S1S60000
Application Note
No.2 Ping reply method

NOTICE
No part of this material may be reproduced or duplicated in any form or by any means without the written
permission of Seiko Epson. Seiko Epson reserves the right to make changes to this material without notice.
Seiko Epson does not assume any liability of any kind arising out of any inaccuracies contained in this material
or due to its application or use in any product or circuit and, further, there is no representation that this material is
applicable to products requiring high level reliability, such as, medical products. Moreover, no license to any
intellectual property rights is granted by implication or otherwise, and there is no representation or warranty that
anything made in accordance with this material will be free from any patent or copyright infringement of a third
party. This material or portions thereof may contain technology or the subject relating to strategic products
under the control of the Foreign Exchange and Foreign Trade Law of Japan and may require an export license
from the Ministry of International Trade and Industry or other approval from another government agency.
All other product names mentioned herein are trademarks and/or registered trademarks of their respective
companies.
©SEIKO EPSON CORPORATION 2006, All rights reserved.

Configuration of product number
DEVICES
S1 S 60000 F 00A5 00
Evaluation Board
S5U 1S 60K00 H 03 00
Packing specifications
Specifications
Shape
(F: QFP)
Model number
Model name
(S: Intelligent Network Controller)
Product classification
(S1: Semiconductors)
Packing specifications
Board Code
Category
(H: Hardware, S: Software)
Corresponding Device Model Code
(60K00: S1S60000)
Product Classification 2
(1S: Semiconductor IC for Communication)
Product Classification 1
(S5U: Development Tools for Semiconductor)

S1S60000 Application Note No.2 (Rev.1.1) EPSON i
CONTENTS
1. DESCRIPTION.................................................................................................................................1
2. CONFIRMATION OF S1S60000 BOOT...........................................................................................2
2.1 Confirming the host interface status.........................................................................................2
2.2 Reading the status...................................................................................................................2
2.3 Reading the boot status...........................................................................................................2
3. CONFIRMATION OF S1S60000 STATUS........................................................................................4
3.1 Reading the status option parameters .....................................................................................4
3.2 Reading the cable disconnection event ...................................................................................4
3.3 Reading cable connection recovery event ...............................................................................7
4. MAC ADDRESS SETTING ..............................................................................................................8
4.1 Writing a command..................................................................................................................8
4.2 Writing option parameters........................................................................................................8
4.3 Setting a MAC Address............................................................................................................8
5. IP ADDRESS SETTING AND PING REPLY ..................................................................................15
5.1 Specifying an IP address to open the SYSTEM communication end point............................15
5.2 Setting an IP address by the DHCP server to open the SYSTEM
communication end point.......................................................................................................17
5.3 Confirming the IP address......................................................................................................19
6. NOTES ON PROGRAMMING........................................................................................................20

1. DESCRIPTION
S1S60000 Application Note No.2 (Rev.1.1) EPSON 1
1. DESCRIPTION
To allow S1S60000 to reply to ping, a MAC address and IP address must be set. The MAC address can be set
by writing it to the S1S60000 internal register. The IP address can be set by opening the SYSTEM
communication end point. Completing these two settings causes S1S60000 to reply (ICMP Echo reply) to ping
(ICMP Echo request) sent through the network.
To perform this processing, the host CPU must read statuses and parameters and write commands and
parameters through the host interface of S1S60000.
This document describes the procedure for enabling S1S60000 to reply to pings while explaining how to use the
host interface.
To perform the procedure, the host interface of S1S60000 will be allocated to the address of the host CPU to
create the program of the host CPU. Alternatively, you can operate the address allocated to S1S60000 using the
debugger of host CPU.
The procedure is as follows.
1Confirm that S1S60000 is booted.
Read the boot status.
2Confirm the status of S1S60000.
Read the event status and option parameters.
3Set a MAC address.
Write the send command and option parameters.
4Set an IP address.
Write the open command and option parameters.
5Confirm ping reply (ICMPEcho reply).
Transmit ping from the PC to S1S60000.
* See description of host interface port in 4.1 and 4.2 in “S1S60000 Technical Manual” before reading the
following chapter.
The description of command port/status port, data port, and flag port is provided.

