EVCO S.p.A. Vcolor 378 | Installer manual ver. 1.0 | Code 144VC378E104
Page 1 o 50
Vcolor 378
Controllers for bread and pizza deck ovens
ENGLISH
INST LLER M NU L ver. 1.0
CODE 144VC378E104

EVCO S.p.A. Vcolor 378 | Installer manual ver. 1.0 | Code 144VC378E104
Page 2 o 50
Important
Read this document care ully be ore installation and be ore
using the device and take all the prescribed precautions. Keep
this document with the device or uture consultation.
Only use the device in the ways described in this document. Do
not use the device as a sa ety device.
Disposal
The device must be disposed o according to local regulations
governing the collection o electrical and electronic equipment.

EVCO S.p.A. Vcolor 378 | Installer manual ver. 1.0 | Code 144VC378E104
Page 3 o 50
Contents
1 INTRODUCTION .................................. 4
1.1 Product description ............................. 4
1.2 Models available and technical eatures . 5
2 INSTALLATION ................................... 8
2.1 Format eatures .................................. 8
2.2 Measurements in mm (inches) and
installation ......................................... 8
2.3 Installation precautions ..................... 10
3 ELECTRICAL CONNECTION ................. 11
3.1 Vcolor 378M electrical connection ....... 11
3.2 Vcolor 378L electrical connection ........ 13
3.3 Vcolor 378M electrical connection in multi-
base mode ....................................... 15
3.4 Vcolor 378L electrical connection in multi-
base mode ....................................... 15
3.5 Electrical connection with a motorised
venting solenoid valve ....................... 16
3.6 Precautions or electrical connection ... 16
4 FIRST-TIME USE ............................... 17
4.1 First-time use .................................. 17
5 USER INTERFACE ............................. 18
5.1 Initial in ormation ............................. 18
5.2 Splash screen .................................. 18
5.3 STAND-BY screen ............................. 18
5.4 ON screen ....................................... 18
5.5 Recipe book ..................................... 21
5.6 Locked display ................................. 23
6 “WEEKLY PROGRAMMED SWITCH-ON"
FUNCTION ....................................... 23
6.1 Initial in ormation ............................. 23
6.2 Setting and activating the "Weekly
programmed switch-on" unction ........ 23
7 MANAGING LOADS ........................... 24
7.1 Initial in ormation ............................. 24
7.2 Temperature regulation ..................... 24
7.3 Steamer management ....................... 25
7.4 Suction hood management ................ 26
7.5 Buzzer management ......................... 26
7.6 Electronics compartment an .............. 26
7.7 Stand-by/on relay management ......... 26
7.8 Sound relay management .................. 26
7.9 Type 1 or 2 burner ault reset ............ 26
8 CONFIGURATION .............................. 27
8.1 Initial in ormation ............................. 27
8.2 Setting the date and time .................. 27
8.3 List o alarms ................................... 27
8.4 Internal values ................................. 27
8.5 Service ............................................ 27
8.6 Languages ....................................... 27
8.7 Oven cleaning cycle .......................... 27
8.8 Display cleaning ............................... 28
8.9 USB ................................................ 28
9 MULTI-BASE CONFIGURATION ........... 28
10 LIST OF CONFIGURATION
PARAMETERS ................................... 30
11 ALARM MANAGEMENT ....................... 38
12 CONNECTIVITY ................................. 40
12.1 Initial in ormation ............................. 40
12.2 EPoCA cloud plat orm ........................ 41
13 USING THE USB PORT ....................... 42
13.1 Initial in ormation ............................. 42
13.2 Uploading the recipe settings ............. 42
13.3 Downloading the recipe settings ......... 42
13.4 Uploading the settings in the con iguration
parameters ...................................... 42
13.5 Downloading the settings in the
con iguration parameters ................... 42
13.6 Uploading CSV iles to personalise the
graphics, recipes and languages ......... 42
14 ACCESSORIES .................................. 43
14.1 Sa ety trans ormer ............................ 43
14.2 Non-optoisolated RS-485/USB serial
inter ace .......................................... 43
14.3 USB plug or panel installation ............ 43
14.4 Connecting cables ............................. 43
14.5 Buzzer expansion.............................. 44
14.6 4GB USB lash drive .......................... 44
14.7 EVlinking Wi-Fi RS-485 module .......... 44
14.8 EV3 Web gateway ............................. 44
15 TECHNICAL SPECIFICATIONS ............. 45
15.1 Technical data .................................. 45

