ETAS BR XETK-S4.0 User manual

ETAS BR_XETK-S4.0
Emulator Probe for STM STELLAR
SR6 MCU Family
User Guide

Copyright
The data in this document may not be altered or amended without special
notification from ETAS GmbH. ETAS GmbH undertakes no further obligation
in relation to this document. The software described in it can only be used if
the customer is in possession of a general license agreement or single
license. Using and copying is only allowed in concurrence with the specifica-
tions stipulated in the contract.
Under no circumstances may any part of this document be copied, repro-
duced, transmitted, stored in a retrieval system or translated into another
language without the express written permission of ETAS GmbH.
© Copyright 2023 ETAS GmbH, Stuttgart
The names and designations used in this document are trademarks or
brands belonging to the respective owners.
BR_XETK-S4.0 | User Guide R05 EN -03.2023

3 | Contents
Contents
ETAS BR_XETK-S4.0 | User Guide
1 Basic Safety Notices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.1 General Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.2 Requirements for Users and Duties for Operators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.3 Intended Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.4 Classification of Safety Messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.5 Safety Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.5.1 Identifications on the Product . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
1.5.2 Taking the Product Back and Recycling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
1.5.3 Declaration of Conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
1.5.4 RoHS Conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
1.5.5 Declarable Substances . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
1.5.6 Use of Open Source Software. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
2 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2.1 Applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2.2 Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
3 Hardware Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
3.1 Architecture. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
3.2 ECU Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
3.3 Automotive Ethernet Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
3.4 Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
3.5 Status LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
3.6 SWD Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
3.7 Data Emulation and Data Measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
3.8 Trigger Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
3.8.1 Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
3.8.2 Pinless Triggering. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
3.8.3 Timer Triggering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
3.9 Reset. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
4 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
4.1 Mounting the BR_XETK-S4.0 on the ECU Housing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
4.1.1 How to attach the BR_XETK-S4.0 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
4.1.2 Fixing the BR_XETK-S4.0 with Mounting Bracket. . . . . . . . . . . . . . . . . . . . . . . . . . . 26
4.1.3 Fixing the BR_XETK-S4.0 without Mounting Bracket . . . . . . . . . . . . . . . . . . . . . . . 28
4.2 Connection to the ECU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
4.3 Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
4.3.1 Compatible Hardware. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
4.3.2 Requirements for failsafe Automotive Ethernet Operation . . . . . . . . . . . . . . . . . 30
4.3.3 CBEB100.1 Automotive Ethernet Media Converter. . . . . . . . . . . . . . . . . . . . . . . . . . 31
4.3.4 CBEB105.1 Automotive Ethernet Media Converter. . . . . . . . . . . . . . . . . . . . . . . . . . 32
4.3.5 ES160.1 Automotive Ethernet Media Converter . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
4.3.6 ES162.1 Automotive Ethernet Media Converter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
4.3.7 ES165.1 Automotive Ethernet Media Converter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
4.3.8 ES88x ECU and Bus Interface Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

4 |
ETAS BR_XETK-S4.0 | User Guide
4.3.9 Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
5 XETK Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
5.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
5.2 Configuration Parameter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
6 Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
6.1 System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
6.1.1 Compatible Hardware. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
6.1.2 PC with one Ethernet Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
6.1.3 Software Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
6.2 Data Emulation and Measurement Memory. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
6.2.1 Data Emulation Memory. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
6.2.2 Measurement Data Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
6.3 Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
6.4 Environmental Conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
6.5 Automotive Ethernet Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
6.6 Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
6.7 Microcontroller Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
6.8 Power-on Delay of ECU Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
6.9 SWD Timing Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
6.9.1 2-Pin SWD Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
6.10 Electrical Characteristics (ECU Interface Connector) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
6.11 Pin Assignment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
6.11.1 Location of the BR_XETK-S4.0 Interfaces. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
6.11.2 Automotive Ethernet Interface Connector CON1. . . . . . . . . . . . . . . . . . . . . . . . . . . 47
6.11.3 ECU Interface Connector CON2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
6.11.4 Power Supply Connector CON3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
6.12 Mechanical Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
7 Cables and Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
7.1 Requirements for failsafe Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
7.2 ETABR1 Cable. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
7.2.1 Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
7.2.2 Pin Assignment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
7.2.3 Order Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
7.3 ETABR2 Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
7.3.1 Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
7.3.2 Mechanical Dimensions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
7.3.3 Pin Assignment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
7.3.4 Temperature Range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
7.3.5 Order Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
7.4 ETABR3 Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
7.4.1 Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
7.4.2 Mechanical Dimensions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
7.4.3 Pin Assignment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
7.4.4 Temperature Range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
7.4.5 Order Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

