ETAS XETK-S23.0 User manual

ETAS XETK-S23.0 -User Guide
JTAG Emulator Probe for TI C2000
Microcontrollers
User Guide

Copyright
The data in this document may not be altered or amended without special noti-
fication from ETAS GmbH. ETAS GmbH undertakes no further obligation in
relation to this document. The software described in it can only be used if the
customer is in possession of a general license agreement or single license.
Using and copying is only allowed in concurrence with the specifications stipu-
lated in the contract.
Under no circumstances may any part of this document be copied, reproduced,
transmitted, stored in a retrieval system or translated into another language
without the express written permission of ETAS GmbH.
© Copyright 2022 ETAS GmbH, Stuttgart
The names and designations used in this document are trademarks or brands
belonging to the respective owners.
XETK-S23.0 -User Guide R01 EN -06.2022

ETAS Contents
Contents
XETK-S23.0 -User Guide 3
1 About this Document . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1.1 Classification of Safety Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1.2 Presentation of Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1.3 Presentation of Supporting Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2Basic Safety Notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.1 General Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.2 Requirements for Users and Duties for Operators . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.3 Intended Use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.4 Identifications on the Product . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2.5 Taking the Product Back and Recycling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2.6 CE Conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2.7 UKCA Conformity. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2.8 RoHS Conformity. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2.9 Declarable Substances . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2.10 Use of Open Source Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
3Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3.1 Applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3.2 Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
3.2.1 General. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
3.2.2 Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
4Hardware Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4.1 Architecture. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4.2 ECU Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
4.3 XETK Ethernet Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
4.4 Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
4.5 ECU Voltage Supervisor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
4.6 Status LEDs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
4.7 Data Emulation and Data Measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
4.8 XETK-S23.0 JTAG Interface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
4.9 Trigger Modes: Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
4.10 Pinless Triggering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
4.10.1 Startup Handshake . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
4.10.2 XETK Trigger Generation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
4.11 Timer Triggering. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
4.12 Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
4.13 Pull CalWakeUp until Startup Handshake . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Contents

ETAS Contents
XETK-S23.0 -User Guide 4
5 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
5.1 Mounting the XETK-S23.0 to the ECU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
5.1.1 Mechanical connection of the XETK-S23.0 to the ECU Housing. . . . . . . 24
5.1.2 Mounting the XETK-S23.0 to the ECU metal Housing. . . . . . . . . . . . . . . . 26
5.2 Electrical Connection to the ECU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
5.3 Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
5.3.1 XETK Ethernet Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
5.3.2 Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
6XETK Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
6.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
6.2 Configuration Parameter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
7Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
7.1 System Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
7.1.1 ETAS Compatible Hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
7.1.2 PC with one Ethernet Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
7.1.3 XETK-S23.0 Software Support. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
7.2 Data Emulation and Measurement Memory. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
7.2.1 Data Emulation Memory and Microcontroller Support . . . . . . . . . . . . . . . 33
7.2.2 Measurement Data Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
7.3 Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
7.4 XETK Ethernet Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
7.5 Environmental Conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
7.6 Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
7.7 Test Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
7.8 JTAG Timing Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
7.8.1 JTAG Timing Diagram. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
7.8.2 JTAG Timing Parameters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
7.9 Electrical Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
7.9.1 ECU Interface Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
7.9.2 ECU Interface Connector CON1 (5.0 V Interface selected) . . . . . . . . . . . 40
7.9.3 ECU Interface Connector CON1 (3.3 V Interface selected) . . . . . . . . . . . 41
7.10 Pin Assignment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
7.10.1 ECU Interface Connector CON1 (XETK-S23.0 Side) . . . . . . . . . . . . . . . . . 42
7.10.2 Interface and Power Supply Connector CON4 . . . . . . . . . . . . . . . . . . . . . . 43
7.11 Mechanical Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
8Cables and Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
8.1 ECU Adapter Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
8.1.1 CBAM230 Adapter Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
8.1.2 CBAM240 Adapter Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
8.1.3 CBAM271 Adapter Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
8.2 Combined Interface and Power Supply Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
8.3 PC Interface Cable. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
8.3.1 CBE200-3 Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
8.3.2 CBAE200 Adapter Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
8.4 ETAS Module Interface Adapter Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