EVCO S.p.A. Vcolor 378 | Installer manual ver. 1.0 | Code 144VC378E104
Page 4 o 50
1INTRODUCTION
1.1 Product description
Vcolor 378 is a controller or electric bread and pizza deck ovens with a remote touch-screen user inter ace in 5- or 7-inch glass which
its in per ectly with the design o the unit. It can control up to 5 levels through an RS-485 network o power boards connected to a single
user inter ace.
It manages steam (generation, injection and venting) in both automatic and manual mode and independently regulates the power and
temperature o the top, loor and ront heaters. Being able to control the temperature o the ront heater is particularly important or
certain baked goods.
The controller has an oven cleaning unction which uses pyrolysis, a sel -cleaning mechanism that does not require chemical detergents
as ood residue is oxidised at high temperature.
The controller can save up to 99 recipes; each recipe can have up to 8 phases, each with independent settings or duration, temperature,
steam injection cycles, venting and suction. Recipes can be compiled in an ODS ile (complete with pictures in BMP or GIF ormat) and
uploaded to the controller using a USB lash drive, thanks to the innovative programmable plat orm which allows users to customise their
recipes and add new languages. Recipes can also be altered, overwritten and saved directly rom the display and two di erent recipes
can be switched on and o or every day o the week.
Users can interact remotely with their equipment and start up/stop working cycles using the EPoCA® cloud plat orm with Wi-Fi or Ethernet
connectivity (which also enables alternative or parallel control through MODBUS TCP). For more details, compare all the connectivity
options in the Technical Data table and consult the Management and Monitoring Products/Systems and the Connectivity Products/Devices
sections o our website.

EVCO S.p.A. Vcolor 378 | Installer manual ver. 1.0 | Code 144VC378E104
Page 5 o 50
1.2 Models available and technical features
The table below shows the technical eatures o the models available.
Vcolor 378 M & L
with J/K thermocouples
Vcolor 378 M & L
with Pt 100 2 wires
Power supply
Control module 12 Vac 12 Vac
User inter ace Powered by the control module Powered by the control module
nalogue inputs (J/K or Pt100)
Top probe (activated as chamber probe i
regulation is by single analogue input with
power distributed between the top and loor)
J/K thermocouples Pt 100 2 wires
Floor probe (deactivated i regulation is by
single analogue input) J/K thermocouples Pt 100 2 wires
Steam probe J/K thermocouples Pt 100 2 wires
Front probe J/K thermocouples Pt 100 2 wires
Digital inputs (for NO/NC contact)
Power consumption (230 Vac) • •
Thermal switch (230 Vac) • •
Type 1/2 burner ault (230 Vac) • •
Door switch • •
Enable steam injection • •
Switch o device • •
Energy saving • •
Digital outputs (electro-mechanical
relays; res. @ 250 Vac)
Con igurable k1 (de ault top heaters) 5 A 5 A
Con igurable k2 (de ault stand-by/on) 5 A 5 A
Con igurable k3 (de ault loor heater) 5 A 5 A
Con igurable k4 (de ault loor ront heater) 5 A 5 A
Con igurable k5 (de ault chamber light) 5 A 5 A
Con igurable k6 (de ault venting) 5 A 5 A

