Exsound JerryFish User manual

EXSOUND JerryFish User's Guide

JerryFish Manual Catalog
•Package Contents ------------------------------------------------------------------------------- 03
03
03
08
09
•Safety Notice --------------------------------------------------------------------------------------
•Product Features / Hardware Diagram -----------------------------------------------------
06
•XBOX Live®SVoice ettings ------------------- -------------------------------------------------
05
•JerryFish Connects to XBOX360®-----------------------------------------------------------
06
•JerryFish Connects to XBOX Live®----------------------------------------------------------
•JerryFish Connects to PC ----------------------------------------------------------------------
•Important Information ----------------------------------------------------------------------------
07
•PS3™/PlayStation Network Settings ------------------------------------------------------
07
•JerryFish Connects to PS3™-----------------------------------------------------------------
2
®

Package Contents
1. One EXSOUND JerryFish Headset
3. One EXSOUND JerryFish Breakaway Inline Controller Cable
2. One EXSOUND JerryFish Microphone
4. One 3.5mm Plug to 2,5mm Plug Cable
5. One 3.5mm Jack to RCA Jack＆Plug Cable
6. One Operation Manual
Safety Notice
WARNING: Continued exposure to high volumes of noise in headsets can cause long-term hearing damage. Your ears
will adapt to loud volume levels over time and damage your hearing even if you don't feel any discomfort. Keeping the
volume at a safe level is important while using the headset. The louder the sound is set, the less time it takes to affect
your hearing.
When putting the headset on, it is advised to turn the volume to a low level, and then slowly increase it to a moderate
and comfortable level.
Product Features / Hardware Diagram
Product Features
EXSOUND JerryFish– Entry Model Gaming Headset, with Best of the Best Sound Quality
To XBOX ®
360 /PS3TM noitcnuFnoitacinummoChtiwCP/
3
1
2 3 4 5 6

Easy to Use, Just Connect with XBOX ®
®
CP//063 PS 3TM
TM
with Analog Interface (RCA)
dedeeNrotpadAon,CP/3SP/063XOBXmorfBSUybrewoP
With Amplifier to Output Title Sound to be Powerful
Build in Communication Function to PS3 via USB, while XBOX360 via XBOX Live
Can be upgraded to Wireless Version or Dolby Digital 5.1 & Dolby Headphone Version with Optical Interface
Hardware Diagram
EXSOUND JerryFish HeadsetA.
B.
EXSOUNDA. JerryFish Headset
1. High Quality & Soft Material Headband
2. Easy to Adjust to Fit in Head Shape
3. Omni-direction Microphone
4. Soft Metal to Adjust Microphone Position.
5. Detachable Microphone with a Smart Lock (Note)
4
Note:
Connect & Remove Microphone with
Headset by aligning two dots
Secure the Microphone by
Rotating it 90 degrees counterclockwise
1
2
34
5
EXSOUND JerryFish Breakaway Inline Controller Cable

6. Volume Up/Down
7. Switch for XBOX 360 / PS3 & PC Selections
8. Microphone Mute / Un-mute
9. Microphone Jack for XBOX Live
10. Separated Volume Control for Voice Communication
from Others
5
EXSOUNDB. JerryFish Breakaway lnline Controller Cable
JerryFish Connects to XBOX360®
1. Connect JerryFish headset with breakaway inline controller cable.
.“063XOBX“otrellortnocenilniehtnohctiws”3SP/063XOBX“ehtedilS.2
3. Plug the audio connector (green) into headphone jack (green) on 3.5 to RCA Cable.
4. Plug the USB connector into a free USB port on XBOX360®
®
®
®
.
5. Plug the RCA connector (red) on Multi-AV Cable into RCA socket (red) on 3.5 to RCA Cable.
Plug the RCA connector (white) on Multi-AV Cable into RCA socket (white) on 3.5 to RCA Cable
6. Plug the RCA connectors (red and white) on 3.5 to RCA Cable into RCA socket on any other device (e.g.: TV).
Plug the RCA connector (Yellow) on Multi-AV Cable into RCA socket on any other device (e.g.: TV).
7. Power on XBOX360.
689
10
7

6
XBOX Live®SVoice ettings
Press the “ XBOX®Global Button “and go to:
Settings -> Preferences -> Voice ->
Voice Output -> Play through Headset
JerryFish Connects to XBOX Live®
1. Connect XBOX Live®communication link cable (2.5mm plug to 3.5mm plug) to inline volume controller and
XBOX360®controller
Adjust Others Voice Volume by Turning the Voice Volume Control
®
®
2. Special Note : When you use XBOX Live communication function not allow recharge your controller
from XBOX360

7
PS3™/ PlayStation Network Settings
■PS3™ Audio Settings
Go to PS3™ dashboard and select:
Settings -> Sound Settings -> Audio output setting
-> Audio Input Connector / SCART / AV MLUTI
™3SPotstcennoChsiFyrreJ
1. Connect JerryFish Headset with breakaway inline controller cable
2. Slide the “XBOX 360 / PS3 & PC” switch on the inline controller to “PS3 & PC“.
3. Plug the audio connector (green) into headphone jack (green) on 3.5 to RCA Cable.
.3SPnotropBSUeerfaotnirotcennocBSUehtgulP.4
.elbaCACRot5.3no)der(tekcosACRotnielbaCVA-itluMno)der(rotcennocACRehtgulP.5
Plug the RCA connector (white) on Multi-AV Cable into RCA socket (white) on 3.5 to RCA Cable.
6. Plug the RCA connectors (red and white) on 3.5 to RCA Cable into RCA socket on any other device (e.g.: TV).
Plug the RCA connector (Yellow) on Multi-AV Cable into RCA socket on any other device (e.g.: TV).
7. Power on PS3 .
®
®

JerryFish Connects to PC
1. Connect JerryFish Headset with breakaway inline controller cable
2. Slide the “XBOX 360 / PS3 & PC” switch on the inline controller to “PS3 & PC“.
3. Plug the audio connector (green) into headphone jack on PC
4. Plug the USB connector into a free USB port on PC
5. Power on PC.
8
Please Check Your PC Audio Setting as Below :
1. Go to Control panel > Sounds and Audio Devices > Audio > Sound Playback > Select Your Default Audio Device
2. Go to Control panel > Sound and Audio Devices > Audio > Sound Recording > Select USB PnP Sound Device.
(Please check your microphone level when using on Windows 7 , as the level might be set to zero by default.)
®
■PlayStation Network Settings
Go to PS3™ dashboard and select:
Settings -> Accessory Settings -> Audio Device Settings
-> Set both the input & Output to “USB PnP Sound Device
®
Adjust Others Voice Volume by Turning the” VOL “ Volume Control

9
Important information
PlayStation, PlayStation 2, PlayStation 3, PS2, PS3 and the respective images/logos are registered trademarks of Sony Computer Entertainment Inc.
XBOX, XBOX360, XBOX Advanced AV Pack, XBOX Communicator, XBOX Live and the respective images/logos are registered trademark or
trademarks of Microsoft Corporation in the U.S and/or other countries.
All other trademarks are property of their respective owners.