2. CONFIRMATION OF S1S60000 BOOT
2 EPSON S1S60000 Application Note No.2 (Rev.1.1)
2. CONFIRMATION OF S1S60000 BOOT
S1S60000 issues the boot status when it is booted. The host CPU reads the boot status to confirm that it has
been booted. This chapter describes how to read statuses through reading the boot status.
2.1 Confirming the host interface status
When the status or data is set in host interface port, the HINT pin changes. Connecting the HINT pin to the
interrupt pin of the host CPU allows interrupt control for reading the status and data. Setting the HINTPOL pin
to LOW enables Low active, and setting it to HIGH enables High active. Please set the interrupt input trigger
mode of the host CPU to level trigger mode.
The flag port indicates the host interface processing status for commands, statuses, or data. When accessing the
host interface, be sure to confirm the flag port. When not performing interrupt control, control the status by
polling of the flag port.
2.2 Reading the status
When the status is set in status port, the HINT pin becomes active. Also, bit0 of the flag port is set to “1”.
Perform polling of the flag port when not performing interrupt control.
The HINT pin becomes active when bit0 or bit1 of the flag port is set; therefore, confirm that bit0 of the flag
port is set to “1” and read the status.
The status form read from the status port is as follows.
Table 2.1 Status form
BIT 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
DATA Sequence number Communication end
point number Status number
For information on numbers corresponding to status types, refer to the “S1S60000 Series Host Interface Manual
- 2.1.1.4 Status number”.
2.3 Reading the boot status
In the same manner as the procedure in 2.2, read the “boot” status. Turn on the power of S1S60000 or input the
reset signal and S1S60000 outputs the “boot” status (0x000b).
Table 2.2 Read value of boot status for each host CPU type
Host CPU type boot status
8-bit connection Little Endian LSB port: 0x0b
MSB port: 0x00
8-bit connection Big Endian LSB port: 0x00
MSB port: 0x0b
16-bit connection Little Endian 0x000b
16-bit connection Big Endian 0x000b

2. CONFIRMATION OF S1S60000 BOOT
S1S60000 Application Note No.2 (Rev.1.1) EPSON 3
Fig.2.1 Boot status read flow
Power on
Status port
Read 0x000b
HINT pin
Active?
Flag port
bit0=1?
When not using interrupt,
the host CPU performs
polling of bit0=1 (set) of the
S1S60000 flag port to awai
t
the status output.
End
Turn on the power o
f
S1S60000 or input the
reset signal.
N
Y
N
Y

3. CONFIRMATION OF S1S60000 STATUS
4 EPSON S1S60000 Application Note No.2 (Rev.1.1)
3. CONFIRMATION OF S1S60000 STATUS
S1S60000 may issue the event status to inform the host CPU of IC status. The host CPU reads the event status
and option parameters to confirm which event has been informed. This chapter describes how to read the status
option parameters through reading the event status and option parameters by generating a cable disconnection
event and connection recovery event by disconnecting and connecting the Ethernet cable.
3.1 Reading the status option parameters
The status option parameters are data added to the status.After reading the status, read them from the data port.
When the status option parameters are set, the HINT pin becomes active and bit1 of the flag port is set to “1”.
Please confirm that bit1 of the flag port is set to “1” without fail before reading the data row.
3.2 Reading the cable disconnection event
In the same manner as the procedure in 3.1, read the “cable disconnection” of the “event” status by actually
disconnecting the LAN cable.
When you disconnect the LAN cable, the “event” status is issued. Read the status in the same manner as “2.
CONFIRMATION OF S1S60000 BOOT”. Then, the “event” status (0x000a) can be read. The “event” status is
provided with 16-byte status option parameters; read them from the data port. When S1S60000 and the host
CPU is 8-bit connected, the parameters are read 16 times, and when 16-bit connected, they are read eight times.
For more information about the “event” status, refer to the “S1S60000 Series Host Interface Manual - 3.11
event status”.
In the case of “cable disconnection” with the LAN cable disconnected, the following data row can be read.

