Epson S5U1C17564T2 User manual

Rev. 1.0
CMOS 16-BIT SINGLE CHIP OCONTROLLER
S5U1C17564T2 Manual
(Software Evaluation Tool for S1C17564)

Evaluation board/kit and Development tool important notice
1. This evaluation board/kit or development tool is designed for use for engineering evaluation, demonstration,
or development purposes only. Do not use it for other purpose. It is not intended to meet the requirement of
design for finished product.
2. This evaluation board/kit or development tool is intended for use by an electronics engineer, and it is not the
product for consumer. The user should use this goods properly and safely. Seiko Epson dose not assume any
responsibility and liability of any kind of damage and/or fire coursed by usage of it. User should cease to use
it when any abnormal issue occurs even during proper and safe use.
3. The part used for this evaluation board/kit or development tool is changed without any notice.
NOTICE
No part of this material may be reproduced or duplicated in any form or by any means without the written
permission of Seiko Epson. Seiko Epson reserves the right to make changes to this material without notice.
Seiko Epson does not assume any liability of any kind arising out of any inaccuracies contained in this material
or due to its application or use in any product or circuit and, further, there is no representation that this material is
applicable to products requiring high level reliability, such as, medical products. Moreover, no license to any
intellectual property rights is granted by implication or otherwise, and there is no representation or warranty that
anything made in accordance with this material will be free from any patent or copyright infringement of a third
party. When exporting the products or technology described in this material, you should comply with the
applicable export control laws and regulations and follow the procedures required by such laws and regulations.
You are requested not to use, to resell, to export and/or to otherwise dispose of the products (and any technical
information furnished, if any) for the development and/or manufacture of weapon of mass destruction or for other
military purposes.
All brands or product names mentioned herein are trademarks and/or registered trademarks of their respective
companies.
©SEIKO EPSON CORPORATION 2012, All rights reserved.

Product code explanation
Device
S1 C17xxx F 00E1 00
Development tool
S5U1 C17000 Y2 100
Packaging specifications
[00: Standard packaging]
Version
［1: Version 1］
Tool classification
Hx : ICE
Dx : Evaluation board
Ex : ROM emulation board
Mx: External ROM emulation memory
Tx : Mounting socket
Cx : Compiler package
Sx : Middleware package
Yx : Writer software
Supported device numbers
[17xxx: For S1C17xxx]
Tool classification
[C: For microprocessor]
Product classification
[S5U1: Semiconductor development tool]
Packaging specifications
00 : Other than tape or reel
0A : TCP BL 2-direction
0B : Tape and reel BACK
0C: TCP BR 2-direction
0D: TCP BT 2-direction
0E : TCP BD 2-direction
0F : Tape and reel FRONT
0G: TCP BT 4-direction
0H: TCP BD 4-direction
0J : TCP SL 2-direction
0K : TCP SR 2-direction
0L : Tape and reel LEFT
0M: TCP ST 2-direction
0N: TCP SD 2-direction
0P : TCP ST 4-direction
0Q: TCP SD 4-direction
0R: Tape and reel RIGHT
99 : Packaging specification undetermined
Specifications
Configuration
[D: Bare chip, F: QFP, B: BGA]
Device numbers
Device name
[C: Microprocessor, digital products]
Product classification
[S1: Semiconductor]

S5U1C17564T2 Manual Seiko Epson Corporation i
(Rev. 1.0)
Table of Contents
1. Overview..................................................................................................................... 1
1.1 Usage Method..........................................................................................................................1
2. Block Diagram............................................................................................................ 2
3. Hardware Information................................................................................................ 3
3.1 Layout information ..................................................................................................................3
3.2 Jumper information.................................................................................................................4
3.2.1 Jumper settings when using S1C17564..............................................................................4
3.2.2 Jumper settings when using S1C17554..............................................................................5
3.3 Circuit diagram ........................................................................................................................6
3.4 Parts List ..................................................................................................................................8
Revision History............................................................................................................... 9

1. Overview
S5U1C17564T2 Manual Seiko Epson Corporation 1
(Rev. 1.0)
1. Overview
The S5U1C17564T2 (S5U1C17564T2: Software Evaluation Tool for S1C17564) is a board used to support the
development and evaluation of the Seiko Epson S1C17564 single-chip microcontroller.
The S5U1C17564T2 features through-holes for attaching expansion connectors to provide I/O pins for the
S1C17564, and can be used to expand functions by connecting a user board or similar via these connector
through-holes.
The S5U1C17564T2 can be used for developing S1C17564 software by connecting to the Seiko Epson
S5U1C17001H (ICDmini) emulator.
This product includes an IC socket, enabling it to be used with the Seiko Epson S1C17554 single-chip
micro-controller in addition to the S1C17564 included.
1.1 Usage Method
The S1C17564 software development environment can be set up using the procedure described below.
(1) Insert the S1C17564*1 into the IC socket (U1).*2 (It is already inserted at the time of shipping.)
(2) Connect the S5U1C17001H (ICDmini) to J5 and J6 on the S5U1C17564T2 via the dedicated cable
provided with the ICDmini.*3
(3) Provide power via the power supply connectors (J7, J8, J9).*4
(4) Connect the ICDmini to the PC*5 via the USB cable provided with the ICDmini.
*1: The S1C17554 can also be mounted.
*2: Insert so that the triangular mark printed on the board aligns with pin 1 on the S1C17564. There is a risk
of damaging the S1C17564 if power is turned on while inserted incorrectly.
*3: For more information on connecting this device, refer to the S5U1C17001H User Manual (ICDmini
Ver2.0). Note that this device should be used with S5U1C17001H2 (ICDmini Ver 2.0) or later. It cannot
be connected to the S5U1C17002H (ICD Board).
*4: Never apply a voltage exceeding the power supply voltage input range for the S1C17564. For more
information on the S1C17564 power supply voltage input range, refer to the S1C17564 Technical Manual.
There is no need to supply power via J8 if the S1C17564 internal regulator is used. For more information,
refer to Section 3.
*5: The PC used for S1C17564 development must be installed with the GNU17 (S5U1C17001C) software
development tool. Note that this device should be used with GNU17 Ver 2.0.0 or later.
Note: When using the S5U1C17564T2, the spacers provided should be used to prevent shorting of the
mounted components.

