Event Lighting LM150B User manual

LM150B
150W LED Beam Moving Head
USER MANUAL
For safety, please read this user manual carefully before initial use.
Event Lighting reserves the right to revise the manual at any time. Information and specifications within this
manual are subject to change without notice. Event Lighting assumes no liability or responsibility for any
errors or omissions. Please consult Event Lighting for any clarification or information regarding this item.
Version: 1.0 (revised 05/11/2020)

www.event-lighting.com.au
2
Safety Instructions
Warning
• Do not open this device, there are no user-serviceable parts inside. Risk of electric shock.
• Do not look at the light source when the device is on.
Caution: This unit's housing may be hot during and after operation.
• Install this device in a location with adequate ventilation, at least 20 inches (50 cm) from adjacent
surfaces.
• Do not leave any flammable material within 50 cm of this unit while operating or connected to
power.
• Use a safety chain when mounting this device overhead.
• Do not operate this device outdoors or in any location where dust, excessive heat, water, or
humidity may affect it.
• Do not operate this device if the housing, lenses, or cables appear damaged.
• Do not connect this device to a dimmer or rheostat.
• ONLY connect this device to a grounded and protected circuit.
• ONLY use the hanging bracket to carry this device.
• In case of a serious operating problem, stop using immediately.
• The maximum ambient temperature is 104° F (40° C). Do not operate this device at higher
temperatures.
Power Input & Power Linking
This device has an auto-switching power supply work with input voltage range of 100~240 VAC, 50/60 Hz.
Link up to the maximum 8A. DO NOT exceed this.
Fuse Replacement
If the fine-wire fuse of the device fuses, only replace the fuse by a fuse of same type and rating.
Before replacing the fuse, unplug mains lead.
Procedure:
Step 1: Unscrew the fuse holder on the rear panel with a fitting screwdriver from the housing
(anticlockwise).
Step 2: Remove the old fuse from the fuse holder.
Step 3: Install the new fuse in the fuse holder.
Step 4: Replace the fuse holder in the housing and fix it.

www.event-lighting.com.au
3
Product Installation
• This device can be mounted in many orientations provided each individual device is secured by the
use of correct mounting bracket.
• Use a safety chain when mounting this device overhead.

www.event-lighting.com.au
4
Dimensions
Lux Chart

www.event-lighting.com.au
5
Colour Wheel
Red
Light Green
Blue
Magenta
Green
Light Yellow
Yellow
Light Blue
Purple
Light Orange
Light Blue
Pink
Indigo
Open
Orange
Static Gobo Wheel
Position 1
Position 10
Position 2
Position 11
Position 3
Position 12
Position 4
Position 13
Position 5
Position 14
Position 6
Position 15

www.event-lighting.com.au
6
Position 7
Position 16
Position 8
Position 17
Position 9
Open
Menu Operation
Menu – Move up a level.
Up – Move selection up one item.
Down – Move selection down one item.
Enter – Select/Move down a level.

www.event-lighting.com.au
7
Menu
MENU
DESCRIPTION
Function
Mode
DMX Address
A001~AXXX
DMX Address Setting
Channel Mode
CH13
13 Channel Mode
CH15
15 Channel Mode
Auto Run
Internal Program1~8
Internal Program
State: Master/Alone
Auto Run State
Auto Run (On/Off)
Toggle Auto Run
Music Control
Internal Program1~8
Internal Program
State: Master/Alone
Sound Control State
Music Run (On/Off)
Toggle Sound Control
Option
Reset Default
Yes/No
Reset to Default Setting
Signal Set
DMX
Wireless DMX
Wireless TX
Wired DMX
Wireless DMX receiver
Wireless DMX transceiver
Pan / Tilt
Reverse Pan (On/Off)
Reverse Tilt (On/Off)
Select Pan 630°/540°/360°
Select Tilt 270°/180°/90°
Limit Mode OFF/CEN./R/L
Reverse Pan
Reverse Tilt
Pan Degree (Default 540°)
Tilt Degree (Default 270°)
Select Edge or Corner Range
UI SET
Mic Sens. 0~99%
Hold on no DMX(On/Off)
Flip Display (On/Off)
Microphone Sensitivity Setting
Hold or no hold
Flip Display
Information
Temperature
XXX℃/℉
Current Temperature
Software
Version
V1.0~V9.9
Current Software Version
Manual
Control
Reset
All
Pan/Tilt
Colour
Gobo
Others
Reset all Setting
Reset Pan/tilt Setting
Reset Colour Setting
Reset Gobo Setting
Reset other Setting
Channel
PAN=XXX……
Manual Control Channel
ADVANCE
D
(Access
Code 088)
Calibration
PAN=XXX……
Calibration
The default selection for each setting is highlighted.
Press the Up and Down buttons simultaneously for 3 seconds to reverse the display.