ETAS Contents
XETK-S23.0 -User Guide 5
8.4.1 CBE230 Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
8.4.2 CBAE330 Adapter Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
8.5 Power Supply Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
8.5.1 Cable K70.1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
8.5.2 Power Supply Cable KA50 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
8.6 ECU Interface Adapters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
8.6.1 XETK - ECU Adapter ETAM2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
8.6.2 XETK - ECU Adapter ETAM5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
8.6.3 XETK - ECU Adapter ETAM9 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
8.7 XETK - ECU Adapter ETAN4A . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
8.8 Waterproof Case ETKS_C3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
9Ordering Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
9.1 XETK-S23.0 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
9.2 XETK - ECU Adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
9.3 Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
9.4 Mounting Material . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
9.5 Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
9.5.1 ECU Adapter Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
9.5.2 Combined ECU Adapter and Power Supply Cables . . . . . . . . . . . . . . . . . . 56
9.5.3 Ethernet Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
9.5.4 Power Supply Cables. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
9.6 Waterproof Case . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
10 Contact Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Figures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

ETAS About this Document
XETK-S23.0 -User Guide 6
1 About this Document
1.1 Classification of Safety Messages
The safety messages used here warn of dangers that can lead to personal
injury or damage to property:
1.2 Presentation of Instructions
The target to be achieved is defined in the heading. The necessary steps for this
are in a step-by-step guide:
Target definition
1. Step 1
2. Step 2
3. Step 3
>Result
1.3 Presentation of Supporting Information
DANGER
indicates a hazardous situation with a high risk of death or serious injury if
not avoided
WARNING
indicates a hazardous situation of medium risk which could result in death or
serious injury if not avoided.
CAUTION
indicates a hazardous situation of low risk which may result in minor or
moder-ate injury if not avoided.
NOTICE
indicates a situation which may result in damage to property if not avoided.
NOTE
Contains additional supporting information.

ETAS Basic Safety Notices
XETK-S23.0 -User Guide 7
2 Basic Safety Notices
This chapter contains information about the following topics:
• General Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
•Requirements for Users and Duties for Operators . . . . . . . . . . . . . . . . . . 7
•Intended Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
•Identifications on the Product. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
•Taking the Product Back and Recycling . . . . . . . . . . . . . . . . . . . . . . . . . . 11
•CE Conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
•UKCA Conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
•RoHS Conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
•Declarable Substances. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
•Use of Open Source Software. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2.1 General Safety Information
Please observe the Product Safety Notices ("ETAS Safety Notice") and the fol-
lowing safety notices to avoid health issues or damage to the device.
ETAS GmbH does not assume any liability for damages resulting from
improper handling, unintended use or non-observance of the safety precau-
tions.
2.2 Requirements for Users and Duties for Operators
The product may be assembled, operated and maintained only if you have the
necessary qualification and experience for this product. Incorrect operation or
operation by users without sufficient qualification may lead to injuries or death
or property damages.
General Safety at Work
The existing regulations for safety at work and accident prevention must be
followed. All applicable regulations and statutes regarding operation must be
strictly followed when using this product.
2.3 Intended Use
An ETK is an electronic component that is installed in a vehicle control unit
(ECU) to read data from the ECU or write data to the ECU.
Application Area of the Product
This product was developed and approved for automotive applications. For use
in other application areas, please contact your ETAS contact partner.
NOTE
Carefully read the documentation (Product Safety Advice and this User
Guide) that belongs to the product prior to the startup.