EVCO S.p.A. Vcolor 378 | Installer manual ver. 1.0 | Code 144VC378E104
Page 6 o 50
Con igurable k7 (de ault steam generation) 5 A 5 A
Con igurable k8 (de ault steam injection) 5 A 5 A
Con igurable k9 (de ault suction hood) 8 A 8 A
Con igurable k10 (de ault electronics
compartment an) 5 A 5 A
Con igurable k11 (de ault sound) 5 A 5 A
Con igurable k12 (de ault reset o burner ault
1/2) 5 A 5 A
Con igurable k13 (de ault top ront heater) 8 A 8 A
Communications ports
RS-485 MODBUS • •
USB • •
Connectivity
RS-485 MODBUS RTU (built-in) • •
Wi-Fi EPoCA/MODBUS TCP (optional through
the EVlinking Wi-Fi module powered by
controller)
• •
Ethernet EPoCA/MODBUS TCP (optional
through EV3 Web gateway) • •
Other features
"Cooking timer" unction • •
"Rapid heating" unction • •
Clock • •
Alarm buzzer • •
Independent management o the power
delivered to top and loor • •
Independent management o the top and loor
temperatures • •
"Weekly programmed switch-on" unction • •
"Programmes" unction • •
"Energy-saving" unction • •

EVCO S.p.A. Vcolor 378 | Installer manual ver. 1.0 | Code 144VC378E104
Page 7 o 50
For more in ormation, see section 1515 “TECHNICAL SPECIFICATIONS”.
The table below lists the purchasing codes o the available models:
Purchasing codes
With J/K thermocouples
Vcolor 378 M (control module + 5” user interface kit):
EVCMC37DJ2E ( lush it installation)
EVCMC37DJ2EF (semi-recessed installation)
Vcolor 378 L (control module + 7” user interface kit):
EVCLC37DJ2E ( lush it installation)
EVCLC37DJ2EF (semi-recessed installation)
Vcolor 378 M&L (additional control modules)
EVCLP37DJ2E
With Pt 100 2 wires
Vcolor 378 M (control module + 5” user interface kit):
EVCMC37DC2E ( lush it installation)
EVCMC37DC2EF (semi-recessed installation)
Vcolor 378 L (control module + 7” user interface kit):
EVCLC37DC2E ( lush it installation)
EVCLC37DC2EF (semi-recessed installation)
Vcolor 378 M&L (additional control modules)
EVCLP37DC2E
For more models, contact the EVCO sales network.

EVCO S.p.A. Vcolor 378 | Installer manual ver. 1.0 | Code 144VC378E104
Page 8 o 50
2ME SUREMENTS ND INST LL TION
2.1 Format features
The control module is available in a split version with an open rame board. User inter aces are available in 5 or 7-inch versions or vertical
operation and have capacitive colour TFT touch-screen graphic displays.
2.2 Measurements and installation of the control module
Measurements are indicated in mm (in). Installation o the control module is on a lat sur ace with spacers.
2.3 Measurements of the user interface
The user inter ace is available in the model or lush installation and in the model or semi-recessed rontal installation. Measurements
vary based on the model as shown below in mm (in).
Vcolor 378 M

EVCO S.p.A. Vcolor 378 | Installer manual ver. 1.0 | Code 144VC378E104
Page 9 o 50
Vcolor 378 L

EVCO S.p.A. Vcolor 378 | Installer manual ver. 1.0 | Code 144VC378E104
Page 10 o 50
2.4 Installation of the user interface
Depending on the model, installation can be:
-lush, rom behind the panel with threaded studs (not provided) welded to hold it in place;
-semi-recessed, rom the ront o the panel with spring clips to hold it in place.
2.5 Installation precautions
- Ensure that the working conditions or the device (operating temperature, humidity, etc.) are within the set limits. See section
15 “TECHNICAL SPECIFICATIONS”
- Do not install the device close to heat sources (heaters, hot air ducts, etc.), equipment with a strong magnetic ield (large
di users, etc.), in places subject to direct sunlight, rain, damp, excessive dust, mechanical vibrations or shocks
- Any metal parts close to the control module must be ar enough away so as not to compromise the sa ety distance
- In compliance with sa ety regulations, the device must be installed properly to ensure adequate protection rom contact with
electrical parts. All protective parts must be ixed in such a way as to need the aid o a tool to remove them
- Ensure that the thermocouple is properly insulated rom contact with metal parts or use already insulated thermocouples.

EVCO S.p.A. Vcolor 378 | Installer manual ver. 1.0 | Code 144VC378E104
Page 11 o 50
3ELECTRIC L CONNECTION
3.1 Vcolor 378M electrical connection
The diagram below shows the electrical connection o the control device with a 5-inch user inter ace.