5 |
ETAS BR_XETK-S4.0 | User Guide
7.5 CBAM290 Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
7.5.1 Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
7.5.2 Mechanical Dimension . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
7.5.3 Tightness. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
7.5.4 Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
7.5.5 Pin Assignment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
7.5.6 Temperature Range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
7.5.7 Order Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
7.6 CBAM295 Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
7.6.1 Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
7.6.2 Mechanical Dimension . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
7.6.3 Tightness. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
7.6.4 Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
7.6.5 Pin Assignment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
7.6.6 Temperature Range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
7.6.7 Order Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
7.7 CBEB120 Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
7.7.1 Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
7.7.2 Order Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
7.8 CBEB121 Cable. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
7.8.1 Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
7.8.2 Pin Assignment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
7.8.3 Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
7.8.4 Order Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
7.9 CBEB125 Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
7.9.1 Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
7.9.2 Order Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
7.10 CBEB240 Cable. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
7.10.1 Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
7.10.2 Assignment of the Automotive Ethernet Channels to the Cable Sections. . 63
7.10.3 Labeling of the Automotive Ethernet Channels and the Cable Sections. . . . 63
7.10.4 Assignment of the Automotive Ethernet Signal to the LEMO Connectors . . 64
7.10.5 Temperature Range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
7.10.6 Order Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
7.11 CBEB242 Cable. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
7.11.1 Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
7.11.2 Assignment of the Automotive Ethernet Channels to the Cable Sections. . 65
7.11.3 Labeling of the Automotive Ethernet Channels and the Cable Sections. . . . 65
7.11.4 Assignment of the Automotive Ethernet Signal to the DSUB9 Connectors 66
7.11.5 Temperature Range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
7.11.6 Order Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
7.12 ETAM2 ECU Adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
7.12.1 Pin Assignment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
7.12.2 ECU Signals. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
7.12.3 Order Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
7.13 ETAM5 ECU Adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
7.13.1 Order Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
7.14 ETAM8 ECU Adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
7.14.1 Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
7.14.2 Product Variants . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
7.14.3 Mechanical Dimensions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
7.14.4 Pin Assignment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

6 |
ETAS BR_XETK-S4.0 | User Guide
7.14.5 ECU Signals. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
7.14.6 Temperature Range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
7.14.7 Order Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
7.15 ETAM9 ECU Adapter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
7.15.1 Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
7.15.2 ECU Signals. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
7.15.3 Temperature Range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
7.15.4 Order Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
7.16 ETAM10 ECU Adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
7.16.1 Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
7.16.2 Mechanical Dimensions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
7.16.3 ECU Signals. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
7.16.4 Temperature Range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
7.16.5 Order Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
8 Ordering Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
8.1 BR_XETK-S4.0. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
8.2 Cable and Adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
8.2.1 XETK - ECU Adapter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
8.2.2 Automotive Ethernet Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
8.2.3 Media Converter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
8.2.4 Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
8.2.5 Mounting Material . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
9 Contact Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
Figures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81

7 | Basic Safety Notices
ETAS BR_XETK-S4.0 | User Guide
1 Basic Safety Notices
This chapter contains information about the following topics:
1.1 General Safety Information
• General Safety Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
• Requirements for Users and Duties for Operators . . . . . . . . . . . . . . . . . . . . . . . . . 7
• Intended Use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
• Classification of Safety Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
• Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Please observe the Product Safety Notices ("ETAS Safety Notice") and the follow-
ing safety notices to avoid health issues or damage to the device.
ETAS GmbH does not assume any liability for damages resulting from improper
handling, unintended use or non-observance of the safety precautions.
1.2 Requirements for Users and Duties for Operators
The product may be assembled, operated, and maintained only if you have the
necessary qualification and experience for this product. Improper use or use by a
user without sufficient qualification can lead to damages or injuries to one's health
or damages to property.
The safety of systems using the product is the responsibility of the system inte-
grator.
General Safety at Work
The existing regulations for safety at work and accident prevention must be fol-
lowed. All applicable regulations and statutes regarding operation must be strictly
followed when using this product.
1.3 Intended Use
An ETK is an electronic component that is installed in a vehicle control unit (ECU)
to read data from the ECU or write data to the ECU.
Application Area of the Product
This product was developed and approved for automotive applications. For use in
other application areas, please contact your ETAS partner.
NOTE
Carefully read the documentation (Product Safety Advice and this User Guide)
that belongs to the product prior to the startup.