ETAS Basic Safety Notices
XETK-S23.0 -User Guide 8
Requirements for Operation
The following requirements are necessary for safe operation of the product:
• Use the product only according to the specifications in the correspond-
ing User Guide. With any deviating operation, the product safety is no
longer ensured.
• Observe the regulations applicable at the operating location concerning
electrical safety as well as the laws and regulations concerning work
safety!
• Do not apply any voltages to the connections of the product that do not
correspond to the specifications of the respective connection.
• Connect only current circuits with safety extra-low voltage in accordance
with EN 61140 (degree of protection III) to the connections of the prod-
uct.
• The power supply for the product must be safely disconnected from the
supply voltage. For example, use a car battery or a suitable lab power
supply.
• Use only lab power supplies with double protection to the supply system.
•Ensure that the connections of the power supply are easily accessible.
•The module does not have an operating voltage switch.
–Switch on the product by connecting the power supply cable with the
power supply or by switching on the power supply.
– Switch off the product by disconnecting it from the power supply or
by switching off the power supply.
DANGER
Connect the power cord only with a vehicle battery or with a lab power sup-
ply! A connection to power outlets is prohibited.
Route the power cord in such a way that it is protected against abrasion,
damages, deformation and kinking. Do not place any objects on the power
cord.
Never apply force to insert a plug into a socket. Ensure that there is no con-
tamination in and on the connection, that the plug fits the socket, and that you
correctly aligned the plugs with the connection.
Do not use the product in a wet or damp environment.
Do not use the product in potentially explosive atmospheres.
Keep the surfaces of the product clean and dry.

ETAS Basic Safety Notices
XETK-S23.0 -User Guide 9
Potential Equalization
Requirements for the technical State of the Product
The product is designed in accordance with state-of-the-art technology and
recognized safety rules. The product may be operated only in a technically flaw-
less condition and according to the intended purpose and with regard to safety
and dangers as stated in the respective product documentation. If the product
is not used according to its intended purpose, the protection of the product
may be impaired.
Maintenance and Cleaning
The product is maintenance-free. Use a lightly moistened, soft, lint-free cloth
for cleaning the product. Ensure that no moisture can enter. Never spray clean-
ing agents directly onto the product. Do not user any sprays, solvents or abra-
sive cleaners which could damage the product.
Transport and Installation
CAUTION
Danger from inadvertent current flow!
Depending on the design, the shield of the Ethernet cables can be connected
with the housing of the module. Install the products only on components with
the same electrical potential or isolate the products from the components.
CAUTION
The ETK can be damaged or destroyed!
Some components of the ETK board may be damaged or destroyed by elec-
trostatic discharges. Please keep the ETK in its storage package until it is
installed.
The board should only be taken from its package, configured, and installed at
a workplace that is protected against static discharge.
CAUTION
During installation and removal, ECU and ETK must be in a de-energized
state!
CAUTION
Risk of short circuiting the internal signals of the ETK!
When you mount the ETK to the ECU, you must ensure that the screws and
washers used will not penetrate the ETK printed circuit board.

ETAS Basic Safety Notices
XETK-S23.0 -User Guide 10
Cabling
Use exclusively ETAS cables at the connections of the product! Adhere to the
maximum permissible cable lengths! Observe the assignment of the cables to
the connectors! Detailed information about cabling is located in the ETK User
Guides.
2.4 Identifications on the Product
Fig. 2-1Adhesive Label (Example: Label for XETK-S14.0)
The following symbols are used for identifications of the product:
CAUTION
Differences in case ground potentials can cause high currents to flow
through the shields of the cables that connect various system modules.
Ensure that the module mounting surfaces are at the same electrical poten-
tial or insulate the modules from their mounting surfaces.
Symbol Description
The User Guide must be read prior to the startup of the
product!
Symbol for WEEE, see chapter 2.5 on page 11
Marking for CE conformity, see chapter 2.6 on page 11
Marking for UKCA conformity, see chapter 2.7
on page 11
Symbol for China RoHS, see chapter 2.8 on page 12
Symbol for China RoHS, see chapter 2.8 on page 12
Symbol for electrostatic sensitive components