EVCO S.p.A. Vcolor 378 | Installer manual ver. 1.0 | Code 144VC378E104
Page 12 o 50
N.B.:
-The USB communications port makes it possible to upload and download the device settings and personalise the graphics,
recipes and languages using an ordinary USB lash drive (see section 14. USING THE USB PORT).
-The RS-485 MODBUS communications port enables connection to the Parameters Manager set-up so tware or to the modules
or Wi-Fi or Ethernet connectivity to manage the unit using the EPoCA cloud plat orm or MODBUS TCP systems (see section 13.
CONNECTIVITY).

EVCO S.p.A. Vcolor 378 | Installer manual ver. 1.0 | Code 144VC378E104
Page 13 o 50
3.2 Vcolor 378L electrical connection
The diagram below shows the electrical connection o the control device with a 7-inch user inter ace.

EVCO S.p.A. Vcolor 378 | Installer manual ver. 1.0 | Code 144VC378E104
Page 14 o 50
N.B.:
-The USB communications port makes it possible to upload and download the device settings and personalise the graphics,
recipes and languages using an ordinary USB lash drive (see section 14. USING THE USB PORT).
-The RS-485 MODBUS communications port enables connection to the Parameters Manager set-up so tware or to the modules
or Wi-Fi or Ethernet connectivity to manage the unit using the EPoCA cloud plat orm or MODBUS TCP systems (see section 13.
CONNECTIVITY).

EVCO S.p.A. Vcolor 378 | Installer manual ver. 1.0 | Code 144VC378E104
Page 15 o 50
3.3 Vcolor 378M electrical connection in multi-base mode
The diagram below shows the electrical connection o an RS-485 network with up to 5 control devices with a single 5- or 7-inch user
inter ace.
3.4 Vcolor 378L electrical connection in multi-base mode
The diagram below shows the electrical connection o an RS-485 network with up to 5 control devices with a single 5- or 7-inch user
inter ace.

EVCO S.p.A. Vcolor 378 | Installer manual ver. 1.0 | Code 144VC378E104
Page 16 o 50
3.5 Electrical connection with a motorised venting solenoid valve
The diagram below shows an example o connection with a motorised venting solenoid valve.
The diagram below shows operation with the parameters set as ollows:
u2 = 140 (14 seconds) pause time or cam to run
u3 = 10 (1 second) motor activation time or short milling output
u4 = 30 (3 seconds) motor activation time or long milling output
3.6 Precautions for electrical connection
- Do not use electric or pneumatic screwdrivers on the terminal blocks o the device
- I the device is moved rom a cold to a warm place, the humidity may cause condensation to orm inside. Wait about an hour
be ore switching on the power
- Make sure that the supply voltage, electrical requency and power o the device correspond to the local power supply. See
section 1515 “TECHNICAL SPECIFICATIONS”
- Disconnect the device rom the power supply be ore doing any type o maintenance
- Locate the power cables as ar away as possible rom those or the signal
- To reduce re lections on the signal transmitted along the cables connecting the user inter ace to the control module, it is
necessary to it a termination resistor
- Ensure that the thermocouple is properly insulated rom contact with metal parts or use already insulated thermocouples
- For repairs and or urther in ormation on the device, contact the EVCO sales network.