3. CONFIRMATION OF S1S60000 STATUS
S1S60000 Application Note No.2 (Rev.1.1) EPSON 5
Table 3.1 Cable disconnection event option parameters
BYTE Read data Contents Comment
0 0x00
1 0x00 Fixed value
2 0x00 Flag Reserved (0)
3 0x00 Fixed value
4 0x00 Event type 0: Cable
5 0x00 Detail of event 0: Cable disconnection
6 0x00
7 0x00
8 0x00
9 0x00
10 0x00
11 0x00
12 0x00
13 0x00
14 0x00
15 0x00
In the case of cable event, 0 for all
When the option parameters are stored in the memory, BYTE0 in Table 3.1 is set to the low-order address of the
memory.
Read data row for each host CPU type are as follows.
Table 3.2 Data row for each host CPU type
Host CPU type Data row
8-bit connection
LittleEndian 0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00
8-bit connection
BigEndian 0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00
16-bit connection
LittleEndian 0x0000,0x0000,0x0000,0x0000,0x0000,0x0000,0x0000,0x0000
16-bit connection
BigEndian 0x0000,0x0000,0x0000,0x0000,0x0000,0x0000,0x0000,0x0000
* Access sequence in the case of 8-bit connection: low-order port →high-order port

3. CONFIRMATION OF S1S60000 STATUS
6 EPSON S1S60000 Application Note No.2 (Rev.1.1)
Fig.3.1 Cable disconnection event read flow
Disconnect the LAN cable
Status port
Read 0x000a
When not using interrupt,
the host CPU performs
polling of bit0=1 (set) of the
S1S60000 flag port to wai
t
the data output.
Reads the “event” status
(0x000a).
End
Flag port
bit1=1?
Data port
Read
16byte
Read?
HINT pin
Active? N
Y
N
Y
Y
N
HINT pin
Active?
Flag port
bit0=1?
N
Y
N
Y
When not using interrupt, the
host CPU performs polling o
f
bit1=1 (set) of the S1S60000
flag port to wait the status
output.

3. CONFIRMATION OF S1S60000 STATUS
S1S60000 Application Note No.2 (Rev.1.1) EPSON 7
3.3 Reading cable connection recovery event
As the next step, connect the disconnected LAN cable to read the “event” status “cable connection recovery”.
The read method is the same as “3.2 Reading the cable disconnection event”. In the case of “cable connection
recovery”, the following byte column can be read. The difference from “cable disconnection” is Detail of
“event” of the option parameter BYTE 5: cable connection recovery=1 (the shadow area of the table).
Table 3.3 Cable connection recovery event option parameters
BYTE Read data Contents Comment
0 0x00
1 0x00 Fixed value
2 0x00 Flag Reserved (0)
3 0x00 Fixed value
4 0x00 Event type 0: Cable
5 0x01 Detail of event 1: Cable connection recovery
6 0x00
7 0x00
8 0x00
9 0x00
10 0x00
11 0x00
12 0x00
13 0x00
14 0x00
15 0x00
In the case of cable event, 0 for all
When the option parameters are stored in the memory, BYTE0 in Table 3.3 is set to the low-order address of the
memory.
Read data row for each host CPU type are as follows.
Table 3.4 Data row for each host CPU type
Host CPU type Data row
8-bit connection
LittleEndian 0x00,0x00,0x00,0x00,0x00,0x01, 0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00
8-bit connection
BigEndian 0x00,0x00,0x00,0x00,0x00,0x01,0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00
16-bit connection
LittleEndian 0x0000,0x0000,0x0100,0x0000,0x0000,0x0000,0x0000,0x0000
16-bit connection
BigEndian 0x0000,0x0000,0x0001,0x0000,0x0000,0x0000,0x0000,0x0000
* Access sequence in the case of 8-bit connection: low-order port →high-order port