ETAS Basic Safety Notices
XETK-S23.0 -User Guide 11
2.5 Taking the Product Back and Recycling
The European Union has passed a directive called Waste Electrical and Elec-
tronic Equipment, or WEEE for short, to ensure that systems are setup through-
out the EU for the collection, treating and recycling of electronic waste.
This ensures that the devices are recycled in a resource-saving way represent-
ing no danger to health or the environment.
Fig. 2-2WEEE-Symbol
The WEEE symbol (see Fig. 2-2 on page 11) on the product or its packaging
shows that the product must not be disposed of as residual garbage.
The user is obliged to collect the old devices separately and return them to the
WEEE take-back system for recycling. The WEEE directive concerns all ETAS
devices but not external cables or batteries.
For more information on the ETAS GmbH Recycling software, contact the ETAS
sales and service locations.
2.6 CE Conformity
With the CE mark attached to the product or its packaging, ETAS confirms that
the product corresponds to the product-specific, applicable directives of the
European Union.
The CE Declaration of Conformity for the product is available upon request.
2.7 UKCA Conformity
With the UKCA mark attached to the product or its packaging, ETAS confirms
that the product corresponds to the product-specific, applicable standards and
directives of Great Britain.
The UKCA declaration of conformity for the product is available on request.
XETK-S14.0A Product designation (example)
F00K 110 722 Order number of the product (example)
SN: yyxxxxx Serial number (7-digit)
XXXX/YY Product version
ZZZZ Year of manufacture
ETAS GmbH,... Manufacturer's address
NOTE
For symbols and product information one or several adhesive labels can be
used.
Symbol Description

ETAS Basic Safety Notices
XETK-S23.0 -User Guide 12
2.8 RoHS Conformity
European Union
The EU Directive 2011/65/EU limits the use of certain dangerous materials for
electrical and electronic devices (RoHS conformity).
This product does not contain any of the restricted substances specified in the
EU Directive 2011/65/EU or exceeds the maximum concentrations stipulated
therein. For individual electronic components used in our products, there are
currently no equivalent alternative substances, which is why we make use of
the exception 7C-I in Annex III of this Directive.
ETAS confirms that the product corresponds to this directive which is applica-
ble in the European Union.
China
ETAS confirms that the product meets the product-specific applicable guide-
lines of the China RoHS (Management Methods for Controlling Pollution
Caused by Electronic Information Products Regulation) applicable in China
with the China RoHS marking affixed to the product or its packaging.
2.9 Declarable Substances
European Union
Some products from ETAS GmbH (e.g., modules, boards, cables) use compo-
nents with substances that are subject to declaration in accordance with the
REACH regulation (EU) no.1907/2006.
Detailed information is located in the ETAS download center in the customer
information "REACH Declaration" (www.etas.com/Reach). This information is
continuously being updated.
2.10 Use of Open Source Software
The product uses Open Source Software (OSS). This software is installed in the
product at the time of delivery and does not have to be installed or updated by
the user. Reference shall be made to the use of the software in order to fulfill
OSS licensing terms. Additional information is available in the document "OSS
Attributions List" at the ETAS website www.etas.com.

ETAS Introduction
XETK-S23.0 -User Guide 13
3 Introduction
This chapter contains information about the following topics:
• Applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
• Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
3.1 Applications
The XETK-S23.0 is a JTAG Emulator Probe for TI C2000 Microcontrollers.
Fig. 3-1XETK-S23.0
The XETK-S23.0 supports the standard full duplex 100Base-T Ethernet inter-
face and can be connected directly or via ES59x/ES600/ES89x/ES910 modules
to the PC. No additional ETAS modules are required for the access to the ECU.
The XETK-S23.0 can be used for rapid prototyping applications (bypass) as
well as for measurement and calibration applications.
NOTE
For supported TI microcontrollers, refer to chapter 7.1.3 on page 33.
XETK-S23.0
XETK ECU interface connectors 40 pin Samtec plus 6 pin Molex
Power supply for FCC devices
(VDDSTBY)
Configurable 1.09 V or 1.25 V
SBRAM sense Yes, on board or external sense
Pinless triggering Yes
Timer triggering Yes