EVCO S.p.A. Vcolor 378 | Installer manual ver. 1.0 | Code 144VC378E104
Page 17 o 50
4FIRST-TIME USE
4.1 First-time use
Proceed as ollows:
1. Install the device as shown in section 2 “INSTALLATION”, taking all the precautions mentioned in paragraph 2.3 “Installation
precautions”.
2. Make the electrical connection as shown in section 3 “ELECTRICAL CONNECTION”.
3. Connect the power supply to the device: the device will show a splash screen or some seconds.
4. Set the time, date and day o the week. See section 8 “CONFIGURATION”.
5. Con igure the device as shown in section 10 “LIST OF CONFIGURATION PARAMETERS”.
The ollowing table describes the main con iguration parameters. The parameters are listed in the recommended con iguration order.
PARAM. DESCRIPTION FACTORY SETTING
P0
type o probe
0 = J thermocouple
1 = K thermocouple
2 = Pt 100
0
P1
unit o measurement
0 = °C
1 = °F
N.B.: passing rom °C to °F automatically adapts the parameter values; please note that this
parameter does not a ect recipe con iguration
0
P2
type o operation
0 = WITH 1 ANALOGUE INPUT (chamber probe, with separate management o the top and
loor heating by setting the percentage o power delivered to the top and loor heaters)
1 = WITH 2 ANALOGUE INPUTS (top and loor probes, with separate temperature
management or the top and the loor by setting 2 di erent temperature setpoints: one
or the top heaters and one or the loor heaters)
0
P3
mode to enable steam injection activation
0 = MANUAL – steam injection will be enabled i the steam generator is switched on
1 = REMOTE – steam injection will be enabled i the steam generator is switched on and i the
multi-purpose input is activated (until the input is deactivated; only i i5 = 1)
1 = THERMOSTATIC – steam injection will be enabled i steam temperature regulation is
activated and the steam temperature is above t1 - t3
3 = DISABLED – steam injection and generation are disabled and the appropriate menu is
NOT visible
0
P4
ront probe present
0 = no
1 = yes
0
u1
load managed by venting output
0 = ON/OFF SOLENOID VALVE
1 = MOTORISED SOLENOID VALVE - with this setting parameters u2, u3 and u4 are relevant
0
e2
oven con iguration
0 = Single regulator
1 = Multi-base regulator (1 user inter ace with max. 5 power boards connected in a
network)
0
Next check the remaining parameters are appropriately set; see section 10 “LIST OF CONFIGURATION PARAMETERS”.

EVCO S.p.A. Vcolor 378 | Installer manual ver. 1.0 | Code 144VC378E104
Page 18 o 50
5USER INTERF CE
5.1 Initial information
The controller has the ollowing operating modes:
•“OFF”: no power to the device; the display and all
the loads are switched o .
•“STAND-BY”: the device is powered, the display is on
and all the loads are switched o (except the
chamber light i activated manually).
•“ON”: the device is powered and the display is on;
the loads may be switched on, depending on machine
status.
5.2 Splash screen
When the control module is powered up, it de aults to the EVCO
splash screen or a ew seconds.
5.3 ST ND-BY screen
A ter the splash screen, the user inter ace displays the stand-
by screen according to the con iguration o parameter e2.
e2 = 0 e2 = 1
Brie ly press the ON/OFF key to switch the device on.
N.B.: OFF status can be orced by activating input id2 (see
parameter i7) and can be linked to a relay output con igured as
“Stand-by/On” (uxc=10).
I the "weekly programming" unction is enabled by the
parameter (C5 = 1), the Planning key will also be displayed,
making it possible to set weekly programmed switch-ons (see
section 6).
The “Con iguration” key
gives access to set the date and time, con igure parameters,
see the list o alarms (see section 8 “CONFIGURATIONS” or a
detailed description o all the possible options).
The “Chamber Light” key allows the user to switch the chamber
light on and o manually, even when the controller is in stand-
by.
5.4 ON screen
5.4.1 Initial information
Depending on the construction eatures o the oven, and
according to whether it has 1 or 2 analogue inputs, the
controller can be regulated in two di erent ways that have to
be correctly set with parameter P2:
P2 = 0 1 analogue input (chamber probe)
P2 = 1 2 analogue inputs (top probe and loor probe)
Control o the ront heater can also be added and is regulated
in two di erent ways:
•1 dedicated analogue input (P4=1 in con igurations with
r12=0, 1, 3, 4, 5)
•by setting a percentage relative to the working percentage
o the top heater (P4=0 with con iguration r12=2); the
working percentage, set by parameters r16 and r17, will
always be calculated considering the set working
percentage o the top heater as the maximum value.
5.4.2 Oven regulated by one chamber probe
In this type o oven, separate temperature management or the
top and the loor is obtained by setting the percentage o power
delivered above (top) and below ( loor). The percentages can
be set individually and are not a ected by each other. The
ollowing screen is displayed:

EVCO S.p.A. Vcolor 378 | Installer manual ver. 1.0 | Code 144VC378E104
Page 19 o 50
The settings or ovens with one chamber probe are as ollows:
•chamber setpoint (shown in smaller type to the side
o the chamber temperature)
•top power
•loor power
•cooking timer
•recipe selection
•mode (economy or rapid)
•venting
•hood
•chamber light
•steam generator
•steam injection
•stand-by
5.4.3 Oven regulated by one chamber probe + one
probe for floor front
This con iguration di ers rom the previous one as it includes a
dedicated probe (P4=1) to manage the ront heater. The
ollowing screen is displayed:
On the basis o parameter r12, the temperature o the ront can
be:
- absolute (r12=0): in this case parameters r13, r14 and r15
are relevant
- relative to the chamber setpoint (r12=1): in this case the ront
setpoint cannot be changed but is considered the same setpoint
as the chamber; a relay must also be con igured as the ront
loor heater (uxc=3).
5.4.4 Oven regulated by one chamber probe + floor
front % adjutment
I the oven is regulated by a single probe and the ront heater
is not controlled by a temperature probe but a percentage
relative to the top cycle time (P4=0, r12=2, in this case
parameters r16 and r17 are relevant), the ollowing screen is
displayed:
5.4.5 Oven regulated by one chamber probe + one
probe for top/floor front
This oven con iguration is used when there is a chamber probe
(P2=0) and a ront probe (P4=1), with the chamber and ront
setpoints set individually but the percentages o the power
delivered to the top/ loor o the ront the same as those
delivered to the top/ loor o the chamber (r12=5).
Four relay outputs must be con igured in this setting: chamber
top heater (uxc=1), chamber loor heater (uxc=2), ront loor
heater (uxc=3) and ront top heater (uxc=13).
5.4.6 Oven regulated by two probes (top and floor)
In this type o oven there are two probes which are independent
o the top temperature and the loor temperature. Separate
temperature management or the top and loor is obtained by
setting two di erent temperature setpoints: one or the top and
one or the loor. The ollowing screen is displayed:

EVCO S.p.A. Vcolor 378 | Installer manual ver. 1.0 | Code 144VC378E104
Page 20 o 50
The possible settings or ovens with 2 probes (top and bottom)
are as ollows:
•top setpoint (shown in smaller type to the side o the
top temperature)
•loor setpoint (shown in smaller type to the side o
the loor temperature)
•cooking timer
•recipe selection
•mode (economy or rapid)
•venting
•hood
•chamber light
•steam generator
•steam injection
•stand-by
5.4.7 Oven regulated by two probes (top and floor) +
one probe for floor front
This con iguration di ers rom the previous one as it includes a
dedicated probe (P4=1) to manage the loor ront heater. The
ollowing screen is displayed:
On the basis o parameter r12, the temperature o the ront can
be:
- absolute (r12=0): in this case parameters r13, r14 and r15
are relevant;
- relative to the top setpoint (r12=3): in this case the setpoint
o the ront cannot be changed but is considered the same
setpoint as the top;
- relative to the loor setpoint (r12=4): in this case the setpoint
o the ront cannot be changed but is considered the same
setpoint as the loor; a relay must also be con igured as the
loor ront heater (uxc=3).
5.4.8 Status bar
When the device is switched on, the oven is already operating
and the outputs are active according to the required settings.
The status bar shows the unction being per ormed by the oven:
Pre-heating
Oven up to temperature, start-up o cycle
Cycle in progress
Cycle terminated
5.4.9 Steamer
I enabled by parameter P3 (except with P3=3, in which case
the two icons will not be visible), two icons will appear on the
display to indicate steamer management and manual steam
injection. The icons have the ollowing meanings:
Steamer on
Steamer o
Manual injection enabled
Manual injection disabled
The ollowing menu opens when the steamer key is pressed:
•OFF: key to switch the steamer o
•ON: key to switch the steamer on
•AUTO: activate automatic cycle
•SET: set automatic cycle