8 | Basic Safety Notices
ETAS BR_XETK-S4.0 | User Guide
1.4 Classification of Safety Messages
The safety messages warn of dangers that can lead to personal injury or damage
to property:
1.5 Safety Information
Requirements for Operation
The following requirements are necessary for safe operation of the product:
- Use the product only according to the specifications in the corresponding
User Guide. With any deviating operation, the product safety is no longer
ensured.
- Observe the regulations applicable at the operating location concerning
electrical safety as well as the laws and regulations concerning work safety!
- Do not apply any voltages to the connections of the product that do not cor-
respond to the specifications of the respective connection.
- Connect only current circuits with safety-extra-low voltage in accordance
with IEC61140 (class III equipment) within the voltage limits for accessible
parts in accordance to IEC61010-1.
- The power supply for the product must be safely disconnected from the
supply voltage. For example, use a car battery or a suitable lab power supply.
- Use only lab power supplies with double protection to the supply system.
- Ensure that the connections of the power supply are easily accessible.
- The module does not have an operating voltage switch.
• Switch on the product by connecting the power supply cable with the
power supply or by switching on the power supply.
DANGER
DANGER indicates a hazardous situation with a high risk of death or serious injury
if not avoided.
WARNING
WARNING indicates a hazardous situation of medium risk, which could result in
death or serious injury if not avoided.
CAUTION
CAUTION indicates a hazardous situation of low risk, which may result in minor or
moderate injury if not avoided.
NOTICE
NOTICE indicates a situation, which may result in damage to property if not
avoided.

9 | Basic Safety Notices
ETAS BR_XETK-S4.0 | User Guide
• Switch off the product by disconnecting it from the power supply or by
switching off the power supply.
Potential Equalization
Requirements for the technical State of the Product
The product is designed in accordance with state-of-the-art technology and rec-
ognized safety rules. The product may be operated only in a technically flawless
condition and according to the intended purpose and with regard to safety and
dangers as stated in the respective product documentation. If the product is not
used according to its intended purpose, the protection of the product may be
impaired.
Maintenance and Cleaning
The product is maintenance-free. Use a lightly moistened, soft, lint-free cloth for
cleaning the product. Ensure that no moisture can enter. Never spray cleaning
agents directly onto the product. Do not user any sprays, solvents or abrasive
cleaners which could damage the product.
DANGER
Connect the power cord only with a vehicle battery or with a lab power supply!
A connection to power outlets is prohibited.
Route the power cord in such a way that it is protected against abrasion, dam-
ages, deformation, and kinking. Do not place any objects on the power cord.
Never apply force to insert a plug into a socket. Ensure that there is no contami-
nation in and on the connection, that the plug fits the socket, and that you cor-
rectly aligned the plugs with the connection.
Do not use the product in a wet or damp environment.
Do not use the product in potentially explosive atmospheres.
Keep the surfaces of the product clean and dry.
CAUTION
Danger from inadvertent current flow!
Depending on the design, the shield of the Ethernet cables can be connected
with the housing of the module. Install the products only on components with
the same electrical potential or isolate the products from the components.

10 | Basic Safety Notices
ETAS BR_XETK-S4.0 | User Guide
Transport and Installation
Cabling
Use exclusively ETAS cables at the connections of the product! Adhere to the
maximum permissible cable lengths! Observe the assignment of the cables to the
connectors! Detailed information about cabling is located in the ETK User Guides.
1.5.1 Identifications on the Product
The following symbols are used for identifications of the product:
CAUTION
The ETK can be damaged or destroyed!
Some components of the ETK board may be damaged or destroyed by electro-
static discharges. Please keep the ETK in its storage package until it is installed.
The board should only be taken from its package, configured, and installed at a
workplace that is protected against static discharge.
CAUTION
During installation and removal, ECU and ETK must be in a de-energized state!
CAUTION
Risk of short circuiting the internal signals of the ETK!
When you mount the ETK to the ECU, you must ensure that the screws and
washers used will not penetrate the ETK printed circuit board.
CAUTION
Differences in case ground potentials can cause high currents to flow
through the shields of the cables that connect various system modules.
Ensure that the module mounting surfaces are at the same electrical potential or
insulate the modules from their mounting surfaces.
Symbol Description
The User Guide must be read prior to the startup of the prod-
uct!
WEEE symbol, see chapter Fig. 1-1 on page 11
CE conformity symbol (European Union), see chapter 1.5.3.1
on page 12