ETAS Introduction
XETK-S23.0 -User Guide 14
3.2 Features
3.2.1 General
• 100 Mbit/s Ethernet Interface:
– Direct connection to PC
–Open XCP on Ethernet Protocol supporting a variety of standard
applications
• XETK-S23.0 JTAG Interface:
–Configurable JTAG output levels: 3.3 V or 5.0V
– Configurable JTAG interface clock speed: 10 MHz, 15 MHz
–JTAG Signals available on the 40 Pin Samtec connector
–Pinless startup protocol for XETK recognition and data acquisition
triggering
– Measurement raster down to 100 µs
• “ETK Drivers and Tools” update to support ETAS software tools (INCA,
XCT)
• Firmware update (programming of the logic device) through HSP soft-
ware service packs; removal of XETK or ECU is not necessary
• Mounting possibilities inside or on top of ECU
•ECU flashing via XETK
–Braindead flashing under ProF control
•Permanent storage of configuration in EEPROM
•Temperature range suitable for automotive application
3.2.2 Calibration
• Concurrent use of calibration and measurement performed via micro-
controller
• Working Page & Reference Page (2 page concept) realized by software
pointer mechanism
• Supports special coldstart mechanism (“Calibration Wake Up”):
–Calibration Wake Up: Wake up mechanism to wake up the power sup-
ply of the ECU via the Calibration Wake up pin
– Pull CalWakeUp until Startup Handshake: duration of the Wake up
mechanism is configurable
NOTE
Flashing not supported in initial release, but will be released with the Decem-
ber 2022 INCA release.

ETAS Hardware Description
XETK-S23.0 -User Guide 15
4 Hardware Description
This chapter contains information about the following topics:
• Architecture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
•ECU Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
•XETK Ethernet Interface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
•Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
•ECU Voltage Supervisor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
•Status LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
•Data Emulation and Data Measurement. . . . . . . . . . . . . . . . . . . . . . . . . . 20
•XETK-S23.0 JTAG Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
•Trigger Modes: Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
•Pinless Triggering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
•Timer Triggering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
•Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
•Pull CalWakeUp until Startup Handshake. . . . . . . . . . . . . . . . . . . . . . . . . 23
4.1 Architecture
Fig. 4-1 shows the block diagram of the XETK-S23.0.
Fig. 4-1XETK-S23.0 Architecture
While the microcontroller accesses the program data (not the program code)
out of the data emulation memory provided by the microcontroller, the content
of the data emulation memory can simultaneously be modified by the calibra-
tion and development system through the XETK Ethernet interface. This pro-
cess enables adjustments of parameters, characteristic lines and maps
through the calibration and development system.
XETK-S23.0A
CALWAKEUP
b`r=
fåíÉêÑ~ÅÉ=
`çååÉÅíçêë
FPGA
XCP on
Ethernet
Interface
SRAM
System
Functions
Ar bi ter
100
MBit/s
Ethernet
Phyte
r
Ethernet
Phy
Automatic
Power On
Ethernet
Traffic
Detection
Ethernet
Traffic
Detection
Power
Supply
Monitoring
ECU
Reset
&
Power
Control
MCU
Core
Ethernet
MAC
Measurement
& Calibration
Unit
ECU
Access
Unit
Serial Flash
Configuration
&
Manufacturing
Da t a
Time
Sync.
JTAG Signals
Resets + WD_DIS
Power
Supply
Standby
Supply
Power
ECU
Buffers
ECU
SBRAM
POWER
SUPPLY
40-Pin Samtec
JTAG
Resets + WD_DIS
U-BATT Input
Sense
ECU &
SBRAM
Power
Supplies
Molex 6
DMA
Trigger
Unit
v01

