Epoch Design Astoria 5190 User manual

Congratulations on the purchase of your Astoria Hardwood Bunk Bed. This bed has been crafted to the
highest standards of quality and safety and will give you many years of enjoyment and practical use.
Your bunk bed can be separated into two individual twin beds if the need arises for alternate sleeping
congurations.
Since this bed is a natural wood product, there will be variations in color and grain, and minor checking
may occur. This is normal and does not compromise the integrity of your bed. In fact, variation in
character of solid hardwood is integral to the beauty and appeal of hardwood furniture, and
distinguishes it from prefabricated, synthetic and composite materials.
Several basic safety considerations must be adhered to when using this bunk bed.
• Never allow a child under 6 years on upper bunk
• Always use the recommended size mattresses or mattress supports - standard twin 38"x 74" (96.5 cm x 188 cm)
- to help prevent the likelihood of entrapment or falls
• Ensure thickness of mattress does not exceed 9" (22.9 cm) for the upper bed
• Surface of mattress must be at least 5" (12.7 cm) below upper edge of safety rails
• Always use safety rails on both sides of upper bunk
• Do not allow horseplay on or under bed(s) and prohibit jumping on the bed(s)
• Prohibit more than one person on upper bed
• If the bunk will be placed next to a wall, the safety rail that runs the full length of the bed should be placed
against the wall to prevent entrapment between the bed and the wall
• Follow the information on the warnings appearing on the upper bunk end board and on the carton
• Do not remove warning label from bed
• Periodically check and ensure that the safety rails, ladder and other components are in their proper positions,
free from damage, and that all connectors are tight
• Do not use substitute parts
• Contact manufacturer or dealer for replacement parts
• The use of a water or sleep otation mattress is prohibited
• Keep these instructions for future reference
• Use of a night light may provide added safety precaution for a child using the upper bunk
• STRANGULATION HAZARD- Never attach or hang items to any parts of the bunk bed that are not designed
for use with the bed, including but not limited to hooks, belts or jump ropes
On this insert you will nd a list of the hardware and bunk bed parts included, as well as detailed
assembly instructions. Assembly is quite simple, and requires only a at head screwdriver and a Phillips
head screwdriver. The use of a power drill with Phillips head attachment is helpful but not necessary.
Assembly will be most easily accomplished if you take the time to carefully sort the hardware and
familiarize yourself with the function of each piece.
If you need assistance with assembly, part replacement, or any other matter, please contact the toll-free
Epoch Design Customer Service Team from Monday through Friday, 9 AM-6PM PST at
1 [phone]. You may also email your request or comments to [e-mail]
and a customer service representative will respond.
Thank you and Enjoy
TO HELP PREVENT SERIOUS OR FATAL INJURY FROM ENTRAPMENT OR FALLS:
Astoria Hardwood Bunk Bed
5190: AS-TT-BB-NB
5192: AS-TT-BB-CO
13-Aug-20181/4
HAVE QUESTIONS OR CONCERNS? CALL US FIRST: 1-800-589-7990
Copyright © 2018 Epoch Design™ All rights reserved

2x Lower bunk Side rails
Connect lower end boards
2x Short end boards
Used on upper bunk
2x Tall end boards
Used on lower bunk
2x Upper bunk side rails
Connects upper end boards
has pre-installed propel nuts to
attach safety rail.
2x Long safety rails
Used for attachment to upright
supports on wall side of bunk
2x Slat bundles
Rests strap side down on
side rails and supports mattress
16x 110 mm bolts
Used to connect headboards
and footboard to side rails
16x 40 mm bolts
Used to assemble long
safety rails and connect
safety rails to side rails
16x Barrel nuts
Used to secure bolts
4x Bunk connector pin
To connect lower
bunk to upper bunk
56x 30 mm Slat screws
Used to secure slats
to side rails
2x 15 mm Round head screw
Used to attach ladder
hooks to side rails
1x Short safety rail
Used on upper bunk
1x Hex key
To tighten
bolt hardware
2x Upright supports
Used for attachment
to long safety rails
Ladder
Attaches to upper side rail
for entry to upper bunk
Ledge
Haveaquestion? Need a part ASAP? Call 1-800-589-7990 or email [e-mail].
13-Aug-20182/4
mm 10 20 30 40 50 60 70 80 90 100 110

Have a question? Need a part ASAP? Please call 1-800-589-7990 (Monday through Friday 9am to 5pm PST).
D
NOTE: Preinserted propel nut
heads face away from
40 mm bolts
To assemble the long safety rail use 40mm
bolts to install the 2 long safety rails to the
2 upright supports. (Diagram D)
**Note: A power screwdriver with clutch set on
low is useful here. (See Diagram C).
Attach the long safety rail to the side rail along
the back wall side of the upper
bunk using 40mm bolts,
again making sure the
propel nuts face away
from the bolts.
C
Unroll the slat bundle and lay it out strap
side down on the upper bunk.
Using a Phillips head
screwdriver and 30mm
slat screws secure the rst
slat on one end, then the
nal slat on the other end
making sure the slats have
been distributed evenly.
Then secure the remaining
slats to the rails.
A
1
5
4
6
3
2
B
pre-installed
propel nuts
To assemble upper bunk, arrange the short end boards and upper
bunk side rails (with pre-drilled holes for safety rail attachment) ledge
side in as shown.
Insert eight barrel nuts into the upper
bunk side rails (See Diagram A).
Insert eight 110mm bolts through end boards
and into barrel nuts in the side rails then tighten
with the hex key provided (Diagram B).
Attach the short rail
on the side of the bunk
accessed by the ladder.
To assemble lower bunk, repeat
procedure used for upper bunk using
taller end boards.
Repeat step 2, securing the second slat bundle
(strap side down) to the lower bunk.
Tighten 110mm bolts
to barrel nuts with hex key.
13-Aug-20183/4

Have a question? Need a part ASAP? Please call 1-800-589-7990 (Monday through Friday 9am to 5pm PST).
7
8
Insert a bunk connector
pin into each corner
post of the lower unit.
You may permanently affix the ladder
by using the 15 mm round head screws.
Now use the hex key to retighten all
bolts so that bunk bed assembly is rigid.
Keep your hex key in a safe place,
as it will be necessary to occasionally
retighten all of the bunk hardware.
Place the upper bunk
assembly on top of the
lower bunk.
