Event Lighting WIP1320 User manual

Model No. WIP1320
USER MANUAL
For safety, please read this user manual carefully before initial use.
Event Lighting reserves the right to revise the manual at any time. Information and specifications within this
manual are subject to change without notice. Event Lighting assumes no liability or responsibility for any
errors or omissions. Please consult Event Lighting for any clarification or information regarding this item.
www.event-lighting.com.au
Ver 1.0

www.event-lighting.com.au
1
CONTENTS
Safety Instructions
Product Installation
Diagrams
Control Board Operation
DMX chart
Technical specifications
Warranty

www.event-lighting.com.au
2
Safety Instructions
WARNING
• Do not open this device, there is no user-serviceable parts inside. Risk of electric shock.
• Do not look at the light source when the device is on.
• CAUTION: This unit's housing may be hot during and after operation.
• Install this device in a location with adequate ventilation, at least 20 inch (50 cm) from adjacent surfaces.
• Do not leave any flammable material within 50 cm of this unit while operating or connected to power.
• Use a safety chain when mounting this device overhead.
• Do not operate this device outdoors or in any location where dust, excessive heat, water, or humidity may affect it.
• Do not operate this device if the housing, lenses, or cables appear damaged.
• Do not connect this device to a dimmer or rheostat.
• ONLY connect this device to a grounded and protected circuit.
• ONLY use the hanging bracket to carry this device.
• In case of a serious operating problem, stop using immediately.
• The maximum ambient temperature is 104° F (40° C). Do not operate this device at higher temperatures.
Power Input & Power Linking
This device has an auto-switching power supply work with input voltage range of 100~240 VAC, 50/60 Hz.
Link up to the maximum 8A. DO NOT exceed this number.
Product Installation
This device can be mounted in many orientations provided each individual device is secured by the use of correct
mounting bracket.
Use a safety chain when mounting this device overhead.

www.event-lighting.com.au
3
Lux Chart
Dimensions

www.event-lighting.com.au
4
Menu Map
Display Options / Values Function
Address <001> to <512> Select DMX address
Channel 4, 5, 7, 13, 15, 31 Select DMX channel modes
DMX Monitor
Channel 4 Mode CH:01 to CH:04 Select DMX channel mode first, set up each
channel values to manual control according to
DMX chart.
Channel 5 Mode CH:01 to CH:05
Channel 7 Mode CH:01 to CH:07
Channel 13 Mode CH:01 to CH:13
Channel 15 Mode CH:01 to CH:15
Channel 31 Mode CH:01 to CH:31
Auto Auto00
Speed <000> to <255>
Select auto program and adjust auto run speed
Auto01
Auto02
….
Auto36
Effect
on Auto
Dimmer <000> to <255> Adjust dimmer level and switch on strobe at
different speed for auto run
Strobe <000> to <255>
MAS mode Yes <Master> or <Slave> Select master or slave mode
No Switch off Master/Slave selection function
Back L on Display background light always stays on
60s Display background light turns off after 60s
120s Display background light turns off after 120s
300s Display background light turns off after 300s
Temp Temp1 XXº Display current temperature on LED panel
Temp2 XXº Display current temperature on chassis
Info Test 1 Test mode without strobe
Test 2 Test mode with strobe
Reset Yes or No Recover to factory default
Version Display current version
Dimmer curve <Curve 0> - <Curve 3> Select dimming curve
Dimmer control <Speed 0> - <Speed 7> Select fade time
DMX Address
After select the “Address” and press “Enter”, use “Up” and “Down” button to select the desired DMX address, press
“Entre” to save new setting.
DMX Modes
After select the “Channel” and press “Enter”, use “Up” and “Down” button to select the desired DMX channel mode,
press “Entre” to save new setting.
DMX Monitor Mode
It is manual control mode according to DMX chart without DMX controller.

www.event-lighting.com.au
5
Set up DMX channel from control panel. When fixture is in 4 DMX channel mode, you will only able to set up from Ch1
to Ch4. When fixture is in 31 DMX channel mode, you will only able to set up from Ch1 to Ch31.
Use “Up” and “Down” button to set up each channel value from <000> to <255>, press “Enter" to save new setting.
Auto Mode
This fixture has 37 built-in programs. Enter "Auto" mode, use “Up” and “Down” button to select the built-in programs
from <Auto 00> to < Auto 36>, then press the "Enter" to confirm. Use “Up” and “Down” button to select the operating
speed of the program from <000> to <255>, press “Enter" to save new setting. You have to use “Effect on Auto” mode
to adjust the brightness, also add strobe effect and adjust strobe speed to auto run.
Effect on Auto
Use “Effect on Auto” to switch on dimmer and strobe function to auto mode. Enter “Effect on Auto” mode, use “Up” and
“Down” button to select dimmer level from <000> to <255>, and then press the "Enter" to confirm. Use “Up” and “Down”
button to select strobe speed from <000> to <255>, press “Enter" to save new setting.
Master/Slave Mode
Set the master fixture to auto or manual modes.
Enter “Master” mode, use “Up” and “Down” button to select “Yes”, and then select <slave>, press “Enter” to set fixture to
slave mode.
Use DMX cable to link master and slave fixture together.
DMX Data
When there is a <*> flashing, the fixture is not receiving any DMX signal. A solid <*> indicates DMX signal is being
received. DMX takes priority over all other functions when a signal is being received.
Once DMX signal is lost, the fixture will revert back to the original setting, which also could be DMX or Manual or
Automatic mode.
DMX Chart
4 channels Mode
Channel Value Function
1 000-255 Red: 0% to 100%
2 000-255 Green: 0% to 100%
3 000-255 Blue: 0% to 100%
4 000-255 White: 0% to 100%
5 channels Mode
Channel Value Function
1
000-005 No function
006-250 Strobe speed from slow to fast at RGBW full on
251-254 RGBW full on
255 Special strobe effect at RGBW full on
2
000-005 No function
006-250 Strobe speed from slow to fast at red full on
251-255 Red full on
3
000-005 No function
006-250 Strobe speed from slow to fast at green full on