ETAS Hardware Description
XETK-S23.0 -User Guide 16
Using an additional measurement data memory area, the ECU microcontroller
can provide data to the calibration and development system by buffering the
data (DISTAB) and triggering the XETK to read the data via JTAG. The XETK
then reads, buffers, processes and sends this measured data to the PC.
The 100 Mbit/s XETK Ethernet interface provides communication with the PC.
The power supply for the XETK-S23.0 is provided by a switch mode power sup-
ply, to minimize power dissipation.
4.2 ECU Interface
The XETK-S23.0 is connected via connectors CON1 and CON4 to the ECU with
two adapter cables (refer to Fig. 4-2 on page 16). The pin definition depends on
the application and the microcontroller type. In general, the ECU interface con-
sists of
• 1 ECU voltage line, which is not used for XETK power supply, but only for
detection of the ECU status, therefore the power consumption on this
line is negligible (refer to chapter 4.4 on page 17)
• 1 Reset line which allows the XETK to control the system reset of the
ECU
• 1 Reset line which allows the XETK to monitor the system reset of the
ECU
• 5 JTAG Debug line interfaces for the communication between the XETK-
S23.0 and the microcontroller
• 1 Watchdog timer disable line
•7 ground lines for proper shielding of the ECU interface lines
Fig. 4-2Location of the ECU Interface connectors
CON1
CON4

ETAS Hardware Description
XETK-S23.0 -User Guide 17
4.3 XETK Ethernet Interface
The XETK Ethernet interface can be directly connected to the PC via CON2
(refer to Fig. 4-3). No additional ETAS module is required for the access to the
ECU.
The interface is a standard full duplex 100Base-TX Ethernet interface using the
XCP protocol. The XETK Ethernet interface is integrated in the ETAS IP world
with automatic IP management and supports the open automotive "Universal
Measurement and Calibration" standard "XCP on Ethernet" (TCP/IP, UDP/IP).
The open XCP on Ethernet interface allows for connecting to the XETK-S23.0
with third party application softw are.
Fig. 4-3Location of the XETK Ethernet Interface connector (CON2)
4.4 Power Supply
The XETK-S23.0 requires a permanent power supply. It is typically powered
directly from the car battery. The input voltage may vary between 6 V and 36 V.
In case of higher input voltages to the XETK, additional voltage protection is
required. The XETK-S23.0 will also accept voltage dips down to 3V (for addi-
tional details of low voltage operation, see ISO standard 16750).
NOTE
The XETK Ethernet interface is not compatible with the ETK interfaces in
modules like e.g., ES910, ES590, ES591, ES592, ES593-D, ES595, ES1232-A.
The XETK Ethernet interface is compatible with the ECU interface of the
ES910 module and the Ethernet interfaces of the ES592/ ES593-D/ ES595/
ES600/ES88x/ES89x modules.
NOTE
Please see chapter 7.1.2 on page 32 for additional information regarding PC
requirements for the Ethernet interface.
CON2

ETAS Hardware Description
XETK-S23.0 -User Guide 18
From the input battery voltage, the XETK-S23.0 creates all necessary voltages
through switching power supplies on the XETK-S23.0. The power supply of the
ECU is not affected by the XETK-S23.0. An automatic switch ensures that the
power supply of the XETK-S23.0 is automatically switched on and off when the
XETK enters and leaves its standby (sleep) mode.
The XETK-S23.0 can be supplied with power through the six-pin connector,
CON4.
Fig. 4-4Location of the XETK-S23.0 Power Supply Connector CON4
4.5 ECU Voltage Supervisor
The ECU voltage (VDD) is monitored by the XETK to recognize whether the ECU
is switched on or off. Additionally, the ECU RAM standby voltage (VDDSTBY) is
monitored to determine if the standby RAM content is still valid. These two sig-
nals are only used for monitoring therefore the load current is negligible.
The XETK-S23.0 provides two opportunities to supply and supervise the ECU
RAM standby voltage:
• The XETK-S23.0 monitors the VDDSTBY supply on board the XETK. The
microcontroller’s standby power supply pin must be connected to the
XETK pin VDDSTBY.
• The XETK-S23.0 monitors the VSTBY pin, provided by the ECU connec-
tion. The microcontroller’s standby power supply pin must be connected
to the XETK pin VSTBY. The microcontroller’s standby power supply may
be provided by the ECU or by the XETK.
NOTE
The XETK-S23.0 only allows switching between reference page and working
page if there is a valid voltage at the sense pin and the working page has been
initialized by the calibration and development system.
CON4