4. MAC ADDRESS SETTING
8 EPSON S1S60000 Application Note No.2 (Rev.1.1)
4. MAC ADDRESS SETTING
To make network communication, a 48-bit MAC address must be set. Set a MAC address in the internal register
of S1S60000. This chapter describes how to write a command and option parameters through setting a MAC
address.
4.1 Writing a command
When the host CPU writes a command in S1S60000, it confirms that bit2 of the flag port is “0” and writes it to
the command port.
The command form to be written to the command port is as follows.
Table 4.1 Command form
BIT 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
DATA Sequence number Communication end
point number Command number
The sequence number is given by the host CPU. The host CPU can give any number. When the command is
written, the status corresponding to the command is returned. The status corresponding to the command with the
sequence number 1 is returned with the sequence number 1. The sequence number shows you to which
command the returned status corresponds.
For information on numbers corresponding to command types, refer to the “S1S60000 Series Host Interface
Manual - 2.1.1.3 Command number”.
4.2 Writing option parameters
After reading the status corresponding to the command, confirm that bit3 of the flag port is “0” and bit4 is “1”,
and then write option parameters. When the option parameters are written, the status corresponding to the
parameters are returned; read them in the same manner as the procedure in “2.2 Reading the status”.
4.3 Setting a MAC Address
In the same manner as 4.1 and 4.2, actually write commands and option parameters here.
Although a method to store the MAC address by connecting an EEPROM is alternatively available, set it from
the host CPU here. Set 00_00_48_14_01_23 (Note) for MAC address. Set the MAC address at the offset
addresses 01h to 03h of the internal register of S1S60000. Set it at three offset addresses; perform the setting
operation three times.
Note: Set the MAC address acquired on a customer basis. In the case of the S5U1S60K00H0300 board mounted
S1S60000, the MAC address set on the EEPROM can be used.
The host CPU sets “0x0000” at the beginning of the MAC address at the offset address 01h of the internal
register. The internal register to set the MAC address will be the communication end point 0 (SYSTEM
communication end point). For information on the communication end point type, refer to the “S1S60000 Series
Host Interface Manual - 2.1.1.2 Communication end point number”.
Write the “send” command (0x0201: sequence number 02, communication end point number 0=SYSTEM,
command number 1=send) to the command port. For information on the “send” command, refer to the
“S1S60000 Series Host Interface Manual - 3.2 send command”.

4. MAC ADDRESS SETTING
S1S60000 Application Note No.2 (Rev.1.1) EPSON 9
Table 4.2 Write value of send command (0x0201) for each host CPU type
Host CPU type send command
8-bit connection Little Endian LSB port: 0x01
MSB port: 0x02
8-bit connection Big Endian LSB port: 0x02
MSB port: 0x01
16-bit connection Little Endian 0x0201
16-bit connection Big Endian 0x0201
S1S60000 returns the “write” status (0x0201: sequence number 02, communication end point number
0=SYSTEM, status number 1=write).
Next, write the option parameters of the “send” command. Write the following data row at the data port.
Table 4.3 send command option parameters
BYTE Write data Contents Comment
0 0x00
1 0x00 Transmission data In the case of internal register, there is no
data following the command options.
2 0x00 Flag 0 when the SYSTEM communication end
point is accessed.
3 0x00 Fixed value
4 0x01 Operation Write (Write to the internal register)
5 0x04 Object Internal register of S1S60000
6 0x00
7 0x01 Offset Internal register/offset address
0x0001
8 0x00
9 0x00
10 0x00
11 0x00
Fixed value Fixed value 0 when the internal register is
accessed
12 0xff
13 0xff Bit mask Specify 1 as the operation object bit.
14 0x00
15 0x00 Bit pattern Write value (0x0000 at the beginning of the
MAC address)
When the option parameters are stored in the memory, BYTE0 in Table 4.3 is set to the low-order address of the
memory.