11 | Basic Safety Notices
ETAS BR_XETK-S4.0 | User Guide
1.5.2 Taking the Product Back and Recycling
The European Union has passed a directive called Waste Electrical and Electronic
Equipment, or WEEE for short, to ensure that systems are setup throughout the
EU for the collection, treating and recycling of electronic waste.
This ensures that the devices are recycled in a resource-saving way representing
no danger to health or the environment.
Fig. 1-1WEEE-Symbol
The WEEE symbol (see Fig. 1-1 on page 11) on the product or its packaging shows
that the product must not be disposed of as residual garbage.
The user is obliged to collect the old devices separately and return them to the
WEEE take-back system for recycling. The WEEE directive concerns all ETAS
devices but not external cables or batteries.
For more information on the ETAS GmbH Recycling software, contact the ETAS
sales and service locations.
UKCA conformity symbol (Great Britain), see chapter 1.5.3.2
on page 12
China RoHS symbol, see chapter 1.5.4.2 on page 12
China RoHS symbol, see chapter 1.5.4.2 on page 12
Symbol for electrostatic sensitive components
XETK-S14.0A Product designation (example)
F00K 110 722 Order number of the product (example)
SN: yyxxxxx Serial number (7-digit)
XXXX/YY Product version
ZZZZ Year of manufacture
NOTE
For symbols and product information one or several adhesive labels can be used.
Symbol Description

12 | Basic Safety Notices
ETAS BR_XETK-S4.0 | User Guide
1.5.3 Declaration of Conformity
1.5.3.1 CE Declaration of Conformity (European Union)
With the CE mark attached to the product or its packaging, ETAS confirms that the
product corresponds to the applicable product-specific European Directives. The
CE Declaration of Conformity for the product is available upon request.
1.5.3.2 UKCA Declaration of Conformity (Great Britain)
With the UKCA mark attached to the product or its packaging, ETAS confirms that
the product corresponds to the product-specific, applicable standards and direc-
tives of Great Britain. The UKCA declaration of conformity for the product is avail-
able on request.
1.5.4 RoHS Conformity
1.5.4.1 European Union
The EU Directive 2011/65/EU limits the use of certain dangerous materials for elec-
trical and electronic devices (RoHS conformity).
This product does not contain any of the restricted substances specified in the EU
Directive 2011/65/EU or exceeds the maximum concentrations stipulated therein.
For individual electronic components used in our products, there are currently no
equivalent alternative substances, which is why we make use of the exception 7A
and 7C-I in Annex III of this Directive.
ETAS confirms that the product corresponds to this directive which is applicable in
the European Union.
1.5.4.2 China
ETAS confirms that the product meets the product-specific applicable guidelines
of the China RoHS (Management Methods for Controlling Pollution Caused by
Electronic Information Products Regulation) applicable in China with the China
RoHS marking affixed to the product or its packaging.
1.5.5 Declarable Substances
European Union
Some products from ETAS GmbH (e.g., modules, boards, cables) use components
with substances that are subject to declaration in accordance with the REACH
regulation (EU) no.1907/2006.
Detailed information is located in the ETAS download center in the customer infor-
mation "REACH Declaration" (www.etas.com/Reach). This information is continu-
ously being updated.

13 | Basic Safety Notices
ETAS BR_XETK-S4.0 | User Guide
1.5.6 Use of Open Source Software
The product uses Open Source Software (OSS). This software is installed in the
product at the time of delivery and does not have to be installed or updated by the
user. Reference shall be made to the use of the software in order to fulfill OSS
licensing terms. Additional information is available in the document "OSS Attribu-
tions List" at the ETAS website www.etas.com.