ETAS Hardware Description
XETK-S23.0 -User Guide 19
4.6 Status LEDs
There are three LEDs (Green, Red, Yellow) displaying the operating status of the
XETK-S23.0 (Fig. 4-5 on page 19).
Fig. 4-5Status LEDs of the XETK-S23.0
LED State Definition
Red On XETK-S23.0 is supplied with power and active (i.e., the
ECU is switched on or the 100 Mbit/s link to the calibration
system is established)
Green Off Working page may be different from reference page. Cali-
bration and development system has downloaded data
since the last power failure. Switching between the Refer-
ence Page and Working Page is possible.
On Power supply has dropped under selected threshold:
- data retention of the calibration data manager in the ECU
is no longer ensured
- as soon as the XETK-S23.0 switches on again, the ECU
switches to the Reference Page.
Green LED stays on until the calibration and development
system downloads data into the calibration data memory.
Otherwise switching to the Working Page is not possible.
Yellow Flashing Communication active
On 100 Mbit/s link to calibration system established
LEDs

ETAS Hardware Description
XETK-S23.0 -User Guide 20
4.7 Data Emulation and Data Measurement
The XETK-S23.0 is a serial XETK using JTAG as the primary microcontroller
interface. Typical for all serial (X)ETKs, the RAM used for data emulation and
data measurement is not accessible by the XETK until the microcontroller is
powered up and the startup handshake is performed.
Serial XETKs use the ETAS two-page concept, consisting of both a Reference
and a Working page.
The Reference Page is located in the ECU flash and cannot be modified by a
simple write access. All changes to the Reference Page must be done via Flash
programming.
The Working Page is located within the microcontroller's EMU RAM. The Work-
ing Page may be a portion of or the entire size of the EMU RAM. The EMU RAM
used for the emulation of calibration data must not be used by the ECU soft-
ware directly as general-purpose RAM. It is recommended that the EMU RAM is
permanently powered by the XETK or ECU. The XETK/INCA has the complete
control over the RAM used as Working Page and it's contents. When enabling
data emulation, the XETK establishes a basic startup configuration of the data
in the Working Page by copying the corresponding data in the Flash to the emu-
lation space.
To enable calibration, the Working Page must be activated. The process of
switching from the Reference Page to the Working Page and vice versa is
known as page switching.
The XETK-S23.0 supports Protocol Based page switching for all supported
microcontrollers. Page switching is done in microcontroller software by switch-
ing the overlay memory on (Working Page) and off (Reference Page) using
microcontroller overlay registers. The XETK-S23.0 does not directly control the
microcontroller overlay registers. Instead, the XETK-S23.0 and microcontroller
software use a simple communication method with a shared mailbox in RAM.
The XETK uses this mailbox to request and monitor page switching; the micro-
controller software is responsible to service this mailbox and perform the page
switches. Using an overlay modification description, also in RAM, the XETK pro-
vides the necessary information of how the overlay registers need to be modi-
fied to realize the page switch which is requested.
The XETK-S23.0 can access both the Reference Page and the Working Page,
regardless of which is active from the microcontroller’s point of view.
Another important restriction is that no access to the memory is possible, while
the ECU is not running. To enable a coldstart measurement in spite of this
restriction, the coldstart measurement procedure is defined to give the user the
feeling of a parallel XETK.