4. MAC ADDRESS SETTING
10 EPSON S1S60000 Application Note No.2 (Rev.1.1)
Write data row for each host CPU type are as follows.
Table 4.4 Data row for each host CPU type
Host CPU type Data row
8-bit connection
LittleEndian 0x00,0x00,0x00,0x00,0x01,0x04,0x00,0x01,0x00,0x00,0x00,0x00,0xff,0xff,0x00,0x00
8-bit connection
BigEndian 0x00,0x00,0x00,0x00,0x01,0x04,0x00,0x01,0x00,0x00,0x00,0x00,0xff,0xff,0x00,0x00
16-bit connection
LittleEndian 0x0000,0x0000,0x0401,0x0100,0x0000,0x0000,0xffff,0x0000
16-bit connection
BigEndian 0x0000,0x0000,0x0104,0x0001,0x0000,0x0000,0xffff,0x0000
* Access sequence in the case of 8-bit connection: low-order port →high-order port
S1S60000 returns the “ok” status (0x0203: sequence number 02, communication end point number 0=SYSTEM,
status number 3=ok). Setting “0x0000” at 0bit to 15bit at the beginning of the MAC address is complete.
Next, write the subsequent “0x4814” of the MAC address to the offset address 02h of the internal register. In the
same manner as the beginning of the MAC address, write the “send” command (0x0301), read the “write” status
(0x0301), and write the option parameters. The sequence number has been set to number 3 in increment by 1.
Write the following data row to the data port. The difference from the first setting is the offset addresses of
internal register at BYTE 6 and 7 and the MAC address at BYTE 14 and 15 (the hatched areas of the table).
Table 4.5 Send command option parameters
BYTE Write data Contents Comment
0 0x00
1 0x00 Transmission data In the case of internal register, there is no
data following the command options.
2 0x00 Flag 0 when the SYSTEM communication end
point is accessed.
3 0x00 Fixed value
4 0x01 Operation Write (Write to the internal register)
5 0x04 Object Internal register of S1S60000
6 0x00
7 0x02 Offset Internal register/offset address
0x0002
8 0x00
9 0x00
10 0x00
11 0x00
Fixed value Fixed value 0 when the internal register is
accessed
12 0xff
13 0xff Bit mask Specify 1 as the operation object bit.
14 0x14
15 0x48 Bit pattern Write value (the subsequent MAC address
4814)
When the option parameters are stored in the memory, BYTE0 in Table 4.5 is set to the low-order address of the
memory.

4. MAC ADDRESS SETTING
S1S60000 Application Note No.2 (Rev.1.1) EPSON 11
Written data row for each host CPU type are as follows.
Table 4.6 Data row for each host CPU type
Host CPU type Data row
8-bit connection
LittleEndian 0x00,0x00,0x00,0x00,0x01,0x04,0x00,0x02,0x00,0x00,0x00,0x00,0xff,0xff,0x14,0x48
8-bit connection
BigEndian 0x00,0x00,0x00,0x00,0x01,0x04,0x00,0x02,0x00,0x00,0x00,0x00,0xff,0xff,0x14,0x48
16-bit connection
LittleEndian 0x0000,0x0000,0x0401,0x0200,0x0000,0x0000,0xffff,0x4814
16-bit connection
BigEndian 0x0000,0x0000,0x0104,0x0002,0x0000,0x0000,0xffff,0x1448
* Access sequence in the case of 8-bit connection: low-order port →high-order port
S1S60000 returns the “ok” status (0x0303). Setting at the “0x4814” part of 16-bit to 31-bit of the MAC address
is complete.
At last, write the remaining “0x0123” of the MAC address at the offset address 03h of the internal register. In
the same manner, write the “send” command (0x0401), read the “write” status (0x0401), and write the option
parameters. The sequence number has been set to 4 in increment by 1.
Write the following data row to the data port. The difference from the second setting is the offset addresses of
internal register at BYTE 6 and 7 and the MAC address at BYTE 14 and 15 (the hatched areas of the table).
Table 4.7 Send command option parameters
BYTE Write data Contents Comment
0 0x00
1 0x00 Transmission data In the case of internal register, there is no
data following the command options.
2 0x00 Flag 0 when the SYSTEM communication end
point is accessed.
3 0x00 Fixed value
4 0x01 Operation Write (Write to the internal register)
5 0x04 Object Internal register of S1S60000
6 0x00
7 0x03 Offset Internal register/offset address
0x0003
8 0x00
9 0x00
10 0x00
11 0x00
Fixed value Fixed value 0 when the internal register is
accessed
12 0xff
13 0xff Bit mask Specify 1 as the operation object bit.
14 0x23
15 0x01 Bit pattern Write value (the subsequent MAC address
0123)
When the option parameters are stored in the memory, BYTE0 in Table 4.7 is set to the low-order address of the
memory.
Write data row for each host CPU type are as follows.