14 | Introduction
ETAS BR_XETK-S4.0 | User Guide
2 Introduction
This chapter contains information about the following topics:
• Applications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
• Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2.1 Applications
The BR_XETK-S4.0 is an emulator probe for the STMicroelectronics STELLAR SR6
microcontroller family. It is a serial XETK with an Automotive Ethernet (100BASE-T1)
interface.
Fig. 2-1BR_XETK-S4.0
An Automotive Ethernet media converter is r equired for the access to the BR_X-
ETK-S4.0 by the standard full duplex 100Base-T Ethernet of the PC.
To connect the PC with the BR_XETK-S4.0 and the Automotive Ethernet interface,
ETAS offers different modules:
- CBEB100.1, CBEB105.1, ES160.1, ES162.1, and ES165.1 Automotive Ethernet
Media Converter
- ES882.1 and ES886.x ECU Interface Module
The BR_XETK-S4.0 can be used for rapid prototyping applications (bypass) as well
as for measurement and calibration applications.
NOTE
For supported STMicroelectronics STELLAR SR6 microcontrollers, refer to chap-
ter 6.1.3 on page 40.
BR_XETK-S4.0
ECU interface connector 20 pin FCI
Power supply connector 6 pin MOLEX
Power supply for ED devices (VDDSTBY) 0.999 V
VDDSTBY sense Yes, on board
Pinless triggering Yes
Timer triggering Yes

15 | Introduction
ETAS BR_XETK-S4.0 | User Guide
2.2 Features
- Measurement interface:
• Measurement via SWD interface
• Clock speed up to 70 MHz
• 3.3 V output levels, 5.0 V tolerant SWD input
• Pinless startup protocol for XETK recognition and data acquisition trig-
gering
- Calibration:
• Microcontroller capability of internal Flash emulation can be used
- ECU flashing via XETK
• Braindead flashing under ProF control
- Permanent storage of configuration in EEPROM
- Automotive Ethernet Interface 100BASE-T1:
• Connection to PC via Automotive Ethernet to Standard Ethernet Media
Converter
• Open XCP on Ethernet Protocol
• Supports a variety of standard applications
- “ETK Tools” update to support ETAS software tools (INCA, XCT)
- Firmware update (programming of the logic device) through HSP software
service packs; removal of XETK or ECU is not necessary
- Temperature range suitable for automotive application
For more technical data on the BR_XETK-S4.0 consult the chapter “Technical
Data” on page 39.

16 | Hardware Description
ETAS BR_XETK-S4.0 | User Guide
3 Hardware Description
This chapter contains information about the following topics:
• Architecture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
• ECU Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
• Automotive Ethernet Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
• Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
• Status LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
• SWD Interface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
• Data Emulation and Data Measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
• Trigger Modes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
• Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
3.1 Architecture
Fig. 3-1 shows the block diagram of the BR_XETK-S4.0.
Fig. 3-1BR_XETK-S4.0 Architecture
While the microcontroller accesses the program data (not the program code) out
of the data emulation memory provided by the microcontroller, the content of the
data emulation memory can simultaneously be modified by the calibration and
development system through the Automotive Ethernet interface. This process
enables adjustments of parameters, characteristic lines and maps through the
calibration and development system. Using an additional measurement data mem-
ory area, the ECU microcontroller can provide data to the calibration and develop-
ment system by buffering the data (DISTAB17) and triggering the BR_XETK-S4.0 to
read the data via SWD. The BR_XETK-S4.0 then reads, buffers, processes and
sends this measured data to the PC.
If no additional measurement data memory is available, the BR_XETK-S4.0 can
alternatively read the data to be measured directly from the microcontroller’s
memory. This process is Triggered Direct Measurement (TDM) with DISTAB17.
FPGA
XCP on
BroadR-Reach
Ethernet Interface
Automatic
Power On
Power Supply Sense Ports
ECU Reset
ECU -
Connector
BroadR-
Reach
Ethernet
Phy
Power -
Connector
JTAG / SWD
ECU VDDP
ECU
Reset &
Power
Control
Power
Supply
Monitoring
Power
Supply
Standby
Power
Supply +U-Batt
UBATT1
UBATT2
ECU Power Supply (2x)
CALWAKEUP
Ethernet
MAC
IEEE1588
Timesync
PHY Config
Traffic Detect
Flash
Loader
MCU
Core
SRAM
System
Functions
ECU
Access
Unit
DMA
Trigger
Unit
Data
Flash
I/O -
Buffers
Low
Pass
Filter CMC 100
Mbi t/s

17 | Hardware Description
ETAS BR_XETK-S4.0 | User Guide
The 100 Mbit/s XETK Ethernet interface provides communication with the PC.
3.2 ECU Interface
The BR_XETK-S4.0 is connected via connector CON2 to the ECU with an adapter
cable (refer to Fig. 3-2 on page 17). The pin definition depends on the application
and the microcontroller type. In general, the ECU interface consists of
- 1 ECU voltage line, which is not used for XETK power supply, but only for
detection of the ECU status, therefore the power consumption on this line is
negligible (refer to chapter 3.4 on page 19)
- 1 Reset line which allows the XETK to control and monitor the system reset
of the ECU
- 1 Reset line which allows the XETK to control and monitor the power-on
reset of the ECU
- 5 Debug lines for the communication between the BR_XETK-S4.0 and the
microcontroller
- 5 ground lines for proper shielding of the ECU interface lines.
Fig. 3-2Location of the ECU Interfaces
ETK Connector Description
CON1 XETK Automotive Ethernet interface
CON2 ECU Interface
CON3 Power supply
CON1
CON2
CON3

