AWLA Assembly Guide
1

Tool Required
Hex Allen Key
keilhauer.com
Proceed to fasten the remaining screws to the pilot holes located above the foot rail, using
the 1/4-20 x 3/4” Hex socket button head cap screws (x4) using the drill , Hex driver or
Hex key. Proceed to fully tighten the the screws fastened to the legs in Step 1.
Hardware Included
Feed the power cable up and into the channel leg, then install plate to secure (illustrated
above) with wood screw #8 X 1” (x4).
Prior to installing the foot rail, ensure the black cable channel cover is placed over the cable
channel leg. Fasten with 1/4-20 x 5/8” flat head socket head cap screw (x6).
AWLA Counter & Bar Height Powered Assembly Instructions
12
1/4-20 x 5/8” flat
head socket head
cap screw (x6)
With a minimum of two assemblers, proceed to flip the table and place in its final position.
The table top can now be completely unwrapped.
DO NOT COMPLETELY UNWRAP TABLE TOP UNTIL STEP 6. Place table top upside down on a
clean surface. One leg has a hollow leg for cable management. Ensure this leg is fastened to the
corner with the protruding power cable (See Figure a) . Proceed to loosely fasten 1/4“ Post & Cap
(x2 each per leg) ( See Figure b ). DO NOT COMPLETELY TIGHTEN THESE SCREWS UNTIL AFTER
STEP 5.
4
3
1/4-20 x 3/4”
Hex socket button
head cap screw (x8)
1/4“ Post & Cap
(x2 each)
Robertson flat head
wood screw
#8 X 1” (x4)
Hex Socket Driver
Power Drill
56
a) b)
With two assemblers holding up the foot rail so it lines up horizontally to the pilot holes located
below the foot rail, proceed to fasten the 1/4-20 x 3/4” Hex socket button head cap screws (x4)
using the drill , Hex driver or Hex key.

keilhauer.com
12
3 4
AWLA Counter & Bar Height Non- Powered Assembly Instructions
With two assemblers holding up the foot rail so it lines up horizontally to the pilot holes located
below the foot rail, proceed to fasten the 1/4-20 x 3/4” Hex socket button head cap screws (x4)
using the drill , Hex driver or Hex key.
With a minimum of two assemblers, proceed to flip the table and place in its final position. The
table top can now be completely unwrapped.
AWLA Conference Height Powered Assembly Instructions
1
Place table top upside down on a clean surface. One leg has a hollow leg for cable management.
Ensure this leg is fastened to the corner with the protruding power cable (See Figure a) . Proceed to
fasten 1/4“ Post & Cap (x2 each per leg) ( See Figure b ). DO NOT COMPLETELY UNWRAP TABLE
TOP UNTIL STEP 6.
a) b) 2
Feed the power cable up and into the channel leg, then fasten the black cable channel cover with
1/4-20 x 5/8” flat head socket head cap screw (x6).
Proceed to fasten the remaining screws to the pilot holes located above the foot rail, using the
1/4-20 x 3/4” Hex socket button head cap screws (x4) using the drill , Hex driver or Hex key.
Proceed to fully tighten the the screws fastened to the legs in Step 1.
DO NOT COMPLETELY UNWRAP TABLE TOP UNTIL STEP 6. Place table top upside down on a
clean surface. Proceed to loosely fasten 1/4“ Post & Cap (x2 each per leg) ( See Figure b ).
DO NOT COMPLETELY TIGHTEN THESE SCREWS UNTIL AFTER STEP 5.
3

AWLA Conference Height Non- Powered Assembly Instructions
1
Place table top upside down on a clean surface. Proceed to fasten 1/4“ Post & Cap (x2 each per
leg) ( See Figure b ). DO NOT COMPLETELY UNWRAP TABLE TOP UNTIL STEP 6.
2
With a minimum of two assemblers, proceed to flip the table and place in its final position. The
table top can now be completely unwrapped.
3
With a minimum of two assemblers, proceed to flip the table and place in its final position. The table
top can now be completely unwrapped.