4. MAC ADDRESS SETTING
12 EPSON S1S60000 Application Note No.2 (Rev.1.1)
Table 4.8 Data row for each host CPU type
Host CPU type Data row
8-bit connection
LittleEndian 0x00,0x00,0x00,0x00,0x01,0x04,0x00,0x03,0x00,0x00,0x00,0x00,0xff,0xff,0x23,0x01
8-bit connection
BigEndian 0x00,0x00,0x00,0x00,0x01,0x04,0x00,0x03,0x00,0x00,0x00,0x00,0xff,0xff,0x23,0x01
16-bit connection
LittleEndian 0x0000,0x0000,0x0401,0x0300,0x0000,0x0000,0xffff,0x0123
16-bit connection
BigEndian 0x0000,0x0000,0x0104,0x0003,0x0000,0x0000,0xffff,0x2301
* Access sequence in the case of 8-bit connection: low-order port →high-order port
S1S60000 returns the “ok” status (0x0403). Setting at the 48bit of the MAC address is complete.

4. MAC ADDRESS SETTING
S1S60000 Application Note No.2 (Rev.1.1) EPSON 13
Fig.4.1 MAC address setting flow
Start
Command port
Write 0x0201
Flag port
bit2=0?
Flag port
bit0=1?
Status port
Read 0x0201
Confirm whether the
command write is enabled.
send command 0x0201
Write sequence numbe
r
02, communication end
point 0, send command 1.
HINT pin
Active?
write status 0x0201
Read sequence numbe
r
02, communication end
point 0, and write status 1.
1
Wait the status.
Perform polling of the flag
port bit0=1? and await the
status when not using
interrupt.
Y
Y
Y
N
N
N

4. MAC ADDRESS SETTING
14 EPSON S1S60000 Application Note No.2 (Rev.1.1)
Fig.4.2 MAC address setting flow
* The above flow is an example of setting the MAC address (0 to 15 bits) in the internal register of the offset
address 01h.
Then, setting in the internal registers of the offset address 02h and 03 in the same manner is required.
Flag port
bit3=0&bit4=1?
Start command option
parameter write control
here.
Data port
write command opt.
command opt.
16b
y
te?
Write 16 bytes of the
command option parameters
to the data port.
1
N
N
Y
Y
Is data writing enabled?
Is the data port receiving
circuit enabled?
HINT pin
Active?
Flag port
bit0=1?
Status port
Read 0x0203
Y
Y
N
N
Is the status present?
End
Ok status 0x0203
Read sequence numbe
r
02, communication end
point 0, and ok status 3.

