Retainers 4x Wooden Dowels
2x Back Panels
For trundle
and storage drawer
1x Center Support
1x Footboard
2x Middle Drawer
Brace (Short)
2x Left & Right
Drawer Brace
(Short)
mm 10 20 30 40

A
Unroll slat bundle (strap side down) onto side rail ledges
evenly from end to end. Using the slat screws provided,
screw the slat closest to the headboard to the two
outside slat rails.
Then screw the slat closest
to the footboard to the two
outside rails. Then proceed to
secure the remaining slats in any order.
*NOTE: A power screwdriver
with the clutch set on
low is useful here.
*NOTE: Do not tighten any of these bolts
until all of them are threaded
part of the way.
Make sure the slat rail is facing the inside of the bed then slide one
rail into the grooves of the headboard (A).
Repeat this process with the other side rail.
1 2
3
Attach the long plank braces and long
middle plank brace to the trundle
with 30mm wood screws.
5
4
6
Have a question? Need a part ASAP? Call 1-800-589-7990 or email [e-mail].
NOTE: If bedrail hook bracket does not drop fully down into the head/footboard bracket,
adjust the hook bracket on the bedrail end by loosening the three screws one half turn each.
Next, do the same with
the other end of the rails
into the footboard (B).
Then tap the top of the rail ends gently with a rubber
mallet to make sure the connections are secure.
LEDGE IN
B
M
I
D
D
L
E
P
L
A
N
K
Put the center support into the
center support brackets.
Secure the center support with
15mm wood screws (C).
C
D
E
Attach long end panels to the front and back
panels with wooden dowels. (D) Use 35mm bolts
to tighten the long end panels with the front and
back panel (E).
First slide the front &
back bottom planks into
place with the countersunk holes
for the 20mm wood screws face up.
Then place the center plank in place,
counter sunk hole side up, and secure the
planks into place with the 20mm wood screws.
FRONT 1
CENTER 3
BACK 2
01-Oct-20182/4 PLATFORM BED
TRUNDLE BED

OPTIONAL STORAGE
8
Carefully ip the trundle over and place it
on a soft surface such as a blanket or
carpet to prevent scratching of your
new drawer. Attach wheels with four
20mm wood screws per wheel as
shown. (Diagram F).
Carefully ip the storage drawer
over and place it on a soft surface
(such as a blanket or carpet).
Attach wheels with
four 20mm wood screws
per wheel as shown.
(Diagram J)
To use the trundle bed as a storage drawer, simply
remove the mattress, insert the wire retainers on both
sides of the trundle (Diagram G), and slide the drawer
divider down the grooves on the divider
into the wire retainers.
7
9
11 12
10
Have a question? Need a part ASAP? Call 1-800-589-7990 or email [e-mail].
F
G
I
Insert and tighten the
20mm wood screws.
M
I
D
D
L
E
P
L
A
N
K
Note: Do not tighten any of the bolts until all of
them have been threaded at least part way.
H
J
Attach short end panels to the front and back panels with wooden
dowels. (Diagram H)Use 35mm bolts to tighten the short end
panels with the front and back panel (Diagram I).
Attach the short plank braces and short
middle plank brace to the trundle with
30mm wood screws.
Lay the bottom planks into the storage drawer.
The top side of the planks will
have countersunk holes for
the 20mm wood screws (L).
STORAGE DRAWER
01-Oct-2018
3/4

OPTIONAL COMPARTMENTALIZED STORAGE
13
To compartmentalize the storage drawer, simply add the wire retainers and the wooden dividers as you wish in order to achieve
your desired size storage area (See Diagram K).
Congratulations, you are now
ready to enjoy your Peyton
Storage trundle platform bed.
Place your storage drawer and trundle
drawer under your platform bed.
