Everbloom R0714C4524 User manual

You need at least 45” x 24” (115 x 61cm) for the finished
product. A flat and firm area (like a garage floor or flat
yard space) is perfect! The only tool you may need is a
rubber mallet.
Small parts are included; we advise you to keep
them away from children and pets.
We alsosuggest having another person help you
assemble. Maximum Load capacity: approximately
5.3 cu. ft. of soil
Questions or Comments?
Email us at [e-mail]
Everbloom-Garden.com
Cascade Wallside Garden Bed
Installation Guide
Thank You!
You’re only a few steps away from your perfect vegetable
garden or elevated planter. We hope you enjoy!
Before You Start
Please read the instructions carefully to familiarize
yourself with every detail and step involved. Keep this
manual for futurereference. Findasuitable space to
assemble your new Cascade Wallside Garden Bed.
Important Notes
Model# R0714C4524
Dimensions 45" L x 24" W x 7" & 14" H
1
Subscribe at www.everbloom-garden.com
for extra savings and upgrading information!

Cascade Wallside Garden Bed - 45" L x 24" W x 7" & 14" H
Parts List
2
Post Cap
X 6
Long Board
X 4
1140mm
Short Board A
X 2
540mm
Short Board B
X 2
240mm
Securing Plate
X 2
Left Corner
Post
(360mm) X 1
Top
Bottom
Right Corner
Post
(360mm) X 1
Top
Left Corner
Post
(180mm) X 2
Top
Right Corner
Post
(180mm) X 2
Top
Bottom
BottomBottom
Bolt
X 2
Nut
X 2
Nut Driver
X 1
Hex Key
X 1

Cascade Wallside Garden Bed - 45" L x 24" W x 7" & 14" H
Assembly
3
IMAGE 1
IMAGE 2
Start by makingsure each corner post is oriented correctly. Reference Image 1. Fix the right corner post
(360mm) and left corner post (180mm) on one short board A from above, as shown in Image 2.
Note: The boards need to be placed in the inward “U” shape of the brackets. (Image 2).
Short
Board A
Left Corner
Post
360mm x 1
Right Corner
Post
360mm x 1
Right Corner
Post
360mm x 1
Left Corner
Post
180mm x 1
Left Corner
Post
180mm x 1
Right Corner
Post
180mm x 1

Cascade Wallside Garden Bed - 45" L x 24" W x 7" & 14" H
Assembly
4
Fix the other right corner post (360mm) and the left corner post (180mm) on the other short board A from
above, and slide two long boards into the corner posts from above, as shown in Image 3.
Short
Board A
Left Corner
Post
180mm x 1
Right Corner
Post
180mm x 1
Right Corner
Post
360mm x 1
Left
Corner
Post
Long
Board
Long
Board

Cascade Wallside Garden Bed - 45" L x 24" W x 7" & 14" H
Assembly
5
Slide one long board and two short boards B from above to form the second layer, as shown in Image 4.
Note：Don’t swivel the short boards on short sides to prevent them splite from the steel posts.
Short
Board B
Long
Board
Short
Board B

Cascade Wallside Garden Bed - 45" L x 24" W x 7" & 14" H
Assembly
6
Fix the securing plates on corner posts (180mm) with bolts and nuts,as shown in Image 5.
Securing
Plate
Bolt
Nut Nut
Bolt
Securing
Plate
Securing
Plate
Securing
Plate
Left Corner
Post
180mm x 1
Left Corner
Post
180mm x 1
Right Corner
Post
180mm x 1
Right Corner
Post
180mm x 1

Cascade Wallside Garden Bed - 45" L x 24" W x 7" & 14" H
Assembly
7
Fasten the bolts and nuts with hex key and nut driver, as shown in Image 6.

Cascade Wallside Garden Bed - 45" L x 24" W x 7" & 14" H
Assembly
8
Slide these two post brackets with securing plates onto the short boards B from above,as shown in Image 7.
Long
Board
Short
Board B
Right Corner
Post
180mm
with
Securing Plate
Left Corner
Post
180mm
with
Securing Plate
Short
Board B

Cascade Wallside Garden Bed - 45" L x 24" W x 7" & 14" H
Assembly
9
Slide the last long board from above, as shown in Image 8.
Long
Board
Note: It is not necessary to screw the securing plates onto the boards. The securing plates will prevent the
short boards from moving sidewards after the last long board is inserted. But if you want to secure them with
screws (not included), please make sure not to overdrive. The WPC boards might be fragile when screws are
overdriven, and not capable of holding the screws in place.

Cascade Wallside Garden Bed - 45" L x 24" W x 7" & 14" H
Assembly
10
If necessary, use your rubber mallet to ensure the boards are tightly in place. Cover the brackets with the
6 end caps, as shown in Image 9. Then, you get an Everbloom Cascade Wallside Garden Bed.
Rubber
Mallet
Post Cap
X 1
Post Cap
X 1
Post Cap
X 1
Post Cap
X 1
Post Cap
X 1
Post Cap
X 1

Cascade Wallside Garden Bed - 45" L x 24" W x 7" & 14" H
Notes
X
X
Sometimes there might be a misalignment of the Corner Posts as shown in Image 10 and Image 11,
which may resultin difficulty of sliding boards into the brackets. Please adjust them to the right position so
that they are parallel to each other, and perpendicular to the ground.
Assembling Problem 1
Assembling Problem 2
11

Bloom On.
Distributed by:
Dynaforge Trading LLC
St. Paul, MN55101
Email: [e-mail]
Everbloom-Garden.com
US Patent Pending
