Event Lighting PAR9X12OB User manual

PAR9X12OB
9x 12W RGBWAU 4-in-1 Outdoor Battery LED PAR
USER MANUAL
For your safety, please read this user manual carefully before use.
Event Lighting reserves the right to revise the manual at any time. Information and specifications
within this manual are subject to change without notice. Event Lighting assumes no liability or
responsibility for any errors or omissions. Please consult Event Lighting for any clarification or
information regarding this item.
Version 1.0

www.event-lighting.com.au
1
Safety Instructions
Warning
 Do not open this device, there are no user serviceable parts inside. Risk of electric
shock.
 Do not look directly at the light source from close range.
 Avoid contact with the unit during operation, as the housing may become hot. Allow the
fixture to cool for at least 15 minutes after turning off before touching.
 Install this device in a location with adequate ventilation, at least 50cm from adjacent
surfaces.
 Do not operate this device, or connect this device to power, within 50cm of any
flammable material.
 Use a safety chain when mounting this device overhead.
 Do not operate this device outdoors where excessive dust, heat, water, or humidity may
affect it.
 This device is IP65 certified, meaning that it is protected against dust ingress, and
protected against low pressure water jets from any direction. Ensure all protective covers
are sealed correctly.
 Do not operate this device if the housing, lenses, or cables appear damaged.
 Do not connect this device to a dimmer or rheostat.
 Do not operate this device at temperatures higher than 40°C (104°F).
 Only connect this device to a grounded and protected circuit.
 Only use the hanging bracket to carry this device.
 Stop using this device immediately if a serious operating problem becomes apparent.
Product Installation
PAR9X12OB can be mounted in many orientations, provided each individual device is secured
by the use of the correct mounting bracket. Use a safety chain when mounting PAR9X12OB
overhead.
IMPORTANT:
Only use the provided Outdoor DMX cable in the device’s DMX out
port. Use of other cables will cause the cable to become stuck in the port,
requiring the unit to be repaired.

www.event-lighting.com.au
2
Dimensions
Lux Chart

www.event-lighting.com.au
3
Control Operation
Button Operation
Menu: Return to the previous screen.
Up: Move selection up.
Down: Move selection down.
Enter: Confirm the selection.
Button Lock
While on the home screen, press Down for 3
sec to lock all buttons, preventing accidental
input. While locked, press Down for 3 sec to
unlock.

www.event-lighting.com.au
4
Menu
Set DMX Address Code
1. Press Menu until “Address Set” is highlighted then press Enter.
2. The screen will display “Address Set: 001”. Press Up or Down to change.
3. Press Enter to save and exit, or press Menu to exit without saving.
Menu Description
Level 1 Level 2 Level 3 Description
6ch 6 channel DMX mode
Channel 10ch 10 channel DMX mode
DMX address 000-512 DMX Address Setting
W-DMX On/Off Turn Wireless DMX on or off
W-DMX Mode Receiver Delete Connection
Delete Connection
W-DMX Transmitter
Create Connection
EL Mode 1-6 ch
Channel List 6ch 6 channel DMX mode
DMX Setting
10ch 10 channel DMX mode
Display Sleep
Open/10s/20s/30s
Linear
Square
Dimmer Mode
Log
High
Normal
Power Setting
ECO
Button Lock On/Off Unlock: press button up>down>up>down>enter
Clear Black out the unit when DMX signal is lost
Lost DMX Hold Maintain the last setting when DMX signal is lost.
Auto Power On/Off
IRC Setting On/Off
Emergency On/Off
System
Setting
Reset Yes/No Reset all settings to factory defaults
R/G/B/W/A
/UV all colour manual dimmer (0-255)
Strobe Master strobe speed(0-99)
Manual
dimming
Clear Clear manual dimmer value to 000
Static Colour C1-C36 Select static colour mode
Jump Colour Jump mode. Adjustable speed (0-99)
Fade Colour Fade mode. Adjustable speed (0-99)
Pulse Colour Pulse mode. Adjustable speed (0-99)
Auto
Combined Combination of Jump, Fade and Pulse. Adjustable
speed (0-99)
Manual
Control
Timer Setting the runtime of static colour or Auto
Work time Working time of the model
Information
Temp Display current temperature

www.event-lighting.com.au
5
Version Version number
Serial number
RDM UID ID code for RDM
DMX Chart
Mode/Channel Description
6 Ch 10 Ch
Min
DMX
Max
DMX
1 0 255 Master dimmer, 0-100%
1 2 0 255 Red, 0-100%
2 3 0 255 Green, 0-100%
3 4 0 255 Blue, 0-100%
4 5 0 255 White, 0-100%
5 6 0 255 Amber, 0-100%
6 7 0 255 UV, 0-100%
0 9 Strobe off 8
10 255 Strobe, slow to fast
0 9 No function
10 50 Auto jump
51 100 Auto fade
101 150 Auto pulse
151 200 Auto combined
9
201 255 No function
10 0 255 Auto program speed
IR Remote
To use the IR Remote, PAR9X12OB must be in DMX mode without an active DMX connection. If
a DMX signal is received, PAR9X12OB will prioritise the DMX signal and ignore the IR Remote.
Use On/Off to turn PAR9X12OB on or off. The current IR settings will be
saved automatically when PAR9X12OB is powered off and reloaded when
it is turned on again. To reset to the factory default Blackout mode, long
press Off.
Press R/G/B/W/A/U to light up the LEDs in red, green, blue, white, amber
or UV respectively. There is also a selection of preset colours underneath
the R/G/B/W/A/U buttons, known as the D Area. Press a button in the D
Area to select that colour.
Press + to increase the intensity of the selected colour and - to decrease
the intensity of the selected colour.
Press Auto/Sound/Strobe to switch on or off Auto mode, Sound Active mode and Strobe mode,
respectively.
Press Blackout to clear all the remote settings and blackout PAR9X12OB.
When PAR9X12OB has been controlled by the remote control, and then use the DMX clear

www.event-lighting.com.au
6
function, please turn off the remote control from menu IRC setting.
Technical Specifications
Power
 Input Voltage: 100~240V AC, 50/60 Hz.
 Power Consumption: 72W.
 Connection: Seetronic True1 Outdoor Power in/out.
 Battery: 12V, 16 Ah
Photometrics
 Light Source: 9x 12W RGBWAU LEDs.
 Beam Angle: 25°.
 PWM: 20,000 Hz
 LED Lifespan: 50,000 hours.
Effects
 Dimming: 0-100%.
 Strobe: 1-20 Hz.
Control
 Protocol: DMX512, Wireless DMX, IR remote.
 DMX Channels: 6 / 10.
 Interface: Outdoor 3-pin XLR in and Outdoor 3-pin XLR out.
 Built-in Programming: 4 built-in auto modes.
 Display: LCD Display with 4-button control.
 Cooling: Fanless
Housing
 Materials: Die Cast Aluminium.
 Finishing: Matte Black.
 IP Rating: IP65.
 Net Weight: 6.5kg
 Overall Size: 238x195x160 mm.
 Optional: Barn Door.
Warranty
Please refer to your local dealer or contact Event Lighting.