18 | Hardware Description
ETAS BR_XETK-S4.0 | User Guide
Fig. 3-3ETAM8 Adapter mounted at CON2
3.3 Automotive Ethernet Interface
The Automotive Ethernet interface (100BASE-T1) of the BR_XETK-S4.0 can not be
connected to a PC directly, but a media converter has to be inserted in between.
Its purpose is to transform the physical layers of Automotive Ethernet (1 differen-
tial pair / 2 wires) into Standard Ethernet (2 differential pairs/ 4 wires) and vice-
versa. The media converter has to be connected to CON1 (refer to Fig. 3-4).
The combination of the BR_XETK-S4.0 and the Automotive Ethernet media con-
verter CBEB10x.1 / ES16x.1 or an ES882.1 / ES886.x ECU Interface Module is inte-
grated in the ETAS IP world with automatic IP management and supports the open
automotive "Universal Measurement and Calibration" standard "XCP on Ethernet"
(TCP/IP, UDP/IP).
The open "XCP on Ethernet" interface allows for connecting to the BR_XETK-S4.0
with third party application software.
NOTE
The Automotive Ethernet interface is not compatible with the standard Ethernet
interfaces of ETAS modules. A CBEB10x.1 Media Converter or an ES88x ECU Inter-
face Module is needed to connect the BR_XETK-S4.0 to the PC.
NOTE
Please see chapter 6.1.2 on page 39 for additional information regarding PC
requirements for the Ethernet interface.
CAUTION
See chapter “Requirements for failsafe Automotive Ethernet Operation” on
page 30 for details on wiring the Automotive Ethernet interface cables.
ETAM8
Adapter
2
1
20
19

19 | Hardware Description
ETAS BR_XETK-S4.0 | User Guide
Fig. 3-4Location of the BR_XETK-S4.0 Ethernet Interface connector (CON1)
3.4 Power Supply
The BR_XETK-S4.0 requires a permanent power supply. It is typically powered
directly from the car battery. The input voltage may vary (see chapter 6.6
on page 43). In case of higher input voltages to the XETK, additional voltage pro-
tection is required. The BR_XETK-S4.0 will also accept voltage dips down to 3 V (for
additional details of low voltage operation, see ISO standard 16750).
From the input battery voltage, switch-mode power supplies provide all necessary
voltages on the BR_XETK-S4.0. The power supply of the ECU is not affected by the
BR_XETK-S4.0. An automatic switch ensures, that the power consumption of the
BR_XETK-S4.0 is reduced to a minimum, when the XETK enters its standby (sleep)
mode.
The BR_XETK-S4.0 is supplied with power through the connector CON3.
Fig. 3-5Location of the BR_XETK-S4.0 Power Supply Connector (CON3)
CON1
CON3

20 | Hardware Description
ETAS BR_XETK-S4.0 | User Guide
3.5 Status LEDs
There are three LEDs displaying the operating status of the BR_XETK-S4.0
(Fig. 3-6 on page 20).
Fig. 3-6Status LEDs
LED State Definition
Red On BR_XETK-S4.0 is supplied with power and active (i.e. the ECU
is switched on or the ETAS calibration and development sys-
tem is connected and ready to communicate with the BR_X-
ETK-S4.0)
Green Off Working Page contains data and is accessible from INCA
Flashing BR_XETK-S4.0 is in boot configuration mode:
- measurement and calibration are not possible,
- BR_XETK-S4.0 update with HSP is required
On Power supply has dropped under selected threshold:
- data retention of the calibration data manager in the ECU is
no longer ensured
- as soon as the BR_XETK-S4.0 switches on again, the ECU
switches to the Reference Page.
Green LED stays lit until the calibration and development sys-
tem downloads data into the calibration data memory. Other-
wise switching to the Working Page is not possible.
Yellow Off BR_XETK-S4.0: no link to calibration system established
On 100 Mbit/s communication to calibration system established
LE D green
LED red
LED yellow
