Event Lighting PAR12X8L User manual

PAR12X8L
12x 8W RGBW 4-in-1 LED PAR
USER MANUAL
For your safety, please read this user manual carefully before use.
Event Lighting reserves the right to revise the manual at any time. Information and specifications
within this manual are subject to change without notice. Event Lighting assumes no liability or
responsibility for any errors or omissions. Please consult Event Lighting for any clarification or
information regarding this item.
Version 1.1 – 23/10/2019 (revised 05/11/2020)

www.event-lighting.com.au
1
Safety Instructions
Warning
• Do not open this device, there are no user serviceable parts inside. Risk of electric
shock.
• Do not look directly at the light source from close range.
• Avoid contact with the unit during operation, as the housing may become hot. Allow the
fixture to cool for at least 15 minutes after turning off before touching.
• Install this device in a location with adequate ventilation, at least 50cm from adjacent
surfaces.
• Do not operate this device, or connect this device to power, within 50cm of any
flammable material.
• Use a safety chain when mounting this device overhead.
• Do not operate this device outdoors where excessive dust, heat, water, or humidity may
affect it.
• Do not operate this device if the housing, lenses, or cables appear damaged.
• Do not connect this device to a dimmer or rheostat.
• Do not operate this device at temperatures higher than 40°C (104°F).
• Only connect this device to a grounded and protected circuit.
• Only use the hanging bracket to carry this device.
• Stop using this device immediately if a serious operating problem becomes apparent.
Fuse Replacement
If the fine-wire fuse of the device fuses, replace the fuse with one of the same type of rating.
Before replacing the fuse, unplug the device from the power source.
Fuse Replacement Steps
1. Unscrew the fuse holder located on the rear panel from the housing.
2. Remove the old fuse from the holder.
3. Install the new fuse into the holder.
4. Place the fuse holder back into the housing and secure tightly.
Product Installation
PAR12X8L can be mounted in many orientations, provided each individual device is secured by
the use of the correct mounting bracket. Use a safety chain when mounting PAR9X15O
overhead.

www.event-lighting.com.au
2
Dimensions
Lux Chart

www.event-lighting.com.au
3
Control Board Operation
Menu Map
->
-
Select DMX address
->
or
Select DMX channel mode (CH-1: 4ch /
CH-2: 9ch)
->
-
Set program speed
->
-
Select built-in program
->
Select sound active mode
->
-
Select static colour mode
(See static colour mode chart below)
->
-
Set strobe speed (Hz)
->
-
Set red colour intensity
->
-
Set green colour intensity
->
-
Set blue colour intensity
->
-
Set white colour intensity
->
-
Set dimmer speed
(nod0: fastest / nod4: slowest)
->
or
Toggle LED display on / off
->
Long press “Enter” button to show current temperature
->
Show current software version
->
or
Restore settings to factory default
Static Colour Mode
Value
Function
C1
Red
C2
Green
C3
Blue
C4
White

www.event-lighting.com.au
4
C5
Red+White
C6
Green+White
C7
Blue+White
C8
Green+Blue
C9
Red+Blue
C10
Red+Green
C11
Red+Green+Blue
C12
Green+Blue+White
C13
Red+Blue+White
C14
Red+Green+White
C15
Red+Green+Blue+White
DMX Chart
4 Channel Mode
Channel
Value
Function
1
000-255
Red: 0% ~ 100%
2
000-255
Green: 0% ~ 100%
3
000-255
Blue: 0% ~ 100%
4
000-255
White: 0% ~ 100%

www.event-lighting.com.au
5
9 Channel Mode
Channel
Value
Function
Note
1
000-255
Master DIMMER 0% ~ 100%
2
000-255
Red: 0% ~ 100%
3
000-255
Green: 0% ~ 100%
4
000-255
Blue: 0% ~ 100%
5
000-255
White: 0% ~ 100%
6
000-012
Strobe OFF
013-255
Strobe (slow-fast)
7
000-009
No Function
010-019
Program 1
020-029
Program 2
030-039
Program 3
040-049
Program 4
050-059
Program 5
060-069
Program 6
070-079
Program 7
080-089
Program 8
090-099
Program 9
100-109
Program 10
110-119
Program 11
120-129
Program 12
130-139
Program 13
140-255
Sound active mode
8
000-255
Speed of auto programs (slow
~ fast)
Ch7 must be set between
10-139
9
000-255
Colour fade time (jump ~ fade)
Mode must be set to “nod0”
IR Remote
In order to use the IR Remote, PAR12X8L must be in DMX mode without an active DMX
connection. If a DMX signal is received, PAR12X8L will prioritise the DMX signal and ignore the
IR Remote.
Use On/Off to turn PAR12X8L on or off. The current IR settings will be saved automatically when
PAR12X8L is powered off and reloaded when it is turned on again. To reset to the factory default
Blackout mode, long press Off.

www.event-lighting.com.au
6
Press R/G/B/W to light up the LEDs in red, green, blue, white, amber or
UV respectively. There is also a selection of pre-set colours underneath
the R/G/B/W buttons, known as the D Area. Press a button in the D
Area to select that colour.
Press X to increase the intensity of the selected colour and Y to
decrease the intensity of the selected colour.
Press Auto/Sound/Strobe to switch on or off Auto mode, Sound Active
mode and Strobe mode, respectively.
Press Blackout to clear all the remote settings and blackout
PAR12X8L.
Technical Specifications
Photometric
• Light Source: 12x 8W RGBW 4-in-1 LEDs
• Beam Angle: 40°
• PWM: 20,000Hz
• LED Lifespan: 50,000hours
Effects
• Dimming: 0~100%
• Strobe: 1 - 20 Hz
Power
• Input Voltage: 100~240V AC, 50/60Hz
• Power Consumption: 60W
• Connection: IEC in/out
Control
• Operation Modes: DMX, manual, auto, sound active, IR remote, master/slave
• DMX channels: 4/9
Housing
• Cooling: Fanless Cooling
• Net weight: 1.85kg
Warranty
Please refer to your local dealer or contact Event Lighting.