5. IP ADDRESS SETTING AND PING REPLY
S1S60000 Application Note No.2 (Rev.1.1) EPSON 15
5. IP ADDRESS SETTING AND PING REPLY
To set an IP address in S1S60000, it is necessary to open the SYSTEM communication end point
(communication end point 0). Opening the SYSTEM communication end point enables S1S60000 to reply to
pings. At the SYSTEM communication end point, write the open command, read the write status, write the
command option parameters, and read the ok status sequentially. This is the same procedure as that for the send
command when setting the MAC address.
This chapter describes how to open the SYSTEM communication end point by specifying an IP address by the
host CPU, and how to set an IP address from the DHCP server.
These are exclusive methods. If you perform one method and then perform the other method, reset S1S60000
once before starting the latter.
5.1 Specifying an IP address to open the SYSTEM communication end point
This section describes how to open the SYSTEM communication end point at the IP address 192.168.0.2,
subnet mask 255.255.255.0, and gateway 192.168.0.1 of S1S60000.
Write the “open” command (0x0500: sequence number 05, communication end point number 0=SYSTEM,
command number 0=open) to the command port. The sequence number has been used to 4 for setting the MAC
address, use number 5 in increment by 1. S1S60000 returns the write status 0x0501.
For information on the “open” command, refer to the “S1S60000 Series Host Interface Manual - 3.1 open
command”.
Write the option parameters of the “open” command. Write the following data row to the data port.
Table 5.1 open command option parameters
BYTE Write data Contents Comment
0 0x00
1 0x00 Fixed value
2 0x70 Flag Bit7 (DATALINK layer is used)=0,
Bit6 (local IP address is enabled)=1,
Bit5 (subnet mask is enabled)=1,
Bit4 (default gateway is enabled)=1,
Bit0 (SOPAR is not used)=0
3 0x00 Fixed value
4 0xc0
5 0xa8
6 0x00
7 0x02
Local IP address
192.168.0.2 (0xc0.0xa8.0x00.0x02)
8 0xff
9 0xff
10 0xff
11 0x00
Subnet mask 255.255.255.0
(0xff.0xff.0xff.0x00)
12 0xc0
13 0xa8
14 0x00
15 0x01
Default gateway 192.168.0.1
(0xc0.0xa8.0x00.0x01)

5. IP ADDRESS SETTING AND PING REPLY
16 EPSON S1S60000 Application Note No.2 (Rev.1.1)
When the option parameters are stored in the memory, BYTE0 in Table 5.1 is set to the low-order address of the
memory.
Write data row for each host CPU type are as follows.
Table 5.2 Data row for each host CPU type
Host CPU type Data row
8-bit connection
LittleEndian 0x00,0x00,0x70,0x00,0xc0,0xa8,0x00,0x02,0xff,0xff,0xff,0x00,0xc0,0xa8,0x00,0x01
8-bit connection
BigEndian 0x00,0x00,0x70,0x00,0xc0,0xa8,0x00,0x02,0xff,0xff,0xff,0x00,0xc0,0xa8,0x00,0x01
16-bit connection
LittleEndian 0x0000,0x0070,0xa8c0,0x0200,0xffff,0x00ff,0xa8c0,0x0100
16-bit connection
BigEndian 0x0000,0x0700,0xc0a8,0x0002,0xffff,0xff00,0xc0a8,0x0001
* Access sequence in the case of 8-bit connection: low-order port →high-order port
S1S60000 returns the “ok” status (0x0503). The flow of the “open” command at the SYSTEM communication
end point is the same as the “send” command described in “MAC Address Setting”.
S1S60000 has been enabled to reply to pings. When the PC issues ping (ICMP ECHO request), S1S60000
replies to pings (ICMP ECHO reply). To confirm whether S1S60000 correctly replies to pings, use the
command prompt of Windows. Start the Windows command prompt and input the following command to the IP
address of S1S60000.
Note: The IP address of S1S60000 has been set at 192.168.0.2; set the IP address of PC to 192.168.0.xxx.
ping<space>192.168.0.2<enter>
Fig.5.1 Transmission of pings from the PC to S1S60000 and reply to pings