2. Block Diagram
2 Seiko Epson Corporation S5U1C17564T2 Manual
(Rev. 1.0)
2. Block Diagram
The S5U1C17564T2 block diagram is as shown below.
Figure 2.1 S5U1C17564T2 block diagram
32kHz
Crystal Unit (X2)
12MHz
Crystal Unit (X1)
Reset SW
(SW1)
VPP
ICDmini i/f
Connecto
r
(
J5
)
S5U1C17001H
Power Supply
Connector (J8)
S1C17564
Debug i/f
ICDmini i/f
Connector (J6)
OSC1
OSC3
Ports
Extension
connector
(J1-J4)
(Not mounted)
Target
Board
Power Supply
Connector (J9)
LVDD
AVDD
Power Supply
Connecto
r
(
J7
)
HVDD
LED (D1)
REGEN
RESET
HVDD LVDD
AVDD
VIN
JP1
JP2 JP5
JP6 JP7
S5U1C17001H

3. Hardware Information
S5U1C17564T2 Manual Seiko Epson Corporation 3
(Rev. 1.0)
3. Hardware Information
3.1 Layout information
The S5U1C17564T2 component layout is as shown in Figures 3.1 and 3.2.
Figure 3.1 S5U1C17564T2 component layout (upper side)
*1: Connectors J1, J2, J3, and J4 are patterns only, and the actual connectors are provided together with the
product for mounting as necessary.
*2: The through-hole bore diameter is 0.85 mm.
Extension
Connector (J1)
(foot pattern only*1*2)
Reset SW
(SW1)
HVDD-IN
(J7) LVDD-IN
(J8) AVDD-IN
(J9)
Extension
Connector (J2)
(foot pattern
only*1*2)
Extension
Connector (J3)
(foot pattern only*1*2)
Extension
Connector (J4)
(foot pattern only*1*2)
S1C17564
(U1)
1 Pin
Regulator
Enable/Disable
Select Jumper
(JP2)

3. Hardware Information
4 Seiko Epson Corporation S5U1C17564T2 Manual
(Rev. 1.0)
Figure 3.2 S5U1C17564T2 component layout (underside)
3.2 Jumper information
3.2.1 Jumper settings when using S1C17564
Table 3.1 lists the S5U1C17564T2 jumper functions (for when using the S1C17564).
Table 3.1 Jumper function list (when using S1C17564)
Jumper Enable internal regulator (default setting) Disable internal regulator
JP1 CLOSE (VIN=HVDD) –
JP2 REGEN EN CLOSE
(Enable S1C17564 internal regulator)
REGEN DS CLOSE
(Disable S1C17564 internal regulator)
JP5 CLOSE
(Supply AVDD (supplied via J9) to S1C17564)
–
JP6 CLOSE
(Supply HVDD (supplied via J7) to S1C17564)
–
JP7 OPEN*1 CLOSE
(Supply LVDD (supplied via J8) to S1C17564)
*1: There is no need to supply LVDD power via J8 if the S1C17564 internal regulator is used.
32.768kHz
Crystal Unit (X2)
12MHz
Crystal Unit
(X1)
ICDmini i/f
connector
(J6)
ICDmini i/f
connector
(J5)

3. Hardware Information
S5U1C17564T2 Manual Seiko Epson Corporation 5
(Rev. 1.0)
3.2.2 Jumper settings when using S1C17554
Table 3.2 lists the S5U1C17564T2 jumper functions (for when using the S1C17554).
Table 3.2 Jumper function list (when using S1C17554)
Jumper (No internal regulator)
JP1 CLOSE (VIN=HVDD)
JP2 REGEN DS CLOSE
JP5 CLOSE
(Supply AVDD (supplied via J9) to S1C17554)
JP6 CLOSE
(Supply HVDD (supplied via J7) to S1C17554)
JP7 CLOSE
(Supply LVDD (supplied via J8) to S1C17554)

5
5
4
4
3
3
2
2
1
1
B B
A A
IC51-0644-807-6
SVTmini17564_CPUboard_sch 1.1
SVTmini17564 CPU Board
A3
1 3Thursday April 15 2010