www.event-lighting.com.au
8
DMX Chart
Mode/Channel
Value
Function
13
15
1
1
Pan
0..255
Pan movement
2
2
Pan Fine
0..255
Fine control of pan movement
3
3
Tilt
0..255
Tilt movement
4
4
Tilt Fine
0..255
Fine control of tilt movement
5
5
Colour
0..7
Open / white
8..15
Red
16..23
Blue
24..31
Green
32..39
Yellow
40..47
Purple
48..55
Light Blue
56..63
Indigo
64..71
Orange
72..79
Light Green
80..87
Magenta
88..95
Light Yellow
96..103
Light Blue
104..111
Light Orange
112..127
Pink
128..189
Forward rainbow effect, fast to slow
190-193
Colour rotation stop
194..255
Backward rainbow effect, slow to fast
6
6
Gobo wheel 1
0..4
Open
5..9
Gobo 1
10..14
Gobo 2
15..19
Gobo 3
20..24
Gobo 4
25..29
Gobo 5
30..34
Gobo 6
35..39
Gobo 7

www.event-lighting.com.au
9
40..44
Gobo 8
45..49
Gobo 9
50..54
Gobo 10
55..59
Gobo 11
60..64
Gobo 12
65..69
Gobo 13
70..74
Gobo 14
75..79
Gobo 15
80..84
Gobo 16
85..89
Gobo 17
90..97
Gobo 1 shake slow to fast
98..105
Gobo 2 shake slow to fast
106..113
Gobo 3 shake slow to fast
114..121
Gobo 4 shake slow to fast
122..129
Gobo 5 shake slow to fast
130..137
Gobo 6 shake slow to fast
138..145
Gobo 7 shake slow to fast
146..153
Gobo 8 shake slow to fast
154..161
Gobo 9 shake slow to fast
162..169
Gobo 10 shake slow to fast
170..177
Gobo 11 shake slow to fast
178..185
Gobo 12 shake slow to fast
186..193
Gobo 13 shake slow to fast
194..201
Gobo 14 shake slow to fast
202..209
Gobo 15 shake slow to fast
210..217
Gobo 16 shake slow to fast
218..225
Gobo 17 shake slow to fast
226..255
Forward wheel pin, slow to fast
7
7
Shutter
0..31
Shutter closed
32..63
Shutter open
64..95
Strobe effect slow to fast
96..127
Shutter open
128..159
Pulse effect, slow to fast
160..191
Shutter open
192..223
Random strobe effect, slow to fast
224..255
Shutter open
8
8
Dimmer
0..255
Dimmer 0%...100%
9
9
Focus
0..255
In(near) to out(far)

www.event-lighting.com.au
10
10
10
Rotating prism, Prism
0..5
OFF
6..127
ON
128..189
Forward rotation, fast to slow
190..193
Prism rotation stop
194..255
Reverse rotation, slow to fast
11
11
Frost
0..199
Frost swing out
200..255
Frost swing in
12
12
Speed pan/tilt
0..225
Pan/tilt speed, fast to slow
226..235
Blackout during pan/tilt functions
236..245
Blackout when colour and gobo switching
246..255
TBD
13
13
Special function
0..19
TBD
20..29
TBD
30..39
TBD
40..79
TBD
80..84
Reset all
85..87
Reset scan
88..90
Reset colour
91..93
Reset gobo
94..96
TBD
97..99
Reset other motor
100..109
Internal program 1
110..119
Internal program 2
120..129
Internal program 3
130..139
Internal program 4
140..149
Internal program 5
150..159
Internal program 6
160..169
Internal program 7
170..179
Internal program 8
180..189
Internal sound program 1
190..199
Internal sound program 2
200..209
Internal sound program 3
210..219
Internal sound program 4
220..229
Internal sound program 5
230..239
Internal sound program 6
240..249
Internal sound program 7
250..255
Internal sound program 8

Vector
Mode
Value
Function
14
Colour Time
0..255
Colour speed, fast to slow
15
Gobo Time
0..255
Gobo speed, fast to slow
The device is controlled by universal DMX 512 protocol, DMX address is the start channel used
to receive instructions from the external controller. For independent control, each fixture must be
assigned its unique address control channels. For example, this device has two channel modes:
13/15, if we set the mode at standard 15 channels mode, and there are several models need to
be independently controlled, we just simply address first fixture at 1, and second fixture at 16,
third one at 31, etc.
• If the devices have the same address, they will behave synchronically.
• Display is flashing when no DMX signal is received.
More Functions
• Software upgrade function via DMX cable. If there is any new firmware for this device, it
can be upgraded simply via a software upgrade box, without the need to change any
mechanical parts. The upgrade box is not included in the package, if you need any
further assistance please contact your authorized dealer.
• Hibernation. The device will enter sleep mode if activated after a period of disconnecting
DMX signal to save power and will wake immediately when the DMX signal is sent or
received again.
Technical Specifications
Photometric
• Light Source: 150W White LED 7,500K
• Beam Angle: 2°
• Output: 32,300lux @ 5m
• PWM: 500Hz
• LED Lifespan: 50,000hours
Colour
• 1 colour wheel (14 Colours + Open)
Gobo
• Fixed: 1 x (17 + open) fixed gobo wheel

www.event-lighting.com.au
12
Effects
• Prism: 8-facet
• Dimming: 0~100%
• Strobe: 0.6~18Hz
• Focus: 2.5~30m linear via DMX
Movement
• 8/16 – bit, auto-reposition
• Pan: 360°/540°/630°
• Tilt: 90°/180°/270°
• Limit mode: Centre/Corner/Edge
Power
• Input Voltage: 90~260V AC, 50/60Hz
• Power Consumption: 200W
• Connection: PowerCon in/out
• Fuse: F4A, 250V
Control
• Protocol: DMX512
• Operation modes: DMX, auto, manual, sound active, master/slave
• DMX Channels: 13/15
• Interface: 3-pin XLR in/out
• Built-in Programming: Yes
• Sound Active: Yes
• Display: 4-button 2.4inch TFT LCD display control panel
Housing
• Materials: Metal & flame retardant ABS
• Finishing: Matte black
• IP rating: IP20
• Cooling: Fan
• Net Weight: 11.5kg
• Rigging: 2x omega brackets with 1/4-turn quick locks
Warranty
Please refer to your local dealer or contact Event Lighting Pty Ltd.