www.event-lighting.com.au
6
251-255 Green full on
4
000-005 No function
006-250 Strobe speed from slow to fast at blue full on
251-255 Blue full on
5
000-005 No function
006-250 Strobe speed from slow to fast at white full on
251-255 White full on
7 channels Mode
Channel Value Function
1 000-255 RGBW dimmer 0% to 100%
2 000-255 Intensity of strobe from short to long
3 000 Strobe off
001-255 Strobe speed from slow to fast
4 000-255 Random strobe
5 000-009 No function
010-255 Strobe with effect
6 000-255 Speed of effect from low to fast
7 000-255 Macro
13 channels Mode
Channel Value Function
1 000-255 Dimmer 0% to 100%
2 000-255 Red: 0% to 100%
3 000-255 Green: 0% to 100%
4 000-255 Blue: 0% to 100%
5 000-255 White: 0% to 100%
6 000-255 Intensity of strobe from short to long
7 000-255 Strobe with effect
8 000-255 Speed of effect from low to fast
9 000-255 Macro
10 000-255 Red at background: 0% to 100%
11 000-255 Green at background: 0% to 100%
12 000-255 Blue at background: 0% to 100%
13 000-255 White at background: 0% to 100%
15 channels Mode
Channel Value Function
1 000-255 Dimmer 0% to 100%
2 000-255 Red: 0% to 100%
3 000-255 Green: 0% to 100%
4 000-255 Blue: 0% to 100%
5 000-255 White: 0% to 100%
6 000-255 Intensity of strobe from short to long
7 000 Strobe off
001-255 Strobe speed from slow to fast
8 000-255 Random strobe

www.event-lighting.com.au
7
9 000-255 Strobe with effect
10 000-255 Speed of effect from low to fast
11 000-255 Macro
12 000-255 Red at background: 0% to 100%
13 000-255 Green at background: 0% to 100%
14 000-255 Blue at background: 0% to 100%
15 000-255 White at background: 0% to 100%
31 channels Mode
Channel Value Function
1 000-255 Master dimmer
2 000-255 Block 1 red
3 000-255 Block 1 green
4 000-255 Block 1 blue
5 000-255 Block 1 white
6 000-255 Block 2 red
7 000-255 Block 2 green
8 000-255 Block 2 blue
9 000-255 Block 2 white
10 000-255 Block 3 red
11 000-255 Block 3 green
12 000-255 Block 3 blue
13 000-255 Block 3 white
14 000-255 Block 4 red
15 000-255 Block 4 green
16 000-255 Block 4 blue
17 000-255 Block 4 white
18 000-255 Block 5 red
19 000-255 Block 5 green
20 000-255 Block 5 blue
21 000-255 Block 5 white
22 000-255 Block 6 red
23 000-255 Block 6 green
24 000-255 Block 6 blue
25 000-255 Block 6 white
26 000-255 Intensity of strobe from short to long
27 000 Strobe off
001-255 Strobe speed from slow to fast
28 000-255 Random strobe
29 000-255 Strobe with effect
30 000-255 Speed of effect from low to fast
31 000-255 Macro

www.event-lighting.com.au
8
TECHNICAL SPECIFICATIONS
Power
-Input Voltages: 100V~240V AC,50/60Hz
-Power Consumption: 1150W
-Power Connection: Seetronic® Outdoor Powerkon Input Connection
Photometrics
-Light Source: 1320 pcs 0.8W SMD5050 RGBW LEDs
-Beam Angle: 120°
-Output: 2,200 lux @3.0 M RGBW full on
-PWM: 2,000 Hz
-LED Life: 50,000 hours
Effects
-Dimming: 0 - 100%
-Strobe: 0.5 - 25 Hz
Control
-Operational Modes: Manual, Auto Program, Master / Slave & DMX Modes
-Section Control: Yes
-Display: 4-button LCD Display Control Panel
-DMX Protocol: DMX512
-DMX Channel Mode: 4 / 5 / 7 / 13 / 15 / 31
-DMX Interface: Seetronic® 3 Pin Outdoor in / out DMX Interfaces
Housing
-Housing Materials: Die-cast Aluminium Housing
-Housing finish: Matte Black
-IP Rate: IP65
-Cooling: Sensor Thermostat Controlled Fan
-Dimension: 490 x 285 x 205 mm
-Net Weight: 8.7 kg
-Rigging: 2pcs Omega Brackets with 1/4-turn Quick Locks
WARRANTY
Please refer to your local dealer or please contact Event Lighting Pty Ltd
Website: www.event-lighting.com.au
